Removal
Disconnect the ground cable from battery.
Remove the console front panel.
Remove the center panel while disconnecting connector.
Scheme 4
- Hook pawl
Remove the fitting screws, and slightly pull out the audio from center console.
Scheme 5
Disconnect the harness connectors and antenna feeder cord.
Installation
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the front door trim.
Remove the front speaker mounting screws.
Scheme 6
Disconnect the harness connector and remove front speaker.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the front door trim.
Remove the tweeter mounting screws.
Scheme 7
Disconnect the harness connector and remove tweeter.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the rear door trim.
Remove the rear speaker mounting screws.
Scheme 8
Disconnect the harness connector and remove rear speaker.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the rear quarter upper trim and roof trim.
Disconnect the harness connector and terminal.
Remove the mounting screws and detach the antenna amplifier.
Scheme 9
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the rear gate trim.
Disconnect the connector from noise suppressor.
Remove the mounting nut and detach the noise suppressor.
Scheme 10
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the console front panel.
Disconnect the harness connectors and remove front accessory power supply socket.
Scheme 11
Install in the reverse order of removal.
