Removal
Disconnect the ground cable from battery.
Scheme 1
Lift up the vehicle.
Disconnect connector (A) from drain valve.
Disconnect evaporation hoses (B) and (C) from canister.
Scheme 2
Disconnect quick connector (A) from canister.
Disconnect drain hoses (B) from canister.
Scheme 3
Remove the canister from vehicle.
Scheme 4
Installation
Install in the reverse order of removal.
Tightening torque
23 Nm (2.3 kgf-m, 17 ft-lb)
Scheme 5
Disconnect the ground cable from battery.
Scheme 6
Disconnect the connector and hoses of purge control solenoid valve, and then remove the purge control solenoid valve.
Scheme 7
Install in the reverse order of removal.
Tightening torque
19 Nm (1.9 kgf-m, 14.0 ft-lb)
Scheme 8
Note. Connect the evaporation hose as shown in the figure.
Scheme 9
- To fuel pipe (Evaporation line)
- To intake manifold
For removal procedure, refer to FUEL LEVEL SENSOR .
For installation procedure, refer to FUEL LEVEL SENSOR .
Fuel temperature sensor and fuel level sensor are integrated into one unit; therefore, the removal procedure is the same as that for fuel level sensor.
Scheme 10
- Fuel temperature sensor
Fuel temperature sensor and fuel level sensor are integrated into one unit; therefore, the installation procedure is the same as that for fuel level sensor.
Scheme 11
- Fuel temperature sensor
For removal procedure, refer to FUEL LEVEL SENSOR .
For installation procedure, refer to FUEL LEVEL SENSOR .
| WARNING | Place "NO FIRE" signs near the working area. Be careful not to spill fuel. |
Remove the fuel tank.
Remove the protector cover.
Scheme 12
Disconnect the connector from fuel tank pressure sensor.
Release the clips which hold the fuel pipes onto fuel tank.
Scheme 13
Remove the nuts and bolts which install the fuel tank pressure sensor on bracket.
Scheme 14
Disconnect the pressure hose from fuel tank pressure sensor.
Scheme 15
Install in the reverse order of removal.
Tightening torque
7.4 Nm (0.75 kgf-m, 5.4 ft-lb)
Scheme 16
Tightening torque
T1: 7.4 Nm (0.75 kgf-m, 5.4 ft-lb)
T2: 4.4 Nm (0.45 kgf-m, 3.3 ft-lb)
Scheme 17
Remove the fuel tank.
Remove the protector cover.
Scheme 18
Disconnect the connector from fuel tank sensor control valve.
Disconnect the hose, and then remove the fuel tank sensor control valve.
Scheme 19
Install in the reverse order of removal.
Tightening torque
T1: 7.4 Nm (0.75 kgf-m, 5.4 ft-lb)
T2: 4.4 Nm (0.45 kgf-m, 3.3 ft-lb)
Scheme 20
Set the vehicle on a lift.
Disconnect the ground cable from battery.
Scheme 21
Lift up the vehicle.
Remove the canister.
Remove the bolt which installs the pressure control solenoid valve holding bracket on body.
Scheme 22
Disconnect the connector from pressure control solenoid valve.
Scheme 23
Disconnect the two evaporation hoses from pressure control solenoid valve.
Remove the pressure control solenoid valve with bracket.
Scheme 24
Remove the pressure control solenoid valve from bracket.
Scheme 25
Disconnect the vacuum hose from pressure control solenoid valve.
Scheme 26
Install in the reverse order of removal.
Tightening torque
17.6 Nm (1.8 kgf-m, 13.0 ft -lb)
