PROCEDURE
| IMPORTANT | Remove foreign matters (dust, water, oil, etc.) from the ABSCM&H/U connector during removal and installation. |
Note. To check harness for broken wires or short circuits, shake trouble spot or connector. Refer to CHECK LIST FOR INTERVIEW .
CHECK PRE-INSPECTION
Ask the customer when and how the trouble occurred using interview checklist.
Before performing diagnostics, check the component which might affect ABS problems.
Is the component that might influence the ABS problem normal?
YES
NO
Repair or replace each unit.
CHECK INDICATION OF DTC ON SCREEN
Turn the ignition switch to OFF.
Connect the Vehicle Diagnostic Interface to data link connector.
Turn the ignition switch to ON and Vehicle Diagnostic Interface to ON.
Note. If the communication function of the Vehicle Diagnostic Interface cannot be executed normally, check the communication circuit.
Read the DTC.
Record all DTCs and Freeze Frame Data.
Is DTC displayed?
YES
NO
PERFORM THE GENERAL DIAGNOSTICS
Inspect using " GENERAL DIAGNOSTIC TABLE ".
Perform clear memory mode.
Perform the inspection mode.
Read the DTC.
Check the DTC does not displayed.
Does the ABS warning light go off after turning the ignition switch to ON?
YES
Finish the diagnosis.
NO
Check in accordance with "Diagnostic Procedure for ABS".
PERFORM THE DIAGNOSIS.
Refer to the " LIST OF DIAGNOSTIC TROUBLE CODE (DTC) ".
Fix the wrong part.
Perform clear memory mode.
Perform the inspection mode.
Read the DTC.
Is DTC displayed?
YES
Repeat step 1 to 4 until DTC is not shown.
NO
Finish the diagnosis.
CHECK
Check the following items about the vehicle's state.
STATE OF ABS WARNING LIGHT
| ABS warning light comes on. | Always Sometimes Only once Not come on When/how long does it come on? | ||
|---|---|---|---|
| Ignition key position | LOCK ACC ON (before starting engine) START ON (after Engine starting, engine is running) ON (after Engine starting, engine is at a standstill) | ||
| Timing | Immediately after turning the ignition to ON Immediately after turning the ignition to START | ||
| When accelerating | Km/h | ||
| MPH | |||
| When driving at a constant speed | Km/h | MPH | |
| When decelerating | Km/h | ||
| MPH | |||
| When turning to the right | Steering angle | Deg | |
| Steering time | Sec. | ||
| When turning to the left | Steering angle | Deg | |
| Steering time | Sec. | ||
| When operating other electrical parts | |||
| Parts name: Operating condition | |||
STATE OF ABS WARNING LIGHT
STATE OF BRAKE WARNING LIGHT
| Brake warning light comes on. | Always Sometimes Only once Not come on When pulling the parking brake lever up. When releasing the parking brake lever down. When/how long does it come on? | ||
|---|---|---|---|
| Ignition key position | LOCK ACC ON (before starting engine) START ON (after Engine starting, engine is running) ON (after Engine starting, engine is at a standstill) | ||
| Timing | Immediately after turning the ignition to ON Immediately after turning the ignition to START | ||
| When accelerating | Km/h | ||
| MPH | |||
| When driving at a constant speed | Km/h | MPH | |
| When decelerating | Km/h | ||
| MPH | |||
| When turning to the right | Steering angle | Deg | |
| Steering time | Sec. | ||
| When turning to the left | Steering angle | Deg | |
| Steering time | Sec. | ||
| When operating other electrical parts | |||
| Parts name: Operating condition | |||
STATE OF BRAKE WARNING LIGHT
BATTERY
Measure battery voltage and check electrolyte.
Standard voltage: 12 V or more
Specific gravity: More than 1.260
HYDRAULIC UNIT
Check the hydraulic unit.
- With brake tester
- Without brake tester
BRAKE DRAG
Check for brake drag.
BRAKE PAD AND ROTOR
Check the brake pad and rotor.
- FRONT
- REAR
TIRE
Check the tire specifications, tire wear and air pressure.
GENERAL PURPOSE TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and amperage. |
| Oscilloscope | Used for measuring sensor. |
GENERAL PURPOSE TOOL SPECIFICATION
SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"
Airbag system wiring harness is routed near the ABS wheel speed sensor and ABSCM&H/U.
| IMPORTANT | All airbag system wiring harness and connectors are colored yellow. Do not use the electrical test equipment on these circuits. Be careful not to damage the airbag system wiring harness when servicing the ABS wheel speed sensor and ABSCM&H/U. |
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
- ABS control module and hydraulic control unit (ABSCM&H/U)
- Connector
- ABS warning light
- Wheel cylinder
- Data link connector (for Vehicle Diagnostic Interface)
- Master cylinder
- Tone wheel
- ABS wheel speed sensor
- Stop light switch
- G sensor
- Brake and EBD warning light
Scheme 47
- ABS control module and hydraulic control unit (ABSCM&H/U) connector
Note. Terminal numbers in ABSCM&H/U connector are as shown in the figure. ABS warning light is illuminates when the connector is removed from ABSCM&H/U.
| Description | Terminal No. (+) - (- ) | Input/Output signal | ||
|---|---|---|---|---|
| Measured value and measuring conditions | ||||
| ABS wheel speed sensor (Wheel speed sensor) | Front LH wheel | Ground | 16 | |
| Signal | 1 - 16 | When the 20 Hz. 0.12 - 1 V | ||
| Front RH wheel | Ground | 5 | ||
| Signal | 6 - 5 | When the 20 Hz. 0.12 - 1 V | ||
| Rear LH wheel | Ground | 2 | ||
| Signal | 17 - 2 | When the 20 Hz. 0.12 - 1 V | ||
| Rear RH wheel | Ground | 3 | ||
| Signal | 4 - 3 | When the 20 Hz. 0.12 - 1 V | ||
| Valve relay power supply *1 | 14 - 15 | 10 - 15 V | ||
| Motor relay power supply *1 | 13 - 15 | 10 - 15 V | ||
| G sensor | Power supply | 24 - 10 | 4.75 - 5.25 V | |
| Ground | 10 | |||
| Output | 21 - 10 | 2.1 - 2.5 V when the vehicle is on a level surface | ||
| Stop light switch *1 | 20 - 15 | Less than 1.5 V when the stop light is OFF; otherwise, 10 - 15 V when the stop light is ON. | ||
| ABS warning light | 22 - 15 | After turning the ignition switch to ON, 10 - 15 V during 1.5 seconds and less than 1.5 V after 1.5 seconds passed. | ||
| Brake warning light (EBD warning light) | 8 - 15 | After turning the ignition switch to ON, 10 - 15 V during 1.5 seconds and less than 1.5 V after 1.5 seconds passed. | ||
| Vehicle Diagnostic Interface | 7 - 15 | Less than 1.5 V when no data is received. 0 ?? 12 V pulse (in communication) | ||
| Power supply *1 | 18 - 15 | When the ignition switch is ON, 10 - 15 V. | ||
| Grounding line | 15 | |||
ABS CONTROL MODULE REFERENCE CHART
COMMUNICATION FOR INITIALIZING IMPOSSIBLE
DETECTING CONDITION
Faulty harness connector
TROUBLE SYMPTOM
Communication cannot be executed between ABS and Vehicle Diagnostic Interface.
WIRING DIAGRAM
Scheme 48
CHECK IGNITION SWITCH.
Is the ignition switch turned to ON?
YES
NO
Turn the ignition switch to ON, and select ABS mode using Vehicle Diagnostic Interface.
CHECK BATTERY.
Turn the ignition switch to OFF.
Measure the battery voltage.
Is the voltage more than 11 V?
YES
NO
Charge or replace the battery.
CHECK BATTERY TERMINAL.
Is there poor contact at battery terminal?
YES
Repair or tighten the battery terminal.
NO
CHECK COMMUNICATION OF Vehicle Diagnostic Interface.
Turn the ignition switch to ON.
Using the Vehicle Diagnostic Interface, check whether communication to other system can be executed normally.
Are the name and year of system displayed on Vehicle Diagnostic Interface?
YES
NO
CHECK COMMUNICATION OF Vehicle Diagnostic Interface.
Turn the ignition switch to OFF.
Disconnect the ABSCM&H/U connector.
Turn the ignition switch to ON.
Check whether communication to other systems can be executed normally.
Are the name and year of system displayed on Vehicle Diagnostic Interface?
YES
Replace the ABSCM&H/U.
NO
CHECK HARNESS CONNECTOR BETWEEN EACH CONTROL MODULE AND DATA LINK CONNECTOR.
Turn the ignition switch to OFF.
Disconnect the ABSCM&H/U, ECM and TCM connectors.
Measure the resistance between data link connector and chassis ground.
Connector & terminal
(B40) No. 10 - Chassis ground
Is the resistance more than 1 MO?
YES
NO
Repair the harness and connector between each control module and data link connector.
CHECK OUTPUT SIGNAL FOR ABSCM&H/U.
Turn the ignition switch to ON.
Measure the voltage between ABSCM&H/U and chassis ground.
Connector & terminal
(B40) No. 10 (+) - Chassis ground (- )
Is the voltage less than 1 V?
YES
NO
Repair the harness and connector between each control module and data link connector.
CHECK HARNESS/CONNECTOR BETWEEN ABSCM&H/U AND DATA LINK CONNECTOR.
Measure the resistance between ABSCM&H/U connector and data link connector.
Connector & terminal
(B301) No. 7 - (B40) No. 10
Is the resistance less than 0.5 O?
YES
NO
Repair the harness and connector between ABSCM&H/U and data link connector.
CHECK INSTALLATION OF ABSCM&H/U CONNECTOR.
Turn the ignition switch to OFF.
Is the ABSCM&H/U connector inserted into ABSCM&H/U until the clamp locks onto it?
YES
NO
Insert the ABSCM&H/U connector into ABSCM&H/U.
CHECK POWER SUPPLY CIRCUIT.
Turn the ignition switch to ON (engine OFF).
Measure the ignition power supply voltage between ABSCM&H/U connector and chassis ground.
Connector & terminal
(B301) No. 18 (+) - Chassis ground (- )
Is the voltage 10 - 15 V?
YES
NO
Repair the open circuit in harness between ABSCM&H/U and battery.
CHECK HARNESS CONNECTOR BETWEEN ABSCM&H/U AND CHASSIS GROUND.
Turn the ignition switch to OFF.
Disconnect the connector from ABSCM&H/U and transmission.
Measure the resistance of harness between ABSCM&H/U and chassis ground.
Connector & terminal
(B301) No. 15 - Chassis ground
Is the resistance less than 0.5 O?
YES
NO
Repair the open circuit in harness between ABSCM&H/U and inhibitor side connector, and poor contact in coupling connector.
CHECK POOR CONTACT IN CONNECTORS.
Is there poor contact in control module power supply, ground line and data link connector?
YES
Repair the connector.
NO
Replace the ABSCM&H/U.
READ CURRENT DATA
On the << Main Menu >> display screen, select the {Each System Check}.
On the << System Selection Menu >> display screen, select the {Brake Control System}.
Select the {OK} after the information of ABS type is displayed.
On the << Brake Control Diagnosis >> display screen, select the {Current Data Display & Save}.
On the << Data Display Menu >> display screen, select the {Data Display}.
Using the scroll key, move the display screen up or down until desired data is shown.
- A list of the support data is shown in the following table.
| Display screen | Contents to be monitored | Unit of measure |
|---|---|---|
| FR Wheel Speed | Wheel speed detected by Front ABS wheel speed sensor RH is displayed | Km/h or MPH |
| FL Wheel Speed | Wheel speed detected by Front ABS wheel speed sensor LH is displayed | Km/h or MPH |
| RR Wheel Speed | Wheel speed detected by Rear ABS wheel speed sensor RH is displayed | Km/h or MPH |
| RL Wheel Speed | Wheel speed detected by Rear ABS wheel speed sensor LH is displayed | Km/h or MPH |
| Stop Light Switch | Stop light switch signal | ON or OFF |
| G Sensor Output Signal | Voltage equivalent to vehicle acceleration detected by analog G sensor is displayed. | M/s (m/s 2 ) |
| Valve Relay Signal | Valve Relay Signal | ON or OFF |
| ABS Warning Lamp | ON operation of ABS warning light is displayed. | ON or OFF |
| EBD Warning Light | ON operation of EBD warning light is displayed. | ON or OFF |
| Motor Relay Monitor | Motor relay monitor voltage is displayed. | V |
| IG power supply voltage | Voltage supplied to ABSCM&H/U is displayed. | V |
| ABS Control Flag | ABS control condition is displayed. | ON or OFF |
| ABS OK B Signal | ABS system normal/abnormal is displayed. | OK or NG |
SUPPORT DATA CHART
Note. For detailed operation procedure, refer to the " VEHICLE DIAGNOSTIC INTERFACE OPERATION MANUAL ".
CLEAR MEMORY MODE
On the << Main Menu >> display screen, select the {2. Each System Check}.
On the << System Select Menu >> display screen, select the {Brake System}.
Select the {OK} after the information of engine type is displayed.
On the << Brake Control Diagnosis >> display screen, select the {Clear Memory}.
| Display screen | Contents to be monitored |
|---|---|
| Clear memory? | Function of clearing DTC. |
CLEAR MEMORY MODE SPECIFICATION
When the "Done" is shown on display screen, turn the Vehicle Diagnostic Interface and ignition switch to OFF.
Note. For detailed operation procedure, refer to the " VEHICLE DIAGNOSTIC INTERFACE OPERATION MANUAL ".
ABS SEQUENCE CONTROL
| Display screen | Contents to be monitored | Index No. |
|---|---|---|
| ABS sequence control | Perform ABS sequence control by operating valve and pump motor sequentially. |
ABS SEQUENCE CONTROL
Reproduce the condition under which the problem has occurred as much as possible.
Drive the vehicle at a speed more than 40 km/h (25 MPH) for at least 1 minute.
DETECTING CONDITION
- Defective combination meter
- Defective harness
- Defective combination meter
- Open in harness
- Brake warning light circuit is shorted.
- Defective sensor/connector
LIST
| DTC | Display screen | Contents of diagnosis |
|---|---|---|
| Communication for initializing impossible | Vehicle Diagnostic Interface communication failure | |
| No DTC | Although no DTC appears on the Vehicle Diagnostic Interface display, the ABS warning light remains on. | |
| 21 | Open or short circuit in Front ABS wheel speed sensor RH circuit | Open or short circuit in Front ABS wheel speed sensor RH circuit |
| 22 | Front ABS wheel speed sensor RH abnormal signal | Front ABS wheel speed sensor RH abnormal signal |
| 23 | Open or short circuit in Front ABS wheel speed sensor LH circuit | Open or short circuit in Front ABS wheel speed sensor LH circuit |
| 24 | Front ABS wheel speed sensor LH abnormal signal | Front ABS wheel speed sensor LH abnormal signal |
| 25 | Open or short circuit in Rear ABS wheel speed sensor RH circuit | Open or short circuit in Rear ABS wheel speed sensor RH circuit |
| 26 | Rear ABS wheel speed sensor RH abnormal signal | Rear ABS wheel speed sensor RH abnormal signal |
| 27 | Open or short circuit in Rear ABS wheel speed sensor LH circuit | Open or short circuit in Rear ABS wheel speed sensor LH circuit |
| 28 | Rear ABS wheel speed sensor LH abnormal signal | Rear ABS wheel speed sensor LH abnormal signal |
| 29 | Abnormal ABS wheel speed sensor signal on any one of four sensor | Abnormal ABS wheel speed sensor signal on any one of four |
| 31 | Front inlet valve RH malfunction | Front inlet valve RH malfunction |
| 32 | Front outlet valve RH malfunction | Front outlet valve RH malfunction |
| 33 | Front inlet valve LH malfunction | Front inlet valve LH malfunction |
| 34 | Front outlet valve LH malfunction | Front outlet valve LH malfunction |
| 35 | Rear inlet valve RH malfunction | Rear inlet valve RH malfunction |
| 36 | Rear outlet valve RH malfunction | Rear outlet valve RH malfunction |
| 37 | Rear inlet valve LH malfunction | Rear inlet valve LH malfunction |
| 38 | Rear outlet valve LH malfunction | Rear outlet valve LH malfunction |
| 41 | ABS control module malfunction | ABSCM&H/U malfunction |
| 42 | Power supply voltage too low | Power supply voltage too low |
| Power supply voltage too high | Power supply voltage too high | |
| 51 | Valve relay malfunction | Valve relay malfunction |
| Valve relay ON failure | Valve relay ON failure | |
| 52 | Open circuit in motor relay circuit | Open circuit in motor relay circuit |
| Motor relay ON failure | Motor relay ON failure | |
| Motor malfunction | Motor malfunction | |
| 54 | Stop light switch signal circuit malfunction | Stop light switch signal circuit malfunction |
| 56 | Open or short circuit in G sensor circuit | Open or short circuit in G sensor circuit |
| Battery short in G sensor circuit | Battery short in G sensor circuit | |
| Abnormal G sensor high output | Abnormal G sensor high output | |
| Detection of G sensor stick | Detection of G sensor stick |
DIAGNOSTIC TROUBLE CODE CHART
| DTC | Display screen | Contents of diagnosis |
|---|---|---|
| Communication for initializing impossible | Vehicle Diagnostic Interface communication failure | |
| No DTC | Although no DTC appears on the Vehicle Diagnostic Interface display, the ABS warning light remains on. | |
| 21 | Open or short circuit in Front ABS wheel speed sensor RH circuit | Open or short circuit in Front ABS wheel speed sensor RH circuit |
| 22 | Front ABS wheel speed sensor RH abnormal signal | Front ABS wheel speed sensor RH abnormal signal |
| 23 | Open or short circuit in Front ABS wheel speed sensor LH circuit | Open or short circuit in Front ABS wheel speed sensor LH circuit |
| 24 | Front ABS wheel speed sensor LH abnormal signal | Front ABS wheel speed sensor LH abnormal signal |
| 25 | Open or short circuit in Rear ABS wheel speed sensor RH circuit | Open or short circuit in Rear ABS wheel speed sensor RH circuit |
| 26 | Rear ABS wheel speed sensor RH abnormal signal | Rear ABS wheel speed sensor RH abnormal signal |
| 27 | Open or short circuit in Rear ABS wheel speed sensor LH circuit | Open or short circuit in Rear ABS wheel speed sensor LH circuit |
| 28 | Rear ABS wheel speed sensor LH abnormal signal | Rear ABS wheel speed sensor LH abnormal signal |
| 29 | Abnormal ABS wheel speed sensor signal on any one of four sensor | Abnormal ABS wheel speed sensor signal on any one of four |
| 31 | Front inlet valve RH malfunction | Front inlet valve RH malfunction |
| 32 | Front outlet valve RH malfunction | Front outlet valve RH malfunction |
| 33 | Front inlet valve LH malfunction | Front inlet valve LH malfunction |
| 34 | Front outlet valve LH malfunction | Front outlet valve LH malfunction |
| 35 | Rear inlet valve RH malfunction | Rear inlet valve RH malfunction |
| 36 | Rear outlet valve RH malfunction | Rear outlet valve RH malfunction |
| 37 | Rear inlet valve LH malfunction | Rear inlet valve LH malfunction |
| 38 | Rear outlet valve LH malfunction | Rear outlet valve LH malfunction |
| 41 | ABS control module malfunction | ABSCM&H/U malfunction |
| 42 | Power supply voltage too low | Power supply voltage too low |
| Power supply voltage too high | Power supply voltage too high | |
| 51 | Valve relay malfunction | Valve relay malfunction |
| Valve relay ON failure | Valve relay ON failure | |
| 52 | Open circuit in motor relay circuit | Open circuit in motor relay circuit |
| Motor relay ON failure | Motor relay ON failure | |
| Motor malfunction | Motor malfunction | |
| 54 | Stop light switch signal circuit malfunction | Stop light switch signal circuit malfunction |
| 56 | Open or short circuit in G sensor circuit | Open or short circuit in G sensor circuit |
| Battery short in G sensor circuit | Battery short in G sensor circuit | |
| Abnormal G sensor high output | Abnormal G sensor high output | |
| Detection of G sensor stick | Detection of G sensor stick |
DIAGNOSTIC TROUBLE CODE CHART
