Power Windows - Service Information: Removal & Installation RAM Pickup 2500

INSTALLATION

1. Connect electrical connector.
2. Place motor/regulator into place and install fasteners.
3. Install door trim panel. Refer to «PANEL, Door Trim , Installation»(ref-457777-S13542642742012030200000) .
4. Connect the negative battery cable.

Scheme 2

Scheme 3

1. Disconnect and isolate the battery negative cable.
2. Remove the rear seats. Refer to «SEAT, Rear , Removal»(ref-457777-S40451389112012030200000) .
3. Remove the rear cab back panel. Refer to «PANEL, Cab Back Trim , Removal»(ref-457777-S15425953532012030200000) .
4. Remove the 2 mounting bolts (1).
5. Disconnect the electrical connector to the power motor.
6. Rotate the assembly and remove the 3 screws (1) that attach the motor to the regulator.

1. Install the power motor to the regulator with the 3 screws (1).
2. Connect the electrical connector to the power motor.
3. Install the 2 mounting bolts (1).
4. Install the rear cab back panel. Refer to «PANEL, Cab Back Trim , Installation»(ref-457777-S21863031712012030200000) .
5. Install the rear seats. Refer to «SEAT, Rear , Installation»(ref-457777-S11645692232012030200000) .
6. Connect the battery negative cable.

REMOVAL

The power window switch is included with the power mirror/lock switch. Refer to SWITCH, Lock, with Window Switches , Removal .

The power window switch is included with the power mirror/lock switch. Refer to SWITCH, Lock, with Window Switches , Installation .
