SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Control Arm Bolt/Nut | 305 | 225 | |
| Park Brake Cable Guide Bolt | 20 | 15 | 177 |
| Shock Absorber Bolt/Nut | 136 | 100 | |
| Stabilizer Bar To Axle Bracket Bolts | 50 | 37 | |
| Stabilizer Link To Frame Bolt/Nut | 75 | 55.5 | |
| Stabilizer Link To Stabilizer Bar Nut | 107 | 79 | |
| Track Bar Bolts | 175 | 129 |
1500
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Jounce Bumper Bolts | 29 | 21.5 | |
| Shock Absorber, Lower Nut/Bolt | 136 | 100 | |
| Shock Absorber, Upper Nut/Bolt | 136 | 100 | |
| Spring Clamp U-Bolt Nuts | 149 | 110 | |
| Spring Front Nut/Bolt to Frame | 345 | 254.5 | |
| Spring Shackle Nut/Bolt, Upper/Lower | 217 | 160 |
2500 and 3500
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Shock Absorber, Lower Bolt/Nut | 136 | 100 | |
| Shock Absorber, Upper Bolt/Nut | 250 | 185 | |
| Spring Clamp U-Bolt Nuts | 488 | 360 | |
| Spring Front Bolt/Nut To Frame | 385 | 289 | |
| Rear Spring Eye To Shackle Bracket Bolt/Nut | 217 | 160 | |
| Rear Spring Shackle To Bracket Bolt/Nut | 217 | 160 | |
| Jounce Bumper Bolts | 55 | 41 | |
| Auxiliary Spring Bumpers | N/A | N/A | N/A |
| Stabilizer Bar Link To Frame | 75 | 55 | |
| Stabilizer Bar To Stabilizer Link | 88 | 65 | |
| Stabilizer Bar To Axle | 65 | 48 |
3500 CAB CHASSIS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Shock Absorber, Lower Bolt/Nut | 136 | 100 | |
| Shock Absorber, Upper Bolt/Nut | 250 | 185 | |
| Spring Clamp U-Bolt Nuts | 488 | 360 | |
| Spring Front Bolt/Nut To Frame | 488 | 360 | |
| Rear Spring Eye To Shackle Bolt/Nut | 217 | 160 | |
| Rear Spring Shackle To Frame Bolt/Nut | 430 | 317 | |
| Jounce Bumper Bolts | 55 | 41 | |
| Auxiliary Spring Bumpers | N/A | N/A | N/A |
| Stabilizer Bar Link To Frame | 75 | 55 | |
| Stabilizer Bar To Stabilizer Link | 88 | 65 | |
| Stabilizer Bar To Axle | 65 | 48 |
4500 and 5500
Scheme 1
Scheme 2
- Raise and support the vehicle. Refer to «Hoisting , Standard Procedure»(ref-457775-S03796115192012030200000) .
- Support the rear axle with a suitable holding fixture.
- Remove the parking brake cable guide bolt (Left side only).
- Remove the lower control arm bolt (1) and nut at the axle and discard the nut .
- Remove the lower control arm bolt and nut (2) at the frame.
- Remove the lower control arm from the vehicle.
