Starting - Service Information: Removal & Installation RAM Pickup 2500

Starter 4 illustrations ~230 words

REMOVAL

The Remote Start Antenna Module Assembly consists of an electrical connection to the WIN (1), a length of coax cable (2), two mounting clips (3) and (4), and a control module/antenna (5).

Scheme 8

Scheme 8

The control module (1) is located behind the instrument panel cluster. The module electrical connector plugs into the WIN at the right side of the steering column.

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Disconnect and isolate negative battery cable.
  2. Remove steering column trim panel (knee blocker).
  3. Remove steering column shrouds.
  4. Remove IP cluster bezel.
  5. Remove IP cluster and its three connectors.
  6. Remove two module mounting screws (2) from module (1).
  7. Using a pair of long needle hose pliers, disengage coax cable retainer clip (2) from IP.
  8. Disconnect coax cable electrical connector (1) at WIN (2).
  9. Remove remote module assembly.

INSTALLATION

The Remote Start Antenna Module Assembly consists of an electrical connection to the WIN (1), a length of coax cable (2), two mounting clips (3) and (4), and a control module/antenna (5).

  1. Connect coax cable electrical connector (1) to WIN module (2). Route coax cable and install cable clip (2) to IP.
  2. Position module (1) and install two module mounting screws (2).
  3. Install IP cluster and its three connectors.
  4. Install IP cluster bezel.
  5. Install steering column trim panel (knee blocker).
  6. Install steering column shrouds.
  7. Connect negative battery cable.
