Possible Causes RAM Pickup 2500

Possible Causes

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using a scan tool, record and erase Diagnostic Trouble Codes (DTCs). Turn the turn signal on. Turn the puddle lamps on, if equipped with puddle lamp mirror. Turn the rear defogger on, if equipped with heated mirror. Press and release the Mirror Select switch to select the Passenger Outside Rearview Mirror. Operate the Mirror Adjust switch in all directions several times while monitoring the scan tool for DTCs. NOTE: After adjusting the mirror in one direction wait at least two seconds before adjusting the mirror in the opposite direction as this will allow time for an active fault to set if present. Is the DTC active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. For vehicle's equipped with folding outside rearview mirrors, repeat test with mirror folded. If DTC is now active, Refer to 2 . Otherwise, use the wiring diagram/schematic as a guide and inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
2. CHECK (P502) PASSENGER MIRROR TURN SIGNAL DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Passenger Outside Rearview Mirror C2 (Component Side) connector from the Door Module C2 connector. Measure the resistance of the (P502) Passenger Mirror Turn Signal Driver circuit between ground and the Passenger Outside Rearview Mirror C2 (Component Side) connector. Is the resistance below 10K Ohms? Yes Repair the (P502) Passenger Mirror Turn Signal Driver circuit for a short to ground. If the wiring harness and connector are okay, replace the Passenger Outside Rearview Mirror in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Go To 3 .
3. CHECK (P502) PASSENGER MIRROR TURN SIGNAL DRIVER CIRCUIT FOR A SHORT TO THE (P72) PASSENGER MIRROR VERTICAL DRIVER CIRCUIT, (P70) PASSENGER MIRROR COMMON DRIVER CIRCUIT, OR TO THE (P74) PASSENGER MIRROR HORIZONTAL DRIVER CIRCUIT Measure the resistance between the (P502) Passenger Mirror Turn Signal Driver circuit and the (P72) Passenger Mirror Vertical Driver circuit at the Passenger Outside Rearview Mirror C2 (Component Side) connector. Measure the resistance between the (P502) Passenger Mirror Turn Signal Driver circuit and the (P70) Passenger Mirror Common Driver circuit at the Passenger Outside Rearview Mirror C2 (Component Side) connector. Measure the resistance between the (P502) Passenger Mirror Turn Signal Driver circuit and the (P74) Passenger Mirror Horizontal Driver circuit at the Passenger Outside Rearview Mirror C2 (Component Side) connector. Is the resistance below 10K Ohms for any measurement? Yes Repair all circuits with a resistance below 10K Ohms for a short to the (P502) Passenger Mirror Turn Signal Driver circuit. If the wiring harness and connector are okay, replace the Passenger Outside Rearview Mirror in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No, with Heated Mirror Go To 4 . No, without Heated Mirror Go To 5 .
4. CHECK (P502) PASSENGER MIRROR TURN SIGNAL DRIVER CIRCUIT FOR A SHORT TO THE (C170) PASSENGER MIRROR HEATER RETURN CIRCUIT Measure the resistance between the (P502) Passenger Mirror Turn Signal Driver circuit and the (C170) Passenger Mirror Heater Return circuit at the Passenger Outside Rearview Mirror C2 (Component Side) connector. Is the resistance below 10K Ohms? Yes Repair the (P502) Passenger Mirror Turn Signal Driver circuit for a short to the (C170) Passenger Mirror Heater Return circuit. If the wiring harness and connector are okay, replace the Passenger Outside Rearview Mirror in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Go To 5 .
5. CHECK (P502) PASSENGER MIRROR TURN SIGNAL DRIVER CIRCUIT FOR A SHORT TO THE (P595) PASSENGER MIRROR TURN SIGNAL RETURN CIRCUIT NOTE: The Ohmmeter positive lead must be connected to the (P595) Passenger Mirror Turn Signal Return circuit and the negative lead to the (P502) Passenger Mirror Turn Signal Driver circuit for the test results to be valid. Measure the resistance between the (P502) Passenger Mirror Turn Signal Driver circuit and the (P595) Passenger Mirror Turn Signal Return circuit at the Passenger Outside Rearview Mirror C2 (Component Side) connector. Is there any resistance present? Yes Repair the (P502) Passenger Mirror Turn Signal Driver circuit for a short to the (P595) Passenger Mirror Turn Signal Return circuit. If the wiring harness and connector are okay, replace the Passenger Outside Rearview Mirror in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Go To 6 .
6. CHECK (P502) PASSENGER MIRROR TURN SIGNAL DRIVER CIRCUIT FOR A SHORT TO THE (P66) PASSENGER MIRROR SENSOR GROUND CIRCUIT Disconnect the Passenger Outside Rearview Mirror C1 (Component Side) connector from the Door Module C1 connector. Measure the resistance between the (P502) Passenger Mirror Turn Signal Driver circuit and the (P66) Passenger Mirror Sensor Ground circuit at the Passenger Outside Rearview Mirror C2 and C1 (Component Side) connectors. Is the resistance below 10K Ohms? Yes Repair the (P502) Passenger Mirror Turn Signal Driver circuit for a short to the (P66) Passenger Mirror Sensor Ground circuit. If the wiring harness and connector are okay, replace the Passenger Outside Rearview Mirror in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No, with Puddle Lamp Mirror Go To 7 . No, without Puddle Lamp Mirror Inspect the wiring and connectors for damage and repair as necessary. If the wiring and connectors are okay, replace the Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
7. CHECK (P502) PASSENGER MIRROR TURN SIGNAL DRIVER CIRCUIT FOR A SHORT TO THE (P592) PASSENGER PUDDLE LAMP RETURN CIRCUIT Measure the resistance between the (P502) Passenger Mirror Turn Signal Driver circuit and the (P592) Passenger Puddle Lamp Return circuit at the Passenger Outside Rearview Mirror C2 and C1 (Component Side) connectors. Is the resistance below 10K Ohms? Yes Repair the (P502) Passenger Mirror Turn Signal Driver circuit for a short to the (P592) Passenger Puddle Lamp Return circuit. If the wiring harness and connector are okay, replace the Passenger Outside Rearview Mirror in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Inspect the wiring and connectors for damage and repair as necessary. If the wiring and connectors are okay, replace the Door Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
