Body - Interior & Exterior: Specifications — Body - Interior & Exterior — Gauges & Instrument Panels

SPECIFICATIONS

Description	N.m	Ft. Lbs	In. Lbs.
A-pillar bolts	5		44
Body isolator nuts	68	50
B-pillar grab handle bolts	5		44
Cab mounting bolts	108	80
Cargo box mounting bolts	108	80
Cargo tie down bolts	34	25
Door striker bolts	30	22
Floor console floor bracket screws	7	5	62.0
Front door carrier plate bolts	5.5		49
Front door exterior handle bolts	7	5	62.0
Front door hinge to pillar bolts	24	18
Front door latch screws	7	5	62.0
Front door lower belt channel shut face screw	8	6	71
Front door striker bolts	30	22
Front door to hinge nuts	22	16
Front seat back bolts	40	29.5
Front seat belt buckle bolts	50	37
Front seat lumbar motor bolts	10	7	89
Front seat mounting bolts	47	35
Hood hinge to fender rail bolts	19	14
Hood hinge to hood nuts	18	13
Hood latch bolts	11	8	97
Hood striker bolts	17	12.5
Instrument panel center mounting bolts	12	9
Instrument panel fence line bolts	12	9
Instrument panel side mounting bolts	12	9
Lower seat belt anchor bolts rear	40	29.5
Ram box mounting bolts	7	5	62.0
Rear door exterior handle bolts	7	5	62.0
Rear door hinge to pillar bolts	24	18
Rear door striker bolts	26	19
Rear door to hinge bolts	22	16
Rear outer seat belt anchor bolts	40	29.5
Rear seat armrest fasteners	28	21
Rear seat back pivot bolts	28	21
Rear seat belt buckle bolts	47	35
Rear seat belt turning loop bolts	40	29.5
Rear seat cushion frame bolts	55	41
Rear seat storage lid bolts	28	21
Rear view mirror set screw	1		9
Seat belt turning loop bolts	40	29.5
Sunroof assembly screws	9		80
Sunroof glass screws	3.5		31
Tailgate handle nuts	6		53
Tailgate latch bolts	23	17.0
Tailgate striker	34	25

CAUTION

** Whenever a body isolator bolts requires servicing or tightening, it is necessary to remove the bolt and install new thread locker compound to the threads.

Note. Because of late model changes to the available paint colors. Refer to Vehicle Certification Label , Description .

EXTERIOR COLOR	CHRYSLER CODE
Austin Tan Pearlcoat	PKL
Black	DX8
Blackberry	HBV
Blazing Saddle	PUS
Bright Silver Metallic Clearcoat	WS2
Bright White Clearcoat	GW7
Brilliant Black Crystal Pearlcoat	AXR
Deep Cherry Red Crystal	JRP
Deep Forest Green	JGT
Deep Water Blue Pearlcoat	GBS
Flame Red Clearcoat	PR4
Gold Rush	JYK
Inferno Red Pearlcoat	ARH
Light Greystone Pearlcoat	EDA
Mango Tango Pearlcoat	HVG
Mineral Grey Metallic Clearcoat	CDM
Rugged Brown Pearlcoat	GTW
Sarsaparilla Sage	JGX
White Gold Metallic	HWL

EXTERIOR COLORS

INTERIOR COLOR	CHRYSLER CODE
Dark Slate Gray	DV
Dark Slate Gray/ Medium Greystone	V3
Dark Slate Gray/ Russet	DE
Light Pebble Beige/ Bark Brown	KT

INTERIOR COLORS

DESCRIPTION	FIGURE
REGULAR CAB	(Scheme 1)
QUAD CAB	(Scheme 2)
CREW CAB	(Scheme 3)

GAP AND FLUSH DIMENSIONS INDEX

Scheme 1

NOTE: All measurements are in millimeters.
O/F = Over Flush		U/F = Under Flush
U/D = Up/Down		F/A = Fore/Aft
DIMENSION	DESCRIPTION	GAP	FLUSH
1	Hood to grille (along top)	7.0 +/- 2.0 transition to 4.5 after corner	Hood O/F 7.0 @ center to 5.5 @ corner to 1.0 around corner +/- 2.0
2	Headlamp to hood	7.0 +/- 2.0	Headlamp O/F 4.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 2.0
3	Fender to headlamp	2.5 +/- 2.0	Fender O/F 2.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 3.0
4	Fender to a-pillar	3.0 +/- 1.5	Fender O/F 0.75 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Side to side within 2.0	Side to side within 2.0
5	Aperture to front door @ a-pillar	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
6	Aperture to front door @ roof	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
7	Aperture to rear door @ roof	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5
8	Box outer to fuel filler door	4.5 +/- 1.5	0.0 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
9	Cab to box	35.0 +/- 4.0	Cab O/F 6.0 +/- 4.0
		Parallel within 3.0	Parallel within 3.0
10	Fender to front door	4.5 +/- 1.5	Box outer O/F 0.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5	Top to bottom within 1.5
11	Fascia to fender	Net to 2.0	0.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
12	Headlamp to fascia	4.5 +/- 2.0	0.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 2.0
13	Grille to headlamp	3.7 +/- 2.0
		Parallel within 2.0
		Side to side within 3.0
14	Grille to fascia	3.5 +/- 2.0
		Parallel within 2.0
		Side to side within 2.0
15	Deflector to tailgate inner	F/A 0.0 +2.0/- 0.0
		Parallel within 2.0
16	Box cab to tailgate deflector		U/D 0.0 +/- 2.0
17	Fender to hood @ cowl	4.5 +/- 1.5	Fender U/D-U/F 0.75 +/-1.5
		Parallel within 1.5	Cross/car 0.0 +/- 1.5
		Side to side within 2.0
18	Fender to hood	4.5 +/- 1.5	Fender O/F 0.5 +/- 1.5
		Parallel within 1.5
		Side to side within 2.0
19	Wheel flare to fascia	1.0 +2.0/- 1.0	0.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
20	Fender to sill	4.5 +/- 1.5	Fender O/F 1.0 +/- 1.5
		Parallel within 1.5
		Side to side within 2.0
21	Sill to front door	6.0 +/- 1.5	Sill O/F 4.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
22	Cab to box	32.0 +/- 3.5
		Parallel within 3.0
23	Box outer to tail lamp	2.5 +/- 2.0	0.0 +/- 2.0
		Parallel within 2.0
24	Rear bumper to box outer	F/A 30.4 +/- 5.0	+/- 1.5
		Parallel within 5.0	Parallel within 1.5
		U/D 26.0 +/- 3.0
		Parallel within 4.0
25	Bumper to tailgate	33.4 +/- 3.0
		Parallel within 4.0
26	Tail lamp to tailgate	5.0 +/- 2.0	Tail lamp O/F 1.5 +/- 2.0
		Parallel within 2.0
		Side to side within 2.0
27	Box outer to tailgate	5.0 +/- 1.5	Box outer O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Side to side within 1.5	Side to side within 1.5

NOTE
All measurements are in millimeters.

Scheme 2

NOTE: All measurements are in millimeters.
O/F = Over Flush		U/D = Up/Down
U/F = Under Flush		F/A = Fore/Aft
DIMENSION	DESCRIPTION	GAP	FLUSH
1	Hood to grille (along top)	7.0 +/- 2.0 transition to 4.5 after corner	Hood O/F 7.0 @ center to 5.5 @ corner to 1.0 around corner +/- 2.0
2	Headlamp to hood	7.0 +/- 2.0	Headlamp O/F 4.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 2.0
3	Fender to headlamp	2.5 +/- 2.0	Fender O/F 2.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 3.0
4	Fender to a-pillar	3.0 +/- 1.5	Fender O/F 0.75 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Side to side within 2.0	Side to side within 2.0
5	Aperture to front door @ a-pillar	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
6	Aperture to front door @ roof	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
7	Aperture to rear door @ roof	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5
8	Quarter panel to rear door	4.5 +/- 1.5	0.0 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5
9	Box outer to fuel filler door	4.5 +/- 1.5	Box outer O/F 0.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
10	Cab to box	35.0 +/- 4.0	Cab O/F 6.0+/- 4.0
		Parallel within 3.0	Parallel within 3.0
11	Front door to rear door above belt	4.5 +/- 1.5	0.0 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5
12	Front door to rear door below belt	4.5 +/- 1.5	Front door O/F 1.0
		Parallel within 1.5	Between belt and character line +/- 1.5
		Top to bottom within 1.5	Parallel within 1.5
			1.0 to 0.0 below character line +/- 1.5
13	Fender to front door	4.5 +/- 1.5	Fender O/F 1.0 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5	Top to bottom within 1.5
14	Fascia to fender	Net to 2.0	0.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
15	Headlamp to fascia	4.5 +/- 2.0	0.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 2.0
16	Grille to headlamp	3.7 +/- 2.0
		Parallel within 2.0
		Side to side within 3.0
17	Grille to fascia	3.5 +/- 2.0
		Parallel within 2.0
		Side to side within 2.0
18	Deflector to tailgate inner	F/A 0.0 +2.0/- 0.0
		Parallel within 2.0
19	Box cab to tailgate deflector		U/D 0.0 +/- 2.0
20	Cab to box	32.0 +/- 3.5
		Parallel within 3.0
21	Front door belt to rear door belt	U/D alignment: 0 +/- 2.0
22	Fender to hood @ cowl	4.5 +/- 1.5	Fender U/D-U/F 0.75 +/-1.5
		Parallel within 1.5	Cross/car 0.0 +/- 1.5
		Side to side within 2.0
23	Fender to hood	4.5 +/- 1.5	Fender O/F 0.5 +/- 1.5
		Parallel within 1.5
		Side to side within 2.0
24	Wheel flare to fascia	1.0 +2.0/- 1.0	0.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
25	Fender to sill	4.5 +/- 1.5	Fender O/F 1.0 +/- 1.5
		Parallel within 1.5
		Side to side within 2.0
26	Sill to front door	6.0 +/- 1.5	Sill O/F 4.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
27	Sill to rear door	6.0 +/- 1.5	Sill O/F 4.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
28	Box outer to tail lamp	2.5 +/- 2.0	0.0 +/- 2.0
		Parallel within 2.0
29	Rear bumper to box outer	F/A 30.4 +/- 5.0	+/- 1.5
		Parallel within 5.0	Parallel within 1.5
		U/D 26.0 +/- 3.0
		Parallel within 4.0
30	Bumper to tailgate	33.4 +/- 3.0
		Parallel within 4.0
31	Box outer to tailgate	5.0 +/- 1.5	Box outer O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Side to side within 1.5	Side to side within 1.5
32	Tail lamp to tailgate	5.0 +/- 2.0	Tail lamp O/F 1.5 +/- 2.0
		Parallel within 2.0
		Side to side within 2.0

NOTE
All measurements are in millimeters.

Scheme 3

NOTE: All measurements are in millimeters.
O/F = Over Flush		U/D = Up/Down
U/F = Under Flush		F/A = Fore/Aft
DIMENSION	DESCRIPTION	GAP	FLUSH
1	Hood to grille (along top)	7.0 +/- 2.0 transition to 4.5 after corner	Hood O/F 7.0 @ center to 5.5 @ corner to 1.0 around corner +/- 2.0
2	Headlamp to hood	7.0 +/- 2.0	Headlamp O/F 4.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 2.0
3	Fender to headlamp	2.5 +/- 2.0	Fender O/F 2.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 3.0
4	Fender to a-pillar	3.0 +/- 1.5	Fender O/F 0.75 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Side to side within 2.0	Side to side within 2.0
5	Aperture to front door @ a-pillar	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
6	Aperture to front door @ roof	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
7	Aperture to rear door @ roof	4.5 +/- 1.5	Aperture O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5
8	Quarter panel to rear door	4.5 +/- 1.5	0.0 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5
9	Ram box to box outer	5.0 +/- 2.0	Flush +/- 2.0
10	Box outer to fuel filler door	4.5 +/- 1.5	Box Outer O/F 0.5 +/- 1.5
10		Parallel within 1.5	Parallel within 1.5
11	Cab to box	35.0 +/- 4.0	Cab O/F 6.0 +/- 4.0
11		Parallel within 3.0	Parallel within 3.0
12	Front door to rear door above belt	4.5 +/- 1.5	0.0 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5
13	Front door to rear door below belt	4.5 +/- 1.5	Front Door O/F 1.0 Between belt and Character line +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5	1.0 to 0.0 below Character line +/- 1.5
14	Fender to front door	4.5 +/- 1.5	Fender O/F 1.0 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Top to bottom within 1.5	Top to bottom within 1.5
15	Fascia to fender	Net to 2.0	0.0 +/- 2.0
15		Parallel within 2.0	Parallel within 2.0
16	Headlamp to fascia	4.5 +/- 2.0	0.0 +/- 2.0
		Parallel within 2.0	Parallel within 2.0
		Side to side within 3.0	Side to side within 2.0
17	Grille to headlamp	3.7 +/- 2.0
		Parallel within 2.0
		Side to side within 3.0
18	Grille to fascia	3.5 +/- 2.0
		Parallel within 2.0
		Side to side within 2.0
19	Deflector to tailgate inner	F/A 0.0 +2.0/- 0.0
19		Parallel within 2.0
20	Box cab to tailgate deflector		U/D 0.0 +/- 2.0
21	Cab to box	32.0 +/- 3.5
21		Parallel within 3.0
22	Front door belt to rear door belt	U/D Alignment: 0 +/- 2.0
23	Fender to hood @ cowl	4.5 +/- 1.5	Fender U/D-U/F 0.75 +/-1.5
		Parallel within 1.5	Cross/Car 0.0 +/- 1.5
		Side to side within 2.0
24	Fender to hood	4.5 +/- 1.5	Fender O/F 0.5 +/- 1.5
		Parallel within 1.5
		Side to side within 2.0
25	Wheel flare to fascia	1.0 +2.0/- 1.0	0.0 +/- 2.0
25		Parallel within 2.0	Parallel within 2.0
26	Fender to sill	4.5 +/- 1.5	Fender O/F 1.0 +/- 1.5
		Parallel within 1.5
		Side to side within 2.0
27	Sill to front door	6.0 +/- 1.5	Sill O/F 4.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
28	Sill to rear door	6.0 +/- 1.5	Sill O/F 4.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Front to back within 1.5	Front to back within 1.5
29	Box outer to tail lamp	2.5 +/- 2.0	0.0 +/- 2.0
29		Parallel within 2.0	0.0 +/- 2.0
30	Rear bumper to box outer	F/A 30.4 +/- 5.0	+/- 1.5
		Parallel within 5.0	Parallel within 1.5
		U/D 26.0 +/- 3.0
		Parallel within 4.0
31	Bumper to tailgate	33.4 +/- 3.0
31		Parallel within 4.0
32	Box outer to tailgate	5.0 +/- 1.5	Box Outer O/F 1.5 +/- 1.5
		Parallel within 1.5	Parallel within 1.5
		Side to side within 1.5	Side to side within 1.5
33	Tail lamp to tailgate	5.0 +/- 2.0	Tail Lamp O/F 1.5 +/- 2.0
		Parallel within 2.0
		Side to side within 2.0

NOTE
All measurements are in millimeters.

Body - Interior & Exterior: Specifications RAM Pickup 2500

SPECIFICATIONS

Scheme 1

Scheme 2

Scheme 3

More articles — Body - Interior & Exterior

Login / Signup

Enter the code

You have successfully logged in!
