Propeller Shaft: Adjustments RAM Pickup 2500

ADJUSTMENTS

Launch shudder is a vibration that occurs at first acceleration from a stop. Shudder vibration usually peaks at the engines highest torque output. Shudder is a symptom associated with vehicles using a two-piece propeller shaft. To decrease shudder, lower the center bearing in 3.0 mm (0.125 in.) increments. Use shim stock or fabricated plates. Do not use washers. Replace the original bolts with the appropriate increased length bolts.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Remove rear propeller shaft.
2. Make installation reference marks on the shaft (1) and slip yoke (2).
3. Remove slip joint boot (1) clamp (2).
4. Slide boot (1) off boot collar (2) and separate the two shafts.
5. Position Bearing Splitter Tool (special tool #1130, Splitter, Bearing/Gear) (2) between slinger and center bearing (1).
6. Install Bridge (special tool #938, Bridge) (3) on the splitter (2) and remove center bearing (1).

Scheme 14

Scheme 15

1. Install new slinger on shaft if removed and drive into position with appropriate installer tool.
2. Install new center bearing (1) and boot collar (2) on shaft.
3. Install bearing (1) and boot collar (2) on shaft with Installer (special tool #6052, Installer, Bearing/Seal) (3).
4. Clean shaft splines and apply a coat of multi-purpose grease.
5. Align master splines and slide front and rear half-shafts together.
6. Position slip yoke boot (1) on boot collar and install clamp (2).
7. Install propeller shaft in vehicle.

Launch shudder is a vibration that occurs at first acceleration from a stop. Shudder vibration usually peaks at the engines highest torque output. Shudder is a symptom associated with vehicles using a two-piece propeller shaft. To decrease shudder, lower the center bearing in 3.0 mm (0.125 in.) increments. Use shim stock or fabricated plates. Do not use washers. Replace the original bolts with the appropriate increased length bolts.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. Remove rear propeller shaft.
2. Make installation reference marks on rear shaft (1) and front shaft (2).
3. Remove slip joint boot (1) clamp (2).
4. Slide boot (1) off boot collar (2) and separate the two shafts.
5. Position Bearing Splitter Tool (special tool #1130, Splitter, Bearing/Gear) (1) between propeller shaft and center bearing (2).
6. Install Bridge (special tool #938, Bridge) (3) on the splitter (1) and remove center bearing.

Scheme 20

Scheme 21

1. Remove rear propeller shaft.
2. Make installation reference marks on rear shaft, center bearing yoke (1) and front shaft (2).
3. Remove joint from center bearing yoke.
4. Remove center bearing yoke (1) nut (2) and washer (3). Discard yoke nut.
5. Remove center bearing yoke (1) from shaft with two jaw puller.
6. Position Bearing Splitter Tool (special tool #1130, Splitter, Bearing/Gear) (1) between propeller shaft and center bearing (2).
7. Install Bridge (special tool #938, Bridge) (3) on the splitter (1) and remove center bearing.

Scheme 22

Scheme 23

1. Slide center bearing (1) and boot collar (2) on shaft.
2. Install boot collar (2) and center bearing (1) with Installer (special tool #6448A, Installer, Bearing/Gear).
3. Clean shaft splines and apply a coat of multi-purpose grease.
4. Align master splines and slide front and rear half-shafts together.
5. Slide slip yoke boot (1) on boot collar (2).
6. Install slip yoke boot (1) clamp (2).
7. Install propeller shaft in vehicle.

Scheme 24

Scheme 25

1. Slide center bearing (1) on shaft (2).
2. Install center bearing (1) with Installer MD 998805 (2).
3. Clean shaft splines and apply a coat of multi-purpose grease.
4. Install center bearing yoke (1) and front shaft (2) with reference marks aligned.
5. Install center bearing yoke (1) new nut (2) and washer (3).
6. Tighten nut to 678 N.m (500 ft. lbs.).
7. Install joint in center bearing yoke (1).

Scheme 26

Scheme 27

1. With vehicle in neutral, position vehicle on hoist.
2. Remove exhaust crossover pipe.
3. Mark a line across the axle companion flange (1), propeller shaft (2), flange yoke (3) and transfer case for installation reference.
4. Remove axle/transfer case companion flange bolts. Remove dust boot clamp (3) from the C/V joint (1) end of the shaft if equipped.
5. Remove propeller shaft.
