Wireless Ignition Node (Win) - Electrical Diagnostics: Other RAM Pickup 2500

B1A08-RKE FOB 1 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When Monitored

Continuously.

Set Condition

Scrambled messages to the Wireless Ignition Node (WIN) from the FOBIK transmitter.

Possible Causes

Note. The most probable cause that sets this code is the RKE transmitter being pressed over 1023 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A09-RKE FOB 2 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the FOBIK transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A0A-RKE FOB 3 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the FOBIK transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A0B-RKE FOB 4 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A0C-RKE FOB 5 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A0D-RKE FOB 6 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A0E-RKE FOB 7 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A0F-RKE FOB 8 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

B1A10-RKE FOB 1 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A11-RKE FOB 2 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A12-RKE FOB 3 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A13-RKE FOB 4 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A14-RKE FOB 5 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A15-RKE FOB 6 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A16-RKE FOB 7 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A17-RKE FOB 8 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

B1A24-KEY NOT PROGRAMMED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During interrogation, the FOBIK sends a low frequency (LF) signal to the WIN that includes the FOBIK identification information.

This DTC sets if the WIN receives the default, secret key status from a FOBIK. Once set, this DTC will remain active until a valid, programmed FOBIK is inserted in the basestation and rotated through the ON position.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

B1A25-INVALID KEY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During interrogation, the FOBIK sends a low frequency (LF) signal to the WIN that includes the inserted FOBIK ID.

This DTC sets if the WIN receives an ID from the FOBIK that does not match any of the eight possible FOBIK IDs currently programmed in the WIN. This DTC will remain active until a valid, programmed FOBIK is inserted in the basestation and rotated through the ON position.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

B1A26-MAXIMUM NUMBER OF KEYS PROGRAMMED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When the WIN is placed into FOBIK programming mode, the module references the number of unique FOBIK identifications stored in its memory.

In the event the WIN detects the user is attempting to program a 9th FOBIK, this DTC will be set as active.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

B1A27-SKREEM PROGRAMMING PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During FOBIK programming mode when the FOBIK and the WIN module are communicating over LF (low frequency) communication.

The WIN will set this DTC if one or more of the three FOBIK transmissions, during FOBIK programming, failed to be properly received by the WIN. The FOBIK may still get programmed because the transmission was successful on one of the other attempts.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

Note. All FOBIKs programmed to this vehicle should be present before continuing.

B1A28-ECM MISMATCH WITH SKIM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever a valid FOBIK is inserted in the basestation and turned to the ON position, the WIN/PCM handshake takes place. The WIN validates that the message is sent to and received by the PCM.

When a valid FOBIK is used and the WIN receives a mismatching cryptology code from the PCM as part of the routine, the WIN will send the command to flash the Security warning lamp and set this DTC as active. The engine will not start and the DTC will remain active until the WIN and PCM complete a successful handshake.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

B1A29-SKIM BASESTATION MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever a FOBIK is inserted in the basestation, the WIN determines its validity status. If determined valid, the WIN allows rotation to the ON position and the WIN/PCM handshake takes place.

When an invalid FOBIK is used and the WIN receives a mismatching or no secret key data from the FOBIK, the WIN will send the command to illuminate the Security warning lamp, send an invalid key status in the handshake with the PCM, and set this DTC as active. The "B1A28 ECM/PCM Mismatch with SKIM" DTC will probably be accompanied along with this B1A29.

Always perform the WIN Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

Note. When diagnosing any WIN system DTCs, all FOBIK used on the vehicle should be present.

B1A35-UNIDENTIFIED KEY COMMUNICATION ERROR

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During interrogation, the FOBIK sends an LF (Low frequency) signal to the WIN that includes the programmed FOBIK ID.

This Diagnostic Trouble Code (DTC) sets if a FOBIK is inserted in the WIN basestation but the WIN does not receive or is unable to read an ID from the FOBIK. This DTC will remain active until a valid programmed FOBIK is inserted in the WIN and its ID is received.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

B1A6C-SECRET KEY MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During interrogation, the FOBIK sends a low frequency (LF) signal to the WIN that includes the current secret key.

This Diagnostic Trouble Code (DTC) sets if the WIN receives a secret key ID from the FOBIK that is not the correct secret key value stored in the WIN. This DTC will remain active until a valid, programmed FOBIK, with the correct secret key is inserted in the basestation and rotated through the ON position.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

B1A77- REMOTE START ANTENNA CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Remote start present and configured.

Short to ground detected on the Remote Start Antenna.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

B1A79- REMOTE START ANTENNA CIRCUIT OPEN OR NOT CONNECTED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Remote start present and configured.

No Remote Start Antenna detected by the Wireless Ignition Node (WIN).

B210A-SYSTEM VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

At all times.

This is a CAN message that the battery voltage was below 10.0 volts for over 15 seconds.

B210B-SYSTEM VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

At all times.

This is a CAN message that the system voltage was above 16.0 volts for over 15 seconds.

With the ignition switch on.

The Wireless Ignition Node (WIN) has detected the Fused (B+) input voltage was below 10.5 volts for over 15 seconds except during cranking or when the FOBIK removal process is engaged.

Scheme 34

1. CHECK PCM FOR CHARGING SYSTEM DTCs NOTE: Be sure the battery is fully charged before proceeding. With a scan tool, read the Powertrain Control Module (PCM) DTCs. Are there any Charging or Starting System DTCs set in the PCM? Yes and perform the appropriate diagnostic procedure. Refer to appropriate Electrical Diagnostic Information . No Go To 2 .
2. VERIFY THAT DTC B210D-BATTERY VOLTAGE LOW IS ACTIVE With the scan tool, record and erase the DTCs. Turn the ignition switch to the OFF position then start the engine and let run for one minute. With the scan tool, read the WIN active DTCs. Does the scan tool display: B210D-BATTERY VOLTAGE LOW active? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
3. (A106) FUSED (B+) CIRCUIT OR (Z911) GROUND CIRCUIT HAS HIGH RESISTANCE NOTE: Check the related fuses to the Fused (B+) circuit. If the fuse is found to be open, repair the circuit for a shorted condition. Turn the ignition off. Disconnect the WIN harness connector. Turn the ignition on. Using a 12-volt test light, connect it between the (A106) Fused (B+) circuit and the (Z911) Ground circuit in the WIN harness connector. The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Is the test light as bright at the module as it is at the battery? Yes Replace and program the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, Wireless Ignition Node , Removal»(ref-457810-S37417346812012030200000) . Perform the WIN VERIFICATION TEST. Refer to «Standard Procedure»(ref-457830-S06668432092012030200000) . No Test the (A106) Fused B(+) circuit and the Ground circuit to determine which one has the high resistance. Repair the Fused B(+) circuit or the Ground circuit for high resistance. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

Scheme 35

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition switch on.

The Wireless Ignition Node (WIN) has detected the Fused (B+) input voltage was below 10.5 volts for over 15 seconds except during cranking or when the FOBIK removal process is engaged.

B210E-BATTERY VOLTAGE HIGH - DD/DP

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition switch on.

The Wireless Ignition Node (WIN) has detected the Fused (B+) input voltage to be above 15.5 volts for over 15 seconds.

B210E-BATTERY VOLTAGE HIGH - DS/DJ/D2

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition switch on.

The Wireless Ignition Node (WIN) has detected the Fused (B+) input voltage to be above 15.5 volts for over 15 seconds.

The WIN checks the feature configuration at power up during the initialization process, and continuously through the ignition cycle.

This DTC sets when the WIN detects a mismatch of Model Year, vehicle line, body style or market country between the current vehicle configuration of the module and the information sent out on the CAN bus. Once set, this DTC is latched for the entire ignition cycle.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

The WIN monitors the VIN broadcast on the CAN C bus three times, when the ignition is turned to the RUN position. When the full VIN has been received by the WIN, all further broadcasts of the VIN are ignored for that ignition cycle.

When the VIN received from the CAN C bus does not match the VIN stored in the memory of the Wireless Ignition Node, the WIN will send the command to flash the Security warning lamp and set this DTC as active and the vehicle will immobilize. The DTC will remain active until a VIN matching the one stored in WIN memory is received by the module from the bus.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to Standard Procedure .

During key insertion and removal and at module power up.

When the internal memory is corrupted. This DTC can also set if the vehicle is equipped with a Steering Column Lock module (BUX). If after any three consecutive unsuccessful Steering Column Lock and/or Unlock (ELV) attempts, which could be caused by an encoded data mismatch or the bolt did not reach the intended position when requested.

Continuously.

A low pressure condition will exist when the tire pressure falls below or is equal to the low pressure threshold value as specified for the vehicle.

With vehicle speed greater than 24 km/h (15 mph).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

With vehicle speed greater than 24 km/h (15 mph).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

With vehicle speed greater than 24 km/h (15 mph).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

With vehicle speed greater than 15 m.p.h. (24 km/h).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

C151C-TIRE PRESSURE MONITORING (TPM) SENSORS MISSING

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During vehicle TPM Sensor ID locate process.

When installing a new Wireless Ignition Node (WIN).

Continuously with the ignition on.

The Diagnostic Trouble Code (DTC) will set if the high side driver detects a short to ground for 10 seconds.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. ENGINE DTCS PRESENT With the scan tool, read PCM DTCs. Are there any Powertrain Control Module (PCM) brake switch related DTCs present? Yes and perform the appropriate diagnostic procedure. Refer to appropriate Electrical Diagnostic Information . No Go To 2 .
2. CHECK THE (K321) BTSI CONTROL CIRCUIT Turn the ignition off to the lock position. Disconnect the Shift Lever Assembly harness connector. NOTE: Check connectors - Clean/repair as necessary. Using a 12-volt test light, connect one end to the (Z911) Ground circuit and the other to the (K321) BTSI Control circuit in the Shifter connector. Turn the Ignition on, engine not running. With the scan tool under WIN, select Actuators and actuate the BTSI. Does the test light illuminate brightly while the actuator is cycling the (K321) BTSI Control circuit on and off? Yes Replace the Shift Lever Assembly in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No With the scan tool, stop the actuation. Go To 3 .
3. CHECK THE (Z911) GROUND CIRCUIT Using a 12-volt test light connected to 12-volts, check the (Z911) Ground circuit in the Shifter connector. Does the test light illuminate brightly? Yes Go To 4 . No Repair the open in the (Z911) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .
4. (K321) BTSI CONTROL CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the WIN harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance between ground and the (K321) BTSI Control circuit in the WIN and the Shift Lever connectors. Is the resistance below 10k Ohms at either connector? Yes Repair the short to ground in the (K321) BTSI Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Go To 5 .
5. (K321) BTSI CONTROL CIRCUIT OPEN Measure the resistance of the (K321) BTSI Control circuit between the Shift Lever harness connector and the WIN harness connector. Is the resistance above 5.0 Ohms? Yes Repair the open in the (K321) BTSI Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Go To 6 .
6. (K321) BTSI CONTROL CIRCUIT SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage between ground and the (K321) BTSI Control circuit in the Shift Lever harness connector and the WIN harness connector. Is there any voltage present at either connector? Yes Repair the short to voltage in the (K321) BTSI Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Replace the Wireless Ignition Node in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

With the ignition on.

Whenever the CAN C Bus (+) or CAN C Bus (-) circuit is open, shorted to voltage or shorted to ground.

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Anti Lock Brake Module (ABS) for approximately two to five seconds.

Continuously when the ignition is on.

The battery voltage between 10.0 and 16.0 Volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Whenever a FOBIK is rotated to the Run position.

This DTC sets if the WIN does not receive a CAN Bus message from the ECM/PCM. This code will set on the 20th start attempt.

VERIFICATION

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Perform the following after completion of a diagnostic repair

Note. When entering the Personal Identification Number (PIN), care should be taken because the WIN will only allow three consecutive attempts to enter the correct PIN. If three consecutive incorrect PIN's are entered the WIN will Lock Out the scan tool. To exit Lock Mode, the ignition key must remain in the Run position for one hour. All accessories must be off. A battery charger connected to the battery during this time period is recommended.

Note. On vehicles equipped with a Base Tire Pressure Monitoring (TPM) system, when the WIN and/or the spare tire pressure sensor is replaced with a new unit, a diagnostic scan tool MUST be used to run a routine that allows the WIN to be programmed with the ID number and location of the spare tire pressure sensor mounted in the wheel of the spare tire. Follow the programming steps outlined in the diagnostic scan tool for "Learn Spare Tire Sensor ID" under "Miscellaneous Functions" for the "WIN" menu item as appropriate. In addition, if the WIN is replaced, the spare tire must be dismounted from its wheel to access and note the ID number on the spare tire pressure sensor so that the ID code for that sensor can be programmed into the new WIN.

1. Reconnect the previously disconnected components and connectors.
2. Obtain the vehicle's unique Personal Identification Number (PIN) assigned to it's original WIN. This number can be obtained from the original vehicle invoice or from your Service Manager or Parts Manager.

Note. If the Powertrain Control Module (PCM) and the WIN are replaced at the same time, program the PCM VIN into the PCM first.

Note. The PCM stores the secret key information. If the WIN ever needs to be replaced, the secret key information can be retrieved from the PCM and then transferred to the WIN for security use.

During PCM/ECM replacement, use the following steps to verify the transfer of the secret key information from the WIN to the new PCM

1. If the PCM is to be replaced, first, replace the PCM/ECM with the original WIN still connected to the vehicle. If the PCM is not being replaced, go to step 3.
2. Using the appropriate Service Information to program the new PCM/ECM. (This will verify the Secret Key Transfer from the original WIN into the new PCM/ECM).
3. Now replace and program (WIN Replaced) the WIN (if necessary). This will cause the WIN to receive the Secret Key from the PCM/ECM back into the new WIN. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WIN. Whenever a WIN is replaced the Steering Wheel Lock Module MUST be replaced.
4. Using the scan tool, select Miscellaneous Functions, WIN. Then select the desired procedure and follow the display on the scan tool.
5. If the vehicle is equipped with the Base Tire Pressure Monitoring System, program the Placard Pressure Values into the WIN.
6. Make sure all the customer's keys have been programmed into the new module if necessary.
7. Using the scan tool, erase all DTCs. Perform five ignition key cycles, leaving the key on for at least 90 seconds per cycle.
8. Using the scan tool, read WIN DTCs.

TPM VERIFICATION

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
