Totally Integrated Power Module (Tipm) - Electrical Diagnostics: Other RAM Cab & Chassis 3500 HD

WHEN MONITORED

With the low beam headlamps active.

SET CONDITION

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L43) Left Low Beam Driver circuit.

POSSIBLE CAUSES

Scheme 263

Scheme 264

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B162B-LEFT LOW BEAM CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Disconnect the Left Headlamp Lamp harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC: B162C-LEFT LOW BEAM CONTROL CIRCUIT HIGH? Yes Replace the Left Low Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L43) LEFT LOW BEAM DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance between ground and the (L43) Left Low Beam Driver circuit. Is the resistance above 10k Ohms? Yes Go To 4 . No Repair the short to ground in the (L43) Left Low Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (L43) LEFT LOW BEAM DRIVER CIRCUIT FOR A SHORT TO THE (L911) LEFT HEADLAMP RETURN SIGNAL CIRCUIT Measure the resistance between the (L43) Left Low Beam Driver circuit and the (L911) Left Headlamp Return Signal circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short between the (L43) Left Low Beam Driver circuit and the (L911) Left Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B162C-LEFT LOW BEAM CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the low beam headlamps active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L43) Left Low Beam Driver circuit.

Scheme 265

Scheme 266

Scheme 267

Scheme 268

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B162C-LEFT LOW BEAM CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L43) LEFT LOW BEAM DRIVER CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Headlamps off. Turn the ignition off. Disconnect the Left Headlamp Lamp harness connector. Disconnect the TIPM C3 harness connector. Turn the ignition on. Measure the voltage between ground and the (L43) Left Low Beam Driver circuit. Is there any voltage present? Yes Repair the short to voltage in the (L43) Left Low Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C3 harness connector. Connect a 12-volt test light between the (L43) Left Low Beam Driver circuit and (L911) Left Headlamp Return Signal circuit in the Left Headlamp Lamp harness connector. Turn the ignition on. Turn the Headlamps on. Does the test light illuminate brightly? Yes Replace the Left Low Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L43) LEFT LOW BEAM DRIVER CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance of the (L43) Left Low Beam Driver circuit between the Left Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L43) Left Low Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (L911) LEFT HEADLAMP RETURN SIGNAL CIRCUIT FOR AN OPEN IN THE HARNESS Measure the resistance of the (L911) Left Headlamp Return Signal circuit between the Left Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (L911) Left Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B162F-RIGHT LOW BEAM CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the low beam headlamps active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L44) Right Low Beam Driver circuit.

Scheme 269

Scheme 270

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B162F-RIGHT LOW BEAM CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Disconnect the Right Headlamp Lamp harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC: B1630-RIGHT LOW BEAM CONTROL CIRCUIT HIGH? Yes Replace the Right Low Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L44) RIGHT LOW BEAM DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance between ground and the (L44) Right Low Beam Driver circuit. Is the resistance above 10k Ohms? Yes Go To 4 . No Repair the short to ground in the (L44) Right Low Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (L44) RIGHT LOW BEAM DRIVER CIRCUIT FOR A SHORT TO THE (L910) RIGHT HEADLAMP RETURN SIGNAL CIRCUIT Measure the resistance between the (L44) Right Low Beam Driver circuit and the (L910) Right Headlamp Return Signal circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short between the (L44) Right Low Beam Driver circuit and the (L910) Right Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the low beam headlamps active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L44) Right Low Beam Driver circuit.

Scheme 271

Scheme 272

Scheme 273

Scheme 274

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B1630-RIGHT LOW BEAM CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L44) RIGHT LOW BEAM DRIVER CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Headlamps off. Turn the ignition off. Disconnect the Right Headlamp Lamp harness connector. Disconnect the TIPM C3 harness connector. Turn the ignition on. Measure the voltage between ground and the (L44) Right Low Beam Driver circuit. Is there any voltage present? Yes Repair the short to voltage in the (L44) Right Low Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C3 harness connector. Connect a 12-volt test light between the (L44) Right Low Beam Driver circuit and (L910) Right Headlamp Return Signal circuit in the Right Headlamp Lamp harness connector. Turn the ignition on. Turn the Headlamps on. Does the test light illuminate brightly? Yes Replace the Right Low Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L44) RIGHT LOW BEAM DRIVER CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance of the (L44) Right Low Beam Driver circuit between the Right Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L44) Right Low Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (L910) RIGHT HEADLAMP RETURN SIGNAL CIRCUIT FOR AN OPEN IN THE HARNESS Measure the resistance of the (L910) Right Headlamp Return Signal circuit between the Right Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (L910) Right Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the high beam headlamps active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L33) Left High Beam Driver circuit.

Scheme 275

Scheme 276

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the High Beam Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B1633-LEFT HI BEAM CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Disconnect the Left Headlamp Lamp harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC: B1634-LEFT HI BEAM CONTROL CIRCUIT HIGH? Yes Replace the Left High Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L33) LEFT HIGH BEAM DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance between ground and the (L33) Left High Beam Driver circuit. Is the resistance above 10k Ohms? Yes Go To 4 . No Repair the short to ground in the (L33) Left High Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (L33) LEFT HIGH BEAM DRIVER CIRCUIT FOR A SHORT TO THE (L911) LEFT HEADLAMP RETURN SIGNAL CIRCUIT Measure the resistance between the (L33) Left High Beam Driver circuit and the (L911) Left Headlamp Return Signal circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short between the (L33) Left High Beam Driver circuit and the (L911) Left Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the high beam headlamps active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L33) Left High Beam Driver circuit.

Scheme 277

Scheme 278

Scheme 279

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the High Beam Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B1634-LEFT HI BEAM CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L33) LEFT HIGH BEAM DRIVER CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Headlamps off. Turn the ignition off. Disconnect the Left Headlamp Lamp harness connector. Disconnect the TIPM C3 harness connector. Turn the ignition on. Measure the voltage between ground and the (L33) Left High Beam Driver circuit. Is there any voltage present? Yes Repair the short to voltage in the (L33) Left High Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C3 harness connector. Connect a 12-volt test light between the (L33) Left High Beam Driver circuit and (L911) Left Headlamp Return Signal circuit in the Left Headlamp Lamp harness connector. Turn the ignition on. Turn the High Beam Headlamps on. Does the test light illuminate brightly? Yes Replace the Left High Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L33) LEFT HIGH BEAM DRIVER CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance of the (L33) Left High Beam Driver circuit between the Left Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L33) Left High Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (L911) LEFT HEADLAMP RETURN SIGNAL CIRCUIT FOR AN OPEN IN THE HARNESS Measure the resistance of the (L911) Left Headlamp Return Signal circuit between the Left Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (L911) Left Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the high beam headlamps active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L34) Right High Beam Driver circuit.

Scheme 280

Scheme 281

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the High Beam Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B1637-RIGHT HI BEAM CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Disconnect the Right Headlamp Lamp harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC: B1638-RIGHT HI BEAM CONTROL CIRCUIT HIGH? Yes Replace the Right High Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L34) RIGHT HIGH BEAM DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance between ground and the (L34) Right High Beam Driver circuit. Is the resistance above 10k Ohms? Yes Go To 4 . No Repair the short to ground in the (L34) Right High Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (L34) RIGHT HIGH BEAM DRIVER CIRCUIT FOR A SHORT TO THE (L910) RIGHT HEADLAMP RETURN SIGNAL CIRCUIT Measure the resistance between the (L34) Right High Beam Driver circuit and the (L910) Right Headlamp Return Signal circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short between the (L34) Right High Beam Driver circuit and the (L910) Right Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the high beam headlamps active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L34) Right High Beam Driver circuit.

Scheme 282

Scheme 283

Scheme 284

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the High Beam Headlamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B1638-RIGHT HI BEAM CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L34) RIGHT HIGH BEAM DRIVER CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Headlamps off. Turn the ignition off. Disconnect the Right Headlamp Lamp harness connector. Disconnect the TIPM C3 harness connector. Turn the ignition on. Measure the voltage between ground and the (L34) Right High Beam Driver circuit. Is there any voltage present? Yes Repair the short to voltage in the (L34) Right High Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C3 harness connector. Connect a 12-volt test light between the (L34) Right High Beam Driver circuit and (L910) Right Headlamp Return Signal circuit in the Right Headlamp Lamp harness connector. Turn the ignition on. Turn the High Beam Headlamps on. Does the test light illuminate brightly? Yes Replace the Right High Beam Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L34) RIGHT HIGH BEAM DRIVER CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance of the (L34) Right High Beam Driver circuit between the Right Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L34) Right High Beam Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (L910) RIGHT HEADLAMP RETURN SIGNAL CIRCUIT FOR AN OPEN IN THE HARNESS Measure the resistance of the (L910) Right Headlamp Return Signal circuit between the Right Headlamp Lamp harness connector and the TIPM C3 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (L910) Right Headlamp Return Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B163B-FRONT LEFT TURN LAMP CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L161) Left Front Turn Signal Control circuit.

Scheme 285

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Left Turn Signal on. With the scan tool, read DTC's. Does the scan tool display DTC: B163B-FRONT LEFT TURN LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the Left Turn Signal off. Turn the ignition off. Disconnect the Left Front Park/Turn Lamp harness connector. Turn the ignition on. Turn the Left Turn Signal on. With the scan tool, read DTC's. Does the scan tool display DTC: B163C-FRONT LEFT TURN LAMP CONTROL CIRCUIT HIGH? Yes Replace the Left Park and Turn Signal Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L161) LEFT FRONT TURN SIGNAL CONTROL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance between ground and the (L161) Left Front Turn Signal Control circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (L161) Left Front Turn Signal Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B163C-FRONT LEFT TURN LAMP CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L161) Left Front Turn Signal Control circuit.

Scheme 286

Scheme 287

Scheme 288

Scheme 289

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Left Turn Signal on. With the scan tool, read DTC's. Does the scan tool display DTC: B163C-FRONT LEFT TURN LAMP CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L161) LEFT FRONT TURN SIGNAL CONTROL CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Left Turn Signal off. Turn the ignition off. Disconnect the Left Front Park/Turn Lamp harness connector. Disconnect the TIPM C4 harness connector. Turn the ignition on. Measure the voltage between ground and the (L161) Left Front Turn Signal Control circuit. Is there any voltage present? Yes Repair the short to voltage in the (L161) Left Front Turn Signal Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C4 harness connector. Connect a 12-volt test light between the (L161) Left Front Turn Signal Control circuit and the (Z906) Ground circuit at the Left Front Park/Turn Lamp harness connector. Turn the ignition on. Turn the Left Turn Signal on. Does the test light blink on and off? Yes Replace the Park and Turn Signal Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L161) LEFT FRONT TURN SIGNAL CONTROL CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance of the (L161) Left Front Turn Signal Control circuit between the Left Front Park/Turn Lamp harness connector and the TIPM C4 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L161) Left Front Turn Signal Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (Z906) GROUND CIRCUIT FOR AN OPEN IN THE HARNESS Using a 12-volt test light connected to 12-volts, check the (Z906) Ground circuit. Does the test light illuminate brightly? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (Z906) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B163F-FRONT RIGHT TURN LAMP CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L160) Right Front Turn Signal Control circuit.

Scheme 290

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Right Turn Signal on. With the scan tool, read DTC's. Does the scan tool display DTC: B163F-FRONT RIGHT TURN LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Disconnect the Right Front Park/Turn Lamp harness connector. Turn the ignition on. Turn the Right Turn Signal on. With the scan tool, read DTC's. Does the scan tool display DTC: B1640-FRONT RIGHT TURN LAMP CONTROL CIRCUIT HIGH? Yes Replace the Right Park and Turn Signal Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L160) RIGHT FRONT TURN SIGNAL CONTROL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Measure the resistance between ground and the (L160) Right Front Turn Signal Control circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (L160) Right Front Turn Signal Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L160) Right Front Turn Signal Driver circuit.

Scheme 291

Scheme 292

Scheme 293

Scheme 294

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Right Turn Signal on. With the scan tool, read DTC's. Does the scan tool display DTC: B1640-FRONT RIGHT TURN LAMP CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L160) RIGHT FRONT TURN SIGNAL DRIVER CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Right Turn Signal off. Turn the ignition off. Disconnect the Right Front Park/Turn Lamp harness connector. Disconnect the TIPM C4 harness connector. Turn the ignition on. Measure the voltage between ground and the (L160) Right Front Turn Signal Driver circuit. Is there any voltage present? Yes Repair the short to voltage in the (L160) Right Front Turn Signal Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C4 harness connector. Connect a 12-volt test light between the (L160) Right Front Turn Signal Driver circuit and the (Z904) Ground circuit at the Right Front Park/Turn Lamp harness connector. Turn the ignition on. Turn the Right Turn Signal on. Does the test light blink on and off? Yes Replace the Park and Turn Signal Bulb in accordance with the Service Information. Refer to «UNIT, FRONT LAMP, REMOVAL»(ref-476510-S09846148402012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L160) RIGHT FRONT TURN SIGNAL DRIVER CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance of the (L160) Right Front Turn Signal Driver circuit between the Right Front Park/Turn Lamp harness connector and the TIPM C4 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L160) Right Front Turn Signal Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (Z904) GROUND CIRCUIT FOR AN OPEN IN THE HARNESS Using a 12-volt test light connected to 12-volts, check the (Z904) Ground circuit. Does the test light illuminate brightly? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (Z904) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L63) Left Rear Turn Lamp Driver circuit.

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L63) Left Rear Turn Lamp Driver circuit.

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L62) Right Rear Turn Lamp Driver circuit.

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L62) Right Rear Turn Lamp Driver circuit.

B165C-PARK LAMP CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Park Lamps active.

When the Totally Integrated Power Module (TIPM) detects a low voltage condition on one of the park lamp voltage supply circuits.

Scheme 295

Scheme 296

Scheme 297

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all TIPM DTC's. Turn the Park Lamps off and on. With the scan tool, read the DTC's. Does the scan tool display B165C-PARK LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ISOLATE THE (L17) FUSED PARK LAMP RELAY OUTPUT CIRCUIT Remove Fuse M35 to isolate the (L17) Fused Park Lamp Relay Output circuit. Turn the Park Lamps off and on. With the scan tool, read the DTC's. Does the scan tool display DTC B165C-PARK LAMP CONTROL CIRCUIT LOW as stored? Yes Go To 3 . No Go To 5 .
3. CHECK THE LAMPS ON THE (L17) FUSED PARK LAMP RELAY OUTPUT CIRCUIT FOR AN INTERNAL SHORT TO GROUND Install Fuse M35. Turn the Park Lamps off and on. Using the wiring diagrams as a guide, disconnect the harness connector for each lamp on the (L17) Fused Park Lamp Relay Output circuit one at a time while checking for the DTC to become stored. Does the DTC change to stored? Yes Repair or replace the lamp/bulb that caused the DTC to change to stored in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L17) FUSED PARK LAMP RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C5 harness connector. Measure the resistance between ground and the (L17) Fused Park Lamp Relay Output circuit in the TIPM C5 harness connector. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (L17) Fused Park Lamp Relay Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. ISOLATE THE (L678) FUSED PARK LAMP RELAY OUTPUT CIRCUIT Install Fuse M35. Remove Fuse J14 to isolate the (L678) Fused Park Lamp Relay Output circuit. Turn the Park Lamps off and on. With the scan tool, read the DTC's. Does the scan tool display DTC B165C-PARK LAMP CONTROL CIRCUIT LOW as stored? Yes Go To 6 . No Go To 8 .
6. CHECK THE AFTERMARKET, TRAILER TOW, OR ACCESSORIES FOR A SHORT TO GROUND NOTE: Inspect the connections at any aftermarket, trailer tow, or accessories using the (L678) Fused Park Lamp Relay Output circuit for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Repair as necessary. Install Fuse J14. Disconnect any aftermarket, trailer tow, or accessories using the (L678) Fused Park Lamp Relay Output circuit. Turn the Park Lamps off and on. With the scan tool, read the DTC's. Does the scan tool display DTC B165C-PARK LAMP CONTROL CIRCUIT LOW as stored? Yes The concern is with the aftermarket, trailer tow, or accessories using the (L678) Fused Park Lamp Relay Output circuit. Repair as necessary. Refer to the aftermarket accessories or accessories information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 7 .
7. CHECK THE (L678) FUSED PARK LAMP RELAY OUTPUT CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C5 harness connector. Measure the resistance between ground and the (L678) Fused Park Lamp Relay Output circuit in the TIPM C5 harness connector. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (L678) Fused Park Lamp Relay Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
8. CHECK THE LAMPS ON THE (L60) RIGHT PARK LAMP DRIVER CIRCUIT FOR AN INTERNAL SHORT TO GROUND Install Fuse J14. Using the wiring diagrams as a guide, disconnect the harness connector for each lamp or component on the (L60) Right Park Lamp Driver circuit one at a time while checking for the DTC to become stored. Does the DTC change to stored? Yes Repair or replace the lamp/bulb that caused the DTC to change to stored in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 9 .
9. CHECK THE (L60) RIGHT PARK LAMP DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C7 harness connector. Measure the resistance between ground and the (L60) Right Park Lamp Driver circuit in the TIPM C7 harness connector. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (L60) Right Park Lamp Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 298

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the fog lamps active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L89) Left Front Fog Lamp Control circuit.

Scheme 299

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Fog Lamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B16F8-FRONT LEFT FOG LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the Fog Lamps off. Turn the ignition off. Disconnect the Left Front Fog Lamp harness connector. Turn the ignition on. Turn the Fog Lamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B16F9-FRONT LEFT FOG LAMP CONTROL CIRCUIT HIGH? Yes Replace the Left Front Fog Lamp Bulb in accordance with the Service Information. Refer to «LAMP, FOG, REMOVAL»(ref-476510-S18440919922012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L89) LEFT FRONT FOG LAMP CONTROL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance between ground and the (L89) Left Front Fog Lamp Control circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (L89) Left Front Fog Lamp Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B16F9-FRONT LEFT FOG LAMP CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the fog lamps active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L89) Left Front Fog Lamp Driver circuit.

Scheme 300

Scheme 301

Scheme 302

Scheme 303

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all TIPM DTC's. Turn the Front Fog Lamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B16F9-FRONT LEFT FOG LAMP CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L89) LEFT FRONT FOG LAMP CONTROL CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Fog Lamps off. Turn the ignition off. Disconnect the Left Front Fog Lamp harness connector. Disconnect the TIPM C4 harness connector. Turn the ignition on. Measure the voltage between ground and the (L89) Left Front Fog Lamp Control circuit. Is there any voltage present? Yes Repair the short to voltage on the (L89) Left Front Fog Lamp Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C4 harness connector. Connect a 12-volt test light between the (L89) Left Front Fog Lamp Control circuit and the (Z904) Ground circuit at the Left Front Fog Lamp harness connector. Turn the ignition on. Turn the Fog Lamps on. Does the test light illuminate brightly? Yes Replace the Left Front Fog Lamp Bulb in accordance with the Service Information. Refer to «LAMP, FOG, REMOVAL»(ref-476510-S18440919922012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L89) LEFT FRONT FOG LAMP CONTROL CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance of the (L89) Left Front Fog Lamp Control circuit between the Left Front Fog Lamp harness connector and the TIPM C4 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L89) Left Front Fog Lamp Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (Z904) GROUND CIRCUIT FOR AN OPEN IN THE HARNESS Using a 12-volt test light connected to 12-volts, check the (Z904) Ground circuit. Does the test light illuminate brightly? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (Z904) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B16FC-FRONT RIGHT FOG LAMP CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the fog lamps active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L90) Right Front Fog Lamp Control circuit.

Scheme 304

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Turn the Fog Lamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B16FC-FRONT RIGHT FOG LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the Fog Lamps off. Turn the ignition off. Disconnect the Right Front Fog Lamp harness connector. Turn the ignition on. Turn the Fog Lamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B16FD-FRONT RIGHT FOG LAMP CONTROL CIRCUIT HIGH? Yes Replace the Right Front Fog Lamp Bulb in accordance with the Service Information. Refer to «LAMP, FOG, REMOVAL»(ref-476510-S18440919922012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (L90) RIGHT FRONT FOG LAMP CONTROL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance between ground and the (L90) Right Front Fog Lamp Control circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (L90) Right Front Fog Lamp Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B16FD-FRONT RIGHT FOG LAMP CONTROL CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the fog lamps active.

When the Totally Integrated Power Module (TIPM) detects a high condition on the (L90) Right Front Fog Lamp Control circuit.

Scheme 305

Scheme 306

Scheme 307

Scheme 308

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all TIPM DTC's. Turn the Front Fog Lamps on. With the scan tool, read DTC's. Does the scan tool display DTC: B16FD-FRONT RIGHT FOG LAMP CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L90) RIGHT FRONT FOG LAMP CONTROL CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the Fog Lamps off. Turn the ignition off. Disconnect the Right Front Fog Lamp harness connectors. Disconnect the TIPM C4 harness connector. Turn the ignition on. Measure the voltage between ground and the (L90) Right Front Fog Lamp Control circuit. Is there any voltage present? Yes Repair the short to voltage on the (L90) Right Front Fog Lamp Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C4 harness connector. Connect a 12-volt test light between the (L90) Right Front Fog Lamp Control circuit and the (Z906) Ground circuit at the Right Front Fog Lamp harness connector. Turn the ignition on. Turn the Fog Lamps on. Does the test light illuminate brightly? Yes Replace the Right Front Fog Lamp Bulb in accordance with the Service Information. Refer to «LAMP, FOG, REMOVAL»(ref-476510-S18440919922012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (L90) RIGHT FRONT FOG LAMP CONTROL CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance of the (L90) Right Front Fog Lamp Control circuit between the Right Front Fog Lamp harness connector and the TIPM C4 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (L90) Right Front Fog Lamp Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (Z906) GROUND CIRCUIT FOR AN OPEN IN THE HARNESS Using a 12-volt test light connected to 12-volts, check the (Z906) Ground circuit. Does the test light illuminate brightly? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (Z906) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B17AE-REAR LEFT TRAILER TURN LAMP CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L655) Left Rear Turn Signal Control circuit.

Scheme 309

1. TEST FOR INTERMITTENT CONDITION NOTE: Make sure any aftermarket or trailer tow accessories are disconnected from the trailer tow connector. Turn the ignition on. With the scan tool, clear all DTC's. Turn on the Left Turn Signal. With the scan tool, read DTC's. Does the scan tool display DTC: B17AE-REAR LEFT TRAILER TURN LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L655) LEFT REAR TURN SIGNAL CONTROL CIRCUIT FOR A SHORT TO GROUND IN THE HARNESS Turn the ignition off. Disconnect the TIPM C7 harness connector. Disconnect the Trailer Tow 7-Way Wiring harness connector. Measure the resistance between ground and the (L655) Left Rear Turn Signal Control circuit. Is the resistance above 10k Ohms? Yes Go To 3 . No Repair the short to ground in the (L655) Left Rear Turn Signal Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE TRAILER TOW CONNECTOR FOR AN INTERNAL SHORT TO GROUND NOTE: This measurement is taken at the Trailer Tow Connector used by the customer. Use the diagram on the Trailer Tow Connector cover to determine the correct terminal. Reconnect the Trailer Tow 7-Way Wiring harness connector. Measure the resistance between ground and the (L655) Left Rear Turn Signal Control circuit at the appropriate terminal in the Trailer Tow Connector. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Trailer Tow Connector in accordance with the Service Information. Refer to «CONNECTOR, TRAILER TOW, REMOVAL»(ref-476510-S21137676002012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B17B2-REAR RIGHT TRAILER TURN LAMP CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the turn signal active.

When the Totally Integrated Power Module (TIPM) detects a low condition on the (L656) Right Rear Turn Signal Control circuit.

Scheme 310

1. TEST FOR INTERMITTENT CONDITION NOTE: Make sure any aftermarket or trailer tow accessories are disconnected from the Trailer Tow Connector. Turn the ignition on. With the scan tool, clear all DTC's. Turn on the Right Turn Signal. With the scan tool, read DTC's. Does the scan tool display DTC: B17B2-REAR RIGHT TRAILER TURN LAMP CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (L656) RIGHT REAR TURN SIGNAL CONTROL CIRCUIT FOR A SHORT TO GROUND IN THE HARNESS Turn the ignition off. Disconnect the TIPM C7 harness connector. Disconnect the Trailer Tow 7-Way Wiring harness connector. Measure the resistance between ground and the (L656) Right Rear Turn Signal Control circuit. Is the resistance above 10k Ohms? Yes Go To 3 . No Repair the short to ground in the (L656) Right Rear Turn Signal Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE TRAILER TOW CONNECTOR FOR AN INTERNAL SHORT TO GROUND NOTE: This measurement is taken at the Trailer Tow Connector used by the customer. Use the diagram on the Trailer Tow Connector cover to determine the correct terminal. Reconnect the Trailer Tow 7-Way Wiring harness connector. Measure the resistance between ground and the (L656) Right Rear Turn Signal Control circuit at the appropriate terminal in the Trailer Tow Connector. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Trailer Tow Connector in accordance with the Service Information. Refer to «CONNECTOR, TRAILER TOW, REMOVAL»(ref-476510-S21137676002012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 311

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously

The Totally Integrated Power Module (TIPM) detects that the Driver Door Unlock Driver circuit voltage is lower than the threshold value for more than five seconds.

Scheme 312

1. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTC's. Operate the Driver Door Lock Switch in all positions several times. Cycle the ignition from on to off. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1801-DRIVER DOOR LOCK/UNLOCK SWITCH CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE DRIVER DOOR LATCH FOR AN INTERNAL SHORT With the scan tool, erase DTC's. Turn the ignition off. Disconnect the Driver Door Latch harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1801-DRIVER DOOR LOCK/UNLOCK SWITCH CIRCUIT LOW as active? Yes Go To 3 . No Replace the Driver Door Latch in accordance with the Service Information. Refer to «LATCH, DOOR, REMOVAL»(ref-476497-S34044818592012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (P1) DRIVER DOOR UNLOCK DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C6 harness connector. Measure the resistance between ground and the (P1) Driver Door Unlock Driver circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (P1) Driver Door Unlock Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Continuously

The Totally Integrated Power Module (TIPM) detects that the Passenger Door Unlock Driver circuit voltage is lower than the threshold value for more than five seconds.

Scheme 313

1. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTC's. Operate the Passenger Door Lock Switch in all positions several times. Cycle the ignition from on to off. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1806-PASSENGER DOOR LOCK/UNLOCK SWITCH CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE PASSENGER DOOR LATCH FOR A SHORT With the scan tool, erase DTC's. Turn the ignition off. Disconnect the Passenger Door Latch harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1806-PASSENGER DOOR LOCK/UNLOCK SWITCH CIRCUIT LOW as active? Yes Go To 3 . No Replace the Passenger Door Latch in accordance with the Service Information. Refer to «LATCH, DOOR, REMOVAL»(ref-476497-S34044818592012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (P4) PASSENGER DOOR UNLOCK DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C5 harness connector. Measure the resistance between ground and the (P4) Passenger Door Unlock Driver circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (P4) Passenger Door Unlock Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 314

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously

When the Totally Integrated Power Module (TIPM) detects and open or short to voltage on the Hood Ajar Switch Sense circuit for over 10 seconds, this code will set.

Scheme 315

Scheme 316

Scheme 317

1. TEST FOR INTERMITTENT CONDITION NOTE: Open the hood and make sure the Hood Ajar Switch is connected before proceeding. With the scan tool, record and erase DTC's. Close the hood. Cycle the ignition from on to off. Turn the ignition on. Open then close the hood. With the scan tool, read DTC's. Does the scan tool display B1820-HOOD AJAR INPUT CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE HOOD AJAR SWITCH Turn the ignition off. Open the hood. Disconnect the Hood Ajar Switch harness connector. For vehicles with a plunger type Hood Ajar Switch, depress the switch plunger. For vehicles with the Hood Ajar Switch integral to the Hood Latch, manually rotate the Hood Latch into the closed position. Measure the resistance between the (G70) Hood Ajar Switch Sense circuit and the (G931) Sensor Return circuit at the component. Is the resistance approximately 1k Ohms? Yes Go To 3 . No For vehicles with a plunger-type Hood Ajar Switch, replace the Hood Ajar Switch in accordance with the Service Information. Refer to «SWITCH, HOOD AJAR, REMOVAL»(ref-476541-S40627699122012060400000) . For vehicles with the Hood Ajar Switch integral to the Hood Latch, replace the Hood Latch in accordance with the Service Information. Refer to «LATCH, HOOD, REMOVAL»(ref-476497-S13489729282012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (G70) HOOD AJAR SWITCH SENSE CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Disconnect the TIPM C4 harness connector. Turn the ignition on. Measure the voltage between ground and the (G70) Hood Ajar Switch Sense circuit. Is there any voltage present? Yes Repair the short to voltage in the (G70) Hood Ajar Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (G70) HOOD AJAR SWITCH SENSE CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Measure the resistance of the (G70) Hood Ajar Switch Sense circuit between the TIPM C4 harness connector and the Hood Ajar Switch harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (G70) Hood Ajar Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (G931) SENSOR RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (G931) Sensor Return circuit between the TIPM C4 harness connector and the Hood Ajar Switch harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (G931) Sensor Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Continuously

The Totally Integrated Power Module (TIPM) detects that the Driver Door Unlock Driver circuit voltage does not change for more than 10 seconds.

Scheme 318

Scheme 319

1. TEST FOR INTERMITTENT CONDITION NOTE: Make sure the Driver Door Lock Switch is not stuck in one position. Clean or repair as necessary. With the scan tool, record and erase DTC's. Operate the Driver Door Lock Switch in all positions several times. Cycle the ignition from on to off. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1934-DRIVER DOOR LOCK/UNLOCK SWITCH CIRCUIT STUCK? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE DRIVER DOOR LATCH FOR AN INTERNAL SHORT With the scan tool, erase DTC's. Turn the ignition off. Disconnect the Driver Door Latch harness connector. Turn the ignition on. Operate the Driver Door Lock Switch in all positions several times. With the scan tool, read DTC's. Does the scan tool display B1934-DRIVER DOOR LOCK/UNLOCK SWITCH CIRCUIT STUCK? Yes Go To 3 . No Replace the Driver Door Latch in accordance with the Service Information. Refer to «LATCH, DOOR, REMOVAL»(ref-476497-S34044818592012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (P1) DRIVER DOOR UNLOCK DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the TIPM C6 harness connector. Turn the ignition on. Measure the voltage between ground and the (P1) Driver Door Unlock Driver circuit in the Driver Door Latch harness connector. Is there any voltage present? Yes Repair the short to voltage in the (P1) Driver Door Unlock Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (P1) DRIVER DOOR UNLOCK DRIVER CIRCUIT FOR AN OPEN Turn the ignition off. Measure the resistance of the (P1) Driver Door Unlock Driver circuit between the Driver Door Latch harness connector and the TIPM C6 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (P1) Driver Door Unlock Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Continuously

The Totally Integrated Power Module (TIPM) detects that the Passenger Door Unlock Driver circuit voltage does not change for more than 10 seconds.

Scheme 320

Scheme 321

1. TEST FOR INTERMITTENT CONDITION NOTE: Make sure the Passenger Door Lock Switch is not stuck in one position. Clean or repair as necessary. With the scan tool, record and erase DTC's. Operate the Passenger Door Lock Switch in all positions several times. Cycle the ignition from on to off. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1935-PASSENGER DOOR LOCK/UNLOCK SWITCH CIRCUIT STUCK? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE PASSENGER DOOR LATCH FOR AN INTERNAL SHORT With the scan tool, erase DTC's. Turn the ignition off. Disconnect the Passenger Door Latch harness connector. Turn the ignition on. Operate the Passenger Door Lock Switch in all positions several times. With the scan tool, read DTC's. Does the scan tool display B1935-PASSENGER DOOR LOCK/UNLOCK SWITCH CIRCUIT STUCK? Yes Go To 3 . No Replace the Passenger Door Latch in accordance with the Service Information. Refer to «LATCH, DOOR, REMOVAL»(ref-476497-S34044818592012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (P4) PASSENGER DOOR UNLOCK DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the TIPM C5 harness connector. Turn the ignition on. Measure the voltage between ground and the (P4) Passenger Door Unlock Driver circuit in the Passenger Door Latch harness connector. Is there any voltage present? Yes Repair the short to voltage in the (P4) Passenger Door Unlock Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (P4) PASSENGER DOOR UNLOCK DRIVER CIRCUIT FOR AN OPEN Turn the ignition off. Measure the resistance of the (P4) Passenger Door Unlock Driver circuit between the Passenger Door Latch harness connector and the TIPM C5 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (P4) Passenger Door Unlock Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 322

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Vehicle is not in reverse.

Cruise control is not active.

If the Totally Integrated Power Module (TIPM) detects a low voltage condition on the (A128) Adjustable Pedals Motor Driver circuit.

Scheme 323

Scheme 324

1. TEST FOR INTERMITTENT CONDITION NOTE: Look closely at the temperatures at which this Diagnostic Trouble Code (DTC) set. Low battery Voltage can also cause excessive current draw in very hot and very cold ambient temperatures. Make sure the battery can pass a load test before continuing. Turn the ignition on. Using a scan tool, record and erase Diagnostic Trouble Codes (DTC's). Cycle the ignition from on to off. Turn the ignition on. Operate the Adjustable Pedals switch in both positions. With the scan tool, read the TIPM DTC's. Is the DTC Active at this time? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. While monitoring the scan tool data relative to this circuit, wiggle test the wiring and connectors. Look for the data to change or for the code to reset during the wiggle test. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK FOR AN ACTIVE DTC WITH THE ADJUSTABLE PEDALS MOTOR DISCONNECTED Turn the ignition off. Disconnect the Adjustable Pedals Motor harness connector. Turn the ignition on. Operate the Adjustable Pedals switch in both positions. With the scan tool, read the TIPM DTC's. Is the DTC Active at this time? Yes Go To 3 . No Replace the Adjustable Pedals Motor in accordance with the Service Information. Refer to «MOTOR, ADJUSTABLE PEDALS, REMOVAL»(ref-476493-S03895293472012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK FOR A SHORTED ADJUSTABLE PEDALS SWITCH Turn the ignition off. Disconnect the Adjustable Pedals Switch harness connector. NOTE: Check connectors. Clean and repair as necessary. Remove the Adjustable Pedals Switch in accordance with the Service Information. Refer to «SWITCH, ADJUSTABLE PEDALS, REMOVAL»(ref-476493-S32661495572012060400000) . NOTE: Adjustable Pedals Switch harness connector shown in illustration. Mirror image for Adjustable Pedals Switch component connector. Measure the resistance between the (A128) Adjustable Pedals Motor Driver circuit and the (P205) Adjustable Pedals Motor Forward circuit at the Adjustable Pedals Switch component connector. Measure the resistance between the (A128) Adjustable Pedals Motor Driver circuit and the (Z910) Ground circuit at the Adjustable Pedals Switch component connector. Measure the resistance between the (A128) Adjustable Pedals Motor Driver circuit and the (P206) Adjustable Pedals Motor Rearward circuit at the Adjustable Pedals Switch component connector. Is the resistance below 10k Ohms for any measurement? Yes Replace the Adjustable Pedals Switch in accordance with the Service Information. Refer to «SWITCH, ADJUSTABLE PEDALS, REMOVAL»(ref-476493-S32661495572012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK (A128) ADJUSTABLE PEDALS MOTOR DRIVER CIRCUIT FOR A SHORT TO GROUND Disconnect the TIPM C7 connector. NOTE: Check connectors. Clean and repair as necessary. Measure the resistance of the (A128) Adjustable Pedals Motor Driver circuit between ground and the Adjustable Pedal Switch harness connector. Is the resistance below 10k Ohms? Yes Repair the short to ground in the (A128) Adjustable Pedals Motor Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 5 .
5. CHECK (A128) ADJUSTABLE PEDALS MOTOR DRIVER CIRCUIT FOR A SHORT TO (P205) ADJUSTABLE PEDALS MOTOR FORWARD CIRCUIT, (Z910) GROUND CIRCUIT, OR TO (P206) ADJUSTABLE PEDALS MOTOR REARWARD CIRCUIT Measure the resistance between the (A128) Adjustable Pedals Motor Driver circuit and the (P205) Adjustable Pedals Motor Forward circuit at the Adjustable Pedals Switch harness connector. Measure the resistance between the (A128) Adjustable Pedals Motor Driver circuit and the (Z910) Ground circuit at the Adjustable Pedals Switch harness connector. Measure the resistance between the (A128) Adjustable Pedals Motor Driver circuit and the (P206) Adjustable Pedals Motor Rearward circuit at the Adjustable Pedals Switch harness connector. Is the resistance below 10k Ohms for any measurement? Yes Repair all circuits with a resistance below 10k Ohms for a short to the (A128) Adjustable Pedals Motor Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 325

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition switch on.

The TIPM has detected that the hardwired ignition switch input voltage from the Wireless Ignition Node (WIN) indicates that the ignition switch is in the off position, but the CAN bus message indicates that the ignition switch is the run position.

Scheme 326

Scheme 327

1. CHECK FOR ACTIVE DTC NOTE: Check to make sure the battery and charging system are operating properly. Battery and/or charging system problems may cause these DTC's to set. NOTE: Diagnose any related Powertrain DTC(s) before continuing. Turn the ignition on. With the scan tool, read TIPM DTC(s). Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (F20) IGNITION RUN/START CONTROL OUTPUT CIRCUIT AT THE TIPM Turn the ignition off. Disconnect the TIPM C7 harness connector. Turn the ignition on. Measure the voltage between ground and the (F20) Ignition Run/Start Control Output circuit. Is the voltage above 10.0 volts? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (F20) IGNITION RUN/START CONTROL OUTPUT CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the WIN harness connector. Measure the resistance between ground and the (F20) Ignition Run/Start Control Output circuit. Is the resistance above 10k Ohms? Yes Replace the WIN in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE, REMOVAL»(ref-476533-S21985724952012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (F20) Ignition Run/Start Control Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition switch on.

The TIPM has detected that the hardwired ignition switch input voltage from the Wireless Ignition Node (WIN) indicates that the ignition switch is in the run position, but the CAN bus message indicates that the ignition switch is the off position.

Scheme 328

Scheme 329

1. CHECK FOR ACTIVE DTC NOTE: Check to make sure the battery and charging system are operating properly. Battery and/or charging system problems may cause these DTC's to set. NOTE: Diagnose any related Powertrain DTC(s) before continuing. Turn the ignition on. Using the scan tool, read TIPM DTC(s). Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (F20) IGNITION RUN/START CONTROL OUTPUT CIRCUIT FOR A SHORT TO BATTERY VOLTAGE Turn the ignition off. Disconnect the TIPM C7 harness connector. Disconnect the WIN harness connector. Measure the voltage between ground and the (F20) Ignition Run/Start Control Output circuit in the WIN harness connector. Is there any voltage present? Yes Repair the short to voltage in the (F20) Ignition Run/Start Control Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE WIN FOR AN INTERNAL SHORT TO VOLTAGE Reconnect the WIN harness connector. Measure the voltage between ground and the (F20) Ignition Run/Start Control Output circuit in the TIPM C7 harness connector. Is there any voltage present? Yes Replace the WIN in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE, REMOVAL»(ref-476533-S21985724952012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B210D-BATTERY VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage less than 9 volts for approximately five to six seconds.

B210E-BATTERY VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 16 volts for approximately five to six seconds.

B212F-IGNITION RUN/ACC CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10 volts.

With the Run/Accessory Relay commanded on.

The Totally Integrated Power Module (TIPM) detects a short to ground in the internal Run/Accessory Relay Control circuit.

With the Ignition on.

Odometer reading is less than 80.5 km (50 mi).

Ignition Off Draw (IOD) Fuse not installed or blown in the Totally Integrated Power Module (TIPM).

With the ignition on.

The Totally Integrated Power Module (TIPM) sets this code when a short to ground condition exists in the (F1) Ignition Off/Run/Start Control Output circuit.

Scheme 330

1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC. Cycle the ignition switch from off to on, leaving the ignition off for a minimum of 30 seconds. With the scan tool, read the active DTC. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. POWERTRAIN CONTROL MODULE (PCM) Turn the ignition off. Disconnect the PCM C1 or C2 (6.7L) harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the PCM in accordance with the Service Information. Refer to «3.7L, 4.7L & 5.7L - MODULE, POWERTRAIN CONTROL, REMOVAL»(ref-476533-S29192226892012060400000) or «MODULE, POWERTRAIN CONTROL, 6.7L DIESEL [ETJ], REMOVAL»(ref-476533-S09065799022012060400000) . Perform the appropriate POWERTRAIN VERIFICATION TEST. Refer to «1500 & 2500 - 3.7L, 4.7L & 5.7L - POWERTRAIN VERIFICATION TEST»(ref-476600-S16182020042012060400000) or «2500 & 3500 - POWERTRAIN VERIFICATION TEST - 6.7L»(ref-476629-S31319329382012060400000) or «3500 CAB & CHASSIS - POWERTRAIN VERIFICATION TEST»(ref-476607-S38255705622012060400000) or «3500 CAB & CHASSIS, 4500 & 5500 - POWERTRAIN VERIFICATION TEST - 6.7L»(ref-476635-S37546799742012060400000) .
3. (F1) IGNITION OFF/RUN/START CONTROL OUTPUT CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the TIPM C1 harness connector. Measure the resistance between ground and the (F1) Ignition Off/Run/Start Control Output circuit. Is the resistance below 10K Ohms? Yes Repair the short to ground in the (F1) Ignition Off/Run/Start Control Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B219F-IGNITION OFF DRAW (IOD) FUSE BLOWN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Ignition on.

Odometer reading is greater than 80.5 km (50 mi).

Ignition Off Draw (IOD) Fuse not installed or open in the Totally Integrated Power Module (TIPM).

With the ignition on.

The current VIN message from the PCM is different than the VIN stored in the TIPM.

Continuously.

The Totally Integrated Power Module (TIPM) detects an internal fault.

B222C-VEHICLE CONFIGURATION NOT PROGRAMMED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Totally Integrated Power Module (TIPM) is not configured correctly to the vehicle.

With the ignition on.

Front Wiper operating in Low Speed or Intermittent mode.

The Totally Integrated Power Module (TIPM) detects a short to ground on the Wiper Park Switch Sense circuit.

Scheme 331

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Cycle the Wiper Switch on and off three times. With the scan tool, read DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. FRONT WIPER MOTOR Turn the ignition off. Disconnect the Front Wiper Motor harness connector. Turn the ignition on. Wait 30 seconds. With the scan tool, read the Front Wiper Park Switch Sense. Does the Front Wiper Park Switch Sense display: Not Parked? Yes Replace the Wiper Motor in accordance with the Service Information. Refer to «MOTOR, WIPER, REMOVAL»(ref-476550-S17614517462012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK (W7) WIPER PARK SWITCH SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C7 harness connector. Measure the resistance between ground and the (W7) Front Wiper Park Sense Circuit. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (W7) Wiper Park Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Front Wiper operating in Low Speed or Intermittent mode.

The Totally Integrated Power Module (TIPM) does not detect a change from High to Low voltage on the Wiper Park Switch Sense Circuit.

Scheme 332

Scheme 333

Scheme 334

1. INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. Cycle the Wiper Switch on and off three times. With the scan tool, read DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (W7) WIPER PARK SWITCH SENSE CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Front Wiper Motor harness connector. Disconnect the TIPM C7 harness connector. Turn the ignition on. Measure the voltage between ground and the (W7) Wiper Park Switch Sense circuit. Is there any voltage present? Yes Repair the short to voltage in the (W7) Wiper Park Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE FRONT WIPER MOTOR Turn the ignition off. Reconnect the TIPM C7 harness connector. Turn the ignition on. Connect a jumper wire between the (W7) Wiper Park Switch Sense circuit and ground. With the scan tool, read the Front Wiper Park Switch Sense. Does the Front Wiper Park Switch Sense display: Parked? Yes Replace the Wiper Motor in accordance with the Service Information. Refer to «MOTOR, WIPER, REMOVAL»(ref-476550-S17614517462012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK (W7) WIPER PARK SWITCH SENSE CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the TIPM C7 harness connector. Measure the resistance of the (W7) Wiper Park Switch Sense circuit between the Front Wiper Motor harness connector and the TIPM C7 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (W7) Wiper Park Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 335

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

When the Totally Integrated Power Module (TIPM) detects the Brake Fluid Level Circuit voltage is greater than expected for more than five seconds.

Scheme 336

Scheme 337

Scheme 338

Scheme 339

1. CHECK FOR ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read the TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (B20) BRAKE FLUID LEVEL SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE IN THE HARNESS Turn the ignition off. Disconnect the Brake Fluid Level Sensor harness connector. Disconnect the TIPM C7 harness connector. Turn the ignition on. Measure the voltage between ground and the (B20) Brake Fluid Level Signal circuit. Is there any voltage present? Yes Repair the short to voltage in the (B20) Brake Fluid Level Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (B20) BRAKE FLUID LEVEL SIGNAL CIRCUIT FOR AN OPEN IN THE HARNESS Turn the ignition off. Measure the resistance of the (B20) Brake Fluid Level Signal circuit between the Brake Fluid Level Sensor harness connector and the TIPM C7 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 4 . No Repair the open in the (B20) Brake Fluid Level Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (Z907) GROUND CIRCUIT FOR AN OPEN IN THE HARNESS Using a 12-volt test light connected to 12-volts, check the (Z907) Ground circuit. Does the test light illuminate brightly? Yes Go To 5 . No Repair the open in the (Z907) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE TIPM FOR CORRECT OPERATION Connect a jumper wire between the (B20) Brake Fluid Level Signal circuit and the (Z907) Ground circuit in the Brake Fluid Level Switch harness connector. Turn the ignition on. With the scan tool, read the Brake Fluid Level Voltage. Is the voltage below 1.0 volt? Yes Replace the Brake Fluid Level Switch. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 340

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on.

Battery voltage between 9.0 and 16.0 volts.

The Totally Integrated Power Module (TIPM) detects a short to ground on the Mode Sensor A circuit for more than five seconds.

Scheme 341

Scheme 342

1. DTC IS ACTIVE Start the engine and allow it to idle. Move the Transfer Case Lever to each position several times. With the scan tool, read the DTC's. Is the status Active for this DTC? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Disconnect the Transfer Case Selector Switch harness connector. Turn the ignition on. With the scan tool, read the TIPM DTC's. Does the scan tool display DTC C1405-TRANSFER CASE RANGE POSITION SENSOR CIRCUIT HIGH? Yes Replace the Transfer Case Selector Switch in accordance with the Service Information. Refer to «SENSOR, POSITION, REMOVAL»(ref-476567-S26069370372012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (D201) MODE SENSOR A CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C1 harness connector. Measure the resistance between ground and the (D201) Mode Sensor A circuit. Is the resistance above 10k Ohms? Yes For Power Wagon vehicles, Go To 4 . For all others, replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short to ground in the (D201) Mode Sensor A circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (D201) MODE SENSOR A CIRCUIT FOR A SHORT TO THE (K91) SENSOR GROUND CIRCUIT Measure the resistance between the (D201) Mode Sensor A circuit and the (K91) Sensor Ground circuit at the Transfer Case Selector Switch harness connector. Is the resistance above 10k Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the short between the (D201) Mode Sensor A circuit and the (K91) Sensor Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage between 9.0 and 16.0 volts.

The Totally Integrated Power Module (TIPM) detects an open or a short to voltage on the Mode Sensor A circuit for more than five seconds.

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

1. DTC IS ACTIVE Start the engine and allow it to idle. Move the Transfer Case Lever to each position several times. With the scan tool, read DTC's. Is the status Active for this DTC? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (D201) MODE SENSOR A CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Transfer Case Selector Switch harness connector. Disconnect the TIPM C1 harness connector. Turn the ignition on. Measure the voltage between ground and the (D201) Mode Sensor A circuit. Is there any voltage present? Yes Repair the short to voltage in the (D201) Mode Sensor A circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Reconnect the TIPM C1 harness connector. Connect a jumper wire between the (Z908) Ground or (K91) Sensor Ground circuit and the (D201) Mode Sensor A circuit at the Transfer Case Selector Switch harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC C1404-TRANSFER CASE RANGE POSITION SENSOR CIRCUIT LOW? Yes Replace the Transfer Case Selector Switch in accordance with the Service Information. Refer to «SENSOR, POSITION, REMOVAL»(ref-476567-S26069370372012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (D201) MODE SENSOR A CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the TIPM C1 harness connector. Measure the resistance of the (D201) Mode Sensor A circuit between the Transfer Case Selector Switch harness connector and the TIPM C1 harness connector. Is the resistance below 5.0 Ohms? Yes For Power Wagon vehicles, Go To 5 . For all others, Go To 6 . No Repair the open in the (D201) Mode Sensor A circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (K91) SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the (K91) Sensor Ground circuit between the Transfer Case Selector Switch harness connector and the TIPM C1 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (K91) Sensor Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
6. CHECK THE (Z908) GROUND CIRCUIT FOR AN OPEN Using a 12-volt test light connected to 12-volts, check the (Z908) Ground circuit. Does the test light illuminate brightly? Yes Replace the Totally Integrated Power Module (TIPM) in accordance with the Service information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (Z908) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 348

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10.4 volts.

The Totally Integrated Power Module (TIPM) detects the Ambient Air Temperature Sensor input voltage is below the minimum acceptable value.

Scheme 349

Scheme 350

1. VERIFY THE DTC IS ACTIVE NOTE: Diagnose and repair any system voltage DTC's before continuing with this test. Start the engine and allow it to reach normal operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, select View DTC's. Is the DTC Active at this time? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE AMBIENT AIR TEMPERATURE SENSOR Turn the ignition off. Disconnect the Ambient Air Temperature Sensor harness connector. Turn the ignition on. With the scan tool, read the Ambient Air Temperature Sensor signal voltage. Is the voltage above 4.5 volts with the Ambient Air Temperature Sensor harness disconnected? Yes Verify there is good pin to terminal contact in the AAT Sensor and TIPM harness connectors. Replace the Ambient Temperature Sensor if no problems were found with the connectors in accordance with the Service Information. Refer to «SENSOR, AMBIENT TEMPERATURE, REMOVAL»(ref-476532-S29075082192012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (G31) AAT SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance between ground and the (G31) AAT Sensor Signal circuit in the Ambient Air Temperature Sensor harness connector. Is the resistance above 10k Ohms? Yes Go To 4 . No Repair the short to ground in the (G31) AAT Sensor Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (G31) AAT SENSOR SIGNAL CIRCUIT FOR A SHORT TO THE (G931) SENSOR RETURN CIRCUIT Measure the resistance between the (G31) AAT Sensor Signal circuit and the (G931) Sensor Return circuit in the Ambient Air Temperature Sensor harness connector. Is the resistance above 10k Ohms? Yes Go To 5 . No Repair the short between the (G31) AAT Sensor Signal circuit and the (G931) Sensor Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. TOTALLY INTEGRATED POWER MODULE (TIPM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ambient Air Temperature Sensor and the Totally Integrated Power Module (TIPM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the AAT Sensor and TIPM connectors. Monitor the scan tool data relative to this circuit and wiggle test the wiring and connectors. Look for the data to change or for the DTC to reset during the wiggle test. Perform any Technical Service Bulletins (TSB)s that may apply. Were any problems found? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage greater than 10.4 volts.

The Totally Integrated Power Module (TIPM) detects that the Ambient Air Temperature Sensor input voltage is above the maximum acceptable value.

Scheme 351

Scheme 352

Scheme 353

Scheme 354

1. VERIFY THE DTC IS ACTIVE NOTE: Diagnose and repair any system voltage DTC's before continuing with this test. Start the engine and allow it to reach normal operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, select View DTC's. Is the DTC Active at this time? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (G31) AAT SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Ambient Air Temperature Sensor harness connector. Disconnect the TIPM C4 harness connector. Turn the ignition on. Measure the voltage of the (G31) AAT Sensor Signal circuit in the Ambient Air Temperature Sensor harness connector. Is there any voltage present? Yes Repair the short to voltage in the (G31) AAT Sensor Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE AMBIENT AIR TEMPERATURE SENSOR Turn the ignition off. Reconnect the TIPM C4 harness connector. Connect a jumper wire between the (G31) AAT Sensor Signal circuit and the (G931) Sensor Return in the Ambient Air Temperature Sensor harness connector. Turn the ignition on. With the scan tool, read the Ambient Air Temperature Sensor signal voltage. Is the voltage below 1.0 volt with the jumper wire in place? Yes Verify there is good pin to terminal contact in the AAT Sensor and TIPM harness connectors. Replace the Ambient Temperature Sensor if no problems were found with the connectors in accordance with the Service Information. Refer to «SENSOR, AMBIENT TEMPERATURE, REMOVAL»(ref-476532-S29075082192012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (G31) AAT SENSOR SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the TIPM C4 harness connector. Measure the resistance of the (G31) AAT Sensor Signal circuit between the Ambient Air Temperature Sensor harness connector and the TIPM C4 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (G31) AAT Sensor Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (G931) SENSOR RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (G931) Sensor Return circuit between the Ambient Air Temperature Sensor harness connector and the TIPM C4 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 6 . No Repair the open in the (G931) Sensor Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
6. TOTALLY INTEGRATED POWER MODULE (TIPM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ambient Air Temperature Sensor and the Totally Integrated Power Module (TIPM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the AAT Sensor and Totally Integrated Power Module connectors. Monitor the scan tool data relative to this circuit and wiggle test the wiring and connectors. Look for the data to change or for the DTC to reset during the wiggle test. Perform any Technical Service Bulletins (TSB)s that may apply. Were any problems found? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 355

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10.4 volts.

The Totally Integrated Power Module (TIPM) detects that the Fuel Level Sensor input voltage is below the minimum acceptable value.

Scheme 356

Scheme 357

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. With the scan tool, read DTC's. Does the scan tool display DTC: P0462-FUEL LEVEL SENSOR 1 CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. ATTEMPT TO SET THE OPPOSITE DTC Turn the ignition off. Disconnect the Fuel Pump Module harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC: P0463-FUEL LEVEL SENSOR 1 CIRCUIT HIGH? Yes Replace the Fuel Pump Module in accordance with the Service Information. Refer to «DIESEL - MODULE, FUEL PUMP, REMOVAL»(ref-476558-S04909988492012060400000) «GAS - MODULE, FUEL PUMP, REMOVAL»(ref-476558-S40177789832012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (N4) FUEL LEVEL SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Fuel Pump Module harness connector. Disconnect the TIPM C7 harness connector. Measure the resistance between ground and the (N4) Fuel Level Sensor Signal circuit at the Fuel Pump Module harness connector. Is the resistance above 10k Ohms? Yes Go To 4 . No Repair the short to ground in the (N4) Fuel Level Sensor Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (N4) FUEL LEVEL SENSOR SIGNAL CIRCUIT FOR A SHORT TO THE (G109) FUEL LEVEL SENSE RETURN CIRCUIT Measure the resistance between the (G109) Fuel Level Sense Return circuit and the (N4) Fuel Level Sensor Signal circuit at the Fuel Pump Module harness connector. Is the resistance above 10k Ohms? Yes Go To 5 . No Repair the short between the (G109) Fuel Level Sense Return circuit and the (N4) Fuel Level Sensor Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. TOTALLY INTEGRATED POWER MODULE (TIPM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Fuel Pump Module and the TIPM. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Fuel Pump Module and the TIPM C7 harness connectors. Perform any Technical Service Bulletins (TSB)s that may apply. Were any problems found? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage greater than 10.4 volts.

The Totally Integrated Power Module (TIPM) detects that the Fuel Level Sensor input voltage is above the maximum acceptable value.

Scheme 358

Scheme 359

Scheme 360

Scheme 361

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. With the scan tool, read DTC's. Does the scan tool display DTC: P0463-FUEL LEVEL SENSOR 1 CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (N4) FUEL LEVEL SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Fuel Pump Module harness connector. Disconnect the TIPM C7 harness connector. Turn the ignition on. Measure the voltage between ground and the (N4) Fuel Level Sensor Signal circuit at the Fuel Pump Module harness connector. Is there any voltage present? Yes Repair the short to voltage in the (N4) Fuel Level Sensor Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE FUEL LEVEL SENSOR FOR CORRECT OPERATION Turn the ignition off. Connect the TIPM C7 harness connector. Connect a jumper wire between the (N4) Fuel Level Sensor Signal circuit and the (G109) Fuel Level Sense Return circuit at the Fuel Pump Module harness connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC: P0463-FUEL LEVEL SENSOR 1 CIRCUIT LOW? Yes Replace the Fuel Pump Module in accordance with the Service Information. Refer to «DIESEL - MODULE, FUEL PUMP, REMOVAL»(ref-476558-S04909988492012060400000) «GAS - MODULE, FUEL PUMP, REMOVAL»(ref-476558-S40177789832012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (N4) FUEL LEVEL SENSOR SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the TIPM C7 harness connector. Measure the resistance of the (N4) Fuel Level Sensor Signal circuit between the Fuel Pump Module harness connector and the TIPM C7 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (N4) Fuel Level Sensor Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (G109) FUEL LEVEL SENSE RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (G109) Fuel Level Sense Return circuit between the Fuel Pump Module harness connector and the TIPM C7 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 6 . No Repair the open in the (G109) Fuel Level Sense Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
6. TOTALLY INTEGRATED POWER MODULE (TIPM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Fuel Pump Module and the TIPM. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the Fuel Pump Module and the TIPM C7 harness connectors. Perform any Technical Service Bulletins (TSB)s that may apply. Were any problems found? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 362

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10 volts.

With the Low Speed Cooling Fan off.

The TIPM detects an open in the internal Low Speed Cooling Fan Control circuit.

With the ignition on.

Battery voltage greater than 10 volts.

With the Low Speed Cooling Fan on.

The TIPM detects a shorted condition in the internal Low Speed Cooling Fan Control circuit.

With the ignition on.

Battery voltage greater than 10 volts.

With the High Speed Cooling Fan off.

The TIPM detects a low condition in the Rad Fan High Speed Control circuit.

Scheme 363

Scheme 364

Scheme 365

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. With the scan tool, clear all DTC's. With the scan tool, read DTC's. Does the scan tool display DTC: P0693-COOLING FAN 2 CONTROL CIRCUIT LOW? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. RADIATOR FAN HIGH RELAY Turn the ignition off. Remove the Radiator Fan High Relay and substitute it with a known good relay. Turn the ignition on. With the scan tool, clear all DTC's. Turn the ignition off. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display DTC: P0693-COOLING FAN 2 CONTROL CIRCUIT LOW? Yes Go To 3 . No Replace the Radiator Fan High Relay. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (W24) FUSED RUN RELAY OUTPUT CIRCUIT FOR AN OPEN Turn the ignition off. Remove the Radiator Fan High Relay. Turn the ignition on. Using a 12-volt test light connected to ground, check the (W24) Fused Run Relay Output circuit. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go To 4 . No Repair the open or high resistance in the (W24) Fused Run Relay Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. CHECK THE (K175) RAD FAN HIGH SPEED CONTROL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C3 harness connector. Measure the resistance between ground and the (K175) Rad Fan High Speed Control circuit. Is the resistance above 10k Ohms? Yes Go To 5 . No Repair the short to ground in the (K175) Rad Fan High Speed Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (K175) RAD FAN HIGH SPEED CONTROL CIRCUIT FOR AN OPEN OR HIGH RESISTANCE Measure the resistance of the (K175) Rad Fan High Speed Control circuit from the TIPM C3 harness connector to the Radiator Fan High Relay. Is the resistance below 5.0 Ohms? Yes Go To 6 . No Repair the open or high resistance in the (K175) Rad Fan High Speed Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
6. TOTALLY INTEGRATED POWER MODULE (TIPM) NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were there any problems found? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage greater than 10 volts.

With the High Speed Cooling Fan on.

The TIPM detects a short to voltage in the Rad Fan High Speed Control circuit.

Scheme 366

1. ACTIVE DTC Turn the ignition on. With the scan tool, clear all DTC's. With the scan tool, actuate Radiator Fan 2. With the scan tool, read DTC's. Does the scan tool display DTC: P0694-COOLING FAN 2 CONTROL CIRCUIT HIGH? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. RADIATOR FAN HIGH RELAY Turn the ignition off. Remove the Radiator Fan High Relay and substitute it with a known good relay. Turn the ignition on. With the scan tool, clear all DTC's. Turn the ignition off. Turn the ignition on. With the scan tool, actuate Radiator Fan 2. With the scan tool, read DTC's. Does the scan tool display DTC: P0694-COOLING FAN 2 CONTROL CIRCUIT HIGH? Yes Go To 3 . No Replace the Radiator Fan High Relay. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (K175) RAD FAN HIGH SPEED CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the TIPM C3 harness connector. Remove the Radiator Fan High Relay. Turn the ignition on. Measure the voltage between ground and the (K175) Rad Fan High Speed Control circuit. Is there any voltage present? Yes Repair the short to voltage in the (K175) Rad Fan High Speed Control circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. TOTALLY INTEGRATED POWER MODULE (TIPM) NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were there any problems found? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage greater than 10.4 volts.

Air Conditioning (A/C) Switch on.

A/C Compressor Clutch command on.

The Totally Integrated Power Module (TIPM) detects the voltage on the A/C Clutch Control Output circuit is higher than the calibrated level.

Scheme 367

Scheme 368

Scheme 369

Scheme 370

1. A/C COMPRESSOR CLUTCH OPERATION NOTE: If Powertrain Control Module (PCM) DTC P0645-A/C CLUTCH CONTROL CIRCUIT is present, diagnose it first. Ignition on, engine not running. With the scan tool, actuate the A/C Clutch. Does the A/C Clutch actuate? Yes Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 2 .
2. CHECK THE (C3) A/C CLUTCH CONTROL OUTPUT CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the A/C Compressor Clutch harness connector. Disconnect the TIPM C1 harness connector. Ignition on, engine not running. Measure the voltage between ground and the (C3) A/C Clutch Control Output circuit at the A/C Compressor Clutch harness connector. Is there any voltage present? Yes Repair the short to voltage in the (C3) A/C Clutch Control Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE TIPM FOR CORRECT OPERATION Turn the ignition off. Reconnect the TIPM C1 harness connector. Ignition on, engine not running. Connect a 12-volt test light between the (C3) A/C Clutch Control Output circuit and (Z908)/(Z916) Ground circuit at the A/C Compressor Clutch harness connector. With the scan tool, actuate the A/C Clutch. Does the test light illuminate when the A/C Clutch is commanded on? Yes Verify that there is good pin to terminal contact in the A/C Compressor Clutch and TIPM connectors. If OK, replace the A/C Compressor Clutch in accordance with the Service Information. Refer to «COMPRESSOR, A/C, REMOVAL»(ref-476508-S09307786332012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (C3) A/C CLUTCH CONTROL OUTPUT CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the TIPM C1 harness connector. Measure the resistance of the (C3) A/C Clutch Control Output circuit between the A/C Compressor Clutch harness connector and the TIPM C1 harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the open in the (C3) A/C Clutch Control Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. CHECK THE (Z908)/(Z916) GROUND CIRCUIT FOR AN OPEN Using a 12-volt test light connected to 12-volts, check the (Z908)/(Z916) Ground circuit at the A/C Compressor Clutch harness connector. Does the test light illuminate brightly? Yes Go To 6 . No Repair the open or excessive resistance in the (Z908)/(Z916) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
6. TOTALLY INTEGRATED POWER MODULE (TIPM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the A/C Clutch and TIPM. Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Verify that there is good pin to terminal contact in the A/C Compressor Clutch and TIPM connectors. Perform any Technical Service Bulletins (TSB)s that may apply. Were any problems found? Yes Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage greater than 10.4 volts.

Air Conditioning (A/C) Switch on.

A/C Compressor Clutch command on.

The TIPM detects the current draw on the A/C Clutch Control Output circuit is higher than the calibrated level.

Scheme 371

Scheme 372

1. A/C CLUTCH OPERATION Ignition on, engine not running. With a scan tool, actuate the A/C Clutch. Does the A/C Clutch actuate? Yes Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 2 .
2. CHECK THE (C3) A/C CLUTCH CONTROL OUTPUT CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the A/C Compressor Clutch harness connector. Disconnect the TIPM C1 harness connector. Measure the resistance between ground and the (C3) A/C Clutch Control Output circuit at the A/C Compressor Clutch harness connector. Is the resistance above 10k Ohms? Yes Go To 3 . No Repair the short to ground in the (C3) A/C Clutch Control Output circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (C3) A/C CLUTCH CONTROL OUTPUT FROM TIPM Reconnect the TIPM C1 harness connector. Ignition on, engine not running. Using the 12-volt test light connected to ground, check the (C3) A/C Clutch Control Output circuit in the A/C Compressor Clutch harness connector. With a scan tool, actuate the A/C Clutch. Does the test light illuminate when the A/C Clutch is commanded on? Yes Verify that there is good pin to terminal contact in the A/C Compressor Clutch and TIPM connectors. If OK, replace the A/C Clutch in accordance with the Service Information. Refer to «COMPRESSOR, A/C, REMOVAL»(ref-476508-S09307786332012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 373

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Battery voltage greater than 10 volts.

Inverter commanded on.

If the Totally Integrated Power Module (TIPM) detects an overcurrent condition on the (P807) Inverter Switch Signal circuit.

Scheme 374

Scheme 375

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's. Operate the 115 Volt AC Outlet switch several times. With the scan tool, read DTC's. Is the DTC active at this time? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK (P807) INVERTER SWITCH SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the TIPM C7 harness connector. Disconnect the Inverter Module harness connector. Measure the resistance between ground and the (P807) Inverter Switch Signal circuit at the Inverter Module harness connector. Is the resistance above 10k Ohms? Yes Go To 3 . No Repair the short to ground in the (P807) Inverter Switch Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK (P807) INVERTER SWITCH SIGNAL CIRCUIT FUNCTION Turn the ignition off. Reconnect the TIPM C7 harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, check the (P807) Inverter Switch Signal circuit at the Inverter Module harness connector. With the scan tool, actuate the Inverter Switch. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Replace the Power Inverter Module in accordance with the Service Information. Refer to «MODULE, POWER INVERTER, REMOVAL»(ref-476543-S38163469632012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a corrupt CAN C Bus message.

Scheme 376

Scheme 377

Scheme 378

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. ANTILOCK BRAKE MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the Antilock Brake Module harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 3 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Antilock Brake Module in accordance with the Service Information. Refer to «MODULE, ANTI-LOCK BRAKE SYSTEM, REMOVAL»(ref-476533-S42742154772012060400000) . Perform the ABS VERIFICATION TEST. Refer to «1500, 2500 & 3500 - ABS VERIFICATION TEST»(ref-476582-S18536955492012060400000) or «3500 CAB & CHASSIS, 4500 & 5500 - ABS VERIFICATION TEST»(ref-476581-S42107068112012060400000) .
3. OCCUPANT RESTRAINT CONTROLLER MODULE - INTERNAL SHORT WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the Occupant Restraint Controller Module harness connectors. Reconnect the 12-volt battery. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 4 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Occupant Restraint Controller Module in accordance with the Service Information. Refer to «CONTROLLER, OCCUPANT RESTRAINT, REMOVAL»(ref-476529-S14397433452012060400000) . Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «RESTRAINTS SYSTEM VERIFICATION TEST»(ref-476575-S17223636292012060400000) .
4. POWERTRAIN CONTROL MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the PCM C1 or PCM C2 (6.7L) harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 5 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Powertrain Control Module in accordance with the Service Information. Refer to «3.7L, 4.7L & 5.7L - MODULE, POWERTRAIN CONTROL, REMOVAL»(ref-476533-S29192226892012060400000) or «MODULE, POWERTRAIN CONTROL, 6.7L DIESEL [ETJ], REMOVAL»(ref-476533-S09065799022012060400000) . Perform the POWERTRAIN VERIFICATION TEST. Refer to «1500 & 2500 - 3.7L, 4.7L & 5.7L - POWERTRAIN VERIFICATION TEST»(ref-476600-S16182020042012060400000) or «2500 & 3500 - POWERTRAIN VERIFICATION TEST - 6.7L»(ref-476629-S31319329382012060400000) or «3500 CAB & CHASSIS - POWERTRAIN VERIFICATION TEST»(ref-476607-S38255705622012060400000) or «3500 CAB & CHASSIS, 4500 & 5500 - POWERTRAIN VERIFICATION TEST - 6.7L»(ref-476635-S37546799742012060400000) .
5. STEERING ANGLE SENSOR - INTERNAL SHORT Turn the ignition off. Disconnect the Clockspring C3 (SAS) harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 6 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Clockspring and program the SAS in accordance with the Service Information. Refer to «CLOCKSPRING, REMOVAL»(ref-476529-S33678809682012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
6. WIRELESS IGNITION NODE - INTERNAL SHORT Turn the ignition off. Disconnect the Wireless Ignition Node harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 7 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Wireless Ignition Node in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE, REMOVAL»(ref-476533-S21985724952012060400000) . Perform the WIRELESS IGNITION NODE (WIN) VERIFICATION TEST. Refer to «WIRELESS IGNITION NODE (WIN) VERIFICATION»(ref-476554-S22266194142012060400000) .
7. DRIVETRAIN CONTROL MODULE - INTERNAL SHORT Turn the ignition off. NOTE: If vehicle is not equipped with this module, answer yes to the question. Disconnect the Drive Train Control Module C1 harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 8 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Drivetrain Control Module in accordance with the Service Information. Refer to «MODULE, DRIVETRAIN CONTROL, REMOVAL»(ref-476533-S26061413582012060400000) . Perform the DTCM VERIFICATION TEST. Refer to «1500, 2500& 3500 - DTCM VERIFICATION TEST»(ref-476585-S36097688012012060400000) or «3500 CAB & CHASSIS, 4500 & 5500 - DTCM VERIFICATION TEST»(ref-476583-S01036358302012060400000) .
8. FINAL DRIVE CONTROL MODULE (FDCM) - INTERNAL SHORT Turn the ignition off. NOTE: If vehicle is not equipped with this module, answer yes to the question. Disconnect the FDCM harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 9 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the FDCM in accordance with the Service Information. Refer to «ACTUATOR, STABILIZER BAR, REMOVAL»(ref-476491-S42023480312012060400000) . Perform the FDCM VERIFICATION TEST. Refer to «FDCM VERIFICATION TEST»(ref-476586-S13695316712012060400000) .
9. INTEGRATED TRAILER BRAKE MODULE (ITBM) - INTERNAL SHORT Turn the ignition off. NOTE: If vehicle is not equipped with this module, answer yes to the question. Disconnect the ITBM harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 10 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the ITBM in accordance with the Service Information. Refer to «MODULE, INTEGRATED TRAILER BRAKE (ITBM), REMOVAL»(ref-476533-S11631635442012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
10. TIRE PRESSURE MONITORING MODULE - INTERNAL SHORT Turn the ignition off. NOTE: If vehicle is not equipped with this module, answer yes to the question. Disconnect the Tire Pressure Module harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 11 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Tire Pressure Monitoring Module in accordance with the Service Information. Refer to «MODULE, TIRE PRESSURE MONITORING (TPM), REMOVAL»(ref-476494-S30761618142012060400000) . Perform the TPM VERIFICATION. Refer to «TPM VERIFICATION TEST»(ref-476573-S22522042732012060400000) .
11. TRANSMISSION CONTROL MODULE (TCM) - INTERNAL SHORT Turn the ignition off. NOTE: If vehicle is not equipped with this module, answer yes to the question. Disconnect the TCM C2 harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display U0001-CAN C BUS as active? Yes Go To 12 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Transmission Control Module in accordance with the Service Information. Refer to «MODULE, TRANSMISSION CONTROL, DESCRIPTION»(ref-476533-S23272040342012060400000) . Perform the TCM VERIFICATION TEST. Refer to «AS68RC TRANSMISSION VERIFICATION TEST»(ref-476612-S09284896472012060400000) .
12. (D51) OR (D64) CAN C BUS (-) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the TIPM C7 and C1 harness connectors. Turn the ignition on. Measure the voltage between the (D51) CAN C Bus (-) circuit and ground at the TIPM C7 harness connector. Measure the voltage between the (D64) CAN C Bus (-) circuit and ground at the TIPM C1 harness connector. Is there any voltage present? Yes Repair the short to voltage in the (D51) or the (D64) CAN C Bus (-) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 13 .
13. (D52) OR (D65) CAN C BUS (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D52) CAN C Bus (+) circuit. Measure the resistance between ground and the (D65) CAN C Bus (+) circuit. Is any resistance present? Yes Repair the short to ground in the (D52) or (D65) CAN C Bus (+) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 14 .
14. CAN C BUS (+) CIRCUIT SHORTED TO CAN C BUS (-) CIRCUIT Measure the resistance between the (D52) CAN C Bus (+) circuit and the (D51) CAN C Bus (-) circuit. Measure the resistance between the (D65) CAN C Bus (+) circuit and the (D64) CAN C Bus (-) circuit. Is any resistance present? Yes Repair the short between the CAN C Bus (+) circuit and the CAN C Bus (-) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The Totally Integrated Power Module (TIPM) detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.

Scheme 379

Scheme 380

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. ANY CAN INTERIOR BUS (125K) MODULE - INTERNAL SHORT NOTE: When performing this step, turn the ignition off (wait one minute) before disconnecting any module. When the module is disconnected turn the ignition on. NOTE: This step is to determine if the fault is internal within a module. While monitoring the scan tool, disconnect each CAN Interior Bus (125K) module (except for the TIPM), one at a time. Check for this DTC to become active after disconnecting each CAN Interior Bus (125K) module the vehicle is equipped with. NOTE: If the DTC becomes stored when a particular module is disconnected, that module is causing the DTC to set. With all the CAN Interior Bus modules disconnected, does the scan tool display this DTC as active? Yes Go To 3 . No Replace the module that when disconnected caused this DTC to become stored in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. (D265) CAN INTERIOR BUS (125K) (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D265) CAN Interior Bus (125K) (+) circuit at the TIPM C7 harness connector. Is any resistance present? Yes Repair the short to ground in the (D265) CAN Interior Bus (125K) (+) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. (D264) CAN INTERIOR BUS (125K) (-) CIRCUIT SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage at the (D264) CAN Interior Bus (125K) (-) circuit at the TIPM C7 harness connector. Is the voltage above 6 volts? Yes Repair the short to voltage in the (D264) CAN Interior Bus (125K) (-) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Inspect the wiring and connectors for damage or short circuits. If OK, replace the TIPM in accordance with the Service Information. Refer to «MODULE, TOTALLY INTEGRATED POWER (TIPM), REMOVAL»(ref-476543-S26517536562012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Powertrain Control Module (PCM) for approximately two to five seconds.

Scheme 381

Scheme 382

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTC's. Is this DTC active? Yes Go To 2 . No Refer to «STORED LOST COMMUNICATION DTC's»(ref-476525-S35361024732012060400000) and perform the diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTC's With the scan tool, read all active DTC's from all modules. NOTE: Check for TIPM configuration, CAN C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTC's. Does the scan tool display any active DTC's to the conditions listed above? Yes Go to «DIAGNOSTIC CODE INDEX»(ref-476553-S13841779632012060400000) and perform the appropriate diagnostic procedure. No Go To 3 .
3. VERIFY THE PCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify the PCM is active on the bus. Is the PCM active on the bus? Yes Go To 4 . No Refer to «NO RESPONSE FROM PCM (POWERTRAIN CONTROL MODULE) - GAS»(ref-476525-S12471972752012060400000) or «NO RESPONSE FROM PCM (POWERTRAIN CONTROL MODULE) - 6.7L»(ref-476525-S29095443852012060400000) and perform the appropriate diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTC's With the scan tool, select Network Diagnostics. Is there more than one module with active DTC's "Logged Against" the PCM? Yes Replace/update the PCM in accordance with the Service Information. Refer to «3.7L, 4.7L & 5.7L - MODULE, POWERTRAIN CONTROL, REMOVAL»(ref-476533-S29192226892012060400000) «MODULE, POWERTRAIN CONTROL, 6.7L DIESEL [ETJ], REMOVAL»(ref-476533-S09065799022012060400000) . Perform the POWERTRAIN VERIFICATION TEST. Refer to «1500 & 2500 - 3.7L, 4.7L & 5.7L - POWERTRAIN VERIFICATION TEST»(ref-476600-S16182020042012060400000) or «2500 & 3500 - POWERTRAIN VERIFICATION TEST - 6.7L»(ref-476629-S31319329382012060400000) or «3500 CAB & CHASSIS - POWERTRAIN VERIFICATION TEST»(ref-476607-S38255705622012060400000) or «3500 CAB & CHASSIS, 4500 & 5500 - POWERTRAIN VERIFICATION TEST - 6.7L»(ref-476635-S37546799742012060400000) . No Go To 5 .
5. CLEAR DTC IN MODULE SETTING FAULT With the scan tool, select the module setting the DTC against the PCM. Clear active DTC's. Is this DTC still active? Yes Replace/update the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 6 .
6. CYCLE IGNITION Cycle the ignition from RUN to OFF three times ending with the key in the RUN position. Does this DTC become active? Yes Go To 7 . No The condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched and partially broken wires and the wiring harness connectors for broken, bent, pushed out and corroded terminals. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
7. CHECK FOR ADDITIONAL LOST COMMUNICATION FAULTS With the scan tool, select Network Diagnostics. Does the TIPM and other CAN C BUS modules show Lost Communication with the remaining CAN C BUS modules? Yes Go To 8 . No Replace/update the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
8. (D52) OR (D65) CAN C BUS (+) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D52) CAN C Bus (+) circuit and ground. Measure the voltage between the (D65) CAN C Bus (+) circuit and ground. Is the voltage above 5.0 volts? Yes Repair the short to voltage in the (D52) or (D65) CAN C Bus (+) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 9 .
9. (D51) OR (D64) CAN C BUS (-) CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D51) CAN C Bus (-) circuit. Measure the resistance between ground and the (D64) CAN C Bus (-) circuit. Is the resistance below 10k Ohms? Yes Repair the short to ground in the (D51) or (D64) CAN C Bus (-) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace/update the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Transmission Control Module (TCM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Drive Train Control Module (DTCM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Final Drive Control Module (FDCM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Anti-Lock Brake Module (ABS) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Tire Pressure Monitoring (TPM) module for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Integrated Trailer Brake Module (ITBM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Occupant Restraint Controller (ORC) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Cluster/Cabin Compartment Node (CCN) for approximately two to five seconds.

Scheme 383

Scheme 384

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTC's. Is this DTC active? Yes Go To 2 . No Refer to «STORED LOST COMMUNICATION DTC's»(ref-476525-S35361024732012060400000) and perform the diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTC's With the scan tool, read all active DTC's from all modules. NOTE: Check for TIPM configuration, CAN Interior Bus hardware electrical, VIN Missing/Mismatch, battery or ignition related DTC's. Does the scan tool display any active DTC's to the conditions listed above? Yes Go to «DIAGNOSTIC CODE INDEX»(ref-476553-S13841779632012060400000) and perform the appropriate diagnostic procedure. No Go To 3 .
3. VERIFY THE CCN IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify the CCN is active on the bus. Is the CCN active on the bus? Yes Go To 4 . No Refer to «NO RESPONSE FROM CCN (CLUSTER)»(ref-476525-S29473327892012060400000) and perform the diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTC's With the scan tool, select Network Diagnostics. Is there more than one module with active DTC's "Logged Against" the CCN? Yes Replace/update the Cluster/CCN in accordance with the Service Information. Refer to «REMOVAL»(ref-476514-S25394978592012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 5 .
5. CLEAR DTC IN MODULE SETTING FAULT With the scan tool, select the module setting the DTC against the Cluster/CCN. Clear active DTC's. Is this DTC still active? Yes Replace/update the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 6 .
6. CYCLE IGNITION Cycle the ignition from RUN to OFF three times ending with the key in the RUN position. Does this DTC become active? Yes Go To 7 . No The condition is not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the appropriate VERIFICATION TEST.
7. CHECK FOR ADDITIONAL LOST COMMUNICATION FAULTS With the scan tool, select Network Diagnostics. Does the TIPM and other CAN Interior BUS (125K) modules show Lost Communication with the remaining CAN Interior BUS (125K) modules? Yes Go To 8 . No Replace/update the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
8. (D265) CAN INTERIOR BUS (+) (125K) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D265) CAN Interior Bus (+) (125K) circuit and ground. Is the voltage above 5.0 volts? Yes Repair the short to voltage in the (D265) CAN Interior Bus (+) (125K) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 9 .
9. (D264) CAN INTERIOR BUS (-) (125K) CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D264) CAN Interior Bus (-) (125K) circuit. Is the resistance below 10k Ohms? Yes Repair the short to ground in the (D264) CAN Interior Bus (-) (125K) circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace/update the module that set this DTC in accordance with the Service Information. Perform the appropriate verification test for the module being replaced. If there is no verification test for the associated module, Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fused installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Park Assist (PTS) Module for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the HVAC Control Module for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Wireless Ignition Node (WIN) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Radio for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Amplifier (AMP) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the HFM for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Door Module Front Left (DMFL) or Driver Door Module for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Door Module Front Right (DMFR) or Passenger Door Module for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Heated Seat Module (HSM) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the MSMD for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Steering Control Module (SCM)/Steering Angle Sensor (SAS) for approximately two to five seconds.

With the ignition on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Vehicle Entertainment Control Module (VES3) for approximately two to five seconds.

Continuously.

The Totally Integrated Power Module (TIPM) detects an additional CAN Interior Bus module and requires reprogramming.

Continuously.

The Totally Integrated Power Module (TIPM) detects an additional CAN C Bus module and requires reprogramming.
