Cabin Compartment Node (Ccn) - Electrical Diagnostics: Other RAM Cab & Chassis 3500 HD

WHEN MONITORED

With the ignition on.

SET CONDITION

If the Cluster (CCN) senses the Left Heated Seat switch input for more than 20 seconds.

POSSIBLE CAUSES

B10BC-RIGHT HEATED SEAT SWITCH INPUT CIRCUIT STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

If the Cluster (CCN) senses the Right Heated Seat switch input for more than 20 seconds.

Ignition on, during the heated seat operation.

If the Cluster (CCN) senses the (P165) Left Rear Heated Seat Switch Sense circuit is low for a predetermined amount of time.

Scheme 393

Scheme 394

Scheme 395

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using a scan tool, record and erase Diagnostic Trouble Codes (DTCs). Operate the Left Rear Heated Seat Switch in both positions several times. Using a scan tool, read DTCs. Does the scan tool display DTC B114C-LEFT REAR HEATED SEAT SWITCH STUCK? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK FOR SHORTED LEFT REAR HEATED SEAT SWITCH Turn the ignition off. Disconnect the Left Rear Heated Seat Switch connector. NOTE: Check connectors. Clean and repair as necessary. Turn the ignition on. With the scan tool in CCN, select Data Display and read the Left Rear Heated Seat state. Does the switch state display Not Set? Yes Replace the Left Rear Heated Seat Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK (P165) LEFT REAR HEATED SEAT SWITCH SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Cluster C2 connector. Measure the resistance of the (P165) Left Rear Heated Seat Switch Sense circuit between ground and the Left Rear Heated Seat Switch connector. Is the resistance below 10K Ohms? Yes Repair the (P165) Left Rear Heated Seat Switch Sense circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK (P165) LEFT REAR HEATED SEAT SWITCH SENSE CIRCUIT FOR A SHORT TO (Z910) GROUND CIRCUIT Measure the resistance between the (P165) Left Rear Heated Seat Switch Sense circuit and the (Z910) Ground circuit at the Left Rear Heated Seat Switch connector. Is the resistance below 10K Ohms? Yes Repair the (P165) Left Rear Heated Seat Switch Sense circuit for a short to the (Z910) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster (CCN) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 396

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on, during the heated seat operation.

If the Cluster (CCN) senses the (P166) Right Rear Heated Seat Switch Sense circuit is low for a predetermined amount of time.

Scheme 397

Scheme 398

Scheme 399

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using a scan tool, record and erase Diagnostic Trouble Codes (DTCs). Operate the Right Rear Heated Seat Switch in both positions several times. Using a scan tool, read DTCs. Does the scan tool display DTC B1151-RIGHT REAR HEATED SEAT SWITCH STUCK? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK FOR SHORTED RIGHT REAR HEATED SEAT SWITCH Turn the ignition off. Disconnect the Right Rear Heated Seat Switch connector. NOTE: Check connectors. Clean and repair as necessary. Turn the ignition on. With the scan tool in CCN, select Data Display and read the Right Rear Heated Seat state. Does the switch state display Not Set? Yes Replace the Right Rear Heated Seat Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK (P166) RIGHT REAR HEATED SEAT SWITCH SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Cluster C2 connector. Measure the resistance of the (P166) Right Rear Heated Seat Switch Sense circuit between ground and the Right Rear Heated Seat Switch connector. Is the resistance below 10K Ohms? Yes Repair the (P166) Right Rear Heated Seat Switch Sense circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK (P166) RIGHT REAR HEATED SEAT SWITCH SENSE CIRCUIT FOR A SHORT TO (Z910) GROUND CIRCUIT Measure the resistance between the (P166) Right Rear Heated Seat Switch Sense circuit and the (Z910) Ground circuit at the Right Rear Heated Seat Switch connector. Is the resistance below 10K Ohms? Yes Repair the (P166) Right Rear Heated Seat Switch Sense circuit for a short to the (Z910) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster (CCN) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B127A-COMPASS PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Internal Compass Module failure detected.

With the ignition on.

The Cluster detects the Park Assist Disable Switch active for greater than 20 seconds.

With the ignition on.

The Cluster detects the Compass / Temp Button active for greater than 20 seconds.

With the ignition on.

The Cluster detects the Reset Switch active for greater than 20 seconds.

With the ignition on.

The Cluster detects the Trip / Toggle Switch active for greater than 20 seconds.

Continuously with the ignition on.

The Cluster senses that the Remote Radio Switch Input circuit is open.

Continuously with the ignition on.

The Cluster senses that the Remote Radio Switch Input circuit is stuck for greater than 600 seconds.

With the ignition on.

The Cluster detects the Steering Wheel Control Down Switch active for greater than 20 seconds.

With the ignition on.

The Cluster detects the Steering Wheel Control Right Switch active for greater than 20 seconds.

With the ignition on.

The Cluster detects a low condition in the Headlamp/fog lamp switch signal circuit.

Scheme 400

Scheme 401

1. CHECK FOR ACTIVE DTC Turn the ignition on. Turn the Headlamps on. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused the symptom is currently not present. Inspect the related wiring for a possible intermittent condition. Look for any chafed, pierced, pinched, or partially broken wires. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. HEADLAMP SWITCH Disconnect the Headlamp Switch harness connector. Turn the ignition on. Measure the voltage of the (L116) Headlamp / Fog Lamp Switch Signal circuit. Does the voltage read 5.0 volts? Yes Replace the Headlamp Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. (L116) HEADLAMP / FOG LAMP SWITCH SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Headlamp Switch harness connector. Disconnect the Instrument Cluster C3 harness connector. Measure the resistance of the (L116) Headlamp Switch Signal circuit to ground. Is the resistance below 5.0 Ohms? Yes Repair short to ground on the (L116) Headlamp / Fog Lamp Switch Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The Cluster detects a high condition in the Headlamp/fog lamp switch signal circuit.

Scheme 402

Scheme 403

Scheme 404

1. CHECK FOR ACTIVE DTC Turn the ignition on. Turn the Headlamps on. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused the symptom is currently not present. Inspect the related wiring for a possible intermittent condition. Look for any chafed, pierced, pinched, or partially broken wires. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. (L116) HEADLAMP / FOG LAMP SWITCH SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Headlamp Switch harness connector. Turn the ignition on. Measure the voltage of the (L116) Headlamp / Fog Lamp Switch Signal circuit. Is the voltage above 10.0 volts? Yes Repair the (L116) Headlamp / Fog Lamp Switch Signal circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. HEADLAMP SWITCH Turn the ignition off. Disconnect the Headlamp Switch harness connector. Connect a jumper wire to the (L116) Headlamp / Fog Lamp Switch Signal circuit at the Headlamp Switch harness connector. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display DTC: B1607-HEADLAMP SWITCH INPUT CIRCUIT LOW? Yes Replace the Headlamp Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. (L116) HEADLAMP / FOG LAMP SWITCH SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Headlamp Switch harness connector. Disconnect the Cluster C3 harness connector. Measure the resistance of the (L116) Headlamp / Fog Lamp Switch Signal circuit. Is the resistance below 5.0 Ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (L116) Headlamp / Fog Lamp Switch Signal circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 405

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the Cluster awake.

Panel Dimmer Input less than 0.5 of a volt.

Scheme 406

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Activate the Panel Dimmer Switch. Wait 30 seconds. With the scan tool, read DTCs. Is the DTC active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK OPERATION OF HEADLAMP SWITCH Disconnect the Headlamp Switch harness connector. With the scan tool, read Cluster DTCs. Is the DTC active? Yes Go To 3 . No Replace the Headlamp Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (E2) PANEL LAMPS DIMMER SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between ground and the (E2) Panel Lamps Dimmer Signal circuit. Is the resistance below 10K Ohms? Yes Repair the (E2) Panel Lamps Dimmer Signal circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B160B-PANEL DIMMER INPUT CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Panel Dimmer signal is greater than 4.8 volts.

Scheme 407

Scheme 408

Scheme 409

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Activate the Panel Dimmer Switch. Wait 30 seconds. With the scan tool, read DTCs. Is the DTC active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CHECK THE (E2) PANEL LAMPS DIMMER SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Headlamp Switch harness connectors. Turn the ignition on. Measure the voltage on the (E2) Panel Lamps Dimmer Signal circuit. Is the voltage greater than 10.0 volts? Yes Repair the (E2) Panel Lamps Dimmer Signal circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE OPERATION OF THE PANEL LAMPS DIMMER SWITCH Turn the ignition off. Connect a jumper wire at the Headlamp Switch harness connector between the (E2) Panel Lamps Dimmer Signal circuit and ground. Turn the ignition on. With the scan tool, read DTCs. Does the Scan tool display-B160A-PANEL DIMMER INPUT CIRCUIT LOW? Yes Replace the Headlamp Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (E2) PANEL LAMPS DIMMER SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance of the (E2) Panel Lamps Dimmer Signal circuit between the Cluster C3 harness connector and the Headlamp Switch harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (E2) Panel Lamps Dimmer Signal circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 410

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on, Cargo Lamp activated.

The Cluster detects the Cargo Lamp Driver circuit is open.

Scheme 411

Scheme 412

Scheme 413

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. CENTER HIGH MOUNTED STOP/CARGO LAMP Disconnect the Center High Mounted Stop/Cargo Lamp harness connector. Turn the Cargo Lamp on. Using a test light, measure the voltage across the (L14) Cargo Lamp Driver circuit and (Z905) Ground circuits at the Center High Mounted Stop/Cargo Lamp harness connector. Does the test light illuminate? Yes Replace the Cargo Lamp in accordance with the Service Information. Refer to «LAMP, CARGO, REMOVAL»(ref-476552-S24277716692012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. (Z905) GROUND CIRCUIT FOR AN OPEN Turn the ignition off. Using a test light connected to 12 volts, measure the resistance to ground of the (Z905) Ground circuit at the Center High Mounted Stop/Cargo Lamp harness connector. Does the test light illuminate? Yes Go To 4 . No Repair the open in the (Z905) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. (L14) CARGO LAMP DRIVER CIRCUIT FOR AN OPEN Disconnect the Cluster C1 harness connector. Measure the resistance of the (L14) Cargo Lamp Driver circuit. Is the resistance below 5.0 Ohms? Yes Replace the Cluster in accordance with the service information. Refer to «REMOVAL»(ref-476514-S25394978592012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the open in the (L14) Cargo Lamp Driver circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B168F-FRONT FOG LAMP SWITCH CIRCUIT STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

When the Cluster detects a Fog Lamp Switch Stuck message.

With the Cargo Lamps on.

When the Cluster detects a low condition on the Cargo Lamp Return circuit.

Scheme 414

Scheme 415

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Operate the Cargo Lamp Switch several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. HEADLAMP SWITCH SHORTED With the scan tool, erase DTCs. Disconnect the Headlamp Switch connector. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Headlamp Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. (L914) CARGO LAMP SWITCH RETURN CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between ground and the (L914) Cargo Lamp Switch Return circuit. Is the resistance below 5 Ohms? Yes Repair the (L914) Cargo Lamp Switch Return circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. (L914) CARGO LAMP SWITCH RETURN CIRCUIT SHORT TO THE (Z910) GROUND CIRCUIT Measure the resistance between the (L914) Cargo Lamp Switch Return circuit and the (Z407) Ground circuit. Is the resistance below 5 Ohms? Yes Repair the (L914) Cargo Lamp Switch Return circuit for a short to the (Z407) ground circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

B17E3-TURN SIGNAL SWITCH PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Cluster detects the Turn Signal function inoperative.

With the ignition on.

The Cluster detects the Wiper Mode Switch Input circuit voltage is less than the expected value.

With the ignition on.

When the Cluster detects a low condition on the Washer Switch Input Circuit.

Continuously with the ignition on.

The Cluster senses that the Horn Switch is pressed for greater than 45 seconds.

B238E-HI BEAM SWITCH CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Cluster detects the High Beam function inoperative.

With the ignition on.

The Cluster detects the Mist function inoperative.

With the ignition on.

The Cluster detects the Flash to Pass / Optical Horn function inoperative.

C159C-TIRE PRESSURE LOAD SWITCH STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Cluster detects the Tire Pressure Load (Light Load) Switch active for greater than 20 seconds.

With the ignition on.

The Cluster detects the TRAC/ESP Off Switch active for greater than 20 seconds.

With the ignition on.

The (K77) Transfer Case Position Sensor Input circuit is shorted to ground.

Scheme 416

1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, read Cluster DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. TRANSFER CASE SELECTOR SWITCH Turn the ignition off. Disconnect the Transfer Case Selector Switch harness connector. Turn the ignition on. With the scan tool, read Cluster DTCs. Does the scan tool display DTC: P0838-FOUR WHEEL DRIVE (4WD) SWITCH CIRCUIT LOW as active? Yes Go To 3 . No Replace the Transfer Case Selector Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between ground and the (K77) Transfer Case Position Sensor Input circuit. Is the resistance less than 5.0 Ohms? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The (K77) Transfer Case Position Sensor Input circuit is shorted to voltage.

Scheme 417

Scheme 418

1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, read Cluster DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. TRANSFER CASE SELECTOR SWITCH Turn the ignition off. Disconnect the Transfer Case Selector Switch harness connector. Turn the ignition on. Measure the voltage of the (K77) Transfer Case Position Sensor Input circuit. Is the voltage above 5.5 volts? Yes Go To 3 . No Replace the Transfer Case Selector Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Cluster C3 harness connector. Turn the ignition on. Measure the voltage of the (K77) Transfer Case Position Sensor Input circuit at the Transfer Case Selector Switch harness connector. Is the voltage above 0.2 of a volt? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The Cluster detects the Overdrive / Tow Switch function inoperative.

With the ignition on.

The Cluster detects a voltage below 0.35 volts for the period of 5.0 seconds on the AutoStick® (ERS) Signal circuit.

Scheme 419

Scheme 420

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. SHIFT LEVER ASSEMBLY (FLOOR SHIFT) / AUTOSTICK® (ERS) SWITCH (COLUMN SHIFT) Turn the ignition off. Disconnect the Shift Lever Assembly (Floor Shift) harness connector. Disconnect the AutoStick® (ERS) Switch (Column Shift) harness connector. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 3 . No Replace the Shift Lever Assembly (Floor Shift) / AutoStick® (ERS) Switch (Column Shift) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. CHECK THE (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR A SHORT TO THE (L900) HEADLAMP SWITCH MUX RETURN CIRCUIT Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between the (T5) AutoStick® (ERS) Signal circuit and the (L900) Headlamp Switch Mux Return circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T5) AutoStick® (ERS) Signal circuit for a short to the (L900) Headlamp Switch Mux Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T5) AutoStick® (ERS) Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T5) AutoStick® (ERS) Signal circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 421

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Cluster detects a voltage below 0.35 of a volt for the period of 5.0 seconds on the AutoStick® (ERS) Signal circuit.

Scheme 422

Scheme 423

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. AUTOSTICK® (ERS) SWITCH Turn the ignition off. Disconnect the AutoStick® (ERS) Switch harness connector. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display DTC: P0593-AUTOSTICK® Input Circuit High? Yes Replace the AutoStick® (ERS) Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. CHECK THE (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR A SHORT TO THE (L900) HEADLAMP SWITCH MUX RETURN CIRCUIT Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between the (T5) AutoStick® (ERS) Signal circuit and the (L900) Headlamp Switch Mux Return circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T5) AutoStick® (ERS) Signal circuit for a short to the (L900) Headlamp Switch Mux Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. CHECK THE (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T5) AutoStick® (ERS) Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T5) AutoStick® (ERS) Signal circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The Cluster detects a voltage above 5.0 volts for the period of 5.0 seconds on the AutoStick® (ERS) Signal circuit.

Scheme 424

Scheme 425

Scheme 426

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the Shift Lever Assembly (Floor Shift) harness connector. Disconnect the AutoStick® (ERS) Switch (Column Shift) harness connector. Turn the ignition on. Measure the voltage of the (T5) AutoStick® (ERS) Signal circuit. Is the voltage above 5.0 volts? Yes Repair the short to voltage in the (T5) AutoStick® (ERS) Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. SHIFT LEVER ASSEMBLY (FLOOR SHIFT) / AUTOSTICK® (ERS) SWITCH (COLUMN SHIFT) Turn the ignition off. Connect a fused jumper wire between the (T5) AutoStick® (ERS) Signal circuit and the (L900) Headlamp Switch MUX Return circuit in the Shift Lever Assembly / AutoStick® (ERS) Switch harness connector. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 4 . No Replace the Shift Lever Assembly (Floor Shift) / AutoStick® (ERS) Switch (Column Shift) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance of the (T5) AutoStick® (ERS) Signal circuit. Is the resistance above 10.0 Ohms? Yes Repair the open in the (T5) AutoStick® (ERS) Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 5 .
5. (L900) HEADLAMP SWITCH MUX RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (L900) Headlamp Switch MUX Return circuit. Is the resistance above 10.0 Ohms? Yes Repair the open in the (L900) Headlamp Switch MUX Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The Cluster detects a voltage above 5.0 volts for the period of 5.0 seconds on the AutoStick® (ERS) Signal circuit.

Scheme 427

Scheme 428

Scheme 429

Scheme 430

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the AutoStick® (ERS) Switch harness connector. Turn the ignition on. Measure the voltage of the (T5) AutoStick® (ERS) Signal circuit. Is the voltage above 5.0 volts? Yes Repair the short to voltage in the (T5) AutoStick® (ERS) Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. AUTOSTICK® (ERS) SWITCH Turn the ignition off. Connect a fused jumper wire between the (T5) AutoStick® (ERS) Signal circuit and the (L900) Headlamp Switch MUX Return circuit in the AutoStick® (ERS) Switch harness connector. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 4 . No Replace the AutoStick® (ERS) Switch in accordance with the Service Information. Refer to «LEVER, GEARSHIFT, REMOVAL»(ref-476492-S09750745602012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. (T5) AUTOSTICK® (ERS) SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance of the (T5) AutoStick® (ERS) Signal circuit. Is the resistance above 10.0 Ohms? Yes Repair the open in the (T5) AutoStick® (ERS) Signal circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 5 .
5. (L900) HEADLAMP SWITCH MUX RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (L900) Headlamp Switch MUX Return circuit. Is the resistance above 10.0 Ohms? Yes Repair the open in the (L900) Headlamp Switch MUX Return circuit. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

If the Cluster senses the Inverter switch input for more than 20 seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

The controller detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the TIPM for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Park Assist Module for approximately two to five seconds.

With the ignition on.

The Cluster does not receive information from the Compass Module.

Scheme 431

Scheme 432

Scheme 433

Scheme 434

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chaffed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Compass Module harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN BUS circuit. Is the voltage above 5 volts? Yes Go To 4 . No Go To 3 .
3. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance of the (D506) LIN BUS circuit. Is the resistance below 10K Ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (D506) LIN BUS circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. (A416) FUSED B(+) CIRCUIT FOR AN OPEN Turn the ignition on. Measure the voltage of the (A416) Fused B(+) circuit. Is the voltage above 10 volts? Yes Go To 5 . No Repair the (A416) Fused B(+) circuit for an open. Inspect the related fuse. If the fuse is open, check the circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. (Z906) GROUND CIRCUIT FOR AN OPEN Turn the ignition off. Measure the resistance between ground and the (Z906) Ground circuit. Is the resistance below 10K Ohms? Yes Replace the Compass Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (Z906) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the HVAC Control Module for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Radio for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Hands Free Phone Module (HFM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Heated Seat Control Module (HSM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Memory Seat Control Module for approximately two to five seconds.

With the ignition on.

LIN 1 Bus Performance.

Scheme 435

Scheme 436

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. SHORTED COMPONENT NOTE: After disconnecting each component, check DTCs with the scan tool. Turn the ignition on. Disconnect the Upper Switch Bank harness connector. Disconnect the Lower Switch Bank harness connector. Disconnect the Compass Module harness connector. Disconnect the Multifunction Switch harness connector. Disconnect the Right Steering Wheel Switch (Speed Control Switch) harness connector. With each component disconnected, did the DTC U1008-LIN 1 BUS change from active to stored? Yes Replace the component that caused the DTC U1008-LIN 1 BUS change from active to stored. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 3 .
3. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Cluster C3 harness connector. Disconnect the Upper Switch Bank harness connector. Measure the resistance of the (D506) LIN Bus circuit. Is the resistance above 10K Ohms? Yes Repair the (D506) LIN Bus circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Go To 4 .
4. (D506) LIN BUS CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Measure the resistance to ground on the (D506) LIN Bus circuit. Is the resistance below 10K Ohms? Yes Repair the (D506) LIN Bus circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Replace the Cluster in accordance with the Service Information. Refer to «REMOVAL»(ref-476514-S25394978592012060400000) . Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

With the ignition on.

The Cluster does not receive information from the Steering Wheel Controls.

With the ignition on.

The Cluster does not receive any LIN Bus messages from the Multifunction Switch.

Scheme 437

Scheme 438

Scheme 439

Scheme 440

1. CHECK FOR AN ACTIVE DTC NOTE: Before proceeding with this diagnostic process, verify the proper connection of the Multifunction Switch harness connector. A loose connection at this connector will cause this DTC to set. Turn the ignition off. Gently pull the Multifunction Switch connector harness to verify the locking tab is fully engaged. If the connector locking tab is not fully engaged, push to seat the connector locking tab. Turn the ignition on. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Multifunction Switch harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN BUS circuit. Is the voltage above 5 volts? Yes Go To 3 . No Repair the (D506) LIN BUS circuit for an open Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
3. (F943) FUSED IGNITION RUN/START CONTROL OUTPUT CIRCUIT FOR AN OPEN Measure the voltage of the (F943) Fused Ignition Run/Start Control Output circuit. Is the voltage above 10 volts? Yes Go To 4 . No Repair the (F943) Fused Ignition Run/Start Control Output circuit for an open. Inspect the related fuse. If the fuse is open, check the circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. (A412) FUSED B(+) (I.O.D.) CIRCUIT FOR AN OPEN Measure the voltage of the (A412) Fused B(+) (I.O.D.) circuit. Is the voltage above 10 volts? Yes Go To 5 . No Repair the (A412) Fused B(+) (I.O.D.) circuit for an open. Inspect the related fuse. If the fuse is open, check the circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. (Z911) GROUND CIRCUIT FOR AN OPEN Turn the ignition off. Measure the resistance between ground and the (Z911) Ground circuit. Is the resistance below 10K Ohms? Yes Replace the Multifunction Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (Z911) Ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 441

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Cluster does not receive information from the Upper Switch Bank.

Scheme 442

Scheme 443

Scheme 444

Scheme 445

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Upper Switch Bank harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN BUS circuit. Is the voltage above 5 volts? Yes Go To 4 . No Go To 3 .
3. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Instrument Cluster C3 harness connector. Measure the resistance of the (D506) LIN BUS circuit between the Cluster C3 and the Upper Switch Bank harness connectors. Is the resistance below 10K Ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (D506) LIN BUS circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. (A909) FUSED B+ CIRCUIT FOR AN OPEN Turn the ignition on. Using a 12-volt test light connected to ground, check the (A909) Fused B+ circuit at the Upper Switch Bank harness connector. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (A909) Fused B+ circuit for an open. Inspect the related fuse. If the fuse is open, check the circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. (Z911) GROUND CIRCUIT FOR AN OPEN Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the (Z911) Ground circuit at the Upper Switch Bank harness connector. Does the test light illuminate brightly? Yes Replace the Upper Switch Bank in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (Z911) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .

Scheme 446

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Cluster does not receive information from the Lower Switch Bank.

Scheme 447

Scheme 448

Scheme 449

Scheme 450

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
2. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Lower Switch Bank harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN BUS circuit. Is the voltage above 5 volts? Yes Go To 4 . No Go To 3 .
3. (D506) LIN BUS CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Instrument Cluster C3 harness connector. Measure the resistance of the (D506) LIN BUS circuit between the Cluster C3 and the Lower Switch Bank harness connectors. Is the resistance below 10K Ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (D506) LIN BUS circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
4. (A909) FUSED B+ CIRCUIT FOR AN OPEN Turn the ignition on. Using a 12-volt test light connected to ground, check the (A909) Fused B+ circuit at the Lower Switch Bank harness connector. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (A909) Fused B+ circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
5. (Z911) GROUND CIRCUIT FOR AN OPEN Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the (Z911) Ground circuit at the Lower Switch Bank harness connector. Does the test light illuminate brightly? Yes Replace the Lower Switch Bank in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) . No Repair the (Z911) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-476553-S41648749512012060400000) .
