Installing release for front lid Porsche Cayenne I facelift

Lids, Flaps 14 illustrations ~429 words

Installing release for front lid

Installation Location

Scheme 27

Scheme 27
Scheme 27

1. Install actuating mechanism for front lid.

Scheme 28

Scheme 28
Scheme 28

1.1. Engage ball head -7- ( -arrow A- ) and clip in rear section of cable for front lid lock -3- at the actuating mechanism for the front lid -5- ( -arrow B- ). (Scheme 28)

Scheme 29

Scheme 29
Scheme 29

1.2. Insert actuating mechanism for front lid -5- into the body ( -arrow C- ). (Scheme 29)

Scheme 30

Scheme 30
Scheme 30

1.3. Screw in -6- fastening screws. (Scheme 30)

Scheme 31

Scheme 31
Scheme 31

2. Clip in rear section of cable for front lid lock.

2.1. Clip in rear section of cable for front lid lock -3- at the fastening clips -4- ( -arrows D- ). (Scheme 31)

Scheme 32

Scheme 32
Scheme 32

3. Secure insulating mat.

3.1. Swivel insulating mat -1- back ( -arrow E- ) and clip in fastening clips -2- ( -arrow F- ). (Scheme 32), (Scheme 33).

Scheme 33

Scheme 33
Scheme 33

4. Install front side section trim panel. Refer to 70 24 19 Removing and installing front side section trim - as of MY 2003 (All Models) .

Scheme 34

Scheme 34: Removing front section of cable for front lid lock
Scheme 34: Removing front section of cable for front lid lock

Scheme 35

Scheme 35
Scheme 35

Note. The lower part of the lock does not have to be removed from the lock support to facilitate the removal of the front section of the cable for the front lid lock.

1. Remove front lock lower part > 551719 Removing and installing front lock lower part - "Removing" .

Scheme 36

Scheme 36
Scheme 36

2. Unclip front section of cable for front lid lock.

2.1. Release front section of cable for front lid lock -1- ( -Arrow A- ) and swivel it out ( -Arrow B- ). (Scheme 36)

Scheme 37

Scheme 37
Scheme 37

3. Disengage ball head and remove front section of cable for front lid lock.

3.1. Disengage ball head -2- ( -Arrow C- ) and remove front section of cable for front lid lock -1- ( -Arrow D- ). (Scheme 37)

Scheme 38

Scheme 38
Scheme 38

Note. The lower part of the lock does not have to be removed from the lock support to facilitate the removal of the front section of the cable for the front lid lock.

1. Remove front lock lower part > 551719 Removing and installing front lock lower part - "Removing" .

Scheme 39

Scheme 39
Scheme 39

2. Unclip emergency release cable.

2.1. Release emergency release cable -1- ( -Arrow A- ) and swivel it out ( -Arrow B- ). (Scheme 39)

Scheme 40

Scheme 40
Scheme 40

3. Disengage ball head and remove emergency release cable.

3.1. Disengage ball head -2- ( -Arrow C- ) and remove emergency release cable -1- ( -Arrow D- ). (Scheme 40)
