Removing spray nozzle for headlight washer system (basic model)
Installation Location
1. Press out nozzle head from the inside -arrow B- and retain it. (Scheme 84)
2. Disengage closure cap at the stops -arrows A-. (Scheme 84)
Scheme 85
3. Disconnect water feed line from lifting cylinder using the rapid-action coupling -arrow A-. see scheme 87
Scheme 86
4. Unscrew the top three fastening screws -arrows C-. see scheme 88
Scheme 87
5. Unscrew the bottom fastening screw -arrow B-. (Scheme 85)
6. Pull lifting cylinder -arrow D- out at the top and disengage at the bottom. see scheme 87
Installation Location
1. Press out nozzle head from the inside -arrow B- and retain it. (Scheme 87)
2. Disengage closure cap at the stops -arrows A-. (Scheme 87)
3. Disconnect water feed line from lifting cylinder using the rapid-action coupling -arrow A-. see scheme 92
4. Unscrew the top three fastening screws -arrows C-. see scheme 93
5. Unscrew the bottom fastening screws -arrows B-. see scheme 94
6. Remove lifting cylinder -arrow D-. see scheme 92
