Installing spray nozzle for headlight washer system (basic model)
1. Engage lifting cylinder -arrow A- at the bottom and insert at the top. see scheme 95
Scheme 88
2. Tighten the bottom fastening screw -arrow B-. --> Tightening torque: 1 ftlb. see scheme 96
Scheme 89
3. Tighten the top three fastening screws -arrows C-. --> Tightening torque: 1 ftlb. see scheme 97
4. Connect rapid-action coupling for water line to lifting cylinder -arrow D-. see scheme 95
5. Press out nozzle head from the inside -arrow A- and retain it. (Scheme 88)
6. Fit cover -arrows B-. (Scheme 88)
