Wiring diagram: Instrument cluster — Electronic compass circuit Porsche Cayenne I
All systems — 36 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft
- Body control modules 2
- Computer data lines
- Cooling fan 3.2l
- Cooling fan 4.5l
- Cooling fan 4.5l turbo
- Cruise control
- Defoggers
- Electronic power steering
- Electronic suspension 2
- Engine performance 3.2l
- Engine performance 4.5l
- Engine performance 4.5l turbo
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster 3
- Interior lights
- Memory systems 2
- Navigation 2
- Power distribution
- Power mirrors
- Power seats 3
- Power top/sunroof 2
- Power windows 2
- Radio 2
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer
Components on these wiring diagrams 3
Click a component to highlight it on every diagram it appears on.
