Porsche Cayenne I (2002-2007) Exterior lamps circuit

BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BRN WIRE FUSE 14 FUSE 15 FUSE 17 FUSE 35 FUSE 53 GRN/YEL WIRE GRY/BLK WIRE GRY/RED WIRE HAZARD SWITCH HOT AT ALL TIMES HOT IN RUN AND START LEFT "D" PILLAR TAILLIGHT ASSEMBLY LEFT FRONT TURN SIGNAL LEFT FUSE BOX (UNDER LEFT SIDE OF DASH) LEFT PARKING LIGHT LEFT REAR LIGHT LEFT REAR TURN SIGNAL LEFT SIDE MARKER LIGHT LEFT XENON HEADLIGHT LIGHT SWITCH ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH) RED WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT TURN SIGNAL RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) RIGHT PARKING LIGHT RIGHT SIDE MARKER LIGHT RIGHT XENON HEADLIGHT STOPLIGHT TERM 31 REDUNDANTLY TERM 31 TERM 15 LOW BEAM PARKING LIGHT ASSIST DRV LIGHT VIO WIRE YEL/WHT WIRE

BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BRN WIRE COMFORT SYSTEMS REAR CONTROL UNIT (RIGHT REAR CARGO AREA) GRY WIRE GRY/BLK WIRE GRY/YEL WIRE HIGH MOUNTED STOPLIGHT LEFT REAR FLAP DOOR SURROUND LIGHT LEFT REAR FLAP LICENSE PLATE LIGHT PSM CONTROL UNIT (RIGHT REAR OF ENGINE COMPT) REAR FLAP WARNING LAMPS RED WIRE RED/BLK WIRE RED/VIO WIRE RED/YEL WIRE RIGHT "D" PILLAR TAILLIGHT ASSEMBLY RIGHT REAR FLAP DOOR SURROUND LIGHT RIGHT REAR FLAP LICENSE PLATE LIGHT RIGHT REAR LIGHT RIGHT REAR TURN SIGNAL SPARE WHEEL LICENSE PLATE LIGHT STOPLIGHT TRAILER TOW CIRCUIT YEL WIRE
