Removing front seat
| CAUTION | Danger of injury and damage to property as a result of incorrect handling of airbag units! Always observe the safety regulations for handling airbag units. Refer to 69 AW Safety regulations for handling airbags and.. - as of MY 2003 (All Models) . The airbag unit must always be deposited so that the airbag opening faces upward! If removed for an extended period, the airbag unit must be kept in a locked place! After the battery is disconnected, always wait for 1 minute before disconnecting the airbag plugs. |
>
Note. In the case of faulty fore-and-aft or vertical adjustment, the seat can only be removed together with the seat frame. > Removing and installing front seat frame
Installation Location
Scheme 35
1. Move backrest all the way forward. Move front seat all the way up and all the way forward.
Scheme 36
2. Unlock the covers -Arrows C- and remove the rear seat rail caps -Arrows D-. (Scheme 36)
3. Unscrew rear seat rail fastening screws -3-. (Scheme 36)
Scheme 37
4. Pull out seat belt cap at the front side -A- and take out to the front -B-. (Scheme 37)
Scheme 38
5. Unlock retaining clip on the belt end fitting with a suitable screwdriver -Arrow A-. (Scheme 38)
6. Push belt end fitting over the retaining pin -Arrow B- until the lug under the retaining pin relieves the clip. (Scheme 38)
Scheme 39
7. Remove belt end fitting from the retaining pin -Arrow A- and pull seat belt out through the belt guide -Arrow B-. (Scheme 41)
8. Move the driver's seat back fully and lower rear seat area.
9. Remove ignition key. Disconnect battery. Route or isolate the ground strap so that all contact with a ground carrier (e. g. body, seat frame) is avoided. --> 90 IN Work instructions after disconnecting the battery - as of MY 2003 (All Models Except Cayenne S TIO Titan) .
Scheme 40
10. Unlock the covers -Arrow A- and remove the front seat rail caps -Arrow B-. (Scheme 40)
11. Unscrew front seat rail fastening screws -4-. (Scheme 40)
12. Tilt seat backwards.
Scheme 41
13. Unlock belt buckle connector -Arrow A- and remove -Arrow B-. (Scheme 41)
14. Unlock central connector -Arrow C- and remove -Arrow D-. (Scheme 41)
Scheme 42
15. Press protective cover on airbag plug down -Arrow A- and hold in this position. (Scheme 42)
16. Unlock airbag connector -Arrow B- and remove -Arrow C-. (Scheme 42)
Scheme 43
17. Unlock plug on seat control module -Arrow A- and remove -Arrow B-. (Scheme 43)
Scheme 44
18. Unclip the wiring harness -arrows-. (Scheme 44)
19. Remove seat.
Installing front seat
| WARNING | Incorrect information for AWS control module. Passenger's airbag is triggered differently. |
> If the passenger's seat was removed and re-installed, the AWS control module must be calibrated.
> If the seat bracket was replaced, the AWS control module must be calibrated.
> If the AWS control module was replaced, the AWS control module must be calibrated.
1. Place front seat in car and tilt backwards.
Scheme 45
2. Insert central plug -1- and belt buckle plug -2- until the locking tabs -arrow- can be heard to engage. (Scheme 45)
Scheme 46
3. Insert airbag plug -Arrow A- until the lock -B- is felt to engage. (Scheme 46)
Scheme 47
4. Insert plug into seat control module -Arrow A- until the locking tabs -B- are felt to engage. (Scheme 47)
Scheme 48
5. Clip wiring harness into place -Arrow -. (Scheme 48)
Scheme 49
6. Fold seat forward -Arrow A- and align on seat frame with centering pin -Arrow B-. (Scheme 49)
7. Connect the battery. --> 90 IN Work instructions after disconnecting the battery - as of MY 2003 (All Models Except Cayenne S TIO Titan) .
| CAUTION | Risk of material damage to screw connections for seat and seat frame! |
> The fastening screws for seat and seat frame are coated and must be replaced after being unscrewed.
> Before screwing in the new fastening screws, clean the thread holes with an M10 x 1.5 tap!
Scheme 50
8. Move front seat all the way back. Screw in front fastening screws -4- only until the seat rails touch the seat frame. (Scheme 50)
Scheme 51
9. Move front seat all the way forwards and screw seat to seat frame at rear -3- --> Tightening torque: 45 (33 ftlb.) Nm. (Scheme 51)
10. Push rear caps onto the seat rails -Arrows A- and press down the covers -Arrows B- until these are felt to engage. (Scheme 51)
Scheme 52
11. Move front seat all the way back and screw seat to seat frame at the front -4- --> Tightening torque: 45 (33 ftlb.) Nm. (Scheme 52)
12. Push front caps onto the seat rails -Arrows C- and press down the covers -Arrows D- until these are felt to engage. (Scheme 52)
Scheme 53
13. Push seat belt through the belt guide on the seat -Arrow A-. (Scheme 53)
14. Position belt end fitting on the retaining pin -Arrow B- and pull upward -Arrow C- until the retaining clip locks audibly. (Scheme 53)
Scheme 54
15. Engage seat belt cover on seat trim -Arrow A- and push in -Arrow B- until it can be felt to engage. (Scheme 54)
16. Carry out work instructions after disconnecting the battery. --> 90 IN Work instructions after disconnecting the battery - as of MY 2003 (All Models Except Cayenne S TIO Titan) .
Preliminary work
1. Remove front seat > 720119 Removing and installing front seat - "Removing" .
2. Remove AWS control module. Refer to 69 68 19 Removing and installing AWS control unit - as of MY 2006 (All Models Except Cayenne S TIO Titan) .
Scheme 55
Scheme 56
1. Lift front trim at the rear -Arrow A-, then unclip and remove it -Arrow B-. (Scheme 56)
2. Unclip and remove side trim -Arrow C-. (Scheme 56)
Scheme 57
3. Remove compressor connection.
Scheme 58
4. Fold sections of carpet forward and unscrew front fastening screws -1-. (Scheme 58)
5. Unscrew rear fastening screws -2-. (Scheme 58)
6. Remove front seat frame.
Installing front seat frame
| CAUTION | Risk of material damage to screw connections for seat and seat frame! |
> The fastening screws for seat and seat frame are coated and must be replaced after being unscrewed.
> Before screwing in the new fastening screws, clean the thread holes with an M10 x 1.5 tap!
| WARNING | Incorrect information for AWS control module. Passenger's airbag is triggered differently. |
> If the passenger's seat was removed and re-installed, the AWS control module must be calibrated.
> If the seat bracket was replaced, the AWS control module must be calibrated.
> If the AWS control module was replaced, the AWS control module must be calibrated.
Note. Calibration applies only for vehicles of MY '06 with country equipment (USA, Canada, Mexico).
1. Place front seat frame into position.
Scheme 59
2. Fold sections of carpet forward and screw in front fastening screws -1-. (Scheme 59)
3. Screw in rear fastening screws -2-. (Scheme 59)
4. Tighten fastening screws -1 and 2- to the specified tightening torque. --> Tightening torque: 45 (33 ftlb.) Nm. (Scheme 59)
Scheme 60
5. Position compressor connection -1- and tighten fastening screw -2- to the specified tightening torque. --> Tightening torque: 20 (15 ftlb.) Nm. (Scheme 60)
Scheme 61
6. Insert side trim -Arrow B-. (Scheme 61)
7. Clip front trim into place -Arrow A- until it can be felt to engage. (Scheme 61)
Subsequent work
1. Install AWS control module. Refer to 69 68 19 Removing and installing AWS control unit - as of MY 2006 (All Models Except Cayenne S TIO Titan) .
2. Install front seat > 720119 Removing and installing front seat - "Installing" .
Removing front seat trim
Installation Location
Scheme 62
Scheme 63
1. Move front seat forward until fastening screws of front trim are accessible.
2. Pull out seat belt cap at the front side -Arrow A- and take out to the front -Arrow B-. see scheme 30
Scheme 64
3. Unscrew fastening screws -arrows-. (Scheme 64)
Scheme 65
4. Fold trim outward -Arrow A-. (Scheme 65)
5. Unlock the two connectors -Arrow B- and remove from the seat adjustment switch -Arrows C-. (Scheme 65)
Note. The number of plugs can vary, depending on the equipment.
Scheme 66
6. Detach backrest cover on the outer side trim -Arrow A-. (Scheme 66)
7. Push pins of expanding clips -B- out towards the inside and remove the expanding clips. (Scheme 66)
Scheme 67
8. Pull outer side trim off belt guide.
Note. If the retaining bracket becomes loose from the side trim during removal, it must be refitted to the side trim for installation.
Scheme 68
9. Detach backrest cover on the inner side trim -Arrow A-. (Scheme 68)
10. Push pins of expanding clips -B- out towards the inside and remove the expanding clips. (Scheme 68)
Scheme 69
11. Release inner trim at front using a commercially available screwdriver -Arrow A-. (Scheme 69)
12. Pull trim at bottom outward -Arrow B- and lift it up and out -Arrow C-. (Scheme 69)
Scheme 70
1. Engage inner side trim onto the seat frame from above -Arrow A-. (Scheme 70)
2. Push lock inward -Arrow C-, then push in the trim at the bottom -Arrow B-. (Scheme 70)
Scheme 71
3. Insert expanding clips -A- and push in the pins. (Scheme 71)
4. Engage backrest cover on side trim -B-. (Scheme 71)
Scheme 72
5. Push outer side trim onto belt guide.
Scheme 73
6. Insert expanding clips -A- and push in the pins.
7. Engage backrest cover on the outer side trim -B-. (Scheme 73)
Scheme 74
8. Insert the two plugs into the seat adjuster switch -A- and swivel trim back to the installation position -B-. (Scheme 74)
Note. The number of plugs can vary, depending on the equipment.
9. Screw front trim into place -arrows-. see scheme 42
Scheme 75
10. Insert seat belt cap on the front trim -Arrow A- and push in -Arrow B- until it can be felt to engage. (Scheme 75)
Tools
Designation Type Number Explanation removal tool, universal commercially available tool NR.21
Scheme 76
Removing front backrest frame
| CAUTION | Danger of injury and damage to property as a result of incorrect handling of airbag units! Always observe the safety regulations for handling airbag units --> 69 Safety regulations for vehicles with airbags and belt tensioners. The airbag unit must always be deposited so that the airbag opening faces upward! If removed for an extended period, the airbag unit must be kept in a locked place! After the battery is disconnected, always wait for 1 minute before disconnecting the airbag plugs. |
>
Installation Location
Scheme 77
Scheme 78
1. Remove front seat > 720119 Removing and installing front seat - "Removing" [9PAAD1 9PAAD7 9PAAE1 9PAAE7 9PAAF1 9PAAJ1] .
Note. Before the battery is disconnected when removing the front seat, the seat must be moved into top position and the backrest must be tipped back by approx. 45°.
2. Remove backrest cover > 722619 Removing and installing cover for backrest - "Removing" .
3. Remove inner and outer seat trim > 721619 Removing and installing front seat trim - "Removing" .
Note. The number of plugs and wiring harnesses can vary, depending on the front seat equipment.
Scheme 79
4. Counter plastic strip -1- of spring core and use a release lever -2- removal tool, universal NR.21 to unclip wiring harnesses from the spring core -arrows-. (Scheme 78)
Scheme 80
5. Push back lock of the side airbag plug -arrow A- and remove the plug -arrow B-. Then unlock side airbag plug on the seat frame -arrow C- and push out towards the front -arrow D-. (Scheme 79)
Scheme 81
6. Unlock ground plug -1- and central plug -2- -arrows A- and remove both plugs -arrows B-. (Scheme 80)
Scheme 82
7. Unscrew inner -3- and outer -4- fastening screws. (Scheme 81)
Scheme 83
8. Using a screwdriver, lever backrest out of the centering bushings at the inner side -arrow-, turn upward and remove from the installation position. (Scheme 82)
Scheme 84
9. Hold backrest in upright position and push outer side of seat cushion inwards -arrow A-. Subsequently pull the wiring harnesses upward -arrow B- out of the seat frame. (Scheme 83)
10. Remove padding for backrest. Refer to 74 17 19 Removing and installing padding for front backrest - as of MY 2003 (All Models) .
11. Remove lumbar support > 723419 Removing and installing lumbar support - "Removing" .
12. Remove motors for lumbar adjustment > 723619 Removing and installing motor for lumbar adjustment - "Removing" .
13. Remove side airbag. Refer to 69 63 19 Removing and installing side airbag - as of MY 2003 (All Models) .
14. Remove wiring harness for backrest. Refer to 97 56 19 Removing and installing wiring for backrest - as of MY 2003 (All Models) .
Installing backrest frame
1. Install wiring harness for backrest. Refer to 97 56 19 Removing and installing wiring for backrest - as of MY 2003 (All Models) .
2. Install side airbag. Refer to 69 63 19 Removing and installing side airbag - as of MY 2003 (All Models) .
3. Install motors for lumbar adjustment > 723619 Removing and installing motor for lumbar adjustment - "Installing" .
4. Install lumbar support > 723419 Removing and installing lumbar support - "Installing" .
5. Install padding for backrest. Refer to 74 17 19 Removing and installing padding for front backrest - as of MY 2003 (All Models) .
Scheme 85
6. Engage backrest at inner side for installation of the wiring harnesses -arrow-. Make sure that the backrest cannot tilt backward or forward. (Scheme 84)
7. Push seat cushion away inward -Arrows A- .
Scheme 86
8. Push wire harnesses down through seat frame -Arrows B-. (Scheme 85)
Scheme 87
9. Engage backrest into the centering bushings at outer side -arrows- and screw in both fastening screws but do not tighten. (Scheme 86)
Note. Make sure that the plastic sleeve is inserted between the top centering bushing and the backrest.
Scheme 88
10. Using a screwdriver, lever inner side of backrest outward -Arrow A-, then shift backrest until bores engage on the centering bushings -B-. (Scheme 87)
Scheme 89
11. Screw in both fastening screws on inner side -3-, then tighten fastening screws on both sides -3, 4- --> Tightening torque: 34.5 (26 ftlb.) Nm. (Scheme 88)
Scheme 90
12. Insert ground plug of side airbag -1- and central plug of backrest -2- into seat wiring harness until they can be felt to engage. (Scheme 89)
Scheme 91
13. Clip airbag plug onto spring core -Arrow A- until lock -B- can be felt to engage. (Scheme 90)
14. Join airbag connectors -Arrow C- until the lock -D- can be felt to engage. (Scheme 91)
Scheme 92
15. Clip wiring harness into spring core -arrows-. see scheme 60
16. Install inner and outer seat trim > 721619 Removing and installing front seat trim - "Installing" .
17. Install backrest cover > 722619 Removing and installing cover for backrest - "Installing" .
Removing cover for backrest
Installation Location
Scheme 93
Scheme 94
1. Pull plastic strips on seat frame forwards and disengage -Arrow A-. (Scheme 93)
2. Disengage rubber strap on inside -Arrow B- of seat frame. (Scheme 93)
3. Using a screwdriver -C-, lever out the clip -D- and remove rubber strap from clip. (Scheme 93)
Scheme 95
4. Disengage cover at side trim on inside -Arrow A- and outside -Arrow B-. (Scheme 94)
Scheme 96
5. Pull cover rearward at the top to unclip it -Arrow A- and lift it up and out -Arrow B-. (Scheme 95)
Scheme 97
1. Engage cover on the backrest frame at the bottom -Arrow A- and push it in at the top -Arrow B- until the cover can be felt to engage. (Scheme 96)
Scheme 98
2. Engage rubber strap at the inside on the fastening clip -Arrow A- of the belt buckle cable and secure the fastening clip to the seat frame with the rubber strap -Arrow B-. (Scheme 97)
Scheme 99
3. Engage plastic strips and rubber strap on outside of seat frame -A, B-. (Scheme 98)
Scheme 100
4. Engage cover on the side trim inside and outside -A, B-. (Scheme 99)
Removing lumbar support
Installation Location
Scheme 101
1. Remove lumbar adjustment cable.
> 723619 Removing and installing motor for lumbar adjustment - "Removing"
2. Remove lumbar curvature cable.
> 723619 Removing and installing motor for lumbar adjustment - "Removing"
Note. Unclip lumbar support at top first. If the lumbar support is first disengaged at the bottom and turned towards the back, the top clips may break.
Scheme 102
3. Using a commercially available screwdriver, lever out lumbar support at the top -arrow-. (Scheme 101)
4. Fold lumbar support forward.
Scheme 103
5. Press holders together -Arrow A- and remove lumbar support from backrest frame -Arrow B-. (Scheme 102)
Installing lumbar support
1. Engage holders on one side of backrest frame.
Scheme 104
2. Push holders on opposite side inwards -Arrow A- and engage on backrest frame -Arrow B-. (Scheme 103)
Scheme 105
3. Fold lumbar support up and push into fastening clips -arrows- until they can be felt to engage. (Scheme 104)
4. Install lumbar curvature cable.
> 723619 Removing and installing motor for lumbar adjustment - "Installing"
5. Install lumbar adjustment cable.
> 723619 Removing and installing motor for lumbar adjustment - "Installing"
Installing motor for lumbar curvature
1. Install motor for lumbar curvature with holder and secure to backrest frame with pop rivets.
Scheme 106
2. Engage cable. To do this, insert the cable nipple into the opening from above -arrow A- and fold it down -arrow B-. see scheme 87
Scheme 107
3. Engage cable in the lower guide -arrows-. (Scheme 106)
Scheme 108
4. Engage the cable sleeve in the upper guide -arrow A-. (Scheme 107)
Scheme 109
5. Push the plug onto the adjusting motor -arrow- until the locks can be felt to engage. (Scheme 108)
6. Install padding for front backrest. Refer to 74 17 19 Removing and installing padding for front backrest - as of MY 2003 (All Models) .
Removing rear backrest
Installation Location
Scheme 110
Installation Location
Scheme 111
Scheme 112
1. Unlock back seats -3, 4- and fold forward by 90°. (Scheme 111)
Scheme 113
2. Only for 2/3-split folding backrest: To undo the belt fitting unscrew the fastening screw -5- and lay seat belt mount -6- to one side. (Scheme 112)
Scheme 114
3. Only for vehicles with heated seats: Release seat heating plug connection -7- -arrow A- and disconnect -arrows B-. (Scheme 113)
4. Fold backrest to the front.
4.1. Remove rear headrests, unlock backrests -1,2- and fold fully forward. (Scheme 111)
Scheme 115
5. Remove safety bracket.
5.1. Unscrew fastening screw -8- for safety bracket -9-. see scheme 97
5.2. Remove safety bracket -9-. see scheme 97
Scheme 116
6. Fold backrest -1,2- upwards 45°. (Scheme 115)
Scheme 117
7. Disengage backrest -1,2- from center bearing in -direction of arrow-. (Scheme 116)
8. Remove backrest -1,2- at outer shaft bolt -10-. (Scheme 117)
Scheme 118
Scheme 119
Note. Make sure that the bearing sleeve -11- does not become loose and tilt. (Scheme 118)
Removing bushing for center bearing
Installation Location
Scheme 120
Scheme 121
1. At the joint of bearing shells -14-, insert a screwdriver between shell and shaft bolt -13-. (Scheme 120)
Scheme 122
2. Gently push the bearing shell -14- sideways. (Scheme 121)
Scheme 123
3. Pull bearing shells -14- apart and remove. (Scheme 121)
Installing bushing for center bearing
Installation Location
Scheme 124
1. Clip in bearing shells. Place both bearing shells -14- on the shaft bolt -13-. see scheme 107
Scheme 125
2. Press together both bearing shells -14- until the locking lugs of the bearing shells are felt to snap together. (Scheme 124)
Installing rear backrest
Installation Location
Scheme 126
Scheme 127
1. Clip any bearing sleeves -12- that may have become unclipped during removal into the backrests -1,2-. (Scheme 126)
Scheme 128
Scheme 129
2. Position backrest -1,2- at an angle of 45°. (Scheme 128)
Scheme 130
3. Push backrest -1,2- onto outer bearing -10-. (Scheme 129)
Scheme 131
4. Insert center shaft bolt of backrest -13- into the center bearing in -direction of arrow-. (Scheme 130)
5. Fold backrest fully down.
Scheme 132
6. Install safety bracket.
6.1. Hook in retaining bar -9-. (Scheme 131)
6.2. Screw in fastening screw -8- on safety bracket -9- and tighten to the specified tightening torque. --> Tightening torque: 15 ftlb. +/-1.5 ftlb.. (Scheme 131)
Scheme 133
7. Fold backrests -1, 2- up fully and engage in locks. Insert rear headrests. (Scheme 132)
Scheme 134
8. Only for vehicles with heated seats: Push together the seat heating plug connection -7-, until the locking tabs can be heard to engage -arrow A-. (Scheme 133)
9. Only for 2/3-split folding backrest: Position seat belt mount -6-. (Scheme 134)
Scheme 135
10. Screw in fastening screw -5- and tighten to the specified tightening torque. --> Tightening torque: 37 ftlb. +/-3.0 ftlb.. (Scheme 134)
11. Fold back seats -3, 4- fully towards the rear and engage in locks. (Scheme 132)
| CAUTION | Safety-related bolts! Always replace fastening screws for seat belt mount after customer service and reworking. Never make alterations to the micro-encapsulated screws, which have a negative effect on the bond (e. g. using lubricant, loosening bolts and screwing them down again). |
Removing back seat
Installation Location
Scheme 136
Scheme 137
1. Unlock rear seats -1, 2- and fold up 90°. (Scheme 136)
Scheme 138
2. Only in vehicles with seat heater: Release plug -Arrow A- and pull it off -Arrow B-. (Scheme 137)
3. Unclip the connector -Arrow C-. (Scheme 137)
Scheme 139
Scheme 140
Scheme 141
4. Unscrew fastening screws -3-, -3- and -3-. (Scheme 138), (Scheme 139), (Scheme 140).
5. Remove rear seats -->. (Scheme 141)
Installing back seat
Installation Location
| CAUTION | Danger of material damage to seat bolts! |
> The fastening screws for seats are coated and must be replaced after being unscrewed.
> Before screwing in the new fastening screws, clean the thread holes with an M 10 tap!
Scheme 142
1. To position the rear seats, unfold hinge parts on the rear seats and place seats in a raised position -->. see scheme 128
Scheme 143
Scheme 144
Scheme 145
2. Screw in fastening screws -3-, -3- and -3- and tighten to the specified tightening torque. --> Tightening torque: 50 (37 ftlb.) Nm +10 (7.5 ftlb.) Nm. (Scheme 142), (Scheme 143), (Scheme 144).
Scheme 146
3. Only for vehicles with seat heater: Clip in plug -Arrow A-. (Scheme 145)
4. Push on the connector -Arrow B- until the locking tabs engage audibly -arrows-. (Scheme 145)
5. Fold down rear seats -1, 2- and lock them. (Scheme 146)
Removing lock for 1/3-split folding rear backrest
Installation Location
Scheme 147
1. Folding rear backrest forward
Scheme 148
Scheme 149
2. Remove cover for rear backrest.
2.1. Unclip cover for rear backrest -1- at fastening clips -2- -Arrows A- and pull out to the right -Arrow B-. (Scheme 148)and (Scheme 147).
Scheme 150
3. Remove cover of lock for rear backrest.
3.1. Unscrew fastening screws -4-, -5-. (Scheme 149), (Scheme 150).
3.2. Remove cover of lock for rear backrest -3- by pulling it forwards -Arrow C-. (Scheme 149)
Scheme 151
Scheme 152
4. Disengage cover piping -7- -Arrow D-. (Scheme 151)
5. Undo fastening screws -8-. (Scheme 152)
6. Pull out lock for backrest -6- -Arrow E-. (Scheme 152)
Scheme 153
Scheme 154
1. Insert lock for backrest -6- -Arrow A-. (Scheme 153)
2. Screw in fastening screws -8- and tighten to the specified torque. --> Tightening torque: 20 (15 ftlb.) Nm +/-2 (1.5 ftlb.) Nm. (Scheme 153)
3. Engage cover piping -7- -Arrow B-. (Scheme 153)
Scheme 155
4. Insert cover of lock for rear backrest -3- -Arrow C-. The release lever guides -9- must engage perfectly in the supports of the locking mechanism -10-. (Scheme 154), (Scheme 155).
Scheme 156
5. Screw in fastening screws -4-, --> Tightening torque: 4.5 (3.5 ftlb.) Nm +/-0.5 (0.5 ftlb.) Nm Screw in fastening screw -5-. --> Tightening torque: 2.5 (2.0 ftlb.) Nm +/-0.2 (0.2 ftlb.) Nm. (Scheme 156), see scheme 146.
Scheme 157
Scheme 158
6. Install cover for rear backrest.
6.1. Insert cover for rear backrest -1- -Arrow D- and clip in on the fastening clips -2- -Arrows E-. (Scheme 157), (Scheme 158).
Scheme 159
7. Fold rear backrest back.
Removing lock for 2/3-split folding rear backrest
Installation Location
Scheme 160
1. Fold rear backrest forward.
Scheme 161
2. Remove net partition: Pull net partition -1- out to the right -Arrow A-. (Scheme 160)
Scheme 162
3. Unclip cover for rear backrest -4- at fastening clips -Arrow C- and pull out to the left -Arrow D-. (Scheme 161)
Scheme 163
4. Undo fastening screws -2-. (Scheme 162)
5. Remove sliding pads for net partition -3- -Arrow B-. (Scheme 162)
Scheme 164
6. Remove retaining clips -6-. (Scheme 163)
Scheme 165
7. Remove cover of lock for rear backrest.
7.1. Unscrew fastening screws -8-, -9-. (Scheme 164)and (Scheme 165).
Scheme 166
8. Pull out cover of lock for rear backrest -7- -Arrow E-. (Scheme 166)
Scheme 167
9. Disengage cover piping -11- -Arrow F-. see scheme 157
10. Undo fastening screws -12-. see scheme 157
11. Pull out lock for backrest -10- -Arrow G-. see scheme 157
Installing lock for 2/3-split folding rear backrest
Installation Location
Scheme 168
Scheme 169
1. Install lock for rear backrest: Insert lock for backrest -10- -Arrow A-. (Scheme 168)
2. Screw in and tighten fastening screws -12-. --> Tightening torque: 20 (15 ftlb.) Nm +/-2 (1.5 ftlb.) Nm. (Scheme 168)
3. Engage cover piping -11- -Arrow B-. (Scheme 168)
Scheme 170
4. Install cover of lock for rear backrest.
4.1. Insert cover of lock for rear backrest -7- -Arrow C-. The release lever guides -13- must engage perfectly in the supports of the locking mechanism -14-. (Scheme 169), (Scheme 170).
Scheme 171
5. Screw in fastening screws -8- -9- and tighten to the specified torque. --> Tightening torque: 4.5 (3.5 ftlb.) Nm +/-0.5 (0.5 ftlb.) Nm --> Tightening torque: 2.5 (2.0 ftlb.) Nm. (Scheme 171), see scheme 163.
Scheme 172
Scheme 173
6. Insert cover for rear backrest -4- -Arrow D- and clip in at the fastening clips -Arrow E-. (Scheme 172)
Scheme 174
7. Push on retaining clips -6- - the springs -arrows- must be pointing left, to the center of the vehicle. (Scheme 173)
Scheme 175
8. Insert sliding pads for net partition -3- -Arrow F-. (Scheme 174)
9. Screw in and tighten fastening screws -2-. --> Tightening torque: 8 (6 ftlb.) Nm +/-1 (0.5 ftlb.) Nm. (Scheme 174)
Scheme 176
10. Insert net partition -1- to the left -Arrow G-. (Scheme 175)
11. Fold rear backrest back.
Removing headrest
Installation Location
Scheme 177
Scheme 178
1. Push adjusting knob -A- and pull headrest up as far as possible -Arrow B-. (Scheme 177)
2. Push limit stop in -C- and pull headrest out in upward direction -Arrow D-. (Scheme 177)
Scheme 179
1. Push headrest into headrest guides -arrow-. Push headrest down -arrow- until locking tab engages at limit stop. (Scheme 178)
1. Remove front seat trim and disconnect both plugs from seat adjustment switch. > 721619 Removing and installing front seat trim - "Removing" section
1. Install front seat trim and insert both plugs at seat adjustment switch until they can be heard to engage. > 721619 Removing and installing front seat trim - "Installing" section
1. Remove front seat. > 720119 Removing and installing front seat - "Removing" [9PAAD1 9PAAD7 9PAAE1 9PAAE7 9PAAF1 9PAAJ1]
1. Install front seat. > 720119 Removing and installing front seat - "Installing" [9PAAD1 9PAAD7 9PAAE1 9PAAE7 9PAAF1 9PAAJ1]
