Removing motor for lumbar adjustment
Installation Location
Scheme 1
Note. Before removing the motor, move the lumbar support as far down as possible in order to take the strain off the cable. If it is not possible to disengage the cable when the lumbar support is in the top position or blocked, the cable may have to be cut.
1. Remove padding for front backrest. Refer to 74 17 19 Removing and installing padding for front backrest - as of MY 2003 (All Models).
2. Remove side airbag. Refer to 69 63 19 Removing and installing side airbag - as of MY 2003 (All Models).
Scheme 2
3. Unlock -A- and unplug -B- the plugs. (Scheme 1)
Scheme 3
4. Pull cable upward and remove cable sleeve from mount -Arrow A-. (Scheme 2)
5. Disengage cable at the lumbar support -B-. (Scheme 2)
Scheme 4
6. Bore out rivets -arrows- on outside and remove motor for lumbar adjustment with holder. (Scheme 3)
Scheme 5
1. Unlock -A- and unplug -B- the plugs. (Scheme 4)
2. Remove padding for front backrest. Refer to 74 17 19 Removing and installing padding for front backrest - as of MY 2003 (All Models).
Scheme 6
3. Disengage cable sleeve -arrow A-. (Scheme 5)
Scheme 7
4. Disengage cable of lumbar curvature adjuster from the lower guide -arrows-. (Scheme 6)
Scheme 8
5. Disengage cable. To do this, fold the cable upward -arrow A- and pull it up and out -arrow B-. (Scheme 7)
Scheme 9
6. Bore out rivets -arrows- on outside and remove motor for lumbar curvature with holder. (Scheme 8)
Installing motor for lumbar adjustment
1. Install motor for lumbar adjustment with holder and secure to backrest frame with pop rivets -arrows-. (Scheme 9)
Scheme 10
2. Engage cable on lumbar support -A-. see scheme 84
3. Pull cable upward and install cable sleeve in mount -Arrow B-. see scheme 84
Scheme 11
4. Push the plug onto the adjusting motor -arrow- until the lock can be felt to engage. (Scheme 10)
5. Install side airbag. Refer to 69 63 19 Removing and installing side airbag - as of MY 2003 (All Models).
6. Install padding for front backrest. Refer to 74 17 19 Removing and installing padding for front backrest - as of MY 2003 (All Models).
Removing switch for seat adjustment
Installation Location
Scheme 12
Scheme 13
1. Unscrew fastening screws -Arrows A- and remove switch for seat adjustment -Arrow B-. (Scheme 12)
Scheme 14
1. Insert switch in front seat trim and screw it down -arrows-. (Scheme 13)
Removing motor for height adjustment
| WARNING | Danger of injury and material damage if airbag units are not handled correctly! |
> Always observe the safety regulations for handling airbag units. Refer to 69 AW Safety regulations for handling airbags and.. - as of MY 2003 (All Models).
> The airbag unit must always be stowed so that the airbag opening faces upwards!
> If removed for an extended period, the airbag unit must be kept in a locked place!
> Switch off ignition and leave ignition key in. Disconnect battery. Route or isolate the ground strap so that all contact with a ground carrier (e. g. body, seat frame) is avoided. Refer to 90 IN Work instructions after disconnecting the battery - as of MY 2003 (All Models Except Cayenne S TIO Titan).
> After the battery is disconnected, always wait for 1 minute before disconnecting the airbag plugs.
Note. Before removing the motor, move seat height up fully, then lower it slightly again so that the height adjustment is not tensioned.
Note. Only disconnect the plug axially from the positioning motor. Otherwise the retaining lugs can break off and a secure plug lock cannot be guaranteed.
Installation Location
Scheme 15
Scheme 16
1. Pull cable plug off motor.
Scheme 17
2. Unscrew the front fastening screws -Arrows 1 and 2- and place the retaining bracket with the plugs to one side. (Scheme 16)
3. Unscrew rear fastening screw -Arrow 3-. (Scheme 17)
Scheme 18
4. Unscrew both fastening screws -Arrows 4- and pull out the holder. see scheme 178
Scheme 19
5. Push motor backwards until the toothed segment is touching the bend -Arrow A- of the contour. (Scheme 18)
6. Turn rear of motor downwards -Arrow B- and remove. (Scheme 19)
Scheme 20
1. Engage motor in bend -Arrow A- of toothed segment and turn upwards at the back -Arrow B-. Make sure that the plastic bush -Arrow C- in the fastening flange of the adjusting shaft is not moved. see scheme 181
Scheme 21
2. Insert front fastening screw -Arrow 1- with the retaining bracket. (Scheme 20)
3. Screw in fastening screw -Arrow 1-, but do not tighten it. (Scheme 21)
4. Screw in fastening screw for retaining bracket -Arrow 2-, but do not tighten it. see scheme 184
Scheme 22
5. Press rear of motor upwards -Arrow A- and insert fastening screw -Arrow 3- with retaining bracket. To do this, turn adjusting shaft -Arrows B- and ensure that toothed segment of adjusting shaft fits into the drive worm of the adjusting gear. see scheme 185
Scheme 23
6. Install holder and tighten with the fastening screws -Arrows 4-. --> Tightening torque: 23 (17 ftlb.) Nm. (Scheme 22)
Scheme 24
7. Tighten fastening screws for motor -Arrows 1 and 3- and retaining bracket -Arrow 2-. --> Tightening torque: 9.7 (7.0 ftlb.) Nm --> Tightening torque: 4.5 (3.5 ftlb.) Nm. (Scheme 23)
Scheme 25
8. Push connector onto adjusting motor -arrow- until it is felt to engage. (Scheme 24)
Removing control unit for memory seat adjustment
Installation Location
Scheme 26
Scheme 27
1. Release covers -Arrows A- and remove front seat rail cover caps -Arrows B-. (Scheme 26)
2. Release covers -Arrows C- and remove rear seat rail cover caps -Arrows D-. (Scheme 27)
3. Move front left seat back and up as far as possible. Move backrest fully forward.
Scheme 28
4. Detach the front seat trim forwards -Arrow A-. see scheme 192
5. Fold the carpet sections forward and remove the two fastening screws -Arrows 1-. (Scheme 28)
6. Fold the seat back as far as possible. With the seat in its folded position, move the seat forward again using the fore-and-aft adjustment.
7. Release the connector -Arrow A- and pull it off -Arrow B-. see scheme 194
Scheme 29
8. Release the holder -Arrows A- and remove the control unit -Arrow B-. see scheme 195
Scheme 30
9. Release the connectors -Arrows A- and pull them off -Arrows B-. (Scheme 29)
Scheme 31
1. Push in the connectors -Arrows A- until the locking tabs -B- are felt to engage. (Scheme 30)
Scheme 32
2. Push control unit into rear locking tabs -Arrows A- ( -Arrow B- ). (Scheme 31)
3. Press control unit into holder -Arrow C- until the locking tabs -Arrows D- are felt to engage. (Scheme 32)
4. Push in the connector -Arrow A- until the locking tabs -Connector B- are felt to engage. see scheme 200
Scheme 33
5. Move seat in folded position backwards and fold forward.
| CAUTION | Risk of material damage to screw connections for seat and seat frame! |
> The fastening screws for seat and seat frame are coated and must be replaced after being unscrewed.
> Before screwing in the new fastening screws, clean the thread holes with an M10 x 1.5 tap!
6. Screw in fastening screws -Arrows 1- and tighten to the specified tightening torque. --> Tightening torque: 45 (33 ftlb.) Nm. see scheme 201
7. Fold back the carpet sections.
8. Clip in front seat trim -Arrow C-. (Scheme 33)
Scheme 34
9. Push rear cover caps onto seat rails -Arrows A- and press down the covers -Arrows B- until these engage audibly. see scheme 203
Note. In vehicles with an electrically adjustable steering column, the control unit for memory seat adjustment must be re-initialized and locked. > 729319 Removing and installing control unit for memory seat adjustment - "Programming"
10. Push front cover caps onto seat rails -Arrows C- and press down the covers -Arrows D- until these engage audibly. (Scheme 34)
initializing control unit for memory seat adjustment
1. Switch on ignition.
2. Use seat adjustment switch to tilt backrest completely forwards (as far as the stop).
3. Keep switch pressed in this position (approx. 5 seconds) until you hear a signal tone on the instrument cluster. The control unit is now initialized.
Locking control unit for memory seat adjustment
The Cayenne comes with either a large or small memory package, depending on the vehicle equipment. The corresponding memory package must therefore be locked in the control unit following initialization.
| CAUTION | Risk of material damage if control unit is not locked correctly |
> The control unit can be locked only once. Given this, the memory package that corresponds to the vehicle equipment must be selected before locking the control unit.
> If the small memory package is inadvertently locked on a vehicle with a large memory package, only the scope of the small memory package can be monitored (no electrical steering column or belt height adjustment monitoring!). This does not impair steering column or belt height adjustment.
Note. The control units for the driver's and front passenger's seat are identical.
- The control unit for the passenger's side is automatically coded correctly and does not need to be locked.
- The control units cannot be switched, e. g. a passenger control unit that has already been locked cannot be installed on the driver's side.
- It is not possible to switch driver's sides in vehicles with different memory packages.
| Small memory package | Large memory package | ||
|---|---|---|---|
| Setting | Driver's seat | Driver's seat | Passenger's seat |
| Fore-and-aft adjustment | X | X | X |
| Seat height | X | X | X |
| Seat angle | X | X | X |
| Backrest | X | X | X |
| Lumbar height | X | X | X |
| Lumbar curvature | X | X | X |
| Door rearview mirrors | X | X | |
| Lowering of door mirrors (passenger, only during parking maneuvers) | X | X | |
| Belt height | X | X | |
| Steering wheel height | X | ||
| Steering wheel, longitudinal setting | X | ||
| Comfort entry | X | ||
1. Connect the Porsche System Tester and switch on the ignition.
2. Select Cayenne as the vehicle type and confirm with the >> key.
3. Use the ↑↓ keys to select Driver's seat memory or Passenger's seat memory and confirm your selection by pressing >>.
4. Use the ↑↓ keys to select Large memory package or Small memory package and confirm by pressing >>.
5. Select Lock in the function selection and confirm with the F8 key.
6. To complete the locking process, switch the ignition off and on and then erase the fault memory.
