Removing selector frame Porsche Cayenne I

Automatic - Actuation, Assembly Housing 8 illustrations ~169 words

Removing selector frame

Installation Location

Scheme 104

Scheme 104: Removing selector frame
Scheme 104: Removing selector frame

Scheme 105

Scheme 105
Scheme 105

1. Remove cover of center console. To do this unscrew two screws -right arrows-, separate plug connection -inset-, tip cover up -curved arrow- and back and remove. (Scheme 104)

Scheme 106

Scheme 106
Scheme 106

2. Remove selector lever cover with special tool unlocking hook P 9713. To do this hook into the left and right of the unlocking bracket -inset- from the front and press outwards. Pull the cover upwards slightly at the same time. (Scheme 105)

3. Unlock the rear unlocking brackets in the same way.

Scheme 107

Scheme 107
Scheme 107

4. Remove selector lever cover and separate cable connection.

Scheme 108

Scheme 108
Scheme 108

5. Pull off electrical plug connections.

Scheme 109

Scheme 109
Scheme 109

6. Remove the transverse strut of the center console.

Scheme 110

Scheme 110
Scheme 110

7. Unscrew selector frame screws -arrows-. (Scheme 109)

Scheme 111

Scheme 111
Scheme 111

8. Unscrew cable fastening screw -right arrow- on the cable adjustment using special tool special inserts model AB NR.170 and remove retaining clip -left arrow-. (Scheme 110)

9. Remove selector frame.
