Connecting and disconnecting battery

> Protective goggles must be worn at all times when working on the battery.

> Do not disconnect battery with engine running.

> Disconnect and reconnect battery with extreme caution. Risk of short circuit and explosion.

> Do not tilt battery when removing it. Risk of acid burns as a result of emerging acid.

> Do not rub the battery with a dry cloth. Risk of explosion as a result of static charge.

> All loads must be switched off beforehand!

> Never start engine without securely connected battery!

> Do not use a boost charger to start the engine!

> Whenever possible, use jump leads with overvoltage protection!

> Always disconnect and cover both battery terminals before carrying out welding work on the vehicle!

> For vehicles with auxiliary battery, also disconnect and cover both terminals of this battery before carrying out welding work!

> Always pull off or push on the wiring harness plugs of control units or other electronic components when the ignition is switched off.

Note. The battery is located in the battery case under the left front seat. For vehicles with a Vehicle Tracking System (VTS), please read the --> 906323 Vehicle Tracking System (VTS) TI!

Unscrewing ground strap from body

1. Move front left seat back and up as far as possible.

Scheme 1

2. Unclip front seat trim towards the front -arrow-. (Scheme 1)

Scheme 2

3. Fold up carpeting and unscrew fastening nuts from battery ground strap on the body.

4. Route or isolate ground strap so that all contact with a ground carrier (e. g. body, seat frame) is avoided.

Screwing ground strap onto body

1. Position battery ground strap on the body and screw it on tight with the fastening nut. --> Tightening torque: 20 (15 ftlb.) Nm

Scheme 3

2. Clip in front seat trim -arrow-. (Scheme 3)

Effect of disconnection or total discharge of battery on electrical systems in the vehicle and the precautions to be taken

Note. Control unit memories Values and faults stored in the control units can be deleted if the battery is disconnected or completely discharged. If possible, all fault memories should be checked and, if necessary, printed out before the battery is disconnected.

Note. Supply voltage fault entry The entry "supply voltage" may be stored in various control units if the battery has been completely discharged. Delete the "supply voltage" entry from the control units in question.

Note. Ready status In some countries (presently the U. S. A. and Canada), after disconnecting the battery, it is necessary to reach the Ready status by a test drive and/or by using the Porsche System Tester DME control module menu). If in doubt about this, contact the relevant importer. 2470 DME control module With all DME systems, the engine must run for several minutes before the engine control module can relearn the idle speed and mixture adaptation values! After disconnection of the power supply, the idle speed might change or fluctuate briefly until the throttle valve adjusting unit has been readapted. The mixture adaptation is also lost. After the battery is connected: With the DME, it is necessary to carry out a learning and adaptation routine as described below: Switch ignition on for 30 seconds without starting the engine. Do not actuate accelerator pedal.

This completes the adaptation of the throttle valve adjusting unit.

Note. Tire pressure monitoring system When the battery is disconnected and connected, the tire pressure is first displayed as "- - - ". Once the battery has been disconnected and work is complete, the vehicle must be driven for a short distance.

The actual pressures will then be displayed again.

Note. 4560 Steering angle sensor The steering angle sensor must be re-initialized when the battery is disconnected and connected. Turn wheels to straight-ahead position. Switch ignition off and then on again twice. Start engine. From the straight-ahead position, turn steering wheel approx. 20° to the right, past the straight-ahead position. Drive the vehicle straight ahead for at least one second at a speed above 4 km/h (2.5 mph).

The steering angle sensor segment is recognized again in this process.

Once the sensor has been successfully initialized, the fault code that is stored in the fault memory is documented using the fault deletion counter. The fault memory erases itself automatically.

The PSM indicator light in the instrument cluster goes out.

Note. 6014 Electric motor for sliding roof, Panorama roof system The limit positions of the large roof are deleted from the control unit when the battery is disconnected and connected. Switch on ignition. Press rocker switch upward.

The roof opens and closes completely.

The limit positions of the large roof are now stored in the control unit again.

Note. 6452 Power windows The limit positions of the power windows are deleted from the control unit when the battery is disconnected and connected. Perform the following procedure for all power windows: Pull rocker switch and fully close window once. Pull rocker switch once more. Press rocker switch and fully open window once. Press rocker switch once more.

The upper end position of the window is stored.

The lower end position of the window is stored.

Note. 9025 Instrument cluster Clock The time is deleted when the power supply is disconnected. The clock is set in the multi-function display. Press clock button on instrument cluster. Set the time in "Hours" with rocker switch on the wiper switch. Press reset switch on the wiper switch. Set the time in "Minutes" with rocker switch on the wiper switch. Press reset switch on the wiper switch.

Effects of overvoltage on electrical and electronic systems during welding work and the precautions to be taken

> Disconnect and cover both battery terminals before carrying out welding work on the vehicle! Refer to 27 06 19 Removing and installing battery - as of MY 2003 (All Models) . Refer to 27 06 19 Removing and installing battery - as of MY 2004 (Cayenne TIP, Cayenne MAN) .

> For vehicles with auxiliary battery, also disconnect and cover both terminals of this battery before carrying out welding work! Refer to 27 07 19 Removing and installing auxiliary battery - as of MY 2003 (Cayenne TIP, Cayenne MAN, Cayenne S TIP, Cayenne S MAN, Cayenne Turbo) .

> Risk of triggering of airbag modules! Before starting welding work, the airbag triggering unit must be disconnected from the vehicle electrical system by pulling off the plug. Refer to 69 53 19 Removing and installing triggering unit for airbag - as of MY 2003 (All Models) .

> During electric arc welding (e. g. gas shielded arc welding), high currents and voltages flow; these are greater than the vehicle voltage and can lead to the damage or destruction of electrical and electronic components. To keep the risk of damage as low as possible, the ground lead must be clamped as near as possible to the welding area.

> Once complete, install the airbag triggering unit. Refer to 69 53 19 Removing and installing triggering unit for airbag - as of MY 2003 (All Models) ., then the battery. Refer to 27 06 19 Removing and installing battery - as of MY 2003 (All Models) . Refer to 27 06 19 Removing and installing battery - as of MY 2004 (Cayenne TIP, Cayenne MAN) and connect the auxiliary battery. Refer to 27 07 19 Removing and installing auxiliary battery - as of MY 2003 (Cayenne TIP, Cayenne MAN, Cayenne S TIP, Cayenne S MAN, Cayenne Turbo) .

Battery trickle charge

Note. When working or carrying out tests on the Cayenne or when it is in the workshop, a battery charging device with a rated current of at least 40 A must be connected. As soon as the vehicle is unlocked, e. g. the vehicle is in the workshop or salesroom, it must be trickle charged with a battery charging device.

Scheme 4

1. Switch off battery charging device.

2. Switch off ignition and remove ignition key.

3. Remove cover for jump lead starting terminal.

Scheme 5

4. Open protective cover on the positive terminal -+- for jump lead starting -a- .

5. First, connect the positive cable from the charging device to the positive terminal -+- for jump lead starting.

6. Connect the negative cable from the charging device to the ground point -(-)- for jump lead starting.

7. Set the charge current on the battery charging device according to the battery capacity.

8. Switch on battery charging device.

Connecting the battery for trickle charging

A suitable battery charging device must be connected to the vehicle electrical system when performing the following tasks. All unnecessary loads must be switched off.

When working on the vehicle for more than 15 minutes

When running a diagnosis using the Porsche System Tester

When adjusting the headlights

When working on or with the Infotainment system

If the doors, bonnet and rear lid are open for a long period of time or if these components are actuated frequently

Tools

Scheme 6

1. Use a plastic spatula to unclip the trim panel -a- from the upper cover at the left and right. (Scheme 6)

Scheme 7

2. Unscrew the two fastening screws -1- for instrument panel insert (cover for instrument cluster). (Scheme 7)

3. Unscrew the fastening screws for the instrument cluster -2-. (Scheme 7)

4. Press in the dashboard inset (cover for instrument cluster) at the side to unclip -arrows A-, lift the front slightly -arrow B-, and unscrew the fastening screw -3-. (Scheme 7)

Scheme 8

5. First pull the dashboard inset (cover for instrument cluster) -b- to the rear -arrow A-, then take out in an upward direction -arrow B-. (Scheme 8)

Scheme 9

1. Position dashboard inset (cover for instrument cluster) -b- into the installation position. (Scheme 9)

Scheme 10

2. Lift dashboard inset (cover for instrument cluster) slightly at the front and -arrow A- position the fastening screw -3-, but do not screw down. (Scheme 10)

3. Push the dashboard inset (cover for instrument cluster) completely to the front -arrows B- and tighten the fastening screw -3-. (Scheme 10)

4. Press the dashboard inset (cover for instrument cluster) downward and screw down the fastening screws -1 and 2-. --> Tightening torque: 1 ftlb. --> Tightening torque: 1 ftlb. (Scheme 10)

Scheme 11

5. Insert trim -a- and press against top of instrument panel insert (cover for instrument cluster) until the clips can be felt to engage. (Scheme 11)

Scheme 12

Removing instrument cluster

Remove left dashboard cover. Refer to 70 16 19 REMOVING AND INSTALLING DASHBOARD COVER ON THE DRIVER'S SIDE - AS OF MY 2003 (ALL MODELS) .

Switch off ignition and remove ignition key.

1. Use a plastic spatula to unclip the trim panel -a- from the upper cover at the left and right. see scheme 13

Scheme 13

2. Unscrew the two fastening screws -1- for dashboard insert (cover for instrument cluster). (Scheme 13)

3. Unscrew fastening screws for instrument cluster -2-. (Scheme 13)

4. Press in the dashboard insert (cover for instrument cluster) at the side to unclip -Arrows A-, lift the front slightly -Arrow B - and unscrew the fastening screw -3-. (Scheme 13)

5. First pull the dashboard insert (cover for instrument cluster) -b- to the rear -Arrow A- then remove it upwards -Arrow B-. see scheme 15

Scheme 14

6. Pull forward instrument cluster and fold forward.

7. Fold up locking mechanism -B- and pull off connectors -A-. (Scheme 14)

8. Remove instrument cluster.

Scheme 15

1. Position instrument cluster, then push on connector -A- and lock it -B- until it is felt to engage. (Scheme 15)

2. Fold back instrument cluster and position in instrument panel.

3. Place dashboard insert (cover for instrument cluster) -b- in the installation position -arrow-. see scheme 18

Scheme 16

4. Lift dashboard insert (cover for instrument cluster) slightly at the front and -Arrow A- insert the fastening screw -3- but do not screw it down. (Scheme 16)

5. Push dashboard insert (cover for instrument cluster) completely to the front -Arrows B- and tighten fastening screw -3-. (Scheme 16)

6. Press dashboard insert (cover for instrument cluster) downwards and secure with fastening screws -1 and 2- --> Tightening torque: 1.0 ftlb. --> Tightening torque: 1.0 ftlb.. (Scheme 16)

7. Insert trim panel -a- and press at top against dashboard insert (cover for instrument cluster) until the clips are felt to engage. see scheme 20

Install left dashboard cover. Refer to 70 16 19 REMOVING AND INSTALLING DASHBOARD COVER ON THE DRIVER'S SIDE - AS OF MY 2003 (ALL MODELS) .

Programming the instrument cluster

Note. In the instrument cluster is also the gateway control unit. When replacing the instrument cluster, the values read out in the Instrument cluster menu must also be written in the gateway control unit. See description of the procedure. If the control unit is replaced, it must be programmed and coded using the Porsche System Tester. This is to adapt the control unit to the vehicle and equipment. If possible, before the control unit is removed and replaced, a read-out of the vehicle data should be obtained using the Porsche System Tester. During coding, it is essential to guarantee the power supply for the Porsche System Tester. It is essential to connect a battery charger with a current rating of at least 40 A to the vehicle battery. Symbol for the Tab key = -->| The Porsche System Tester instructions take precedence and in the event of a discrepancy these are the instructions that must be followed. Deviations may occur with later software versions. The procedure described here has been structured in general terms; different texts or additions may appear in the Porsche System Tester.

1. Connect the Porsche System Tester to the vehicle and start the System Tester. Switch on ignition. >> Continue.

2. Select vehicle type using the cursor keys.

3. Using the -->| key, move from the vehicle type to the control units.

4. Select Instrument cluster with the cursor keys and press the >> key.

5. Select Control unit replacement with the cursor keys and press the >> key.

6. Select Read out values (codings) and press the >> key.

7. The message Coding read-out complete will appear on the screen of the Porsche System Tester. Press the >> key.

8. Switch off ignition and replace instrument cluster > Removing instrument cluster .

9. Switch on ignition. After replacement of the control unit, the vehicle data are installed under the menu Write in data (see Section 6). Press the >> key.

10. System Tester displays Coding write-in complete. Press the >> key.

11. Follow the instructions on the Tester.

12. Go back to the control unit overview and select Gateway control unit.

13. In the Control unit replacement menu, press >> to continue.

14. Under the menu Write in data, the data read out (see Step 6) are installed. Press the >> key.

15. System Tester displays Coding write-in complete. Press the >> key.

16. Quit menu, switch off ignition, lock then unlock vehicle and read out fault memory once more.

Designation Type Number Explanation PIWIS tester special tool P 9718

Scheme 17

Preliminary work

Remove cover under instrument panel on the passenger's side. Refer to 70 22 19 REMOVING AND INSTALLING COVER UNDER DASHBOARD - AS OF MY 2003 (ALL MODELS) .

Removing gateway control module

Installation Location

Scheme 18

Note. The gateway control module is located on the rear of the glove compartment.

1. Read out data in gateway control module. --> Programming gateway control unit .

> Switch off ignition and remove ignition key.

2. Switch off ignition and remove ignition key.

Scheme 19

3. Unclip gateway control module on glove compartment -arrows A- and remove. (Scheme 18)

Scheme 20

4. Release plug -arrow a- and unplug. (Scheme 19)

Installing gateway control module

Installation Location

Scheme 21

1. Insert the plug until it is felt to engage.

Scheme 22

2. Insert the gateway control module with the guide pin in the guide on the glove compartment and clip in.

3. Program gateway control module. --> Programming gateway control unit .

Programming gateway control module

Note. If the gateway control module is replaced, the gateway control module must be programmed or coded with the PIWIS tester. This is to adapt the Gateway control module to the vehicle and equipment. Before the gateway control module is removed, the vehicle data should be read out with the PIWIS tester if possible. If reading out the data is not possible, the new gateway control module must be coded. --> Coding gateway control unit . The power supply for the PIWIS tester must be ensured while reading out the data. It is essential to connect a battery charger with a current rating of at least 40 A to the vehicle battery. The PIWIS tester instructions take precedence and in the event of a discrepancy these are the instructions that must be followed. Deviations may occur with later software versions. The procedure described here has been structured in general terms; different text or additions may appear in the PIWIS tester.

1. Connect the PIWIS tester P 9718 to the vehicle and start it. Switch on the ignition. >> Continue.

2. Select vehicle type and continue with >>.

3. Select the gateway control module and continue with >>.

4. Select Control module replacement and continue with >>.

5. Select Read-out values and continue with >>.

6. On the screen of the PIWIS tester, the following information appears Coding read-out complete . >> continue.

7. Switch off ignition and replace Gateway control module. --> Removing gateway control module .

8. Switch on ignition, after replacing the gateway control module the read-out data are installed in the Values menu. >> continue.

9. On the screen of the PIWIS tester, the following information appears Coding write-in complete . >> continue.

10. Follow the instructions on the PIWIS tester.

11. Read out the fault memory and, if necessary, erase it.

Coding the gateway control module

Note. Coding the new gateway control module is necessary when the data of the old gateway control module cannot be read out with the PIWIS tester. --> Programming gateway control unit . During coding, it is essential to guarantee the power supply for the PIWIS tester. It is essential to connect a battery charger with a current rating of at least 40 A to the vehicle battery. The PIWIS tester instructions take precedence and in the event of a discrepancy these are the instructions that must be followed. Deviations may occur with later software versions. The procedure described here has been structured in general terms; different text or additions may appear in the PIWIS tester.

1. Connect the PIWIS tester P 9718 to the vehicle and start it. Switch on the ignition. >> Continue.

2. Select vehicle type and continue with >>.

3. Select the gateway control module and continue with >>.

4. Select coding and continue with >>.

5. Select the respective equipment versions and code them.

6. Follow the instructions on the PIWIS tester.

7. Read out the fault memory and, if necessary, erase it.

Subsequent work

Install cover under dashboard on the passenger's side. Refer to 70 22 19 Removing and installing cover under dashboard - as of MY 2003 (All Models) .

Cayenne V8

Partly remove wheel housing liner. Refer to 50 56 19 Removing and installing front wheel housing liner - as of MY 2003 (All Models) .

Remove ignition key.

Cayenne V8 Turbo

Remove front apron. Refer to 63 15 19 Removing and installing front spoiler - as of MY 2003 (All Models) .

Removing horn

Note. There is a horn at the front left and front right in the area of the fog lights.

1. Remove ignition key.

Scheme 23

2. Unscrewing fastening screw and disconnecting plug

3. Remove the horn.

Scheme 24

1. Connect the electrical plug, position the horn and secure with the fastening screw. --> Tightening torque: 15 ftlb.

Cayenne V8

Install wheel housing liner. Refer to 50 56 19 Removing and installing front wheel housing liner - as of MY 2003 (All Models) .

Cayenne V8 Turbo

Installing front apron. Refer to 63 15 19 Removing and installing front spoiler - as of MY 2003 (All Models) .

Remove cover under instrument panel on the passenger's side. Refer to 70 22 19 Removing and installing cover under dashboard - as of MY 2003 (All Models) .

Removing passenger's socket

Installation Location

Scheme 25

Scheme 26

1. Release -a- and pull off plug. (Scheme 25)

2. Open socket cover and press out the passenger's socket -arrow-. (Scheme 25)

Removing luggage compartment socket

Installation Location

1. Remove the side panel cover at the left or right.

Scheme 27

2. Release plug connection -a- and disconnect. see scheme 32

Scheme 28

3. Pull the trim towards the front and use an open-ended wrench 30 to hold the fastening nut behind the trim tight and screw the socket out.

Note. Ensure the fastening nut does not fall out behind the trim.

Note. Ensure the fastening nut does not fall out behind the trim.

4. Remove the open-ended wrench and hold the fastening nut with the hand.

5. Screw out the socket from the trim. Remove the fastening nut.

Scheme 29

1. Open the socket and insert it as far as it will go.

2. Press in the connector until it is felt to engage.

Scheme 30

1. Feed the electrical lead through the trim and slide the fastening nut behind the trim over the lead.

2. Hold the fastening nut with an open-ended wrench and screw in the socket as far as it will go -arrow-. (Scheme 29)

3. Push the electrical plug connection together until the plug is felt to engage.

4. Fit the side panel cover at the left or right.

Installing trim under instrument panel on the passenger's side. Refer to 70 22 19 Removing and installing cover under dashboard - as of MY 2003 (All Models) .

For vehicles with rear seat heating, remove the regulators for rear seat heating. Refer to 74 26 19 Removing and installing regulator for rear seat heating - as of MY 2003 (All Models) .

Removing front cigar lighter

Installation Location

Scheme 31

Scheme 32

1. Open the ashtray and remove the two fastening screws.

2. Remove the ashtray completely.

Scheme 33

Note. The front cigar lighter can only be replaced together with the ashtray.

3. Remove plug from holder, press in -a- and disconnect the electrical plug connection. (Scheme 32)

Removing rear cigar lighter

Installation Location

Scheme 34

1. Open cupholder and remove completely beyond stop.

Scheme 35

2. Open rear cigar lighter cover.

3. Reach through the cupholder compartment and press out the cigar lighter from the rear.

4. Pull out cigar lighter and release -a- and remove connector. (Scheme 34)

Scheme 36

1. Push the plug connection together until the plug is felt to engage.

2. Snap plug connection for ashtray into place.

Scheme 37

3. Insert ashtray into center console and secure with fastening screws. --> Tightening torque: 1.0 ftlb.

Scheme 38

1. Press the plug into the cigar lighter until it is felt to engage.

2. Insert cigar lighter as far as it will go and close the cover.

Scheme 39

3. Slide cupholder back into console as far as it will go.

For vehicles with rear seat heating, install the regulators for rear seat heating. Refer to 74 26 19 Removing and installing regulator for rear seat heating - as of MY 2003 (All Models) .

Poses Online
