Removing front backrest frame
| CAUTION | Danger of injury and damage to property as a result of incorrect handling of airbag units! Always observe the safety regulations for handling airbag units --> 69 Safety regulations for vehicles with airbags and belt tensioners. The airbag unit must always be deposited so that the airbag opening faces upward! If removed for an extended period, the airbag unit must be kept in a locked place! After the battery is disconnected, always wait for 1 minute before disconnecting the airbag plugs. |
>
Installation Location
Scheme 43
Scheme 44
1. Remove front seat > 720119 Removing and installing front seat - "Removing" [9PAAD1 9PAAD7 9PAAE1 9PAAE7 9PAAF1 9PAAJ1] .
Note. Before the battery is disconnected when removing the front seat, the seat must be moved into top position and the backrest must be tipped back by approx. 45°.
2. Remove backrest cover > 722619 Removing and installing cover for backrest - "Removing" .
3. Remove inner and outer seat trim > 721619 Removing and installing front seat trim - "Removing" .
Note. The number of plugs and wiring harnesses can vary, depending on the front seat equipment.
Scheme 45
4. Counter plastic strip -1- of spring core and use a release lever -2- removal tool, universal NR.21 to unclip wiring harnesses from the spring core -arrows-. (Scheme 44)
Scheme 46
5. Push back lock of the side airbag plug -arrow A- and remove the plug -arrow B-. Then unlock side airbag plug on the seat frame -arrow C- and push out towards the front -arrow D-. (Scheme 45)
Scheme 47
6. Unlock ground plug -1- and central plug -2- -arrows A- and remove both plugs -arrows B-. (Scheme 46)
Scheme 48
7. Unscrew inner -3- and outer -4- fastening screws. (Scheme 47)
Scheme 49
8. Using a screwdriver, lever backrest out of the centering bushings at the inner side -arrow-, turn upward and remove from the installation position. (Scheme 48)
Scheme 50
9. Hold backrest in upright position and push outer side of seat cushion inwards -arrow A-. Subsequently pull the wiring harnesses upward -arrow B- out of the seat frame. (Scheme 49)
10. Remove padding for backrest. Refer to 74 17 19 Removing and installing padding for front backrest - as of MY 2003 (All Models) .
11. Remove lumbar support > 723419 Removing and installing lumbar support - "Removing" .
12. Remove motors for lumbar adjustment > 723619 Removing and installing motor for lumbar adjustment - "Removing" .
13. Remove side airbag. Refer to 69 63 19 Removing and installing side airbag - as of MY 2003 (All Models) .
14. Remove wiring harness for backrest. Refer to 97 56 19 Removing and installing wiring for backrest - as of MY 2003 (All Models) .
