Seats, Frames: Adjustments Porsche Boxster 987

Removing control unit for memory seat adjustment with support

Installation Location

Scheme 3

Scheme 4

1. Unscrew the two fastening screws -1- and remove control unit for memory seat adjustment together with the support -2- from the seat frame. see scheme 56

Scheme 5

2. Unlock and pull off the three connectors on the control unit for memory seat adjustment -arrows a-. see scheme 57

Removing height adjustment lever

Installation Location

1. Press out trim panel -7- using a plastic spatula. see scheme 159

2. Unscrew fastening screw -8- from the lever -9- and remove lever. see scheme 160

Installing height adjustment lever

Installation Location

1. Position lever -9- on the seat and screw down fastening screw -8-. Tightening torque --> Tightening torque: 5.9 (4.5 ftlb.) Nm. see scheme 162

2. Press in trim panel -7-. see scheme 163

Scheme 6

1. Press the control button -1- up and maintain in this position. see scheme 164

Note. The cloth protects the collar from damage when pushing out the control button. Note that the control button will be damaged during removal. It must not be reused.

2. Insert a screwdriver -2- underneath the control button and press the control button -1- out. see scheme 164

Scheme 7

1. Press in control button -1- until it clicks into place. see scheme 165

Removing switch for seat adjustment

Installation Location

Scheme 8

Scheme 9

1. Carefully unclip the two control buttons -1- using a plastic wedge. (Scheme 13)

Scheme 10

2. Unscrew the three fastening screws -1- and remove seat adjustment switch -2-. (Scheme 14)

Scheme 11

1. Position switch for seat adjustment -2- and screw down using the three fastening screws -1-. (Scheme 15)

Scheme 12

2. Position the two control buttons -1- precisely and carefully press down onto the seat adjustment switch until they are felt to engage. (Scheme 16)

Scheme 13

Note. The assembly clip must be removed in order to install a new seat adjustment switch.

3. Use a small screwdriver to lever the assembly clip -1- out of the seat adjustment switch -2-. (Scheme 17)

Removing motor for seat adjustment

Installation Location

Scheme 14

Scheme 15

1. Unclip sleeve of long drive shaft -2- of seat adjustment motor -1- at the support. (Scheme 19)

Scheme 16

2. Press motor for seat adjustment -1- out of the support -2- at the boot -arrow A-. (Scheme 20)

3. Pull motor for seat adjustment -1- off the short drive shaft -arrow B-. (Scheme 20)

4. Pull motor for seat adjustment -1- forward under the support -2- ( -arrow C- ) and pull off connector -3- ( -arrow D- ). (Scheme 20)

Scheme 17

5. Pull motor for seat adjustment -1- and sleeve off the long drive shaft -2- ( -arrow A- ). (Scheme 21)

6. Pull the long drive shaft -2- out of the gear mount -arrow B- and check for damage. (Scheme 21)

7. Pull the short drive shaft -1- out of the gear mount -2- and check for damage. see scheme 218

Scheme 18

1. Insert the short drive shaft -1- into the gear mount -2- by twisting slightly. see scheme 219

Scheme 19

2. Insert the long drive shaft -2- into the gear mount -arrow A- by twisting slightly. see scheme 220

Note. When installing the motor for seat adjustment, make sure the two seat rails are in the same position.

3. Push motor for seat adjustment -1- and sleeve onto the long drive shaft -2- by twisting slightly -arrow A-. see scheme 220

Scheme 20

4. Attach the connector -3- to the motor for seat adjustment -1- ( -arrow A- ) until it engages firmly. (Scheme 22)

5. Push motor for seat adjustment -1- under the support -2- ( -arrow B- ). (Scheme 22)

Note. When installing the motor for seat adjustment, make sure the two seat rails are in the same position.

6. Push motor for seat adjustment -1- onto the short drive shaft by twisting slightly -arrow C-. (Scheme 22)

7. Press motor for seat adjustment -1- into the support -2- at the boot -arrow D-. (Scheme 22)

Scheme 21

8. Clip in sleeve of long drive shaft -2- of seat adjustment motor -1- on the support. (Scheme 23)

Installation Location

1. Unscrew the two fastening screws -1- and remove control unit for memory seat adjustment together with the support -2- from the seat frame. (Scheme 24)

2. Unlock and pull off the three connectors on the control unit for memory seat adjustment -arrows a-. see scheme 225

Removing motor for front vertical adjustment

Installation Location

Scheme 22

Scheme 23

1. Pull connector -1- off the motor for front vertical adjustment -3-. see scheme 227

2. Unscrew the two fastening screws -2- and remove motor for front vertical adjustment -3-. see scheme 227

3. Pull drive shaft -1- out of the gear mount -2- and check for damage. see scheme 228

Installing motor for front vertical adjustment

1. Insert the drive shaft -1- into the gear mount -2- by twisting slightly. see scheme 229

Scheme 24

2. Push motor for front vertical adjustment -3- onto the drive shaft by twisting slightly and secure with the two fastening screws -2-. --> Tightening torque: 7 (5 ftlb.) Nm. see scheme 230

3. Attach connector -1- to motor for front vertical adjustment -3- until it engages firmly. see scheme 230

Installing control unit for memory seat adjustment with support

1. Attach the three connectors on the control unit for memory seat adjustment until they are felt to engage.

2. Position control unit for memory seat adjustment with support -2- on seat frame and secure with both fastening screws -1-. see scheme 232

Removing motor for rear vertical adjustment

Installation Location

Scheme 25

1. Pull connector -1- off the motor for rear vertical adjustment -3-. (Scheme 26)

2. Unscrew the two fastening screws -2- and remove motor for rear vertical adjustment -3-. (Scheme 26)

3. Pull drive shaft -1- out of the gear mount -2- and check for damage. (Scheme 27)

Installing motor for rear vertical adjustment

1. Insert the drive shaft -1- into the gear mount -2- by twisting slightly. (Scheme 28)

2. Push motor for rear vertical adjustment -3- onto the drive shaft by twisting slightly and secure with the two fastening screws -2-. --> Tightening torque: 7 (5 ftlb.) Nm. (Scheme 29)

3. Attach connector -1- to motor for rear vertical adjustment -3- until it engages firmly. (Scheme 29)

Preliminary work for control unit for memory seat adjustment

Remove seat. > 720119 Removing and installing front seat - section on "Removing" [987120 987310 987320] > 720119 Removing and installing front seat - section on "Removing" [987121 987311 987321]

Removing control unit for memory seat adjustment

> During programming, it is essential to guarantee the power supply for the Porsche System tester. It is essential to connect a battery charger with a current rating of at least 40 A to the vehicle battery.

> Prior to disconnecting the control module, switch off the ignition and remove the ignition key.

Note. If the control unit must be replaced, first read out the values using the PIWIS Tester P 9718 .

Installation Location

Scheme 26

1. Unscrew the two fastening screws -1-. (Scheme 31)

Scheme 27

2. Release electric connectors -A- on the control unit and disconnect them. (Scheme 32)

Scheme 28

1. Insert electric connectors into control unit until they are felt to engage.

Scheme 29

2. Position control unit on the holder and screw it down using the two fastening screws -1-. (Scheme 34)

Subsequent work for control unit for memory seat adjustment

Install seat. > 720119 Removing and installing front seat - section on "Installing" [987120 987310 987320] > 720119 Removing and installing front seat - section on "Installing" [987121 987311 987321]

Removing switch for memory seat adjustment

Installation Location

Scheme 30

Scheme 31

1. Release switch for memory seat adjustment -1- at the four locking tabs -arrows a-. Swivel switch for memory seat adjustment -1- out of the door trim panel at the clip -2- in -direction of arrow-. see scheme 252

Scheme 32

2. Release connector -2- and remove it -arrow a-. Remove switch for memory seat adjustment -1-. see scheme 253

Scheme 33

1. Place switch for memory seat adjustment -1- into position and attach connector -2- until it engages correctly. see scheme 254

Scheme 34

2. Guide switch for memory seat adjustment -1- with the clip -2- into position behind the door trim panel and press down until the locking tabs -arrows- engage correctly. see scheme 255
