Brake hoses and lines
Carry out visual inspection for leaks, damage, routing and corrosion.
Technical values
| Designation | Type | Note, dimensions | Wear limit |
|---|---|---|---|
| Pad thickness, front | |||
| Boxster/Boxster S | Approx. 12 mm | Approx. 2 mm | |
| Pad thickness, rear | |||
| Boxster/Boxster S | Approx. 10.5 mm | Approx. 2 mm | |
| Brake disc thickness, new front | |||
| Boxster | 24 mm | 22 mm | |
| Boxster S | 28 mm | 26 mm | |
| Brake disc thickness, new rear | |||
| Boxster | 20 mm | 18 mm | |
| Boxster S | 24 mm | 22 mm |
Axle joints: checking play and dust boots
1. Check play.
2. Visually inspect the dust boots for damage.
Note. When doing so, the rubber dust boots should be pressed down with the fingers to reveal hidden cracks. If a rubber dust boot leaks, the corresponding joint or control arm must be replaced, because any dirt or moisture that seeps in will destroy the joint.
3. Inspect the dust boots of the axle joints (ball joints) on the wheel suspension (front and rear) as follows
- Place the vehicle on a lifting platform with the steering lock disengaged.
- Perform a visual inspection after cleaning.
Note. Over a small area in the vicinity of the brake cover panels, no visual inspection is possible. Check this area by touch.
The procedure for the front axle is as follows
- Turn the front wheels as far as they will go
- Perform a visual inspection of the visible surfaces on the left and right
- After turning the front wheels to the other steering stop, check the other half of each rubber dust boot.
Checking bellows
Note. The bellows on the steering gear can be damaged by outside influences, for example by stone damage or during assembly work. The steering gear can become leaky if dirt or moisture enters a leaky bellows.
Visually inspect bellows for damage.
Tie rod ends: check play and dust bellows
1. Raise the vehicle. Refer to 40 Tightening torques for front axle - as of MY 2005 (All Models) .
Note. The rubber dust bellows and tie rods can be damaged by external influences, e. g. stone impact, or during assembly work. If a rubber dust bellow leaks, the joint or the tie rod must be replaced because any dirt or moisture that seeps in will destroy the joint.
2. Check play and dust bellows.
3. Check dust bellows and joints are in working order and free of leaks.
Notes
Note. The engine oil and oil filter must be changed every 10,000 km (6,000 mls) in vehicles which are operated in countries where leaded fuel is used. Maintenance item > Check drive belt< must always be performed 60,000 km (40,000 mls) after replacement of the drive belt.
Tools
Designation Type Number Explanation PIWIS tester special tool P 9718
Scheme 2
Reading out and erasing fault memory
| WARNING | Sudden voltage interruption of the power supply to the control unit. Damage to control units. |
> During on-board diagnosis, it is essential to guarantee the power supply for the Porsche System Tester. A battery charger with a current rating of at least 40 A must be connected to the vehicle battery.
Scheme 3
The PIWIS tester P 9718 is connected to the vehicle via a diagnostic socket. The diagnostic socket is located inside the vehicle in the vicinity of the driver's A-pillar below the instrument panel.
1. Start the PIWIS Tester P 9718 and follow the instructions on the Tester.
2. Select vehicle type, press >> and start the automatic control unit search.
3. If an asterisk appears in front of the relevant control unit, read out the fault memory and follow the instructions on the Tester.
Note. The engine oil and oil filter must be changed every 10,000 km (6,000 mls) in vehicles which are operated in countries where leaded fuel is used. Maintenance item > Check drive belt< must always be performed 60,000 km (40,000 mls) after replacement of the drive belt.
