Test drive - maintenance
The following test items are included in the test drive.
Actuate remote control of central locking and check operation.
Seats: check operation of adjustments.
Check footbrake operation and actuation travel.
Start engine, check operation.
Actuate clutch, check operation.
Actuate steering, check operation.
Shift transmission, check operation.
ParkAssist: select reverse gear and check operation.
Activate cruise control during the test drive and check operation.
Actuate PSM switch during the test drive and check operation.
Actuate PASM switch during the test drive and check operation.
Actuate Sport switch during the test drive and check operation.
Check operation of heating adjustment when engine is warm.
Check operation of air-conditioning system when engine is running.
Check operation of instruments.
Brake system: visual inspection of the brake pads and brake discs for wear
| WARNING | Risk of accident if brake pads and/or brake discs are not replaced in time. Injury and material damage due to impaired braking effect. |
> The brake pads must be replaced when the brake pad warning indicator lights up, but no later than when there is a residual pad thickness of 2 mm.
> Brake discs must be replaced on reaching the wear limits.
Note. If brake pad wear is indicated by the warning light, the warning contact (sender including wire and plug connection) must also be replaced. Replacing the warning contact can be avoided by replacing the brake pads no later than when the pad thickness is 2.5 mm. Warning contacts must be replaced if the core of the line is worn. However, if only the plastic part of the warning contact is worn, there is no need to replace it.
1. To check the brake pads, remove the wheels. Refer to 44 05 19 Removing and installing wheel - as of MY 2005 (All Models) .
Scheme 1
2. Visually inspect the brake pads for wear -Arrows- (wear limit 2 mm). (Scheme 1)
3. Carry out a visual inspection of the brake discs for wear > 0300IN Running gear maintenance: Visual inspection of brake lines/brake pads/brake discs - section on "Technical values" .
Drive shafts: visual inspection of boots
Perform a visual inspection of the boots for leaks and damage.
