TIGHTENING TORQUES
| Location | Thread | Tightening torque Nm (ft.lb) |
|---|---|---|
| M/T Oil filler screw | M24 x 1.5 | 25 (18.5 ft.lb) |
| M/T Oil drain plug | M24 x 1.5 | 25 (18.5 ft.lb) |
TIGHTENING TORQUES SPECIFICATIONS - MANUAL TRANSMISSION (G86/00)
| Location | Thread | Tightening torque Nm (ft.lb) |
|---|---|---|
| M/T Oil filler screw | M22 x 1.5 | 30 (22 ft.lb) |
| M/T Oil drain plug | M22 x 1.5 | 30 (22 ft.lb) |
TIGHTENING TORQUES SPECIFICATIONS - MANUAL TRANSMISSION (G86/20)
Scheme 1
| Location | Thread | Tightening torque Nm (ft.lb) |
|---|---|---|
| Drainage screw on AFT pan | 40 (30 ft.lb) |
TIGHTENING TORQUES SPECIFICATIONS - ATF DRAIN SCREW
Scheme 2
| Location | Thread | Tightening torque Nm (ft.lb) |
|---|---|---|
| ATF filter screws | 6 (4.5 ft.lb.) | |
| ATF pan screws | 10 (7.5 ft.lb.) |
TIGHTENING TORQUES SPECIFICATIONS - ATF FILTER & PAN
Scheme 3
| Location | Thread | Tightening torque Nm (ft.lb) |
|---|---|---|
| Oil filler plug | 30 (22 ft.lb) |
TIGHTENING TORQUES SPECIFICATIONS - FINAL DRIVE OIL FILLER PLUG
CHECKING DOOR AND LID TIGHTENING TORQUES
- Check the tightening torque of the fastening screws of the door lock, the latch striker, the lower part of the lid lock and the upper part of the lid lock.
Fastening screws of upper part of the lid lock on front cover. See CHECKING INNER RELEASE OF LUGGAGE COMPARTMENT (TRUNK ENTRAPMENT) .
Fastening screws of lower part of the lid lock on front closing panel. See CHECKING INNER RELEASE OF LUGGAGE COMPARTMENT (TRUNK ENTRAPMENT) .
Fastening screws on door lock on the doors. See CHECKING INNER RELEASE OF LUGGAGE COMPARTMENT (TRUNK ENTRAPMENT) .
Fastening screws of latch striker on side section. See CHECKING INNER RELEASE OF LUGGAGE COMPARTMENT (TRUNK ENTRAPMENT) .
| Location | Thread | Tightening torque |
|---|---|---|
| Fastening screws of upper part of the lid lock on front cover | M6 | 10 (7.5) Nm (ft.lb) |
| Fastening screws of lower part of the lid lock on front closing panel | M6 | 10 (7.5) Nm (ft.lb) |
| Fastening screws on door lock on the doors | M8 | 20 (15) + 2 (1-5) Nm (ft.lb) |
| Fastening screws of latch striker on side section | M8 | 23 (17) Nm (ft.lb) |
TIGHTENING TORQUES SPECIFICATIONS - LUGGAGE COMPARTMENT
