Removing interior rearview mirror
Shown on 911 Turbo (996)
Scheme 23
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Secure the pliers | Set the pliers to the diameter of the window base and secure to the mirror base with the projecting plastic parts towards the windscreen. |
| 2 | Detach the mirror | Using the pliers, turn the rearview mirror 90° counter-clockwise. Then release the pliers from the mirror base. |
| 3 | Remove the mirror | Unclip the base of the interior rearview mirror from the retainer plate. Then remove the small aluminium chip in the locking area, otherwise it cannot be ensured that the mirror will be securely fit when replaced. If the mirror is being fitted for the second or third time, inspect locking area for signs of wear and replace if necessary. |
REMOVING INTERIOR REARVIEW MIRROR INSTRUCTIONS
Installing the interior rearview mirror
Shown on 911 Turbo (996)
Scheme 24
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Fit interior rearview mirror | Clip in the base of the interior rearview mirror while turned 90° counter-clockwise. |
| 2 | Fix interior rearview mirror | Secure the pliers with the projecting plastic parts to the windscreen on the mirror base. Then turn the mirror base 90° clockwise using the pliers while applying pressure to the retainer plate. The interior rearview mirror must not be turned past the locking point. Now release the pliers. |
INSTALLING INTERIOR REARVIEW MIRROR INSTRUCTIONS
Scheme 25
Scheme 26
| No. | Designation | Qty. | Removal | Installation |
|---|---|---|---|---|
| 1 | Removing lid for glove compartment | 1 | See REMOVING LID FOR GLOVE COMPARTMENT | See INSTALLING LID FOR GLOVE COMPARTMENT |
| 2 | Fastening screws | 2 | Unscrew the fastening screws -2-. (Scheme 26) | Screw in fastening screws -2-. (Scheme 26) |
| Information: The lock for the glove compartment can not be removed from the handle. | ||||
| 3 | Handle with lock for glove compartment | 1 | Remove lock for glove compartment -3-. (Scheme 26) | Position the lock for the glove compartment -3-1-2-. (Scheme 26) |
REMOVING & INSTALLING GLOVE COMPARTMENT LOCK
Scheme 27
Scheme 28
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Unscrewing the front fastening screws | Unscrew front fastening screws -1-. (Scheme 28) |
| 2 | Unscrewing fastening screws at the side | Unscrew fastening screws -1-. (Scheme 28) |
REMOVING LID FOR GLOVE COMPARTMENT INSTRUCTIONS
Scheme 29
| No. | Procedure | Instructions |
|---|---|---|
| Checking rubber stop | Before installing the glove compartment lid, check the rubber stop -2-. (Scheme 29) | |
| 1 | Screwing in the front fastening screws | Screw in front fastening screws -1-. (Scheme 29) |
| 2 | Screwing in fastening screws at the side | Screw in fastening screws -1-. (Scheme 29) |
INSTALLING LID FOR GLOVE COMPARTMENT INSTRUCTIONS
Replacing microswitch and interior light
- Replacing microswitch and interior light NOTE: In the case of a defective microswitch, the complete wiring harness -4- must be replaced! (Scheme 30) See «REMOVING GLOVE COMPARTMENT»(ref-199812-S33900167952005102000000). On the retaining bracket -2-, press the locking tabs -A- apart. Guide out the microswitch -5-. (Scheme 30) Insert a plastic spatula into the side of the interior light -1- and press out. Disconnect the electrical plug connection. (Scheme 30) 2 - Installing microswitch and interior light Plug in the electrical plug connection of the interior light -1-. Press the interior light -1- into the cut-out of the glove compartment. (Scheme 30) Press the microswitch -5- into the retaining bracket -2-. Note the coding of the microswitch. (Scheme 30) To fit the glove compartment, engage the electrical lead -4- into the clip -3-. (Scheme 30) See «INSTALLING GLOVE COMPARTMENT»(ref-199812-S19728393732005102000000).
Replacing pneumatic shock absorber
- Removing the pneumatic shock absorber Press the pneumatic shock absorber -1- out of the fastening tab -arrow B-. Turn the pneumatic shock absorber by 90° anti-clockwise in the direction of arrow -A- and guide it out of the glove compartment. (Scheme 31) 2 - Installing the pneumatic shock absorber Insert the pneumatic shock absorber -1- and turn it 90° clockwise in the direction of arrow -A-. Insert the pneumatic shock absorber into the fastening tab towards the -direction of arrow B-. (Scheme 31)
Scheme 30
Scheme 31
Scheme 32
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Unclipping plastic clips | Unclip plastic clips -2--arrows-. (Scheme 33) |
| 2 | Unscrewing the rear fastening screws | Unscrew fastening screws -3-. (Scheme 33) |
| 3 | Unscrewing the front fastening screws | Unscrew fastening screws -4-. (Scheme 33) |
| 4 | Disconnecting the electrical plug connection | Disconnect the electrical plug connection in the -direction of the arrow-. (Scheme 33) |
| 5 | Removing the glove compartment | Lift the glove compartment upwards -arrow--1-. (Scheme 33) |
REMOVING GLOVE COMPARTMENT INSTRUCTIONS
Scheme 33
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Connect electrical plug connection | Connect the electrical plug connection in the -direction of the arrow-. (Scheme 34) |
| 2 | Installing glove compartment | Swivel the glove compartment into the dashboard in the -direction of the arrow--A-. (Scheme 34) |
| 3 | Screwing in the front fastening screws | Screw in the fastening screws -4-. (Scheme 34) |
| 4 | Screwing in the rear fastening screws | Screw in the fastening screws -3-. (Scheme 34) |
| 5 | Fitting the plastic clips | Position the insulation, making sure that the corners are inserted correctly under the dashboard. Press in plastic clips -2-. (Scheme 34) |
INSTALLING GLOVE COMPARTMENT INSTRUCTIONS
Bonding on the interior rearview mirror
The following materials are required to bond on the complete interior mirror
Scheme 34
* = Porsche part number
Scheme 35
Note. When using the primer, the drying time of 15 - 20 minutes must be observed! When using the activator, the drying time of 2 minutes must be observed! During adhesion, observe the press-on duration of 40 - 50 seconds! The bonding strength is 60% after one hour. 100% bonding strength is reached after 24 hours of curing time!
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Mark the position of the interior mirror | Mark the position of the bonding plate on the outside of the windscreen. -A--B-. (Scheme 36) Dimension -A--B-. (Scheme 36) |
| Remove adhesive residues | Remove adhesive residues from the windscreen mechanically using a scraper. Remove adhesive residues on the bonding plate of the interior mirror mechanically using a scraper. | |
| 2 | Sand the bonding plate of the interior mirror flat | Sand the bonding plate of the interior mirror flat mechanically using 100 grain sandpaper. |
| Clean the bonding plate of the interior mirror | Clean the bonding plate of the interior mirror with cleaning solution (A). | |
| Clean the bonding area on the windscreen | Clean the bonding area on the windscreen with cleaning solution (A). | |
| 3 | Mask the bonding area on the windscreen | Mask the bonding area on the windscreen with primer template (cover film C). The marking for the position of the interior mirror must be visible in the centre of the primer template. |
| 4 | Prime the bonding area on the windscreen | Treat the masked bonding area on the windscreen thinly and evenly using primer (B). |
| 5 | Activate the bonding area on the windscreen | Spray activator (D) onto the bonding area of the windscreen. |
| Remove the primer template | ||
| 6 | Apply adhesive to the bonding plate | Apply a drop of adhesive (E) to the bonding plate of the interior mirror. |
| 7 | Stick on the interior mirror | Press the interior mirror with the bonding plate onto the primed and activated area of the windscreen. |
BONDING ASSEMBLED INTERIOR MIRROR ONTO WINDSCREEN INSTRUCTIONS
Scheme 36
Scheme 37
| CAUTION | Danger of damage if windstop parts are not fitted correctly. Windstop parts must always be fitted or engaged correctly, especially when driving with the convertible-top open. |
| No. | Designation | Qty. | Removal | Installation |
|---|---|---|---|---|
| 1 | Left outer windstop part | 1 | Press outer windstop parts -1-. (Scheme 38) | Insert outer windstop parts -1-. (Scheme 38) |
| 2 | Right outer windstop part | 1 | Press outer windstop parts -2-. (Scheme 38) | Insert outer windstop parts -2-. (Scheme 38) |
| 3 | Centre windstop part | 1 | Open one of the two locking levers on the windstop -3-arrow--3-. (Scheme 38) | First insert into the central mount, then engage the two upper fastening points. |
REMOVING & INSTALLING WINDSTOP
Installing locking bracket and holder
- Installing locking bracket Position the left or right locking bracket -A- on the roll-over bar and rivet in place with tubular rivets. (Scheme 38)
- Installing holder. Position the holder -B- on the roll-over bar and rivet in place with tubular rivets. (Scheme 38)
Scheme 38
Removing cup holder
- Removing cup holder Refer to «DISASSEMBLING AND ASSEMBLING THE INSTRUMENT PANEL»(ref-199814-S40796100602005102000000) . Press metal clip -1- -arrow- and hold. Pull the cup holder -2- out of the retaining bracket -3- .
Scheme 39
Installing cup holder
- Installing cup holder Push cup holder -2- into the shaft of the retaining bracket -3- . Make sure that the metal clip -1- engages. Refer to «DISASSEMBLING AND ASSEMBLING THE INSTRUMENT PANEL»(ref-199814-S40796100602005102000000) .
Scheme 40
Scheme 41
Scheme 42
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Unclip mirror insert -3-. (Scheme 43) | Insert a narrow screwdriver between the mirror insert -3-2-. (Scheme 43) |
| 2 | Remove mirror insert -3-. (Scheme 43) | Pull the mirror insert -3-2-. (Scheme 43) |
| 3 | Remove bulb -5-4-. (Scheme 43) | Remove the Sofitte 12V/3W bulb -5-4-. (Scheme 43) |
| 4 | Unclip mirror housing -2-. (Scheme 43) | Insert a narrow plastic spatula between the mirror housing -2-1-. (Scheme 43) |
| 5 | Remove mirror housing -2-. (Scheme 43) | Take the electric lead out of the mirror housing -2-. (Scheme 43) |
DISASSEMBLING SUN VISOR INSTRUCTIONS
Scheme 43
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Insert mirror housing -2-. (Scheme 44) | Insert electric lead into the mirror housing -2-. (Scheme 44) |
| 2 | Press in mirror housing -2-. (Scheme 44) | Press the mirror housing -2-. (Scheme 44) |
| 3 | Insert contact clips -4-5-. (Scheme 44) | Position the contact clips -4-5-. (Scheme 44) |
| 4 | Position mirror insert -3-. (Scheme 44) | Position the lugs on the left and right of the mirror insert -3-2-. (Scheme 44) |
| 5 | Clip in mirror insert -3-. (Scheme 44) | Clip the mirror insert -3-2-. (Scheme 44) |
ASSEMBLING SUN VISOR INSTRUCTIONS
Scheme 44
Scheme 45
| No. | Designation | Qty. | Removal | Installation |
|---|---|---|---|---|
| 1 | Cover, front left | 1 | Unclip the front left cover -1-. (Scheme 46) | Position the front cover -1-15-3-. (Scheme 46) |
| 2 | Cover, front right | 1 | Unclip the front right cover -2-. (Scheme 46) | Position the front cover -2-15-3-. (Scheme 46) |
| 3 | Clip | 10 | Inspect clip -3-. (Scheme 46) | |
| 4 | Cover cap (telephone trim panel) | 1 | ||
| 5 | Fastening screw | 9 | ||
| 6 | Telephone trim panel | 1 | Insert a wire into the hole of the cover cap -4-5-8-. (Scheme 46) | Insert the locking tabs of the telephone trim panel into the front cover -8-5-2.3 Nm (1.5 ftlb.)-4-. (Scheme 46) |
| 7 | Installation frame for (telephone handset) | 1 | ||
| 8 | Cover, front left (telephone carrier) | 1 | Unscrew fastening screws -5-. (Scheme 46) | Position cover at the centre console at the front, clip in at the side and fasten with the fastening screws -5-2.3 Nm (1.5 ftlb.)-. (Scheme 46) |
| 9 | Adapter | 1 | Unscrew fastening screws -5-. (Scheme 46) | Position the adapter at the centre console at the front -9-5-2.3 Nm (1.5 ftlb.)-. (Scheme 46) |
| 10 | Combi-single CD drive for navigation | 1 | See: Refer to REMOVING AND INSTALLING THE NAVIGATION UNIT | |
| 11 | Heating/air-conditioning control | 1 | See: Refer to Removing and installing the heating/air-conditioning control | |
| 12 | Front trim | 1 | Unclip the front trim -12-. (Scheme 46) | Connect the electrical connection, position the front trim -12-15-. (Scheme 46) |
| 13 | Cover, left | 1 | Unclip the left cover -13-. (Scheme 46) | Position the right cover -13-3-. (Scheme 46) |
| 14 | Cover, right | 1 | Unclip the right cover -14-. (Scheme 46) | Position the right cover -14-3-. (Scheme 46) |
| 15 | Centre console (front section) | 1 | Undo fastening screws -5-15-. (Scheme 46) | Position the front of the centre console -15-18-5-. (Scheme 46) |
| 16 | Plug-in nut | 4 | Inspect and replace if necessary. | |
| 17 | Collar nut | 4 | Tightening torque: -10 Nm (7.5 ftlb.) | |
| 18 | Holder | 1 |
REMOVING & INSTALLING CENTER CONSOLE (FRONT SECTION)
Scheme 46
Removing sun visors
- Detaching sun visor Unclip cover -1- with a screwdriver and unscrew the fastening screw -2- . Pull off the sun visor -3- from the bearing pedestal towards the centre of the car.
Scheme 47
Installing sun visors
- Fitting sun visor Insert sun visor -3- into the bearing pedestal. Position sun visor -3- and screw down using the fastening screw -2- . Press in cover -1- until it engages.
Scheme 48
Scheme 49
Scheme 50
Note. Before removal of the centre console, the centre console (front) must be partly disassembled. For this purpose, remove both the front covers and the front trim. See REMOVING AND INSTALLING CENTER CONSOLE (FRONT SECTION) .
| No. | Designation | Qty. | Removal | Installation |
|---|---|---|---|---|
| 1 | Shift lever knob | 1 | Disengage from the clips -2-1-. (Scheme 51) | Push on. |
| 2 | Clip | 4 | Inspect and replace if necessary. | |
| 3 | Fastening screws | 3 | Undo. | Screw in. |
| 4 | Ashtray insert | 1 | Lift out. | Press in. |
| 5 | Expanding nut | 2 | Press out. | Press in. |
| 6 | Ashtray retaining bracket | 1 | Unclip the ashtray retaining bracket -6-. (Scheme 51) | Connect the electrical plug connections, secure the ashtray retaining bracket -6-3-. (Scheme 51) |
| 7 | Rubber insert | 1 | ||
| 8 | Floor oddments tray | 1 | Undo fastening screw -3-8-. (Scheme 51) | Position the floor oddments tray -8-3-. (Scheme 51) |
| 9 | Coin box | 1 | Unclip the coin box -9-3-. (Scheme 51) | Tighten the fastening screw -3-9-. (Scheme 51) |
REMOVING & INSTALLING CENTER CONSOLE
Scheme 51
Scheme 52
| No. | Designation | Qty. | Removal | Installation |
|---|---|---|---|---|
| 1 | Cover, front left | 1 | Unclip. | Clip in. |
| 2 | Clip | 28 | Inspect and replace if necessary | |
| 3 | Cover, centre left | 1 | Unclip. | Clip in. |
| 4 | Fastening screws | 3 | ||
| 5 | Lock support | 1 | ||
| 6 | Plastic nuts | 7 | ||
| 7 | Microswitch | 1 | From the console -8-inset A--7-. (Scheme 53) | Clip the microswitch -7-8-. (Scheme 53) |
| 8 | Console | 1 | Press the locking tabs of the console -8-inset B--5-. (Scheme 53) | Position console -8-5-. (Scheme 53) |
| 9 | Lock barrel | 1 | Press in the locking tabs in -inset C--9-5-. (Scheme 53) | Press the lock barrel -9-5-. (Scheme 53) |
| 10 | Cover, rear left | 1 | Unclip. | Clip in. |
DISASSEMBLING & ASSEMBLING CENTRE CONSOLE - AS OF MY 1996
Scheme 53
| No. | Designation | Qty. | Removal | Installation |
|---|---|---|---|---|
| 1 | Fastening screws | 8 | Unscrew tightening torque (Torx): 0.9 Nm (0.5 ftlb.). | |
| 2 | Cover, oddments tray | 1 | ||
| 3 | Lower section of oddments tray cover | 1 | ||
| 4 | Plug-in nut | 8 | Inspect and replace if necessary. | |
| 5 | Hinge pin | 1 | Press the hinge pin out -5-3-. (Scheme 54) | Position lower section of oddments tray cover -3-5-. (Scheme 54) |
DISASSEMBLING & ASSEMBLING COVER FOR ODDMENTS TRAY
Scheme 54
Scheme 55
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Undoing fastening screws -2-. (Scheme 56) | Lift rubber mat -2-3-. (Scheme 56) |
| 2 | Removing sill -1-. (Scheme 56) | Lift sill -1-4-. (Scheme 56) |
REMOVING INNER SILL INSTRUCTIONS
Scheme 56
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Putting on sill -1-. (Scheme 57) | Clip in new fastening clips -4-1-. (Scheme 57) |
| 2 | Fastening sill -1-. (Scheme 57) | Screw in fastening screws -3-2-. (Scheme 57) |
INSTALLING INNER SILL INSTRUCTIONS
Scheme 57
Scheme 58
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Undoing hexagon socket head bolts -2-. (Scheme 59) | Remove plastic plugs -3-2-. (Scheme 59) |
| 2 | Removing sill -1-. (Scheme 59) | Lift sill -1-4-. (Scheme 59) |
| 3 | Pulling off plug connections -5, 6-. (Scheme 59) | Pull off plug connections -5, 6-. (Scheme 59) |
| 4 | Removing actuating switches of front lid -7, 8-. (Scheme 59) | Press the fastening ribs of the sill -arrows-7-. (Scheme 59) |
DISASSEMBLING RELEASE FOR FRONT LID INSTRUCTIONS
Scheme 59
| No. | Procedure | Instructions |
|---|---|---|
| 1 | Installing actuating switches of front lid -7-. see scheme 39 | Clip the actuating switches of the front lid -7-. see scheme 39 |
| 2 | Joining plug connections -5, 6-. see scheme 39 | Push plug connections -5, 6-. see scheme 39 |
| 3 | Putting on sill -1-. see scheme 39 | Clip in new fastening clips -4-1-. see scheme 39 |
| 4 | Tightening hexagon socket head bolts -2-. see scheme 39 | Screw in hexagon socket head bolts -2-3-. see scheme 39 |
ASSEMBLING RELEASE FOR FRONT LID INSTRUCTIONS
