Scheme 1
Scheme 1: REMOVING AND INSTALLING CURRENT DISTRIBUTOR
Scheme 2
Scheme 2: REMOVING CURRENT DISTRIBUTOR
| No. | Procedure | Instructions |
|---|
| Disconnect battery | Remove the battery cover and the cover of the right radiator tank. Removing and installing cowl panel cover. Refer to REMOVING AND INSTALLING COWL PANEL COVER . Refer to WORK INSTRUCTIONS AFTER DISCONNECTING THE BATTERY . Disconnect and cover the ground terminal on the battery |
| 1 | Current distributor fastening | Pull off the covering cap -1-2-3- (1) |
| 2 | Cover in passenger's footwell | Unscrew both plastic screws -4-5- (1) |
| 3 | Lowering the current distributor | Disconnect the tie-wrap -7-6-6-A-arrow- (1) |
| 4 | Opening the current distributor | Disengage the lock -arrow-8-green-red-blue- (1) |
| 5 | Disconnecting the connection lines | Mark the connection lines -C-C-B-9- (1) |
| (1) (Scheme 2) |
CURRENT DISTRIBUTOR REMOVAL SEQUENCE
