Engine Control System & Fuel System - 2.4L (Lax) - Introduction: Specifications Pontiac Vibe II

Testing & Diagnostics 10 illustrations

Ignition System Specifications

ApplicationSpecification
MetricEnglish
Firing Order1-3-4-2
Spark Plug Torque25 N.m18 lb ft
Spark Plug Gap1.0-1.2 mm0.040-0.048 in
Spark Plug TypeSK20R11 DENSO / IFR6A11 NGK

Ignition System Specifications

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Accelerator Cable Adjusting Locknut8 N.m71 lb in
Accelerator Cable Attaching Fastener2 N.m18 lb in
Accelerator Cable-to-Bulkhead Fastener15 N.m11 lb ft
Accelerator Pedal Bracket Fastener5 N.m44 lb in
Accelerator Pedal Cable-to-Bulkhead Fastener15 N.m11 lb ft
Camshaft Position (CMP) Actuator Solenoid Valve Fastener9 N.m80 lb in
Camshaft Position (CMP) Actuator Solenoid Valve Oil Filter Plug30 N.m22 lb ft
Camshaft Position (CMP) Sensor Fastener9 N.m80 lb in
Crankshaft Position (CKP) Sensor Fastener9 N.m80 lb in
Engine Coolant Temperature (ECT) Sensor20 N.m15 lb ft
Engine Cover Plate Fastener7 N.m62 lb in
Evaporative Emission (EVAP) Canister Support Bracket-to-Chassis Fastener19 N.m14 lb ft
EVAP Canister Bracket Fastener8 N.m71 lb in
EVAP Vacuum Leak Pump Assembly Fastener8 N.m71 lb in
EVAP/Fuel Pipe Protector Fasteners1.2-2 N.m11-18 lb in
Fuel Filler Pipe Bracket Fastener30 N.m22 lb ft
Fuel Filler Pipe-to-Fuel Filler Pipe Bracket Fasteners6 N.m53 lb in
Fuel Injector Wire Harness Cover Plate Fastener16 N.m12 lb ft
Fuel Pipe Front Bulkhead Support Fastener6 N.m53 lb in
Fuel Rail Fastener19 N.m14 lb ft
Fuel Rail Inlet Pipe Hold Fastener9 N.m80 lb in
Fuel Sender Assembly Hold Down Plate Fastener6 N.m53 lb in
Fuel Sender Assembly Protective Cover Fastener6 N.m53 lb in
Fuel Tank Access Panel Fasteners6 N.m53 lb in
Fuel Tank - Rear Exhaust Heat Shield Fastener5.4 N.m48 lb in
Fuel Tank Retaining Strap Fastener39 N.m29 lb ft
Heated Oxygen Sensor (HO2S) 144 N.m32 lb ft
Heated Oxygen Sensor (HO2S) 244 N.m32 lb ft
Idle Air Control (IAC) Fasteners3.7 N.m33 lb in
Ignition Coil Fastener9 N.m80 lb in
Knock Sensor (KS)20 N.m15 lb ft
Mass Air Flow (MAF) Sensor Fasteners2.0 N.m18 lb in
Negative Battery Cable Terminal Retainer Fastener15 N.m11 lb ft
Parking Brake Cable Fasteners5.4 N.m48 lb in
Powertrain Control Module (PCM) Mounting Fastener15 N.m11 lb ft
Power Steering Pressure (PSP) Switch21 N.m15.5 lb ft
Spark Plug25 N.m18 lb ft
Throttle Body/Accelerator Cable Bracket Fastener13 N.m9.5 lb ft
Throttle Body Fasteners, with Throttle Actuator Control (TAC) System9 N.m80 lb in
Throttle Position (TP) Sensor Fasteners2.0 N.m18 lb in

Scheme 64

Scheme 64: Evaporative Emissions Hose Routing Diagram
Scheme 64: Evaporative Emissions Hose Routing Diagram
CalloutComponent Name
1EVAP Canister
2Fill Limiter Vent Valve (FLVV)
3EVAP Canister Air Filter
4Purge Line from Canister
5EVAP Canister Purge Solenoid Valve
6Fuel Filler Cap
7Fuel Filler Pipe Check Valve
8Purge Line to Engine
9Throttle Body
10Air Cleaner
11Fuel Tank
12Fuel Sender Assembly
13ORVR Vent Line

Scheme 65

Scheme 65: Engine Controls Schematics
Scheme 65: Engine Controls Schematics

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73
