Frame and Underbody: Specifications — Pontiac Vibe I рестайлинг (2002-2008)

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Transmission Support Bolt (Front)	39 N.m	29 lb ft
Transmission Support Bolt (Rear)	52 N.m	38 lb ft
Transmission Mount Nut (Rear)	52 N.m	38 lb ft
Transmission Mount Nut (Front)	52 N.m	38 lb ft

Fastener Tightening Specifications

Scheme 1: Underbody Dimensions 2-Wheel Drive

Measurement Points	Distance from Centerline	Measurement Points	Distance from Vertical Imaginary Standard Line
1, 13	435 mm (17.13 in)	1, 13	0.0 mm (0.0 in)
2, 12	614 mm (24.17 in)	2, 12	407 mm (16.02 in)
3, 11	512 mm (20.16 in)	3, 11	599 mm (23.58 in)
4	238 mm (9.37 in)	4	920 mm (36.22 in)
5, 8	437 mm (17.20 in)	5, 8	1125 mm (44.29 in)
6, 7	464 mm (18.27 in)	6, 7	1596 mm (62.83 in)
9	72 mm (2.83 in)	9	1002 mm (39.45 in)
10	265 mm (10.43 in)	10	920 mm (36.22 in)
17	626 mm (24.65 in)	17	1539 mm (60.59 in)
15, 27	445 mm (17.52 in)	15, 27	1258 mm (49.53 in)
23, 20	330 mm (12.99 in)	20, 15	1501 mm (49.53 in)
19	485 mm (19.09 in)	19	2064 mm (81.26 in)
24	500 mm (19.69 in)	24	2064 mm (81.26 in)
21	80 mm (3.15 in)	21	2162 mm (85.12 in)
22	20 mm (0.79 in)	22	2162 mm (85.12 in)
20	465 mm 18.31 in)	20	2349 mm (92.48 in)
23	486 mm (19.13 in)	23	2347 mm (92.40 in)
26	456 mm (17.95 in)	26	1542 mm (60.71 in)

Underbody Dimensions 2-Wheel Drive (1 of 2)

Measurement Points	Distance Between Control Points	Measurement Points	Distance Between Control Points
1-2	455 mm (17.91 in)	18-16	839 mm (33.03 in)
1-12	1129 mm (44.85 in)	25-28	840 mm (33.07 in)
1-13	870 mm (34.25 in)	15-27	890 mm (35.04 in)
2-12	1228 mm (48.35 in)	26-17	912 mm (35.91 in)
2-5	754 mm (29.69 in)	21-17	730 mm (28.74 in)
5-7	1018 mm (40.08 in)	27-19	1252 mm (49.29 in)
2-9	909 mm (35.79 in)	24-15	1263 mm (49.72 in)
2-4	657 mm (25.87 in)	26-22	786 mm (30.94 in)
3-11	1023 mm (40.28 in)	24-19	985 mm (38.78 in)
5-6	473 mm (18.62 in)	23-20	953 mm (37.52 in)
5-12	1282 mm (50.47 in)	5, 8	874 mm (34.41 in)
6-7	929 mm (36.57 in)	10-12	641 mm (25.24 in)
9-12	805 mm (31.69 in)	13-29	1223 mm (48.15 in)
29, 1	860 mm (33.86 in)	27, 29	400 mm (15.75 in)
14-29	870 mm (34.25 in)	14-27	966 mm (38.03 in)
14-26	1135 mm (44.69 in)	0-0	0 mm (0.0 in)

Underbody Dimensions 2-Wheel Drive (2 of 2)

Scheme 2: Underbody Dimensions All-Wheel Drive

Measurement Points	Distance from Centerline	Measurement Points	Distance from Vertical Imaginary Standard Line
1, 14	435 mm (17.13 in)	1, 13	0.0 mm (0.0 in)
2, 13	614 mm (24.17 in)	2, 12	407 mm (16.02 in)
3, 12	621 mm (24.45 in)	3, 12	544 mm (21.42 in)
4, 11	476 mm (18.74 in)	4, 11	760 mm (29.92 in)
5	238 mm (9.37 in)	5	920 mm (36.22 in)
6, 9	437 mm (17.20 in)	6,9	1125 mm (44.29 in)
7, 8	464 mm (18.27 in)	7, 8	1596 mm (62.83 in)
10	265 mm (10.43 in)	10	920 mm (36.22 in)
15, 26	435 mm (17.13 in)	15, 26	860 mm (33.86 in)
16, 25	445 mm (17.52 in)	16, 25	1258 mm (49.53 in)
17	626 mm (24.65 in)	17	1539 mm (60.59 in)
18	485 mm (19.09 in)	18	2064 mm (81.26 in)
19	465 mm (18.31 in)	19	2349 mm (92.48 in)
20	80 mm (3.15 in)	20	2162 mm (85.12 in)
21	20 mm (0.79 in)	21	2162 mm (85.12 in)
22	486 mm (19.13 in)	22	2347 mm (92.40 in)
23	500 mm (19.69 in)	23	2064 mm (81.26 in)
24	456 mm (17.95 in)	24	1542 mm (60.71 in)

Underbody Dimensions All-Wheel Drive (1 of 2)

Measurement Points	Distance Between Control Points	Measurement Points	Distance Between Control Points
1-2	455 mm (17.91 in)	18-16	839 mm (33.03 in)
1-13	1129 mm (44.85 in)	23-25	840 mm (33.07 in)
1-14	870 mm (34.25 in)	16-25	890 mm (35.04 in)
2-13	1228 mm (48.35 in)	24-17	912 mm (35.91 in)
2-6	754 mm (29.69 in)	20-17	730 mm (28.74 in)
6-8	1018 mm (40.08 in)	25-18	1252 mm (49.29 in)
2-9	1282 mm (50.47 in)	23-16	1263 mm (49.72 in)
2-5	657 mm (25.87 in)	24-21	786 mm (30.94 in)
4-11	952 mm (37.48 in)	23-18	985 mm (38.78 in)
6-7	473 mm (18.62 in)	19-22	953 mm (37.52 in)
3-12	1243 mm (48.94 in)	6, 9	874 mm (34.41 in)
7-8	929 mm (36.57 in)	10-12	641 mm (25.24 in)
13-10	641 mm (25.24 in)	14-26	1223 mm (48.15 in)
26, 1	860 mm (33.86 in)	25, 26	400 mm (15.75 in)
15-26	870 mm (34.25 in)	15-25	966 mm (38.03 in)
15-24	1135 mm (44.69 in)	0-0	0 mm (0.0 in)

Underbody Dimensions All-Wheel Drive (2 of 2)

Scheme 3: Front Body Dimensions

Measurement Points	Distance Between Control Points	Measurement Points	Distance Between Control Points
1-7	624 mm (24.57 in)	4-24	1410 mm (55.51 in)
1-9	834 mm (32.83 in)	5-23	1383 mm (54.45 in)
1-17	849 mm (33.43 in)	6-22	1307 mm (51.46 in)
1-21	647 mm (25.47 in)	7-25	1022 mm (40.24 in)
2-4	278 mm (10.94 in)	8-20	1469 mm (57.83 in)
2-13	946 mm (37.24 in)	10-14	514 mm (20.24 in)
2-19	1375 mm (54.13 in)	11-14	387 mm (15.24 in)
2-22	1514 mm (59.61 in)	11-15	800 mm (31.50 in)
3-21	1038 mm (40.87 in)	12-14	500 mm (19.69 in)
3-25	1023 mm (40.28 in)	12-15	827 mm (32.56 in)
3-26	1240 mm (48.82 in)	12-18	788 mm (31.02 in)
13-26	1365 mm (53.74 in)	14-15	441 mm (17.36 in)
14-16	581 mm (22.87 in)	14-18	542 mm (21.34 in)
19-26	941 mm (37.05 in)	0-0	0 mm (0 in)

Front Body Dimensions

Scheme 4: Body Side Dimensions

Measurement Points	Distance Between Control Points	Measurement Points	Distance Between Control Points
2-3	1118 mm (44.02 in)	21-22	1418 mm (55.83 in)
3-22	1086 mm (42.26 in)	23-24	1418 mm (55.83 in)
4-5	1216 mm (47.87 in)	25-18	1004 mm (39.53 in)
6-7	1215 mm (47.83 in)	26-5	1255 mm (49.41 in)
7-11	664 mm (26.14 in)	26-20	803 mm (31.61 in)
7-13	915 mm (36.02 in)	26-26	1397 mm (55.00 in)
8-9	1114 mm (43.86 in)
9-15	1086 mm (42.76 in)	29-1	1548 mm (60.94 in)
10-11	1204 mm (47.40 in)	29-28	1431 mm (56.34 in)
11-17	1078 mm (42.44 in)	30-1	1118 mm (44.02 in)
12-13	1405 mm (55.31 in)	30-29	892 mm (35.12 in)
14-15	1418 mm (55.83 in)	31-32	1343 mm (52.87 in)
15-11	1120 mm (44.09 in)	32-5	862 mm (33.94 in)
16-17	1406 mm (55.35 in)	32-20	900 mm (35.43 in)
17-13	616 mm (24.25 in)	32-22	900 mm (35.43 in)
19-20	1412 mm (55.39 in)

Body Side Dimensions

Scheme 5: Rear Body Dimensions

Measurement Points	Distance Between Control Points
2-14	1090 mm (42.91 in)
6-1	961 mm (37.83 in)
7-13	1631 mm (64.21 in)
11-4	1429 mm (56.26 in)
12-3	1262 mm (49.69 in)
10-7	1074 mm (42.28 in)
8-1	1204 mm (47.40 in)
13-10	1163 mm (45.79 in)

Rear Body Dimensions
