Engine Cooling System: Specifications Pontiac Vibe I рестайлинг

Cooling System (Mechanical) 3 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Radiator Drain Plug13 N.m9 lb in
Radiator Fan To Fan Motor Bolts6 N.m53 lb in
Radiator Fan To Fan Shroud Assembly Bolts3 N.m34 lb in
Radiator Fan Blade Nut6 N.m53 lb in
Radiator Upper Support Bracket Bolts19 N.m14 lb ft
Thermostat Housing Nuts10 N.m7 lb ft
Water Pump Bolts
LNK9 N.m80 lb in
LV6
1.18 in bolt9 N.m80 lb in
1.38 in bolt11 N.m8 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Engine Cooling Schematics
Scheme 1: Engine Cooling Schematics

Scheme 2

Scheme 2: Cooling System Component Views
Scheme 2: Cooling System Component Views
CalloutComponent Name
1Cooling Fan
2Cooling Fan Electrical Connector

Scheme 3

Scheme 3
Scheme 3
CalloutComponent Name
1No. 1 Fan Relay
2No. 2 Fan Relay
