Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Manual Selector Retaining Nuts | 12 N.m | 106 lb in |
| Shift Lock Control Module Retaining Bolt | 6 N.m | 53 lb in |
| Shift Lock Solenoid Retaining Bolt | 6 N.m | 53 lb in |
Fastener Tightening Specifications
Scheme 36
Scheme 36: Automatic Transmission Shift Lock Control Schematics
Scheme 37
Scheme 37: Automatic Transmission Shift Lock Control Component Views
| Callout | Component Name |
|---|
| 1 | Shift Lock Overdrive Switch |
| 2 | Shift Lock Solenoid and Shift Lock Electronic Control Unit |
| 3 | Shift Lock Cable |
| 4 | Stop Light Switch |
