Scheme 1
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | I/P Trim |
| 2 | Console Arm Rest |
| 3 | Cigar Lighter |
| 4 | Shift Lock Control Solenoid |
Scheme 3
| Connector Part Information OEM: 12124037 Service: 12101858 Description: 2-Way F Metri-Pack 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Torque Converter Clutch Pressure Control Solenoid Valve Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | PK/BK | 5292 | Ignition 1 Voltage |
| B | D-GN/WH | 428 | EVAP Canister Purge Solenoid Control |
Torque Converter Clutch Pressure Control Solenoid Valve Connector Terminal Identification
Scheme 4
| Connector Part Information OEM: 7183-7192-30 Service: See Catalog Description |
|---|
| Terminal Part Information Pins: 5, 6, 7, 8, 11, 12, 14 Terminal/Tray: 7116-4720-02/14 Core/Insulation Crimp: J/J Release Tool/Test Probe: 15315247/J-35616-64B (L-BU) Pins: 1, 9 Terminal/Tray: 7116-4103-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-2A (GY) |
Transmission Control Module Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | RD/WH | 540 | Battery Positive Voltage |
| 5 | OG/BK | 1786 | Park/Neutral Signal Ignition Lock Cylinder Control Actuator Signal (2003 and later) |
| 6 | TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
| 7 | TN | 2501 | High Speed GMLAN Serial Data Bus |
| 8 | TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
| 9 | BK/WH | 451 | Ground |
| 11 | PK | 1339 | Ignition 1 Voltage |
| 12 | BN | 4 | Accessory Voltage |
| 14 | TN | 2501 | High Speed GMLAN Serial Data Bus |
Transmission Control Module Connector Terminal Identification
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: Listen for an audible click when the automatic transmission shift lock control solenoid operates. Command both the ON and OFF states. Repeat the commands as necessary.
- 3: This step tests for a good ground at the ground circuit of the automatic transmission shift lock control solenoid.
- 4: This step verifies that the BCM is providing battery voltage to the automatic transmission shift lock control solenoid.
- 5: This step tests if battery voltage is constantly being applied to the automatic transmission shift lock control solenoid.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Shift Lock Control Schematics Connector End View Reference: Shift Lock Control Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, command the Shift Lock Solenoid output control ON and OFF. Does the automatic transmission shift lock control solenoid turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the automatic transmission shift lock control solenoid. Connect a test lamp between the shift lock control solenoid ground circuit at the connector of the shift lock control solenoid and battery positive voltage. Does the test lamp illuminate? | Go to Step 4 | Go to Step 10 |
| 4 | Turn OFF the ignition. Connect a test lamp between the shift lock solenoid control circuit and the shift lock solenoid ground circuit at the connector of the shift lock control solenoid. With a scan tool, command the Shift Lock Solenoid output control ON and OFF several times. Does the test lamp turn ON and OFF with each command? | Go to Step 8 | Go to Step 5 |
| 5 | Does the test lamp remain illuminated? | Go to Step 6 | Go to Step 7 |
| 6 | Test the control circuit of the automatic transmission shift lock control solenoid for a short to battery voltage. Refer to Circuit Testing and Wiring Repairs. Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 7 | Test the control circuit of the automatic transmission shift lock control solenoid for an open or short to ground. Refer to Circuit Testing and Wiring Repairs. Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 8 | Inspect for poor connections at the harness connector of the automatic transmission shift lock control solenoid. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs. Did you find and correct the condition? | Go to Step 13 | Go to Step 11 |
| 9 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs. Did you find and correct the condition? | Go to Step 13 | Go to Step 12 |
| 10 | Repair the open in the automatic transmission shift lock control ground circuit. Refer to Circuit Testing and Wiring Repairs. Did you complete the repair? | Go to Step 13 | |
| 11 | Replace the automatic transmission shift lock control solenoid. Refer Shift Control Replacement . Did you complete the replacement? | Go to Step 13 | |
| 12 | Replace the BCM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 13 | |
| 13 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC, as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B2705
Symptoms - Automatic Transmission Shift Lock Control
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Automatic Transmission Shift Lock Control Description and Operation. |
See also:
• Shift Control Replacement
