Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Shift Lever Does Not Move with Brake Pedal Depressed
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Shift Lock Control Schematics Connector End View Reference: Shift Lock Control Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Turn ON the ignition, with the engine OFF. Apply the parking brake and block the wheels. Press and hold the brake pedal. Attempt to move the shift lever out of the PARK position. Does the shift lever move out of the PARK position? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 |
| 3 | Turn OFF the ignition. Install a scan tool. Turn ON the ignition, with the engine OFF. Press and release the brake pedal several times while observing the Shift Lock Solenoid Command parameter in the body control module (BCM) data list. Does the scan tool display On and Off status? | Go to Step 4 | Go to Step 6 |
| 4 | Turn OFF the ignition. Disconnect the electrical connector of the automatic transmission shift lock control solenoid. Turn ON the ignition, with the engine OFF. Press and hold the brake pedal. Attempt to move the shift lever out of the PARK position. Does the shift lever move out of the PARK position? | Go to Step 5 | Go to Step 7 |
| 5 | Test the control circuit of the automatic transmission shift lock control solenoid for a short to battery positive voltage. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 11 | Go to Step 8 |
| 6 | Press and release the brake pedal several times while observing the BPP Circuit Signal parameter in the engine control module (ECM) data list. Does the Scan tool display Applied and Released status of the parameter? | Go to Step 8 | Go to Stop Lamps Inoperative |
| 7 | Inspect for poor connections at the harness connector of the automatic transmission shift lock control solenoid. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 11 | Go to Step 9 |
| 8 | Inspect for poor connections at the harness connector of the BCM. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 11 | Go to Step 10 |
| 9 | Replace the automatic transmission shift lock control solenoid. Refer Shift Control Replacement . Did you complete the replacement? | Go to Step 11 | |
| 10 | Replace the BCM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 11 | |
| 11 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
Shift Lever Does Not Move with Brake Pedal Depressed
Shift Lever Can Be Moved without Brake Pedal Depressed
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Shift Lock Control Schematics Connector End View Reference: Shift Lock Control Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, command the Shift Lock Solenoid output control ON and OFF. Does the automatic transmission shift lock control solenoid turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the automatic transmission shift lock control solenoid. Connect a test lamp between the shift lock control solenoid ground circuit at the connector of the shift lock control solenoid and battery positive voltage. Turn ON the ignition, with the engine OFF. Does the test lamp illuminate? | Go to Step 4 | Go to Step 10 |
| 4 | Turn OFF the ignition. Connect a test lamp between the shift lock solenoid control circuit and the shift lock solenoid ground circuit at the connector of the shift lock control solenoid. With a scan tool, command the Shift Lock Solenoid output control ON and OFF several times. Does the test lamp turn ON and OFF with each command? | Go to Step 8 | Go to Step 5 |
| 5 | Does the test lamp remain illuminated? | Go to Step 6 | Go to Step 7 |
| 6 | Test the control circuit of the automatic transmission shift lock control solenoid for a short to battery voltage. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 7 | Test the control circuit of the automatic transmission shift lock control solenoid for an open or short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 9 |
| 8 | Inspect for poor connections at the harness connector of the automatic transmission shift lock control solenoid. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 11 |
| 9 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 13 | Go to Step 12 |
| 10 | Repair the open in the automatic transmission shift lock control ground circuit. Refer to Circuit Testing and Wiring Repairs . Did you complete the repair? | Go to Step 13 | |
| 11 | Replace the automatic transmission shift lock control solenoid. Refer Shift Control Replacement . Did you complete the replacement? | Go to Step 13 | |
| 12 | Replace the BCM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 13 | |
| 13 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
Shift Lever Can Be Moved without Brake Pedal Depressed
Scheme 5
| Callout | Component Name |
|---|---|
| Preliminary Procedures Remove the console side trim panel. Refer to Front Floor Console Side Trim Panel Replacement - Right Side . Disconnect the brake transaxle shift interlock (BTSI) solenoid electrical harness connector. | |
| 1 | Brake Transaxle Shift Interlock Solenoid Retainer |
| 2 | Brake Transaxle Shift Interlock Solenoid |
Shift Lock Solenoid/Switch Assembly Replacement
Automatic Transmission Shift Lock Control System
The automatic transmission shift lock control system is a safety device that prevents an inadvertent shift out of PARK when the engine is running. The driver must press the brake pedal before moving the shift lever out of the PARK position. The system consists of the following components
- The automatic transmission shift lock control solenoid
- The body control module (BCM)
- The engine control module (ECM)
The BCM controls the voltage to the supply circuit of the shift lock control solenoid. The following conditions must be met before the BCM will supply voltage to the shift lock control solenoid
- The ignition is in the ON position.
- The ECM sends an input via GMLAN serial data to the BCM indicating the transmission is in the PARK position.
- The BCM determines the brake pedal is applied according to the brake pedal position sensor.
Since the shift lock control solenoid is permanently grounded, the BCM supplies voltage to the automatic transmission shift lock control solenoid, mechanically unlocking the shift lever allowing the driver to move the shift lever out of the PARK position as the solenoid energizes. When the brake pedal is not applied, the BCM turns the control voltage output of the shift lock control solenoid OFF, de-energizing the shift lock control solenoid. The de-energized solenoid mechanically locks the shift lever in the PARK position.
