Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Condenser Bolt/Nut (2.4L) | 6 N.m | 53 lb in |
| Condenser-to-Radiator Bolt | 6 N.m | 53 lb in |
| Coolant Crossover Pipe Bolt (3.9L) | 50 N.m | 37 lb ft |
| Coolant Heater (3.5L and 3.9L) | 60 N.m | 44 lb ft |
| Coolant Heater Bolt (2.4L) | 10 N.m | 89 lb in |
| Exhaust Heat Shield Bolt (2.4L) | 23 N.m | 17 lb ft |
| Lower Radiator Support Bracket Bolt | 60 N.m | 44 lb ft |
| Radiator Surge Tank Pipe Bolt (3.9L) | 10 N.m | 89 lb in |
| Thermostat Bypass Pipe-to-Engine Front Cover Bolt (3.5L) | 11 N.m | 98 lb in |
| Thermostat Bypass Pipe-to-Throttle Body Nut (3.5L) | 25 N.m | 18 lb ft |
| Thermostat Housing Bolt (2.4L) | 10 N.m | 89 lb in |
| Thermostat Housing Bolt/Stud (3.5L and 3.9L) | 25 N.m | 18 lb ft |
| Thermostat Housing Cover Bolt (2.4L) | 10 N.m | 89 lb in |
| Transmission Oil Cooler Pipe Attachment Nut | 7 N.m | 62 lb in |
| Upper Radiator Support Bracket Bolt | 10 N.m | 89 lb in |
| Water Pump Access Plate Bolt (2.4L) | 10 N.m | 89 lb in |
| Water Pump Bolt (2.4L, 3.5L and 3.9L) | 25 N.m | 18 lb in |
| Water Pump Pulley Bolt (3.5L and 3.9L) | 25 N.m | 18 lb ft |
| Water Pump Sprocket Bolt (2.4L) | 10 N.m | 89 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Engine Cooling Schematics
Scheme 2
Scheme 3
Scheme 3: Cooling System Component Views
| Callout | Component Name |
|---|
| 1 | Cooling Fan - Left |
| 2 | Cooling Fan - Right |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Coolant Level Switch |
| 2 | Battery |
| 3 | Electronic Brake Control Module (EBCM) |
| 4 | C101 |
| 5 | G103 |
| 6 | Fuse Block - Underhood |
| 7 | Powertrain Control Module (PCM) |
| 8 | Powertrain Control Module (PCM), C3 |
| 9 | Powertrain Control Module (PCM), C2 |
| 10 | Powertrain Control Module (PCM), C1 |
Scheme 5
Scheme 5: Coolant Level Switch
| Connector Part Information OEM: 12052641 Service: 12102747 Description: 2-Way F Metri-Pack 150 Series Sealed (BK) |
Cooling System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK | 350 | Ground |
| B | L-GN | 1478 | Coolant Level Switch Signal |
Scheme 6
Scheme 6: Cooling Fan - Left
| Connector Part Information OEM: 12033769 Service: 12101917 Description: 2-Way F Metri-Pack 630 Series Sealed Pull-to-Seat (BK) |
Cooling System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | WH | 504 | Cooling Fan Low Reference |
| B | L-BU | 409 | Cooling Fan Motor Supply Voltage |
