Engine/vin Breakdown: Overview Pontiac Bonneville X

Application 2 illustrations

General Motors Introduction - Cars

MODELBODY CODEENGINE (RPO CODE) (1)ENGINE IDFUEL SYSTEMIGNITION SYSTEM
AleroN2.2L (L61)FSFIDIS
3.4L (LA1)ESFIDIS
AuroraG3.5L (LX5)HSFIDIS
4.0L (L47)CSFIDIS
BonnevilleH3.8L (L36)KSFIDIS
3.8L (L67)1SFI (2)DIS
CamaroF3.8L (L36)KSFIDIS
5.7L (LS1)GSFIDIS
CavalierJ2.2L (LN2)4SFIDIS
2.2L (L61)FSFIDIS
2.2L (LN2/KL6) (3)4SFIDIS
2.4L (LD9)TSFIDIS
CenturyW3.1L (LG8)JSFIDIS
CorvetteY5.7L (LS1)GSFIDIS
5.7L (LS6)SSFIDIS
DeVilleK4.6L (LD8)YTPI-SFIDIS
4.6L (L37)9TPI-SFIDIS
EldoradoE4.6L (LD8)YTPI-SFIDIS
4.6L (L37)9TPI-SFIDIS
FirebirdF3.8L (L36)KSFIDIS
5.7L (LS1)GSFIDIS
Grand AmN2.2L (L61)FSFIDIS
3.4L (LA1)ESFIDIS
Grand PrixW3.1L (LG8)JSFIDIS
3.8L (L36)KSFIDIS
3.8L (L67)1SFI (2)DIS
ImpalaW3.4L (LA1)ESFIDIS
3.8L (L36)KSFIDIS
IntrigueW3.5L (LX5)HSFIDIS
LeSabreH3.8L (L36)KSFIDIS
MalibuN3.1L (LG8)JSFIDIS
Monte CarloW3.4L (LA1)ESFIDIS
3.8L (L36)KSFIDIS
Park AvenueC3.8L (L36)KSFIDIS
3.8L (L67)1SFI (2)DIS
PrizmS1.8L (LV6)8SFIDIS
RegalW3.8L (L36)KSFIDIS
3.8L (L67)1SFI (2)DIS
Saturn ("L" Series)J2.2L (L61)FSFIDIS
3.0L (L81)RSFIDIS
Saturn ("S" Series)Z1.9L (L24)8SFIDIS
1.9L (LL0)7SFIDIS
SevilleK4.6L (LD8)YTPI-SFIDIS
4.6L (L37)9TPI-SFIDIS
SunfireJ2.2L (LN2)4SFIDIS
2.2L (L61)FSFIDIS
2.4L (LD9)TSFIDIS
(1) Engine code is stamped on engine block. See ENGINE CODE LOCATION . (2) Supercharged engine. (3) Flex-fuel engine.
(1)Engine code is stamped on engine block. See ENGINE CODE LOCATION .
(2)Supercharged engine.
(3)Flex-fuel engine.

2002 MODEL COVERAGE

Scheme 1

Scheme 1

Scheme 2

Scheme 2
