Engine/vin Breakdown: Component Locations Pontiac Bonneville X

ENGINE CODE LOCATION

Note. For description of engine (RPO) code, see 2002 MODEL COVERAGE table.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. LA1 & LG8 On left side of engine block, on engine-to-transmission mating flange, OR on top front of engine block, near timing chain housing. (Scheme 3)
2. LS1, LS6 & L81 On left side of engine block, on engine-to-transmission mating flange. (Scheme 4)or (Scheme 5).
3. LD8 & L37 On right front side of engine block, on cam cover, OR on right front side of engine block, forward of transmission extension. (Scheme 6)
4. LD9, LN2, LN2/KL6 & L61 On left rear side of engine block. (Scheme 7)or (Scheme 8).
5. LL0 & L24 On left rear side of engine block.
6. LX5& L47 On right front side of engine block, near oil pan. (Scheme 9)
7. LV6 On right rear side of engine block. (Scheme 10)
8. L36 & L67 Right rear of engine, under exhaust manifold near bellhousing/engine mating surface. (Scheme 11)
