Shift Interlock System: Overview — Pontiac Aztek I (2001-2005)

Shift Interlock System: Overview Pontiac Aztek I

Automatic Trans 7 illustrations ~132 words

Scheme 713

Scheme 713: Automatic Transmission Shift Lock Control Schematics (Pontiac)

Scheme 714

Scheme 714: Automatic Transmission Shift Lock Control Schematics (Buick)

Scheme 715

Scheme 715: Center Console - Pontiac

Scheme 716

Scheme 716: Steering Column - Buick

Scheme 717

Scheme 717: A/T Shift Lock Control Solenoid - Pontiac

Scheme 718

Scheme 718: A/T Shift Lock Control Solenoid - Buick

Test Description

The numbers below refer to the step numbers on the diagnostic table.

2. Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
5. The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.

Scheme 719

Symptoms - Automatic Transmission Shift Lock Control

Important: Review the system operation in order to familiarize yourself with the system functions. Refer to AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL DESCRIPTION AND OPERATION .
