TORQUE CONVERTER
Remove torque converter and turbine shaft "O" ring seal. (Scheme 1) Install Holding Fixture (J-28664-B) onto transaxle. (Scheme 2) Install transaxle and holding fixture into Base (J-3289-20). Insert pin into base to hold transaxle in desired position.
Scheme 1
Scheme 1: TORQUE CONVERTER
Scheme 2
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Case Cover Bolt (1) |
| Bolt No. 3 | 18 (25) |
| Bolts No. 1, 2 & 4 | (2) |
| Case Extension Bolt | 26 (35) |
| Case Side Cover Bolt (3) | 18 (25) |
| Control Valve Body Bolt (4) |
| Bolts No. 1-5 | (2) |
| Bolt No. 6 | 12 (16) |
| Bolt No. 7 | 18 (25) |
| Bolt No. 8 | (5) |
| Bolt No. 9 | (2) |
| Drive Sprocket Support Bolt | 18 (25) |
| Manual Shaft-To-Detent Lever Nut | 24 (32) |
| Oil Cooler Fitting | 28 (38) |
| Shift Shaft Nut | 23 (31) |
| Transfer Case-To-Transaxle Bolt |
| Bolts No. 1 & 2 | (6) |
| Bolt No. 3 | (7) |
| Bolts No. 4 & 5 | 30 (40) |
| Transfer Case Lower Brace-To-Transaxle Bolt | 23 (31) |
| Transfer Case Lower Brace-To-Transaxle Lower Bolt | 42 (56) |
| Transfer Case Side Brace Bolt | 23 (31) |
| 2-1 Manual Band Servo Cover Bolt | 18 (25) |
| INCH Lbs. (N.m) |
| Accumulator Bolt | 106 (12) |
| Accumulator Cover-To-Case Bolt | 106 (12) |
| Forward Band Servo Cover Bolt | 106 (12) |
| Manual Valve Shift Detent Bolt | 106 (12) |
| Oil Pan Bolt | 120 (14) |
| Oil Pressure Test Plug | 106 (12) |
| Oil Pump Bolt (8) |
| Bolt No. 1 | 71 (8) |
| Bolts No. 2 & 3 | 106 (12) |
| Vehicle Speed Sensor Bolt | 106 (12) |
| (1) see scheme 65 (2) Tighten bolts to 106 INCH lbs. (12 N.m). (3) see scheme 45 (4) See VALVE BODY BOLT SPECIFICATIONS table. (5) Tighten bolts to 71 INCH lbs. (8 N.m). (6) Tighten bolts in 2 passes, 1st pass 26 ft. lbs. (35 N.m) and 2nd pass an additional 160 degrees. (7) Tighten bolt in 2 passes, 1st pass 26 ft. lbs. (35 N.m) and 2nd pass an additional 70 degrees. (8) See OIL PUMP BOLT SPECIFICATIONS table. |
| (2) | Tighten bolts to 106 INCH lbs. (12 N.m). |
| (4) | See VALVE BODY BOLT SPECIFICATIONS table. |
| (5) | Tighten bolts to 71 INCH lbs. (8 N.m). |
| (6) | Tighten bolts in 2 passes, 1st pass 26 ft. lbs. (35 N.m) and 2nd pass an additional 160 degrees. |
| (7) | Tighten bolt in 2 passes, 1st pass 26 ft. lbs. (35 N.m) and 2nd pass an additional 70 degrees. |
| (8) | See OIL PUMP BOLT SPECIFICATIONS table. |
TRANSAXLE SPECIFICATIONS
| Application | End Play - In. (mm) |
|---|
| Differential Carrier Planetary Pinion Gears | .009-.025 (.23-.64) |
| Front Differential Carrier | .005-.025 (.13-.64) |
| Input Carrier Pinion Gears | .009-.030 (.23-.76) |
| Input Clutch Housing | 0-.006 (0-.15) |
| Reaction Carrier Pinion Gear | .009-.030 (.23-.76) |
| Torque Converter | 0-.020 (0-.50) |
