Maintenance Information Pontiac 6000 I

Procedures 7 illustrations ~2857 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation (1 Of 2). Scheme 1

Scheme 1: VIN Code ID Explanation (1 Of 2)
Scheme 1: VIN Code ID Explanation (1 Of 2)

VIN Code ID Explanation (2 Of 2). Scheme 2

Scheme 2: VIN Code ID Explanation (2 Of 2)
Scheme 2: VIN Code ID Explanation (2 Of 2)

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (4 Miles Or Less)
  2. When Most Trips Are Less Than 10 Miles And Outside Temperatures Remain Below Freezing.
  3. Towing Or Heavily Loaded
  4. Severe Dust Conditions
  5. Hot Weather, Stop-And-Go Driving
  6. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Severe Service Operating Conditions

Scheme 3

Scheme 3: SERVICE POINT LOCATIONS
Scheme 3: SERVICE POINT LOCATIONS

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: INFORMATION LABEL LOCATIONS
Scheme 5: INFORMATION LABEL LOCATIONS

Scheme 6

Scheme 6
Scheme 6

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

The tire specification decal is located on rear of the driver's door.

WHEEL TIGHTENING

Tighten all standard wheel lug nuts to 100 ft. lbs. (135 N.m).

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

1983-90

Models with VIN Code "R" and Heavy Duty models use Group 75A-72 batteries. Models with VIN Code "T" and "W" use Group 75-60 batteries.

1991

2.5L and 3.1L engines use Group 75-630 batteries.

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

REPLACING BLOWN FUSES

CAUTIONBefore replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER (GASOLINE MODELS)

CAUTIONTo prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) or Ethylene-Glycol -35° F (-37°C) - 263° F (128°C).
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

DIESEL FUEL ANTI-FUNGAL ADDITIVES

CAUTIONIf fuel contamination due to fungi or other microorganisms is suspected a fuel additive with a biocide may be used. Follow the manufacturers dosage as recommended on product label. Use biocides ONLY when necessary, excessive use can may cause other fuel system problems.

DIESEL FUEL CONTAMINATION

WARNINGDiesel fuel system may be contaminated with fungi or other microorganisms. Keep contaminated fuel away from open skin cuts or sores to prevent skin irritation or infection.

DIESEL FUEL REQUIREMENTS

CAUTIONAll diesel engines are to use Diesel Fuel #2 when the outside temperature is above 20°F (-7°C). In temperatures that are below 20°F (-7°C) use Diesel Fuel #1, this will reduce the chance of the fuel thickening and forming wax.

Note: A Diesel Fuel #1 and #2 combination (Blended Fuel) may be used, and is recommended for mild winter driving.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BUMPER TO BUMPER PLUS COVERAGE LIMITED WARRANTY

Everything covered for 3 years or 50,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts by the Dealer. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first. Maintenance items are covered up to their first scheduled replacement interval only.

CORROSION COVERAGE

Covers any body sheet metal panel that rusts through due to corrosion. Begins at warranty start date and lasts 6 years or 100,000 miles, whichever occurs first (with no deductible).

EMISSIONS DEFECT WARRANTY (EXCEPT CALIFORNIA)

Warrants that the vehicle is free from defects in materials and workmanship which cause the car to fail to conform with EPA regulations for a period of use of 5 years or 50,000 miles, whichever occurs first. Begins on the date the car is delivered to the first retail purchaser. Emission related defects in the genuine GM components listed below including reasonable related diagnostic costs, are covered by this warranty

  1. Engine Control Module, Associated Sensors And Parts
  2. Fuel Injection System
  3. Thermostatic Air Cleaner System
  4. Ignition Parts And Associated Controls, Including Spark Plugs And Ignition Wires
  5. Catalytic Converter And Associated Parts
  6. Positive Crankcase Ventilation (PCV) Valve And Associated Parts
  7. Exhaust Gas Recirculation (EGR) Valve And Associated Controls
  8. Air Pump, Air Distributor And Valves
  9. Vapor Storage Canister And Associated Controls, Fuel Tank Filler Cap And Restrictor
  10. Miscellaneous Items Used In The Above Systems Such As Hoses, Clamps, Belts, Pulleys, Tubes, Fittings, Mounting Hardware, Sealing Devices, Etc.

EMISSIONS PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)

Owner may be eligible for Emissions Performance Warranty if all of the following conditions apply

  1. Vehicle has been maintained in accordance with the instructions for proper maintenance and use set forth in Owner's Manual.
  2. Vehicle fails to conform for a period of 5 years or 50,000 miles whichever occurs first, to the applicable emission standards of the U.S. Environmental Protection Agency, as judged by an EPA-approved I/M test.
  3. The failure to conform results or will result in the owner of the vehicle having to bear a penalty or other sanctions under local, state or federal law.

If these conditions are met, GM warrants that dealer will replace, repair or adjust to GM specification, at no charge, any of the above listed components which may be necessary to cause your car to conform to applicable emission standards. Non-GM parts labeled "Certified to EPA Standards" are also covered by this warranty.

EMISSIONS PERFORMANCE WARRANTY (CALIFORNIA)

Warrants that the car is free from defects in materials and workmanship which cause the car to fail to pass a California smog check test for a period of 3 years or 50,000 miles, whichever occurs first. Dealer will replace, repair or adjust to GM specification any genuine GM components which may be necessary to ensure that your car passes the smog test.

EMISSIONS DEFECT WARRANTY (CALIFORNIA)

Warrants that specific emission-related parts (listed above) are free from defects in materials and workmanship for a period of 7 years or 70,000 miles, whichever occurs first.

Scheme 7

Scheme 7: FUSE PANEL IDENTIFICATION (1983-86 CELEBRITY)
Scheme 7: FUSE PANEL IDENTIFICATION (1983-86 CELEBRITY)

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp Diesel Engine Glow Plugs (1983-85), Electronic Fuel Injection
  2. 2 - 10 Amp Fuel Pump (1983-86)
  3. 3 - 20 Amp Stoplights, Hazard Lights
  4. 4 - 20 Amp Choke Heater, Coolant Fan, Warning Indicators
  5. 5 - 15 Amp Turn Flasher, Back-Up Lights
  6. 6 - 10 Amp Crank Signal To ECM (1983-86)
  7. 7 - 20 Amp Front Parking, Side Marker, Taillights License Plate, Stoplights, Turn Signal Lights, Radio/Digital Clock
  8. 8 - 25 Amp Heater & Air Conditioner
  9. 9 - 10 Amp Gauges, Warning Indicator, Audible Warning System, Computer Command Control, Rear Window Defogger, Brake Warning Indicator, Torque Converter Clutch, Trunk Release
  10. 10 - 25 Amp Windshield Wiper/Washer Motor
  11. 11 - 20 Amp Courtesy Lights, Audible Warning System, Cigarette Lighter, Engine Compartment Light, Horn, Interior Lights, Power Door Locks (1983)
  12. 12 - 30 Amp (Circuit Breaker) Power Window, Rear Washer/Wiper (1985-86)
  13. 13 - 5 Amp Audible Warning System, Rear Window Defogger, Instrument Panel Lights, Radio Lights (1983)
  14. 14 - 10 Amp Radio
  15. 15 - 30 Amp (Circuit Breaker) Power Accessory (1983), Rear Window Defogger, Power Door Locks, Power Seats, Rear Washer/Wiper (1985-86), Tailgate Release (1985-86)
  16. 16 - Blank
  17. 17 - 10 Amp ECM-Computer Command Control (V6 Only)
  1. 1 - 10 Amp (1987-89) Computer Command Control, ECM Ignition, Fuel Injection 15 Amp (1990) ECM Injectors, Direct Ignition System
  2. 2 - 10 Amp (1987-89) Fuel Pump Relay, Crank Signal Blank (1990)
  3. 3 - 20 Amp (1987-89) Stoplights, Hazard Lights, Audible Warning System 10 Amp (1990) A/C Relay, EGR Solenoid, Canister Purge Solenoid
  4. 4 - 20 Amp (1987-89) Cooling Fan Relay, Choke Heater (1987 Only) 10 Amp (1990) Electric Fan, Heater Resistor, Generator, Daytime Running Lights
  5. 5 - 15 Amp Turn Signal Flasher, Back-Up Lights, Trunk & Tailgate Release With Automatic Transmission)
  6. 6 - 10 Amp (1987-89) Crank Signal To ECM (V6 Engine), Cold Start Injector (1987) Blank (1990)
  7. 7 - 20 Amp Parking Light, Side Marker, Taillight, License Plate, Stoplight & Turn Signal
  8. 8 - 25 Amp Heater & Air Conditioner
  9. 9 - 10 Amp Gauges, Warning Indicator, Audible Warning System, Computer Command Control, Rear Window Defogger, Brake Warning Indicator, Torque Converter Clutch, Trunk Release, Air Conditioning Relay, Vehicle Speed Sensor
  10. 10 - 25 Amp (1987-89) Windshield Wiper Motor 20 Amp (1990) Stoplights, Hazard Flasher
  11. 11 - 20 Amp Courtesy Lights, Instrument Panel Lights, Trunk Light, Interior Lights Cigarette Lighter, Underhood Lights, Ashtray Door Locks, Horn & Passive Restraint (1990)
  12. 12 - 30 Amp (Circuit Breaker) Power Window, Rear Washer/Wiper, Power Tailgate Release, Trunk Release (w/Manual Trans.)
  13. 13 - 5 Amp (1987-89) Instrument Panel Lights 5 Amp (1990) Radio, Pod Lights, Heater & A/C Defogger Switch, Headlight, Ashtray
  14. 14 - 10 Amp Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats, Rear Washer/Wiper
  16. 16 - Blank (1987-89) 25 Amp (1990) Windshield Wiper/Washer
  17. 17 - 10 Amp (1987-89) ECM - Computer Command Control Blank (1990)
  1. 1 - 10 Amp (Red) Diesel Engine Glow Plugs, Electronic Fuel Injection
  2. 2 - 10 Amp (Red) Fuel Pump (L4)
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow) Choke Heater, Coolant Fan, Warning Indicators
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM
  7. 7 - 20 Amp (Yellow) Park, Side Marker, Tail, License Plate, Stoplights, Turn Signal Lights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Audible Warning System, Computer Command Control, Electronic Ride Control, BRAKE Warning Light, Torque Converter Clutch, Cruise Control
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Courtesy Light, Cigarette Lighter, Trunk Release, Horn, Interior Lights, Power Door Locks, Radio/Digital Clock, Display (ETR), Power Sport Mirrors, Electronic Ride Control
  12. 12 - 30 Amp (Circuit Breaker) Power Windows
  13. 13 - 5 Amp (Tan) Audible Warning System, Rear Window Defogger, Instrument Panel Lights, Radio Lights
  14. 14 - 10 Amp (Red) Radio
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 10 Amp (Red) ECM (Computer Command Control)
  1. 1 - 10 Amp (Red) Computer Command Control, Diesel Glow Plugs
  2. 2 - 10 Amp (Red) Fuel Pump Relay (Except STE), Oil Pressure Switch (L4), Cigarette Lighter (STE), Glove Box Light, Horn
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow) Choke Heater (V6)
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM (Except STE), Air Conditioning Control Panel (STE)
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Electronic Ride Control, Torque Converter Clutch Brake Switch, Air Conditioning Relay, Vehicle Speed Sensor, Electric Rear Window Defogger Switch
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette Lighter (Except STE), Electric Trunk Release, Horn Relay (Except STE), Electronic Ride Control, Clock, Glove Box Light (Except STE), A/C Relay
  12. 12 - 30 Amp (Circuit Breaker) Power Windows
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 10 Amp (Red) Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - Blank (Except STE) 10 Amp (Red) Electronic Instrument Cluster
  17. 17 - 10 Amp (Red) ECM (Computer Command Control)
  1. 1 - 10 Amp (Red) (Except Diesel) Computer Command Control, ECM Ignition, Fuel Injection 20 Amp (Yellow) (Diesel) Diesel Glow Plugs
  2. 2 - 10 Amp (Red) (Except STE) Fuel Pump Relay, Oil Pressure Switch (L4) 20 Amp (Yellow) (STE) Cigarette Lighter, Horn, Glove Box Light
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow)(Except Elec. I.P. Cluster) Choke Heater 10 Amp (Red)(Electronic I.P. Cluster) Cooling Fan, I.P. Cluster, Electronics
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM, Cold Start Injector
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Electronic Ride Control, Torque Converter Clutch Brake Switch, Electric Rear Window Defogger Switch, Air Conditioning Relay, Vehicle Speed Sensor
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette, Lighter (Except STE), Electric Trunk Release, Horn Relay (Except STE), Electronic Ride Control, Clock, Glove Box Light (Except STE), A/C Relay
  12. 12 - 30 Amp (Circuit Breaker) Power Windows, Rear Window Wiper/Washer (Wagon)
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 10 Amp (Red) Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 10 Amp (Red) Multi-Port Fuel Injection Engine Controls
  17. 17 - 10 Amp (Red) ECM - Computer Command Control (Except STE), Driver Information Center (STE)
  1. 1 - 10 Amp (Red) Computer Command Control ECM Ignition, Fuel Injection
  2. 2 - 10 Amp (Red) Fuel Pump Relay, Oil Pressure Switch 20 Amp (1987 STE) Cigarette Lighter, Glove Box Light, Horn Relay
  3. 3 - 20 Amp (Yellow) Stoplights, Hazard Flasher, Audible Warning System
  4. 4 - 20 Amp (Yellow)(Except Electronic I.P. Cluster) Choke Heater 10 Amp (Red)(Electronic I.P. Cluster) Cooling Fan, I.P. Cluster Electronics
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 10 Amp (Red) Crank Signal To ECM, Cold Start Injector (1987)
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Torque Converter Clutch Brake Switch, Electric Rear Window Defogger Switch, Air Conditioning Relay, Vehicle Speed Sensor Electronic Ride Control (1987)
  10. 10 - 25 Amp (White) Windshield Wiper/Washer Motor
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette Lighter, Electric Trunk Release, Horn Relay, Clock, Glove Box Light, A/C Relay, Power Mirrors, Power Antenna Relay, Power Door Lock Relay, Electronic Ride Control (1987)
  12. 12 - 30 Amp (Circuit Breaker) Power Windows, Rear Window Wiper/Washer (Wagon), Power Sun Roof, Power Tailgate Release (Wagon)
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 15 Amp Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 10 Amp (Red)(Engine Code W) Multi-Port Fuel Injection Engine Controls
  17. 17 - 10 Amp (Red) ECM - Computer Command Control, Driver Information Center 1987)
  1. 1 - 15 Amp (Blue) Computer Command Control ECM Ignition, Fuel Injection
  2. 2 - 20 Amp (Yellow) Lighter, Horn, ETR
  3. 3 - 10 Amp (Red) Engine Controls
  4. 4 - 10 Amp (Red) Cooling Fan
  5. 5 - 15 Amp (Light Blue) Turn Signal Flasher, Back-Up Lights
  6. 6 - 15 Amp (Light Blue) Foglights, ABS
  7. 7 - 20 Amp (Yellow) Taillights
  8. 8 - 25 Amp (White) Heater & Air Conditioner
  9. 9 - 10 Amp (Red) Gauges, Torque Converter Clutch Brake Switch, Electric Rear Window Defogger Switch, Air Conditioning Relay, Vehicle Speed Sensor
  10. 10 - 20 Amp (Yellow) Stop, Hazard, Audible Warning System
  11. 11 - 20 Amp (Yellow) Interior Lights, Cigarette Lighter Electric Trunk Release, Horn Relay, Clock, Glove Box Light, A/C Relay, Power Mirrors, Power Antenna Relay, Power Door Lock Relay
  12. 12 - 30 Amp (Circuit Breaker) Power Windows, Rear Window Wiper/Washer (Wagon), Power Sun Roof, Power Tailgate Release
  13. 13 - 5 Amp (Tan) Instrument Panel Lights
  14. 14 - 15 Amp Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Electric Rear Window Defogger, Power Door Locks, Power Seats
  16. 16 - 25 Amp (White) Wiper
  17. 17 - 20 Amp (Yellow) I.P. Cluster Electronics
  1. 1 - 15 Amp (1990) ECM Injectors, Direct Ignition System 15 Amp (1991) ECM Control, MAF
  2. 2 - Blank (1990) 20 Amp (1991) Injector/Coil
  3. 3 - 10 Amp Engine Control, A/C Relay, EGR Solenoid, Canister Purge Solenoid, Diff./Lock Solenoid (1990)
  4. 4 - 10 Amp Electric Fan, Heater Resistor (1990), Generator, Daytime Running Lights Module, AWD Switch (1990)
  5. 5 - 15 Amp Turn Signals, Back-Up Lights, Trunk & Tailgate Release With Automatic Transaxle
  6. 6 - 15 Amp Fog Light Relay
  7. 7 - 20 Amp Taillights, Parking Lights, Side Marker Lights, License Lights, Stoplights, Turn Signals
  8. 8 - 25 Amp Heater & Air Conditioner
  9. 9 - 10 Amp Gauges, Warning Indicator, Torque Converter Clutch, Audible Warning System, Computer Command Control, Trunk Release, BRAKE Warning Light, Rear Window Defogger, Air Conditioning Relay (1990), Speedometer
  10. 10 - 20 Amp Stoplights, Hazard Flasher
  11. 11 - 20 Amp Interior Lights, Underhood Light, Ashtray, Courtesy Lights, Instrument Panel Lights, Trunk Light, Passive Restraint System, Deck-Lid Release, Door Locks, Horn, Automatic Leveling System, Power Antenna (1991)
  12. 12 - 30 Amp (Circuit Breaker) Tailgate Release, Power Windows, Rear Wiper/Washer
  13. 13 - 5 Amp Radio, Pod Lights, Ashtray, Console Light, Control Head - Heater & A/C, Defogger Switch, Headlight/Foglight Switch, AWD Switch (1990)
  14. 14 - 10 Amp Radio, Cruise Control
  15. 15 - 30 Amp (Circuit Breaker) Seats, Door Locks, Rear Wiper Motor, Rear Defogger
  16. 16 - 25 Amp Windshield Wiper/Washer
  17. 17 - Blank (1990) 20 Amp (1991) Cigarette Lighter

More articles — Maintenance
