Engine Controls - Tests W/codes - 3.3l Plymouth Voyager II

MODEL IDENTIFICATION

VEHICLE BODY IDENTIFICATION

INTRODUCTION

If no faults were found while performing F - GAS BASIC TESTING article, proceed with self-diagnostics. If no fault codes or only pass codes are present after entering self-diagnostics, proceed to TEST NF-1A and H - GAS TESTS W/O CODES article in the ENGINE PERFORMANCE Section for diagnosis by symptom (i.e., ROUGH IDLE, NO START, etc.).

SELF-DIAGNOSTIC SYSTEM

SYSTEM DIAGNOSTICS

Note. Malfunction Indicator Light (MIL) may also be referred to as CHECK ENGINE Light.

Self-diagnostic capabilities of this system, if properly used, can simplify testing. Powertrain Control Module (PCM) monitors several different engine control system circuits.

If a problem is sensed with a monitored circuit, PCM memory stores a fault, MIL glows and PCM enters limp-in mode. In limp-in mode, PCM compensates for component failure by substituting information from other sources. This allows vehicle operation until repairs can be made.

Test circuits and repair or replace components as required. If problem is repaired or ceases to exist, PCM cancels fault after 50 ignition on/off cycles.

A specific fault results from a particular system failure. A fault does not condemn a specific component; component is not necessarily reason for failure. Faults only suggest probable malfunction area.

Hard Failures

Hard failures cause MIL to glow and remain on until malfunction is repaired. If light comes on and remains on (light may flash) during vehicle operation, determine cause of malfunction using self-diagnostic tests. If a sensor fails, PCM will use a substitute value in its calculations, allowing engine to operate in limp-in mode. In this condition, vehicle will run, but driveability may be poor.

Intermittent Failures

Intermittent failures may cause MIL to flicker or stay on until intermittent fault goes away. However, PCM memory will retain corresponding fault. If related fault does not reoccur within a certain time frame, related fault will be erased from PCM memory. Intermittent failures can be caused by a faulty sensor, bad connector or wiring related problems.

SERVICE PRECAUTIONS

During diagnosis, following these precautions

1. Always relieve fuel pressure before disconnecting any fuel injection-related component. DO NOT allow fuel to contact engine or electrical components. See «FUEL PRESSURE RELEASE»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__fuel-pressure-release) .
2. When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION Section before disconnecting battery.
3. Vehicle must have a fully charged battery and functional charging system.
4. Probe PCM 60-pin connector from pin side. DO NOT backprobe PCM connector.
5. DO NOT cause short circuits when performing electrical tests. This will set additional faults, making diagnosis of original problem more difficult.
6. DO NOT use a test light instead of a voltmeter.
7. When checking for spark, ensure coil wire is no more than 1/4" from ground. If coil wire is more than 1/4" from ground, damage to vehicle electronics and/or PCM may result.
8. DO NOT prolong testing of fuel injectors, or engine may hydrostatically (liquid) lock.
9. Always repair lowest fault code number (CHECK ENGINE light) or first fault displayed (DRB-II) first.
10. Always perform verification procedure test after repairs are made.
11. Always disconnect DRB-II after use.
12. Always disconnect DRB-II before charging battery.

VISUAL INSPECTION

Most driveability problems in engine control system result from faulty wiring, poor electrical connections or leaking air and vacuum hose connections. To avoid unnecessary component testing, perform a visual inspection before beginning self-diagnostic tests.

DIAGNOSTIC PROCEDURE

Note. DO NOT skip any steps in self-diagnostic tests, or incorrect diagnosis may result.

Always perform a visual inspection before attempting to diagnose engine control system problems. See VISUAL INSPECTION . Enter on-board diagnostics, and retrieve fault codes. See ENTERING ON-BOARD DIAGNOSTICS . If fault codes are not present and/or using Diagnostic Readout Box II (DRB-II), proceed to one of following tests.

1. Go to appropriate «TEST NS-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-1a-qualifying-no-start-condition) if a no-start condition exists or engine stalls after start-up. Perform indicated VERIFICATION TEST after repairs have been made.
2. Go to appropriate «TEST FC-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-1a-checking-for-faults) if engine runs but has performance problems. Perform indicated VERIFICATION TEST after repairs have been made.
3. Go to appropriate «TEST NF-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l) if a driveability problem exits but no fault codes are present. Perform indicated VERIFICATION TEST after repairs have been made.

ENTERING ON-BOARD DIAGNOSTICS

Note. Although other scan testers are available, manufacturer recommends using Diagnostic Readout Box II (DRB-II). MIL function can be used but has limited diagnostic capability.

DRB-II Diagnostic Mode

1. Ensure ignition is off. Attach DRB-II to engine diagnostic connector. Engine diagnostic connector is located in engine compartment, near PCM on all models except Dakota. On Dakota, diagnostic connector is located in right rear corner of engine compartment, taped to harness.
2. Start engine (if possible). Turn A/C on, then off (if equipped). Turn engine off. Without starting engine, turn ignition on and access READ FAULTS function of DRB-II FUEL/IGN MENU. Record all fault messages displayed by DRB-II.

MIL Diagnostic Mode

1. Start engine (if possible). Move transmission shift lever through all positions, ending in Park. Turn A/C on, then off (if equipped).
2. Turn engine off. Without starting engine again, turn ignition on, off, on, off and on within 5 seconds. Record 2-digit fault codes as displayed by flashing MIL.
3. For example, fault code 23 is displayed as flash, flash, 4-second pause, flash, flash, flash. After a slightly longer pause, other codes stored are displayed in numerical order. When MIL begins to flash fault codes, it cannot be stopped. Start over if count is lost. Code 55 indicates end of fault code display.
4. Refer to FAULT CODES/MESSAGES to translate trouble code number to a DRB-II fault message. Once trouble area is identified,refer to «TEST FC-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-1a-checking-for-faults) . Use DRB-II fault messages to find appropriate test.
5. As an example, a 2.5L engine starts and runs but has a driveability problem. MIL indicates a Code 14. Refer to FAULT CODES/MESSAGES to translate trouble code number to a DRB-II fault message. When DRB-II fault message is obtained, refer to appropriate test. To clear fault codes, see «CLEARING FAULTS»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__clearing-faults) .

CLEARING FAULTS

Note. Fault codes can also be cleared in READ FAULTS mode of DRB-II. To ensure all faults are read, use READ FAULTS mode to erase fault codes. See DRB-II DIAGNOSTIC MODE under ENTERING ON-BOARD DIAGNOSTICS .

1. If DRB-II is not available, go to step 3). If DRB-II is available, enter FUEL/IGN MENU. At FUEL/IGN MENU, press "5" (ADJUSTMENTS) key. Press ENTER key. At ADJUSTMENTS menu, press "1" (ERASE FAULTS) key. Press ENTER key.
2. DRB-II will display ERASE FAULTS ARE YOU SURE? (ENTER TO ERASE). Press ENTER key. When DRB-II is finished erasing fault codes, screen will display FAULTS ERASED.
3. If DRB-II is not available, fault codes may be cleared by disconnecting negative battery cable for at least 15 seconds.

INACTIVE FAULT CONDITION

This procedure applies if you have been sent here from diagnostic tests and have just attempted to simulate condition that initially set fault message. Following additional checks may assist in identifying a possible intermittent problem

1. Visually inspect related wiring harness connectors for broken, bent, pushed-out or corroded terminals.
2. Visually inspect related wiring harnesses for chafed, pierced or partially broken wires.
3. Check all pertinent TECH SERVICE BULLETINS (TSBs).

SUMMARY

If no hard fault codes (or only pass codes) are present, driveability symptoms exist or intermittent codes exist, proceed to appropriate TESTS W/O CODES article in the ENGINE PERFORMANCE Section for diagnosis by symptom (i.e., ROUGH IDLE, NO START, etc.) or intermittent diagnostic procedures.

USING DRB-II

Note. Although other scan testers are available, manufacturer recommends using Diagnostic Readout Box II (DRB-II) to diagnose system.

Ensure DRB-II is connected to engine diagnostic connector located in engine compartment. Ensure correct cartridge for vehicle and system being diagnosed is installed in DRB-II. Menu selections will vary depending on vehicle and system being diagnosed. Follow DRB-II screen prompts to actuate, adjust, monitor, reset, test and diagnose system as necessary.

DRB-II is grounded through engine diagnostic connector. Only one volt-ohmmeter test lead is required when using volt-ohmmeter option. DRB-II volt-ohmmeter should only be used when self-diagnostic tests require use of this option.

If DRB-II has a blank screen or displays RAM TEST FAILURE, CARTRIDGE ERROR, KEY PAD TEST FAILURE, LOW BATTERY or HIGH BATTERY, DRB-II failure is indicated. To diagnose and correct these conditions, see G - BODY TESTS W/CODES article in the ENGINE PERFORMANCE Section.

SERVICE REMINDER INDICATOR (SRI) MEMORY CHECK & MILEAGE

TRANSFER

Note. Perform SRI memory check only if referred here by diagnostic tests. Perform mileage transfer procedure only if PCM is being replaced.

When PCM is replaced, copy vehicle mileage from odometer to replacement PCM memory. Transfer of vehicle mileage will enable new PCM to operate SRI light properly.

1) Ensure ignition is off. Attach DRB-II to engine diagnostic connector. Engine diagnostic connector is located in engine compartment, near PCM on all models except Dakota. On Dakota, diagnostic connector is located in right rear corner of engine compartment, taped to harness. Turn ignition switch to RUN position.

2) Copyright information and diagnostic program version will appear on screen for a few seconds. After a few seconds DRB-II menu will appear. At FUEL/IGN MENU, press "5" (ADJUSTMENTS) key. Press ENTER key. At ADJUSTMENTS menu, press "4" (SRI MEMORY CHK) key. Press ENTER key. DRB-II display will read SRI MEMORY CHECK ARE YOU SURE? (ENTER TO CONTINUE).

3) Press ENTER key. DRB-II will display SRI MEMORY TEST WRITE TEST [-------] and, after a few seconds, IS INSTRUMENT PANEL MILEAGE BETWEEN XXXXX AND XXXXX? (PRESS YES OR NO). If vehicle mileage is within specification, SRI memory check is complete. Press YES key. If vehicle mileage is not within specification, go to next step.

4) Press NO key. DRB-II will display ENTER MILEAGE SHOWN ON INSTRUMENT PANEL (USE ENTER TO END) XXXXXXX. Enter vehicle mileage. DO NOT enter tenths. When correct vehicle mileage is entered, press ENTER key.

5) DRB-II will ask for verification of mileage entry. If mileage entry was accurate, press ENTER key. DRB-II will display SRI MEMORY CHECK COMPLETE. Vehicle must travel at least 8 miles for reset to occur.

SERVICE REMINDER INDICATOR (SRI) LIGHT RESET PROCEDURE

Note: Service Reminder Indicator (SRI) light is designed to be a reminder to service vehicle emissions control system. It is not an emissions warning system, only a reminder to perform necessary emissions servicing. Components to be serviced include PCV valve, oxygen sensor and some vacuum-operated components. SRI light will glow after a predetermined mileage.

1) To reset SRI light, ensure ignition is off. Connect DRB-II to engine diagnostic connector. Engine diagnostic connector is located in engine compartment, near PCM on all models except Dakota. On Dakota, diagnostic connector is located in right rear corner of engine compartment, taped to harness.

2) Turn ignition switch to RUN position. Copyright information and diagnostic program version will appear on screen for a few seconds. After a few seconds DRB-II menu will appear. At FUEL/IGN MENU, press "5" (ADJUSTMENTS) key. Press ENTER key.

3) At ADJUSTMENTS menu, press "3" (RESET SRI LIGHT) key. Press ENTER key. Display will read RESET SRI LIGHT ARE YOU SURE? (ENTER TO RESET). Press ENTER key.

FUEL PRESSURE RELEASE

Scheme 76

1. Fuel pressure must be fully released before opening fuel system or removing any fuel-carrying components. To release pressure in tank, open fuel tank cap slowly.
2. To release remaining pressure in system, disconnect injector wiring harness. Using jumper wire, connect injector harness ground terminal No. 1 to ground. (Scheme 76) Connect injector harness positive terminal No. 2 to positive battery terminal with second jumper wire.
3. DO NOT keep injector connector connected to positive battery terminal for longer than 5 seconds. Remove jumper wires. This releases system pressure. CAUTION: To minimize fuel spill, wrap a shop towel around and under pressure test port.
4. Using Fuel Pressure Gauge/Hose Tool (5069) with gauge removed, place gauge end of hose into approved gasoline container. To release pressure, screw other end of hose onto pressure test port. After pressure is released, remove hose from test port and continue fuel system service. When servicing is completed, install protective cap on fuel rail test port.

DTC & FAULT CODES/MESSAGES

Note. Not all fault codes apply to all vehicles. Some fault codes have more than one meaning. When a fault code has more than one meaning, MIL is unable to distinguish between different failures.

CODES/ MESSAGES

Note. For DTC table, see TEST FC-1A - CHECKING FOR FAULTS .

Code 11

DRB-II displays NO CRANK REFERENCE SIGNAL AT PCM. Condition is: no crankshaft reference signal picked up during cranking.

Code 13

DRB-II displays SLOW CHANGE IN IDLE MAP SENSOR SIGNAL. Condition is: Manifold Absolute Pressure (MAP) sensor output change slower and/or smaller than expected.

DRB-II displays NO CHANGE IN MAP FROM START TO RUN. Condition is: no difference recognized between Manifold Absolute Pressure (MAP) reading and barometric (atmospheric) pressure reading at start-up.

Code 14

DRB-II displays MAP VOLTAGE TOO LOW. Condition is: Manifold Absolute Pressure (MAP) sensor input less than minimum acceptable voltage.

DRB-II displays MAP VOLTAGE TOO HIGH. Condition is: Manifold Absolute Pressure (MAP) sensor input more than maximum acceptable voltage.

Code 15

DRB-II displays NO VEHICLE SPEED SENSOR SIGNAL. Condition is: no Vehicle Speed Sensor (VSS) signal detected with road load conditions.

Code 17

DRB-II displays ENGINE IS COLD TOO LONG. Condition is: coolant temperature stays less than normal operating temperature during vehicle operation.

Code 21

DRB-II displays O2S STAYS AT CENTER. Condition is: no rich or lean signal detected from oxygen sensor input.

DRB-II displays O2S SHORTED TO VOLTAGE. Condition is: oxygen sensor input voltage maintained at more than normal operating range.

Code 22

DRB-II displays ECT SENSOR VOLTAGE TOO LOW. Condition is: Engine Coolant Temperature (ECT) sensor input less than minimum acceptable voltage.

DRB-II displays ECT SENSOR VOLTAGE TOO HIGH. Condition is: Engine Coolant Temperature (ECT) sensor input more than maximum acceptable voltage.

Code 23

DRB-II displays INTAKE AIR TEMPERATURE SENSOR VOLTAGE LOW. Condition is: Intake Air Temperature (IAT) sensor input less than minimum acceptable voltage.

DRB-II displays INTAKE AIR TEMPERATURE SENSOR VOLTAGE HIGH. Condition is: Intake Air Temperature (IAT) sensor input more than maximum acceptable voltage.

DRB-II displays THROTTLE BODY TEMP VOLTAGE HIGH. Condition is: throttle body temperature input is more than maximum acceptable voltage.

DRB-II displays THROTTLE BODY TEMP VOLTAGE LOW. Condition is: throttle body temperature input is less than maximum acceptable voltage.

Code 24

DRB-II displays THROTTLE POSITION SENSOR VOLTAGE LOW. Condition is: Throttle Position Sensor (TPS) input less than minimum acceptable voltage.

DRB-II displays THROTTLE POSITION SENSOR VOLTAGE HIGH. Condition is: Throttle Position Sensor (TPS) input more than maximum acceptable voltage.

Code 25

DRB-II displays IDLE AIR CONTROL MOTOR CIRCUITS. Condition is: open or shorted condition detected in one or more Idle Air Control (IAC) motor circuits.

Code 27

DRB-II displays INJECTOR NO. 1-6 CONTROL CIRCUIT. Condition is: injector output driver does not respond properly to Powertrain Control Module (PCM) control signal.

Code 31

DRB-II displays EVAP PURGE SOLENOID CIRCUIT. Condition is: open or shorted condition detected in purge solenoid circuit.

Code 32

DRB-II displays EGR SOLENOID FAILURE. Condition is: open or shorted condition detected in EGR solenoid circuit.

DRB-II displays EGR SYSTEM FAILURE. Condition is: required change in air/fuel ratio not detected during diagnostic test. Fault is only present on models with California emissions packages.

Code 33

DRB-II displays A/C CLUTCH RELAY CIRCUIT. Condition is: open or shorted condition detected in A/C clutch relay circuit.

Code 34

DRB-II displays SPEED CONTROL SOLENOID CIRCUITS. Condition is: open or shorted condition detected in Speed Control (S/C) vacuum or vent solenoid circuits.

Code 35

DRB-II displays RADIATOR FAN RELAY CIRCUIT. Condition is: open or shorted condition detected in radiator fan relay circuit.

Code 37

DRB-II displays TORQUE CONVERTER CLUTCH SOLENOID CIRCUIT. Condition is: open or shorted condition detected in torque converter clutch solenoid circuit.

Code 41

DRB-II displays GENERATOR FIELD NOT SWITCHING PROPERLY. Condition is: open or shorted condition detected in alternator field circuit.

Code 42

DRB-II displays AUTO SHUTDOWN RELAY CONTROL CIRCUIT. Condition is: open or shorted condition detected in Auto Shutdown (ASD) relay circuit.

DRB-II displays NO ASD RELAY VOLTAGE SENSE AT PCM. Condition is: Powertrain Control Module (PCM) did not receive message in Auto Shutdown (ASD) relay circuit.

Code 43

DRB-II displays IGNITION COIL NO. 1-3 PRIMARY CIRCUIT. Condition is: peak primary circuit current not achieved with maximum dwell time.

Code 44

DRB-II displays BATTERY TEMP SENSOR VOLTS OUT OF LIMIT. Condition is: battery temperature sensor volts out of limit.

Code 45

DRB-II displays OVERDRIVE SOLENOID. Condition is: open or shorted condition detected in overdrive solenoid circuit.

Code 46

DRB-II displays CHARGING SYSTEM VOLTAGE TOO HIGH. Condition is: battery voltage sense input more than target charging voltage during engine operation.

Code 47

DRB-II displays CHARGING SYSTEM VOLTAGE TOO LOW. Condition is: battery voltage sense input less than target charging voltage during engine operation.

Code 51

DRB-II displays O2S STAYS BELOW CENTER (LEAN). Condition is: oxygen sensor input indicates lean air/fuel ratio during engine operation.

Code 52

DRB-II displays ADDITIVE ADAPTIVE MEMORY AT LEAN LIMIT. Condition is: additive adaptive memory at lean limit. Code 52

DRB-II displays O2S STAYS ABOVE CENTER (RICH). Condition is: oxygen sensor input indicates rich air/fuel ratio during engine operation.

Code 53

DRB-II displays INTERNAL PCM FAILURE. Condition is: Powertrain Control Module (PCM) detects internal failure.

DRB-II displays PCM FAILURE SPI COMMUNICATION. Condition is: no Chrysler Collision Detection (CCD) bus communication.

Code 54

DRB-II displays CRANKSHAFT SIGNAL SYNC PICK-UP SIGNAL. Condition is: no fuel sync signal detected during crankshaft rotation.

DRB-II displays NO CAM SYNC SIGNAL AT PCM. Condition is: open or shorted condition detected in cam sync signal circuit.

Code 55

DRB-II display will be blank. Completion of fault code display by MIL light.

Code 62

DRB-II displays PCM FAILURE SRI MILE NOT STORED. Condition is: Powertrain Control Module (PCM) detects internal failure.

Code 63

DRB-II displays PCM FAILURE EEPROM WRITE DENIED. Condition is: unsuccessful attempt to write to an EEPROM location by PCM.

Code 76

DRB-II displays FUEL PUMP RESISTOR BYPASS RELAY CIRCUIT. Condition is: open or shorted condition detected in ballast resistor by-pass relay circuit.

CONNECTOR IDENTIFICATION

CONNECTOR IDENTIFICATION DIRECTORY

Scheme 77

A/C CLUTCH RELAY CONNECTOR TERMINAL IDENTIFICATION (EXCEPT DAKOTA)

Scheme 78

ASD RELAY CONNECTOR TERMINAL IDENTIFICATION

Scheme 79

CAMSHAFT POSITION SENSOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 80

CRANKSHAFT POSITION SENSOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 81

DISTRIBUTOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 82

EGR SOLENOID CONNECTOR TERMINAL IDENTIFICATION

Scheme 83

ENGINE COOLANT TEMPERATURE (ECT) SENSOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 84

EVAPORATIVE PURGE SOLENOID CONNECTOR TERMINAL IDENTIFICATION

Scheme 85

FUEL PUMP CONNECTOR TERMINAL IDENTIFICATION

Scheme 86

FUEL PUMP RELAY CONNECTOR TERMINAL IDENTIFICATION

Scheme 87

IDLE AIR CONTROL (IAC) MOTOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 88

IGNITION COIL CONNECTOR TERMINAL IDENTIFICATION

Scheme 89

10-PIN INJECTOR CONNECTOR TERMINAL IDENTIFICATION (INJECTOR SIDE)

Scheme 90

6-PIN INJECTOR CONNECTOR TERMINAL IDENTIFICATION (INJECTOR SIDE)

Scheme 91

INTAKE AIR TEMPERATURE SENSOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 92

MAP SENSOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 93

OXYGEN SENSOR CONNECTOR TERMINAL ID (EXCEPT 5.9L HEAVY DUTY)

Scheme 94

RADIATOR FAN RELAY CONNECTOR TERMINAL IDENTIFICATION

Scheme 95

TCC RELAY CONNECTOR TERMINAL IDENTIFICATION

Scheme 96

TCC SOLENOID CONNECTOR TERMINAL IDENTIFICATION

Scheme 97

TPS CONNECTOR TERMINAL IDENTIFICATION

Scheme 98

TRANSMISSION SOLENOID CONNECTOR TERMINAL IDENTIFICATION

Scheme 99

TEST FC-1A - CHECKING FOR FAULTS

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Battery must be fully charged before proceeding. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds. Connect DRB-II to engine diagnostic connector. Record DRB-II fault messages.
2. If DRB-II has a blank screen or displays RAM TEST FAILURE, CARTRIDGE ERROR, KEY PAD TEST FAILURE, LOW BATTERY or HIGH BATTERY, DRB-II failure is indicated. To diagnose and correct, see G - BODY TESTS W/CODES article in the ENGINE PERFORMANCE Section.
3. If DRB-II displays NO RESPONSE, go to «TEST NS-6A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-6a-correcting-no-response) . If fault messages are displayed, see DRB-II FAULT MESSAGES table. If no fault messages are displayed and a driveability problem is present, go to TEST NF-1A. If no fault messages are displayed and a no-start problem is present, go to «TEST NS-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-1a-qualifying-no-start-condition) .

DRB-II FAULT MESSAGES

TEST FC-2A - NO CRANK REFERENCE SIGNAL AT PCM (DTC 11)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds.
2. Using DRB-II, read fault messages. If DRB-II does not display NO CRANK REFERENCE SIGNAL AT PCM, condition required to set fault is not present at this time. Go to next step. If DRB-II displays NO CRANK REFERENCE SIGNAL AT PCM, go to step 6). NOTE: Wire color for crank sensor signal circuit changes from Gray/Black to Orange/Dark Blue after going through a 10-pin Gray connector.
3. NO CRANK REFERENCE SIGNAL AT PCM fault sets if Powertrain Control Module (PCM) does not see a Crankshaft Position (CKP) sensor signal with Camshaft Position (CMP) sensor signal present. Possible causes are: failed CKP sensor, open or shorted CKP sensor signal circuit (Gray/Black wire), open or shorted CKP sensor 8-volt supply circuit (Orange wire), open CKP sensor ground circuit (Black/Light Blue wire), improperly adjusted CKP sensor, failed Powertrain Control Module (PCM) or failed Transmission Control Module (TCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, go to next step.
5. Start engine. Wiggle wiring harness from CKP sensor to Powertrain Control Module (PCM). If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
6. Turn ignition off. Disconnect Crankshaft Position (CKP) sensor connector. Using DRB-II in ohmmeter mode, check resistance of CKP sensor connector, 8-volt supply circuit (Orange wire). If resistance is less than 5 ohms, repair short to ground in Orange wire.
7. If resistance is more than 5 ohms, turn ignition on. Using DRB-II in voltmeter mode, check voltage on CKP sensor connector, 8-volt supply circuit (Orange wire). If voltage is less than 7 volts, go to TEST FC-2B. If voltage is more than 7 volts, turn ignition off.
8. Connect a jumper wire between signal circuit (Gray/Black wire) and ground circuit (Black/Light Blue wire) on CKP sensor connector harness side. Using DRB-II, read Distributorless Ignition System (DIS) signal status. Make and break connection at CKP sensor connector several times while observing DRB-II.
9. If DRB-II displayed CRANK ONLY, replace CKP sensor. Perform TEST VER-2. If DRB-II did not display CRANK ONLY, turn ignition off. Put DRB-II in ohmmeter mode.
10. Check resistance on CKP sensor connector, ground circuit (Black/Light Blue wire). If resistance is more than 5 ohms, repair open in Black/Light Blue wire. Perform TEST VER-2.
11. If resistance is less than 5 ohms, disconnect PCM connector. Inspect PCM sensor connector for damaged or pushed-out terminals. Repair as necessary. Perform TEST VER-2. If PCM connector terminals are okay, go to next step.
12. Using an external ohmmeter, check resistance of signal circuit between CKP sensor connector harness side (Gray/Black wire) and PCM connector terminal No. 24 (Orange/Dark Blue wire). If resistance is more than 5 ohms, repair open in signal circuit (wire color changes after going through a 10-pin Gray connector). Perform TEST VER-2.
13. If resistance is less than 5 ohms, put DRB-II in ohmmeter mode. Check resistance of CKP sensor connector, signal circuit (Gray/Black wire). If resistance is more than 5 ohms, replace PCM. Perform TEST VER-2.
14. If resistance is less than 5 ohms, disconnect Transmission Control Module (TCM) connector. Using DRB-II, check resistance of CKP sensor connector, signal circuit (Gray/Black wire). If resistance is more than 5 ohms, replace TCM. Perform TEST VER-2. If resistance is less than 5 ohms, repair short to ground in Gray/Black wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .

TEST FC-2B - NO CRANK REFERENCE SIGNAL AT PCM (DTC 11)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect PCM connector for damaged or pushed-out terminals. Repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If PCM connector terminals are okay, go to next step.
2. Using an external ohmmeter, check resistance of 8-volt supply circuit (Orange wire) between CKP sensor connector harness side and PCM connector terminal No. 7. If resistance is more than 5 ohms, repair open in Orange wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-3A - NO CAM SYNC SIGNAL AT PCM (DTC 54)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Camshaft Position (CMP) sensor connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of CMP sensor connector, 8-volt supply circuit (Orange wire). If resistance is less than 5 ohms, repair short to ground in Orange wire. Perform TEST VER-2.
2. If resistance is more than 5 ohms, turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on CMP sensor connector, 8-volt supply circuit (Orange wire). If voltage is less than 7 volts, go to TEST FC-3B.
3. If voltage is more than 7 volts, turn ignition off. Connect a jumper wire between signal circuit (Tan/Yellow wire) and ground circuit (Black/Light Blue wire) on CMP sensor connector harness side. Using DRB-II, read Distributorless Ignition System (DIS) signal status. Make and break connection at CMP sensor connector several times while observing DRB-II.
4. If DRB-II displayed CAM ONLY, replace CMP sensor. Perform TEST VER-2. If DRB-II did not display CAM ONLY, turn ignition off. Put DRB-II in ohmmeter mode.
5. Turn ignition off. Put DRB-II in ohmmeter mode. Check resistance on CMP sensor connector, ground circuit (Black/Light Blue wire). If resistance is more than 5 ohms, repair open in Black/Light Blue wire. Perform TEST VER-2.
6. If resistance is less than 5 ohms, disconnect PCM connector. Inspect PCM sensor connector for damaged or pushed-out terminals. Repair as necessary. Perform TEST VER-2. If PCM connector terminals are okay, go to next step.
7. Using an external ohmmeter, check resistance of signal circuit (Tan/Yellow wire) between CMP sensor connector harness side and PCM connector terminal No. 44. If resistance is more than 5 ohms, repair open in Tan/Yellow wire. Perform TEST VER-2.
8. If resistance is less than 5 ohms, put DRB-II in ohmmeter mode. Check resistance of CMP sensor connector, signal circuit (Tan/Yellow wire). If resistance is more than 5 ohms, replace PCM. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, repair short to ground in Tan/Yellow wire. Perform TEST VER-2.

TEST FC-3B - NO CAM SYNC SIGNAL AT PCM (DTC 54)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect PCM connector for damaged or pushed-out terminals. Repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If PCM connector terminals are okay, go to next step.
2. Using an external ohmmeter, check resistance of 8-volt supply circuit (Orange wire) between CMP sensor connector harness side and PCM connector terminal No. 7. If resistance is more than 5 ohms, repair open in Orange wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-4A - NO CHANGE IN MAP FROM START TO RUN (DTC 13)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition on. Using DRB-II, erase fault messages. Start engine. Allow engine to idle for 30 seconds. With engine running, use DRB-II to read fault messages. If DRB-II does not display NO CHANGE IN MAP FROM START TO RUN, go to step 4).
2. If DRB-II displays NO CHANGE IN MAP FROM START TO RUN, turn ignition off. Disconnect Manifold Absolute Pressure (MAP) sensor connector. Turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on MAP sensor connector, 5-volt supply circuit (Violet/White wire).
3. If voltage is less than 4 volts, repair open or short in Violet/White wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If voltage is more than 4 volts, remove MAP sensor vacuum hose. Inspect condition of MAP sensor vacuum hose. If MAP sensor vacuum hose is restricted or open, replace vacuum hose as necessary. Perform TEST VER-2. If MAP sensor vacuum hose is okay, replace MAP sensor. Perform TEST VER-2.
4. Using DRB-II, set engine speed to 1500 RPM. With engine running at 1500 RPM, read DRB-II MAP sensor voltage. While monitoring MAP sensor voltage, wiggle MAP sensor connector and wiring harness.
5. If engine stalled or MAP sensor voltage became erratic, inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If engine did not stall and MAP sensor voltage did not become erratic, snap throttle open and closed while monitoring DRB-II.
6. If engine vacuum did not rapidly drop to less than one in. Hg, go to step 8). If engine vacuum rapidly dropped to less than one in. Hg, condition required to set fault is not present at this time. Go to next step.
7. NO CHANGE IN MAP FROM START TO RUN fault sets if too small a difference is seen between barometric pressure at key on and manifold vacuum after engine start. Possible causes are: restricted or leaking vacuum/pressure hose to MAP sensor, ice in MAP sensor or passage, or MAP sensor failure. Perform TEST VER-2.
8. Remove MAP sensor vacuum hose. Inspect condition of MAP sensor vacuum hose. If MAP sensor vacuum hose is restricted or open, replace vacuum hose as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If MAP sensor vacuum hose is okay, replace MAP sensor. Perform TEST VER-2.

TEST FC-5A - MAP SENSOR VOLTAGE TOO LOW (DTC 14)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Start engine. Using DRB-II, read Manifold Absolute Pressure (MAP) sensor voltage. If MAP sensor voltage is less than .2 volt, go to step 5). If MAP sensor voltage is more than .2 volt, turn engine off. Turn ignition on.
2. Using DRB-II, read MAP sensor voltage. If voltage is less than 1.2 volts, go to step 5). If voltage is more than 1.2 volts, wiggle MAP sensor connector and wiring harness while watching DRB-II display. If MAP sensor voltage changed, repair connector or wiring harness as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
3. If MAP sensor voltage did not change, condition required to set fault is not present at this time. MAP SENSOR VOLTAGE TOO LOW fault sets if MAP sensor output is less than 1.2 volts at start or less than .2 volt with engine running. Engine speed must be more than 400 RPM, but less than 1500 RPM, and Throttle Position Sensor (TPS) voltage must be less than one volt. Possible causes are: short to ground in MAP sensor signal circuit (Dark Green/Red wire), MAP sensor shorted internally or loss of MAP sensor 5-volt supply circuit (Violet/White wire). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
5. Turn ignition on. Ensure engine is off. Disconnect MAP sensor connector. Using DRB-II, read MAP sensor voltage. If MAP sensor voltage is more than 4 volts, replace MAP sensor. Perform TEST VER-2.
6. If MAP sensor voltage is less than 4 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Using an external ohmmeter, check resistance between signal circuit (Dark Green/Red wire) and ground circuit (Black/Light Blue wire) on MAP sensor connector. If resistance is less than 5 ohms, repair short to ground in Dark Green/Red wire. Perform TEST VER-2. If resistance is more than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-6A - MAP SENSOR VOLTAGE TOO HIGH (DTC 14)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Start engine. Using DRB-II, read Manifold Absolute Pressure (MAP) sensor voltage. If MAP sensor voltage is more than 4.6 volts, go to step 4). If MAP sensor voltage is less than 4.6 volts, wiggle MAP sensor connector and wiring harness while watching DRB-II display. If MAP sensor voltage changed, repair connector or wiring harness as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
2. If MAP sensor voltage did not change, condition required to set fault is not present at this time. MAP SENSOR VOLTAGE TOO HIGH fault sets if MAP sensor output is more than 4.6 volts at start or with engine running. Engine speed must be more than 400 RPM, but less than 1500 RPM, and Throttle Position Sensor (TPS) voltage must be less than one volt. Possible causes are: open MAP sensor signal circuit (Dark Green/Red wire), MAP sensor open internally, open MAP sensor ground circuit (Black/Light Blue wire) or short to voltage in MAP sensor signal circuit (Dark Green/Red wire). Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
4. Turn ignition on. Ensure engine is off. Disconnect MAP sensor connector. Connect a jumper wire between signal circuit (Dark Green/Red wire) and ground circuit (Black/Light Blue wire) on MAP sensor connector. Using DRB-II, read MAP sensor voltage. If voltage is less than one volt, replace MAP sensor. Perform TEST VER-2.
5. If MAP sensor voltage is more than one volt, move jumper wire from MAP sensor connector, ground circuit (Black/Light Blue wire) to an engine ground. Using DRB-II, read MAP sensor voltage.
6. If MAP sensor voltage is less than one volt, repair open in Black/Light Blue wire. Perform TEST VER-2. If MAP sensor voltage is more than one volt, turn ignition off. Disconnect PCM connector.
7. Using an external ohmmeter, check resistance of signal circuit (Dark Green/Red wire) between MAP sensor connector and PCM connector terminal No. 1. If resistance is less than 5 ohms, replace PCM. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is more than 5 ohms, repair open in Dark Green/Red wire. Perform TEST VER-2.

TEST FC-7A - NO VEHICLE SPEED SENSOR SIGNAL (DTC 15)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Raise vehicle so drive wheels are free to spin. Start engine. Using DRB-II, read Vehicle Speed Sensor (VSS) signal. Put transmission in any forward gear. If DRB-II displays more than zero MPH, go to next step. If DRB-II does not display more than zero MPH, go to step 4).
2. Condition required to set fault is not present at this time. NO VEHICLE SPEED SENSOR SIGNAL fault sets if Powertrain Control Module (PCM) does not see a VSS signal at PCM terminal No. 47 (White/Orange wire) under road load conditions. Possible causes are: open or shorted VSS signal circuit (White/Orange wire), no signal from Transmission Control Module (TCM), failed Daytime Running Light (DRL) module (if equipped) or failed Powertrain Control Module (PCM). Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2). If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition). Perform TEST VER-2.
4. Using DRB-II, read electronic automatic transmission fault codes. If Code(s) 50-58 is displayed, go to appropriate TRANSMISSION SERVICE & REPAIR manual. If Code(s) 50-58 is not displayed, turn ignition off.
5. Disconnect Transmission Control Module (TCM) connector. Turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on TCM connector terminal No. 58, Vehicle Speed Sensor (VSS) signal circuit (White/Orange wire). If voltage is more than 4 volts, go to step 9).
6. If voltage is less than 4 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. If vehicle is equipped with Daytime Running Lights (DRL) or a mechanical dash, go to «TEST FC-7B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-7b-no-vehicle-speed). If vehicle is not equipped with Daytime Running Lights (DRL) or a mechanical dash, go to next step.
7. Using an external ohmmeter, check resistance of signal circuit (White/Orange wire) between TCM connector terminal No. 58 and PCM connector terminal No. 47. If resistance is more than 5 ohms, repair open in White/Orange wire. Perform TEST VER-2.
8. If resistance is less than 5 ohms, put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 47, signal circuit (White/Orange wire). If resistance is less than 5 ohms, repair short to ground in White/Orange wire. Perform TEST VER-2. If resistance is more than 5 ohms, replace PCM. Perform TEST VER-2.
9. Using DRB-II, read vehicle speed. Connect a jumper wire to TCM connector terminal No. 58 (White/Orange wire). While observing DRB-II display, tap other end of jumper wire to ground. If DRB-II displayed vehicle speed more than zero MPH, replace TCM. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2).
10. If DRB-II did not display more than zero MPH, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Using an external ohmmeter, check resistance of signal circuit (White/Orange wire) between TCM connector terminal No. 58 and PCM connector terminal No. 47.
11. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2. If resistance is more than 5 ohms, repair open in White/Orange wire. Perform TEST VER-2.

TEST FC-7B - NO VEHICLE SPEED SENSOR SIGNAL (DTC 15)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 47 (White/Orange wire). If resistance is more than 5 ohms, go to step 4). If resistance is less than 5 ohms, disconnect Daytime Running Light (DRL) module connector. DRL module is located next to right shock tower. Using DRB-II, check resistance of PCM connector terminal No. 47 (White/Orange wire).
2. If resistance is more than 5 ohms, replace DRL module. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, disconnect Red mechanical instrument cluster connector.
3. Using DRB-II, check resistance of PCM connector terminal No. 47 (White/Orange wire). If resistance is more than 5 ohms, repair short to ground in mechanical instrument cluster. Perform TEST VER-2. If resistance is less than 5 ohms, repair short to ground in White/Orange wire. Perform TEST VER-2.
4. Using an external ohmmeter, check resistance of VSS signal circuit (White/Orange wire) between TCM connector terminal No. 58 and PCM connector terminal No. 47. If resistance is more than 5 ohms, repair open in White/Orange wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-8A - 02S SHORTED TO VOLTAGE (DTC 21)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, read oxygen sensor voltage. If oxygen sensor voltage is more than 1.2 volts, go to step 4). If oxygen sensor voltage is less than 1.2 volts, wiggle oxygen sensor connector and wiring harness while watching DRB-II display. If voltage went to more than 1.2 volts at any time, repair wiring and connectors as necessary. Perform TEST VER-2.
2. If voltage did not go to more than 1.2 volts at any time, condition required to set fault is not present at this time. 02S SHORTED TO VOLTAGE fault sets if oxygen sensor signal circuit voltage goes to more than 1.2 volts. Possible causes are: oxygen sensor signal circuit (Black/Dark Green wire) shorted to another circuit, oxygen sensor connector has excessive dirt, grease and/or water build-up, or oxygen sensor failure. Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
4. Disconnect oxygen sensor connector. Using DRB-II, read oxygen sensor voltage. If voltage is more than 1.2 volts, repair short to battery voltage in Black/Dark Green wire on oxygen sensor connector harness side. Perform TEST VER-2. If voltage is less than 1.2 volts, replace oxygen sensor. Perform TEST VER-2.

TEST FC-9A - 02S STAYS AT CENTER (DTC 21)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Start engine. Allow engine to run until normal operating temperature is reached. Using DRB-II, set engine speed to 1500 RPM. Using DRB-II, read oxygen sensor state. If oxygen sensor is not switching from rich to lean, go to step 4). If oxygen sensor is switching from rich to lean, wiggle sensor connector and wiring harness while watching DRB-II display.
2. If oxygen sensor was locked at center at any time, inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If oxygen sensor was not locked at center at any time, condition required to set fault is not present at this time. 02S STAYS AT CENTER fault sets if oxygen sensor output voltage stays at .5 volt for 1.5 minutes with engine temperature more than 170°F (77°C) and engine running for 2 minutes. Possible causes are: open oxygen sensor circuit or oxygen sensor failure. Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
4. Turn ignition off. Disconnect oxygen sensor connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of ground circuit (Black/Light Blue wire) at oxygen sensor connector harness side. If resistance is more than 5 ohms, repair open in Black/Light Blue wire. Perform TEST VER-2.
5. If resistance is less than 5 ohms, connect a jumper wire between oxygen sensor signal circuit (Black/Dark Green wire) and battery positive terminal. Using DRB-II, read oxygen sensor voltage. If oxygen sensor voltage is more than one volt, replace oxygen sensor. Perform TEST VER-2.
6. If oxygen sensor voltage is less than one volt, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Disconnect jumper wire between oxygen sensor signal circuit (Black/Dark Green wire) and battery positive terminal.
7. Using an external ohmmeter, check resistance of signal circuit (Black/Dark Green wire) between oxygen sensor connector harness side and PCM connector terminal No. 41. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2. If resistance is more than 5 ohms, repair open in Black/Dark Green wire. Perform TEST VER-2.

TEST FC-10A - 02S STAYS ABOVE CENTER (RICH) (DTC 52)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Start engine. Allow engine to run until normal operating temperature is reached. Using DRB-II, set engine speed to 1500 RPM. Using DRB-II, read oxygen sensor voltage. If oxygen sensor voltage is not always more than .5 volt, condition required to set fault is not present at this time. Go to next step. If oxygen sensor voltage is always more than .5 volt, go to step 3).
2. 02S STAYS ABOVE CENTER (RICH) fault sets if oxygen sensor output voltage stays at more than .5 volt, but less than 1.2 volts, without changing for more than 8 minutes. Possible causes are: high fuel pressure, other engine sensor calibration failures, ignition system failure, oxygen sensor failure or fuel contamination. Go to «TEST NF-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l) .
3. Using DRB-II, stop all actuation tests. Turn ignition off. Inspect air cleaner filter and inlet ducts for restrictions. If restrictions are present, repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If restrictions are not present, remove upper half of intake manifold.
4. Turn ignition on. Using DRB-II, actuate ASD fuel system test. Inspect all injectors for leakage. If injectors are leaking, stop ASD fuel system test. Replace leaking fuel injectors as necessary. Perform TEST VER-2.
5. If injectors are not leaking, using DRB-II, stop ASD fuel system test. A condition causing engine to run rich is present. Go to step 2).

TEST FC-11A - 02S STAYS BELOW CENTER (LEAN) (DTC 51)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Start engine. Allow engine to run until normal operating temperature is reached. Using DRB-II, set engine speed to 1500 RPM and read oxygen sensor voltage. If oxygen sensor voltage is not always less than .5 volt, condition required to set fault is not present at this time. Go to next step. If oxygen sensor voltage is always less than .5 volt, go to step 3).
2. 02S STAYS BELOW CENTER (LEAN) fault sets if oxygen sensor output voltage stays at less than .5 volt without changing for more than 8 minutes. Possible causes are: large vacuum leak, low fuel pressure, other engine sensor calibration failures, ignition system failure, oxygen sensor failure or fuel contamination. Go to «TEST NF-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l) .
3. Using DRB-II, check if oxygen sensor voltage is always zero volts. If oxygen sensor voltage is always zero volts, go to next step. If oxygen sensor voltage is not always zero volts, a condition causing engine to run lean is present. Go to TEST NF-1A.
4. Using DRB-II, stop all actuation tests. Turn ignition on with engine off. Disconnect oxygen sensor connector. Using DRB-II, read oxygen sensor state. If oxygen sensor state is at center, replace oxygen sensor. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
5. If oxygen sensor state is not at center, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of oxygen sensor connector (harness side), signal circuit (Black/Dark Green wire).
6. If resistance is less than 5 ohms, repair short to ground in Black/Dark Green wire. Perform TEST VER-2. If resistance is more than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-12A - ECT SENSOR VOLTAGE TOO HIGH (DTC 22)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, read Engine Coolant Temperature (ECT) sensor voltage. If voltage is more than 4.5 volts, go to step 4). If voltage is less than 4.5 volts, wiggle wiring harness from ECT sensor to Powertrain Control Module (PCM) while observing DRB-II. If voltage changed, repair wiring harness as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
2. If voltage did not change, condition required to set fault is not present at this time. ECT SENSOR VOLTAGE TOO HIGH fault sets if ECT sensor signal circuit (Tan/Black wire) is more than 4.9 volts. Possible causes are: open ECT sensor signal circuit (Tan/Black wire), ECT sensor open internally or open ECT sensor ground circuit (Black/Light Blue wire). Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
4. Disconnect ECT sensor connector. Connect a jumper wire between signal circuit (Tan/Black wire) and ground circuit (Black/Light Blue wire) on ECT sensor connector. Using DRB-II, read ECT sensor voltage.
5. If voltage is less than one volt, replace ECT sensor. Perform TEST VER-2. If voltage is more than one volt, move jumper wire from ECT sensor connector, ground circuit (Black/Light Blue wire) to an engine ground.
6. Using DRB-II, read ECT sensor voltage. If voltage is less than one volt, repair open in Black/Light Blue wire. If voltage is more than one volt, turn ignition off. Disconnect Powertrain Control Module (PCM) connector.
7. Using an external ohmmeter, check resistance of signal circuit (Tan/Black wire) between ECT sensor connector and PCM connector terminal No. 2. If resistance is more than 5 ohms, repair open in Tan/Black wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-13A - ECT SENSOR VOLTAGE TOO LOW (DTC 22)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, read Engine Coolant Temperature (ECT) sensor voltage. If voltage is less than .5 volt, go to step 4). If voltage is more than .5 volt, wiggle wiring harness from ECT sensor to Powertrain Control Module (PCM) while observing DRB-II. If voltage changed, repair wiring harness as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
2. If voltage did not change, condition required to set fault is not present at this time. ECT SENSOR VOLTAGE TOO LOW fault sets if ECT sensor signal circuit (Tan/Black wire) is less than .5 volt. Possible causes are: short to ground in ECT sensor signal circuit (Tan/Black wire) or ECT sensor shorted internally. Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
4. Disconnect ECT sensor connector. Using DRB-II, read ECT sensor voltage. If voltage is more than 4 volts, replace ECT sensor. Perform TEST VER-2. If voltage is less than 4 volts, turn ignition off. Disconnect PCM connector.
5. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of ECT sensor connector, signal circuit (Tan/Black wire). If resistance is more than 5 ohms, replace PCM. Perform TEST VER-2. If resistance is less than 5 ohms, repair short to ground in Tan/Black wire. Perform TEST VER-2.

TEST FC-14A - THROTTLE POSITION SENSOR VOLTAGE HIGH (DTC 24)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, read Throttle Position Sensor (TPS) voltage. If TPS voltage is more than 4.5 volts, go to step 5). If TPS voltage is less than 4.5 volts, slowly open and close throttle while observing DRB-II.
2. If voltage change was not smooth, replace TPS. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If voltage change was smooth, wiggle wiring harness from TPS to Powertrain Control Module (PCM) while observing DRB-II. If voltage changed, repair wiring harness as necessary. Perform TEST VER-2.
3. If voltage did not change, condition required to set fault is not present at this time. THROTTLE POSITION SENSOR VOLTAGE HIGH fault sets if TPS signal circuit (Orange/Dark Blue wire) is more than 4.5 volts. Possible causes are: open TPS signal circuit (Orange/Dark Blue wire), open TPS ground circuit (Black/Light Blue wire) or TPS sensor failure. Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
5. Disconnect TPS connector. Connect a jumper wire between TPS signal circuit (Orange/Dark Blue wire) and TPS ground circuit (Black/Light Blue wire) on TPS connector. Using DRB-II, read TPS voltage. If voltage is less than one volt, replace TPS. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
6. If voltage is more than one volt, move jumper wire from TPS connector, ground circuit (Black/Light Blue wire), to an engine ground. Using DRB-II, read TPS sensor voltage.
7. If TPS sensor voltage is less than one volt, repair open in Black/Light Blue wire. Perform TEST VER-2. If TPS voltage is more than one volt, turn ignition off. Disconnect PCM connector.
8. Using an external ohmmeter, check resistance of TPS signal circuit (Orange/Dark Blue wire) between TPS connector and PCM connector terminal No. 22. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2. If resistance is more than 5 ohms, repair open in Orange/Dark Blue wire. Perform TEST VER-2.

TEST FC-15A - THROTTLE POSITION SENSOR VOLTAGE LOW (DTC 24)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, read Throttle Position Sensor (TPS) voltage. If TPS voltage is less than .2 volt, go to step 5). If TPS voltage is more than .2 volt, slowly open and close throttle while observing DRB-II.
2. If voltage change was not smooth, replace TPS. Perform TEST VER-2. If voltage change was smooth, wiggle wiring harness from TPS to Powertrain Control Module (PCM) while observing DRB-II. If voltage changed, repair wiring harness as necessary. Perform TEST VER-2.
3. If voltage did not change, condition required to set fault is not present at this time. THROTTLE POSITION SENSOR VOLTAGE LOW fault sets if TPS signal circuit (Orange/Dark Blue wire) is less than .2 volt or if vehicle speed is more than 20 MPH, engine speed is more than 1500 RPM and vacuum is less than 2 in. Hg with TPS signal circuit (Orange/Dark Blue wire) less than .5 volt. Possible causes are: short to ground in TPS signal circuit (Orange/Dark Blue wire), TPS sensor failure or open TPS 5-volt supply circuit (Violet/White wire). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
5. Disconnect TPS connector. Using DRB-II, read TPS voltage. If voltage is more than one volt, replace TPS. Perform TEST VER-2. If voltage is less than one volt, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Using DRB-II, check resistance of TPS connector, signal circuit (Orange/Dark Blue wire).
6. If resistance is more than 5 ohms, replace PCM. Perform TEST VER-2. If resistance is less than 5 ohms, disconnect Transmission Control Module (TCM) connector. Using DRB-II, check resistance of TPS connector, signal circuit (Orange/Dark Blue wire).
7. If resistance is less than 5 ohms, repair short to ground in Orange/Dark Blue wire. Perform TEST VER-2. If resistance is more than 5 ohms, replace TCM. Perform TEST VER-2.

TEST FC-16A - IDLE AIR CONTROL MOTOR CIRCUITS (DTC 25)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Turn ignition off. Start engine. Allow engine to reach normal operating temperature. Using DRB-II, read fault messages. If DRB-II displays IDLE AIR CONTROL MOTOR CIRCUITS, go to step 5).
2. If DRB-II does not display IDLE AIR CONTROL MOTOR CIRCUITS, use DRB-II to set engine speed to 1800 RPM, then to 700 RPM. If engine speed responded accordingly, go to next step. If engine speed did not respond accordingly, go to step 5).
3. Condition required to set fault is not present at this time. IDLE AIR CONTROL MOTOR CIRCUITS fault sets if any of 4 Idle Air Control (IAC) motor wires are shorted to ground or battery voltage. Possible causes are: open IAC motor wires, IAC motor internally shorted or IAC motor wires shorted together. Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
5. Turn ignition off. Disconnect Idle Air Control (IAC) motor connector. Disconnect Powertrain Control Module (PCM) connector. Using DRB-II, check resistance of each wire on IAC motor connector. If resistance for any wire was less than 5 ohms, repair necessary wire for a short to ground. Perform TEST VER-2.
6. If resistance for all wires was more than 5 ohms, turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on each wire of IAC motor connector. If voltage for any wire was more than one volt, repair necessary wire for a short to voltage. Perform TEST VER-2.
7. If voltage for all wires was less than one volt, turn ignition off. Using an external ohmmeter, check resistance of each wire between IAC motor connector and PCM connector. See PCM TERMINAL IDENTIFICATION table. If resistance for any wire was more than 5 ohms, repair open on necessary wire. Perform TEST VER-2. If resistance for all wires was less than 5 ohms, go to next step. PCM TERMINAL IDENTIFICATION Wire Color Terminal No. Gray/Red 39 Brown/White 40 Violet/Black 59 Yellow/Black 60
8. Using an external ohmmeter, check resistance between following wires at PCM connector. Record resistance readings. PCM connector terminal No. 39 (Gray/Red wire) and terminal No. 60 (Yellow/Black wire). PCM connector terminal No. 59 (Violet/Black wire) and terminal No. 60 (Yellow/Black wire). PCM connector terminal No. 39 (Gray/Red wire) and terminal No. 59 (Violet/Black wire). PCM connector terminal No. 40 (Brown/White wire) and terminal No. 60 (Yellow/Black wire).
9. If resistance between any 2 wires was less than 5 ohms, repair those wires for shorting together. Perform TEST VER-2. If resistance between all pairs of wires was more than 5 ohms, reconnect PCM connector.
10. Turn ignition on. Using DRB-II, actuate IAC motor. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on each IAC motor connector wire at IAC motor connector. Normal voltage reading will switch from less than one volt to more than 10 volts.
11. If voltage is switching at each IAC motor connector wire, replace IAC motor. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If voltage is not switching at each IAC motor connector wire, replace PCM. Perform TEST VER-2.

TEST FC-17A - INJECTOR NO. 1 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds.
2. Using DRB-II, read fault messages. If engine started, allow engine to idle for at least 20 seconds. If DRB-II does not display INJECTOR NO. 1 CONTROL CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays INJECTOR NO. 1 CONTROL CIRCUIT, go to step 6).
3. INJECTOR NO. 1 CONTROL CIRCUIT fault sets if Powertrain Control Module (PCM) does not detect injector "turn off edge" when expected. Possible causes are: open or shorted injector ground circuit (White/Dark Blue wire), open injector power supply circuit (Dark Green/Orange wire), open injector, or failed driver in Powertrain Control Module (PCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
5. Start engine. Wiggle wiring harness from injector No. 1 to Powertrain Control Module (PCM). If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
6. Turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit between injector connector (harness side) White/Dark Blue wire and Dark Green/Orange wire. If resistance is not 10-15 ohms, go to «TEST FC-17B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-17b-injector-no-1) .
7. If resistance is 10-15 ohms, move ohmmeter lead from injector connector Dark Green/Orange wire to ground. If resistance is less than 5 ohms, repair short to ground in White/Dark Blue wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on injector connector (harness side) Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
9. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 16, injector driver circuit (White/Dark Blue wire). If resistance is less than 5 ohms, repair short to ground in White/Dark Blue wire. Perform TEST VER-2.
10. If resistance is more than 5 ohms, check resistance of injector driver circuit (White/Dark Blue wire) between injector connector (harness side) and PCM connector terminal No. 16 using an external ohmmeter.
11. If resistance is more than 5 ohms, repair open in White/Dark Blue wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-17B - INJECTOR NO. 1 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. It may be necessary to remove intake plenum to access injector connectors. Reconnect 10-pin injector connector. Disconnect injector No. 1 connector. Turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode.
2. Using DRB-II, check voltage on injector No. 1 connector Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. If voltage is more than 10 volts, turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit (White/Dark Blue wire) between injector No. 1 connector and 10-pin injector connector.
3. If resistance is more than 5 ohms, repair open in White/Dark Blue wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, replace injector. Perform TEST VER-2.

TEST FC-18A - INJECTOR NO. 2 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds.
2. Using DRB-II, read fault messages. If engine started, allow engine to idle for at least 20 seconds. If DRB-II does not display INJECTOR NO. 2 CONTROL CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays INJECTOR NO. 2 CONTROL CIRCUIT, go to step 6).
3. INJECTOR NO. 2 CONTROL CIRCUIT fault sets if Powertrain Control Module (PCM) does not detect injector "turn off edge" when expected. Possible causes are: open or shorted injector ground circuit (Tan wire), open injector power supply circuit (Dark Green/Orange wire), open injector, or failed driver in Powertrain Control Module (PCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, go to next step.
5. Start engine. Wiggle wiring harness from injector No. 2 to Powertrain Control Module (PCM). If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
6. Turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit between injector connector (harness side) Tan wire and Dark Green/Orange wire. If resistance is not 10-15 ohms, go to «TEST FC-18B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-18b-injector-no-2) .
7. If resistance is 10-15 ohms, move ohmmeter lead from injector connector Dark Green/Orange wire to ground. If resistance is less than 5 ohms, repair short to ground in Tan wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
8. If resistance is more than 5 ohms, turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on injector connector (harness side) Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
9. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 15, injector driver circuit (Tan wire). If resistance is less than 5 ohms, repair short to ground in Tan wire. Perform TEST VER-2.
10. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of injector driver circuit (Tan wire) between injector connector (harness side) and PCM connector terminal No. 15.
11. If resistance is more than 5 ohms, repair open in Tan wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-18B - INJECTOR NO. 2 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. It may be necessary to remove intake plenum to access injector connectors. Reconnect 10-pin injector connector. Disconnect injector No. 2 connector. Turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode.
2. Using DRB-II, check voltage on injector No. 2 connector Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. If voltage is more than 10 volts, turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit (Tan wire) between injector No. 2 connector and 10-pin injector connector.
3. If resistance is more than 5 ohms, repair open in Tan wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace injector. Perform TEST VER-2.

TEST FC-19A - INJECTOR NO. 3 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds.
2. Using DRB-II, read fault messages. If engine started, allow engine to idle for at least 20 seconds. If DRB-II does not display INJECTOR NO. 3 CONTROL CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays INJECTOR NO. 3 CONTROL CIRCUIT, go to step 6).
3. INJECTOR NO. 3 CONTROL CIRCUIT fault sets if Powertrain Control Module (PCM) does not detect injector "turn off edge" when expected. Possible causes are: open or shorted injector ground circuit (Yellow/White wire), open injector power supply circuit (Dark Green/Orange wire), open injector, or failed driver in Powertrain Control Module (PCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
5. Start engine. Wiggle wiring harness from injector No. 3 to Powertrain Control Module (PCM). If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
6. Turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit between injector connector (harness side) Yellow/White wire and Dark Green/Orange wire. If resistance is not 10-15 ohms, go to «TEST FC-19B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-19b-injector-no-3) .
7. If resistance is 10-15 ohms, move ohmmeter lead from injector connector Dark Green/Orange wire to ground. If resistance is less than 5 ohms, repair short to ground in Yellow/White wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
8. If resistance is more than 5 ohms, turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on injector connector (harness side) Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
9. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 14, injector driver circuit (Yellow/White wire). If resistance is less than 5 ohms, repair short to ground in Yellow/White wire. Perform TEST VER-2.
10. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of injector driver circuit (Yellow/White wire) between injector connector (harness side) and PCM connector terminal No. 14.
11. If resistance is more than 5 ohms, repair open in Yellow/White wire. Perform TEST VER-2. If it is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-19B - INJECTOR NO. 3 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. It may be necessary to remove intake plenum to access injector connectors. Reconnect 10-pin injector connector. Disconnect injector No. 3 connector. Turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode.
2. Using DRB-II, check voltage on injector No. 3 connector Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. If voltage is more than 10 volts, turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit (Yellow/White wire) between injector No. 3 connector and 10-pin injector connector.
3. If resistance is more than 5 ohms, repair open in Yellow/White wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, replace injector. Perform TEST VER-2.

TEST FC-20A - INJECTOR NO. 4 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds.
2. Using DRB-II, read fault messages. If engine started, allow engine to idle for at least 20 seconds. If DRB-II does not display INJECTOR NO. 4 CONTROL CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays INJECTOR NO. 4 CONTROL CIRCUIT, go to step 6).
3. INJECTOR NO. 4 CONTROL CIRCUIT fault sets if Powertrain Control Module (PCM) does not detect injector "turn off edge" when expected. Possible causes are: open or shorted injector ground circuit (Light Blue/Brown wire), open injector power supply circuit (Dark Green/Orange wire), open injector, or failed driver in Powertrain Control Module (PCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
5. Start engine. Wiggle wiring harness from injector No. 4 to Powertrain Control Module (PCM). If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
6. Turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit between injector connector (harness side) Light Blue/Brown wire and Dark Green/Orange wire. If resistance is not 10-15 ohms, go to «TEST FC-20B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-20b-injector-no-4) .
7. If resistance is 10-15 ohms, move ohmmeter lead from injector connector Dark Green/Orange wire to ground. If resistance is less than 5 ohms, repair short to ground in Light Blue/Brown wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on injector connector (harness side) Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
9. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 13, injector driver circuit (Light Blue/Brown wire). If resistance is less than 5 ohms, repair short to ground in Light Blue/Brown wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
10. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of injector driver circuit (Light Blue/Brown wire) between injector connector (harness side) and PCM connector terminal No. 13.
11. If resistance is more than 5 ohms, repair open in Light Blue/Brown wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-20B - INJECTOR NO. 4 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. It may be necessary to remove intake plenum to access injector connectors. Reconnect 10-pin injector connector. Disconnect injector No. 4 connector. Turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode.
2. Using DRB-II, check voltage on injector No. 4 connector Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. If voltage is more than 10 volts, turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit (Light Blue/Brown wire) between injector No. 4 connector and 10-pin injector connector.
3. If resistance is more than 5 ohms, repair open in Light Blue/Brown wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, replace injector. Perform TEST VER-2.

TEST FC-21A - INJECTOR NO. 5 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds.
2. Using DRB-II, read fault messages. If engine started, allow engine to idle for at least 20 seconds. If DRB-II does not display INJECTOR NO. 5 CONTROL CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays INJECTOR NO. 5 CONTROL CIRCUIT, go to step 6).
3. INJECTOR NO. 5 CONTROL CIRCUIT fault sets if Powertrain Control Module (PCM) does not detect injector "turn off edge" when expected. Possible causes are: open or shorted injector ground circuit (Gray wire), open injector power supply circuit (Dark Green/Orange wire), open injector, or failed driver in Powertrain Control Module (PCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
5. Start engine. Wiggle wiring harness from injector No. 5 to Powertrain Control Module (PCM). If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
6. Turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit between injector connector (harness side) Gray wire and Dark Green/Orange wire. If resistance is not 10-15 ohms, go to «TEST FC-21B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-21b-injector-no-5) .
7. If resistance is 10-15 ohms, move ohmmeter lead from injector connector Dark Green/Orange wire to ground. If resistance is less than 5 ohms, repair short to ground in Gray wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
8. If resistance is more than 5 ohms, turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on injector connector (harness side) Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
9. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 38, injector driver circuit (Gray wire). If resistance is less than 5 ohms, repair short to ground in Gray wire. Perform TEST VER-2.
10. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of injector driver circuit (Gray wire) between injector connector (harness side) and PCM connector terminal No. 38.
11. If resistance is more than 5 ohms, repair open in Gray wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-21B - INJECTOR NO. 5 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. It may be necessary to remove intake plenum to access injector connectors. Reconnect 10-pin injector connector. Disconnect injector No. 5 connector. Turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode.
2. Using DRB-II, check voltage on injector No. 5 connector Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. If voltage is more than 10 volts, turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit (Gray wire) between injector No. 5 connector and 10-pin injector connector.
3. If resistance is more than 5 ohms, repair open in Gray wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace injector. Perform TEST VER-2.

TEST FC-22A - INJECTOR NO. 6 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Attempt to start engine. If engine will not start, crank engine for at least 10 seconds.
2. Using DRB-II, read fault messages. If engine started, allow engine to idle for at least 20 seconds. If DRB-II does not display INJECTOR NO. 6 CONTROL CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays INJECTOR NO. 6 CONTROL CIRCUIT, go to step 6).
3. INJECTOR NO. 6 CONTROL CIRCUIT fault sets if Powertrain Control Module (PCM) does not detect injector "turn off edge" when expected. Possible causes are: open or shorted injector ground circuit (Brown/Dark Blue wire), open injector power supply circuit (Dark Green/Orange wire), open injector, or failed driver in Powertrain Control Module (PCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
5. Start engine. Wiggle wiring harness from injector No. 6 to Powertrain Control Module (PCM). If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
6. Turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit between injector connector (harness side) Brown/Dark Blue wire and Dark Green/Orange wire. If resistance is not 10-15 ohms, go to «TEST FC-22B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-22b-injector-no-6) .
7. If resistance is 10-15 ohms, move ohmmeter lead from injector connector Dark Green/Orange wire to ground. If resistance is less than 5 ohms, repair short to ground in Brown/Dark Blue wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
8. If resistance is more than 5 ohms, turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on injector connector (harness side) Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
9. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 58, injector driver circuit (Brown/Dark Blue wire). If resistance is less than 5 ohms, repair short to ground in Brown/Dark Blue wire. Perform TEST VER-2.
10. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of injector driver circuit (Brown/Dark Blue wire) between injector connector (harness side) and PCM connector terminal No. 58.
11. If resistance is more than 5 ohms, repair open in Brown/Dark Blue wire. Perform TEST VER-2. If it is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-22B - INJECTOR NO. 6 CONTROL CIRCUIT (DTC 27)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. It may be necessary to remove intake plenum to access injector connectors. Reconnect 10-pin injector connector. Disconnect injector No. 6 connector. Turn ignition on. Using DRB-II, actuate Auto Shutdown (ASD) relay. Put DRB-II in voltmeter mode.
2. Using DRB-II, check voltage on injector No. 6 connector Dark Green/Orange wire. If voltage is less than 10 volts, repair open in Dark Green/Orange wire. If voltage is more than 10 volts, turn ignition off. Disconnect 10-pin injector connector. Using an external ohmmeter, check resistance of injector driver circuit (Brown/Dark Blue wire) between injector No. 6 connector and 10-pin injector connector.
3. If resistance is more than 5 ohms, repair open in Brown/Dark Blue wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace injector. Perform TEST VER-2.

TEST FC-23A - EVAP PURGE SOLENOID CIRCUIT (DTC 31)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Using DRB-II, actuate Evaporative (EVAP) purge solenoid. Using DRB-II, read fault messages. If DRB-II does not display EVAP PURGE SOLENOID CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays EVAP PURGE SOLENOID CIRCUIT, go to step 5).
2. EVAP PURGE SOLENOID CIRCUIT fault sets if evaporative purge solenoid is not in its proper state when monitored by Powertrain Control Module (PCM). Possible causes are: open or shorted evaporative purge solenoid, open evaporative purge solenoid power supply circuit (Dark Blue wire), open or shorted evaporative purge solenoid ground circuit (Pink/Black wire), or failed Powertrain Control Module (PCM). Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
4. Using DRB-II, read fault messages. Evaporative purge solenoid actuation test should still be running. Wiggle wiring harness from evaporative purge solenoid to Powertrain Control Module (PCM). If EVAP PURGE SOLENOID CIRCUIT fault returned, repair wiring harness as necessary. Perform TEST VER-2. If EVAP PURGE SOLENOID CIRCUIT fault did not return, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
5. Turn ignition off. Disconnect evaporative purge solenoid connector. Turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on evaporative purge solenoid connector Dark Blue wire. If voltage is less than 10 volts, repair open in Dark Blue wire. Perform TEST VER-2.
6. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Using an external ohmmeter, check resistance of ground circuit (Pink/Black wire) between evaporative purge solenoid connector and PCM connector terminal No. 52. If resistance is less than 5 ohms, repair short to ground in Pink/Black wire. Perform TEST VER-2.
7. If resistance is more than 5 ohms, reconnect evaporative purge solenoid connector. Turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on PCM connector terminal No. 52 (Pink/Black wire). If voltage is less than 10 volts, replace evaporative purge solenoid. Perform TEST VER-2. If voltage is more than 10 volts, replace PCM. Perform TEST VER-2.

TEST FC-24A - EGR SOLENOID CIRCUIT (DTC 32)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Using DRB-II, actuate EGR solenoid. Using DRB-II, read fault messages. If DRB-II does not display EGR SOLENOID CIRCUIT, condition required to set fault is not present at this time. Go to next step. If DRB-II displays EGR SOLENOID CIRCUIT, go to step 5).
2. EGR SOLENOID CIRCUIT fault sets if EGR solenoid is not in its proper state when monitored by Powertrain Control Module (PCM). Possible causes are: open or shorted EGR solenoid, open EGR solenoid power supply circuit (Dark Blue wire), open or shorted EGR solenoid ground circuit (Gray/Yellow wire), or failed Powertrain Control Module (PCM). Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
4. Using DRB-II, read fault messages. EGR actuation test should still be running. Wiggle wiring harness from EGR solenoid to Powertrain Control Module (PCM). If EGR SOLENOID CIRCUIT fault returned, repair wiring harness as necessary. Perform TEST VER-2. If EGR SOLENOID CIRCUIT fault did not return, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.
5. Turn ignition off. Disconnect EGR solenoid connector. Turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on EGR solenoid connector, 12-volt feed circuit (Dark Blue wire). If voltage is less than 10 volts, repair open in Dark Blue wire. Perform TEST VER-2.
6. If voltage is more than 10 volts, turn ignition off. Disconnect Power-train Control Module (PCM) connector. Using an external ohmmeter, check resistance of ground circuit (Gray/Yellow wire) between EGR solenoid connector and PCM connector terminal No. 35. If resistance is more than 5 ohms, repair open in Gray/Yellow wire. Perform TEST VER-2.
7. If resistance is less than 5 ohms, put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 35 (Gray/Yellow wire). If resistance is less than 5 ohms, repair short to ground in Gray/Yellow wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
8. If resistance is more than 5 ohms, reconnect EGR solenoid connector. Turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on PCM connector terminal No. 35 (Gray/Yellow wire). If voltage is less than 10 volts, replace EGR solenoid. Perform TEST VER-2. If voltage is more than 10 volts, replace PCM. Perform TEST VER-2.

TEST FC-25A - EGR SYSTEM FAILURE (DTC 32)

1. Start engine. Allow engine to idle for at least 2 minutes. Disconnect vacuum supply hose from Exhaust Gas Recirculation (EGR) solenoid. Connect a vacuum gauge to end of disconnected hose. If vacuum gauge indicates less than 10 in. Hg, repair vacuum supply to EGR solenoid. Perform TEST VER-2.
2. If vacuum gauge indicates more than 10 in. Hg, reconnect vacuum hose to EGR solenoid. Disconnect vacuum hose from EGR valve. Connect a vacuum gauge to end of disconnected hose. While observing vacuum gauge, momentarily raise engine speed to more than 2000 RPM.
3. If vacuum gauge indicated less than 5 in. Hg while throttle was opened, replace EGR valve assembly. Perform TEST VER-2. If vacuum gauge indicated more than 5 in. Hg while throttle was opened, remove vacuum gauge.
4. Connect a vacuum pump to EGR valve. With engine idling, slowly apply vacuum to EGR valve. If engine idle became rough as vacuum was applied, go to next step. If engine idle did not become rough, remove EGR valve and inspect manifold and EGR backpressure tube for restrictions. If restrictions are present, clean as necessary. Perform TEST VER-2. If no restrictions are present, replace EGR valve assembly. Perform TEST VER-2.
5. Turn ignition off. Apply vacuum to EGR valve. Observe vacuum gauge. If vacuum was not held for at least 10 seconds, replace EGR valve assembly. Perform TEST VER-2.
6. If vacuum was held for at least 10 seconds, condition required to set fault is not present at this time. EGR SYSTEM FAILURE fault sets when Powertrain Control Module (PCM) performs a test of EGR system and monitors oxygen sensor signal for a change, but does not detect any change in oxygen sensor signal. Possible causes are: EGR valve not opening, EGR backpressure tube blocked or EGR passages in manifold blocked. Go to next step.
7. Inspect all related vacuum hoses and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with vacuum hoses and connectors, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition) . Perform TEST VER-2.

TEST FC-26A - A/C CLUTCH RELAY CIRCUIT (DTC 33)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Using DRB-II, actuate A/C clutch relay. If A/C clutch relay is clicking, go to next step. If A/C clutch relay is not clicking, go to step 5).
2. Condition required to set fault is not present at this time. A/C CLUTCH RELAY CIRCUIT fault sets if A/C clutch relay control circuit (Dark Blue/Orange wire) is not in its proper state when monitored by Powertrain Control Module (PCM). Possible causes are: open or short in A/C clutch relay coil windings, open or short in A/C clutch relay control circuit (Dark Blue/Orange wire), open or short in A/C clutch relay ignition feed circuit (Dark Green wire), or failed driver in Powertrain Control Module (PCM). Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
4. While still actuating A/C clutch relay, wiggle wiring harness from A/C clutch relay to Powertrain Control Module (PCM). Stop actuation of A/C clutch relay. Using DRB-II, read fault messages. If A/C CLUTCH RELAY CIRCUIT fault returned, repair wiring harness as necessary. Perform TEST VER-2. If A/C CLUTCH RELAY CIRCUIT fault did not return, system is now functioning properly. Perform TEST VER-2.
5. Remove A/C clutch relay. Install a known good A/C clutch relay. If known good A/C clutch relay is clicking, replace original A/C clutch relay. Perform TEST VER-2. If known good A/C clutch relay is not clicking, remove known good A/C clutch relay. Put DRB-II in voltmeter mode.
6. Ensure A/C clutch relay actuation test is still running. Using DRB-II, check voltage on A/C clutch relay connector, ignition feed circuit (Dark Green wire). If voltage is less than 10 volts, repair open in Dark Green wire. Perform TEST VER-2.
7. If voltage is more than 10 volts, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of A/C clutch relay connector, control circuit (Dark Blue/Orange wire). If resistance is less than 5 ohms, repair short to ground in Dark Blue/Orange wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of control circuit (Dark Blue/Orange wire) between A/C clutch relay connector and PCM connector terminal No. 34. If resistance is more than 5 ohms, repair open in Dark Blue/Orange wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-27A - RAD FAN CONTROL RELAY CIRCUIT (DTC 35)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Using DRB-II, actuate radiator fan relay. If radiator fan relay is clicking, condition required to set fault is not present at this time. Go to next step. If radiator fan relay is not clicking, go to step 5).
2. RAD FAN CONTROL RELAY CIRCUIT fault sets if radiator fan relay control circuit (Dark Blue/Pink wire) is not in its proper state when monitored by Powertrain Control Module (PCM). Possible causes are: open or short in radiator fan relay coil windings, open or short in radiator fan relay control circuit (Dark Blue/Pink wire), open or short in radiator fan relay ignition feed circuit (White wire), or failed driver in Powertrain Control Module (PCM). Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
4. While still actuating radiator fan relay, wiggle wiring harness from radiator fan relay to Powertrain Control Module (PCM). Stop actuation of radiator fan relay. Using DRB-II, read fault messages. If RAD FAN CONTROL RELAY CIRCUIT fault returned, repair wiring harness as necessary. Perform TEST VER-2. If RAD FAN CONTROL RELAY CIRCUIT fault did not return, system is now functioning properly. Perform TEST VER-2.
5. Remove radiator fan relay. Install a known good radiator fan relay. If known good radiator fan relay is clicking, replace original radiator fan relay. Perform TEST VER-2. If known good radiator fan relay is not clicking, remove known good radiator fan relay. Put DRB-II in voltmeter mode.
6. DRB-II should still be actuating radiator fan relay. Using DRB-II, check voltage on radiator fan relay connector, ignition feed circuit (White wire). If voltage is less than 10 volts, repair open in White wire. Perform TEST VER-2. If voltage is more than 10 volts, turn ignition off.
7. Disconnect PCM connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of radiator fan relay connector, control circuit (Dark Blue/Pink wire). If resistance is less than 5 ohms, repair short to ground in Dark Blue/Pink wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of control circuit (Dark Blue/Pink wire) between radiator fan relay connector and PCM connector terminal No. 31. If resistance is more than 5 ohms, repair open in Dark Blue/Pink wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-28A - LOW SPEED FAN CONTROL RELAY CIRCUIT (DTC 35)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Using DRB-II, actuate low speed radiator fan relay. If low speed radiator fan relay is not clicking, go to step 5). If low speed radiator fan relay is clicking, condition required to set fault is not present at this time. Go to next step.
2. The LOW SPEED FAN CONTROL RELAY CIRCUIT fault sets if low speed radiator fan relay control circuit (Dark Blue/Pink wire) is not in its proper state when monitored by Powertrain Control Module (PCM). Possible causes are: open or short in low speed radiator fan relay coil windings, open or short in low speed radiator fan relay control circuit (Dark Blue/Pink wire), open or short in low speed radiator fan relay ignition feed circuit (Dark Blue wire) or failed driver in PCM. Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
4. While still actuating low speed radiator fan relay, wiggle wiring harness from radiator fan relay to PCM. Stop actuation of low speed radiator fan relay. Using DRB-II, read fault messages. If LOW SPEED FAN CONTROL RELAY CIRCUIT fault returned, repair wiring harness as necessary. Perform TEST VER-2. If LOW SPEED FAN CONTROL RELAY CIRCUIT fault did not return, system is now functioning properly. Perform TEST VER-2.
5. Remove low speed radiator fan relay. Install a known good low speed radiator fan relay. If known good low speed radiator fan relay is clicking, replace original low speed radiator fan relay. Perform TEST VER-2. If known good low speed radiator fan relay is not clicking, remove known good low speed radiator fan relay. Put DRB-II in voltmeter mode.
6. DRB-II should still be actuating low speed radiator fan relay. Using DRB-II, check voltage on low speed radiator fan relay connector, ignition feed circuit (Dark Blue wire). If voltage is less than 10 volts, repair open in Dark Blue wire. Perform TEST VER-2. If voltage is more than 10 volts, turn ignition off.
7. Disconnect PCM connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of low speed radiator fan relay connector, control circuit (Dark Blue/Pink wire). If resistance is less than 5 ohms, repair short to ground in Dark Blue/Pink wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of control circuit (Dark Blue/Pink wire) between radiator fan relay connector and PCM connector terminal No. 31. If resistance is more than 5 ohms, repair open in Dark Blue/Pink wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-29A - HIGH SPEED FAN CONTROL RELAY CIRCUIT (DTC 35)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Using DRB-II, actuate high speed radiator fan relay. If high speed radiator fan relay is not clicking, go to step 5). If high speed radiator fan relay is clicking, condition required to set fault is not present at this time. Go to next step.
2. The HIGH SPEED FAN CONTROL RELAY CIRCUIT fault sets if high speed radiator fan relay control circuit (Yellow wire) is not in its proper state when monitored by Powertrain Control Module (PCM). Possible causes are: open or short in high speed radiator fan relay coil windings, open or short in high speed radiator fan relay control circuit (Yellow wire), open or short in high speed radiator fan relay ignition feed circuit (Dark Blue wire) or failed driver in PCM. Go to next step.
3. Inspect all related wiring and connectors, and repair as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no problems were found with wiring and connectors, go to next step.
4. While still actuating high speed radiator fan relay, wiggle wiring harness from radiator fan relay to PCM. Stop actuation of high speed radiator fan relay. Using DRB-II, read fault messages. If HIGH SPEED FAN CONTROL RELAY CIRCUIT fault returned, repair wiring harness as necessary. Perform TEST VER-2. If HIGH SPEED FAN CONTROL RELAY CIRCUIT fault did not return, system is now functioning properly. Perform TEST VER-2.
5. Remove high speed radiator fan relay. Install a known good high speed radiator fan relay. If known good high speed radiator fan relay is clicking, replace original high speed radiator fan relay. Perform TEST VER-2. If known good high speed radiator fan relay is not clicking, remove known good high speed radiator fan relay. Put DRB-II in voltmeter mode.
6. DRB-II should still be actuating high speed radiator fan relay. Using DRB-II, check voltage on high speed radiator fan relay connector, ignition feed circuit (Dark Blue wire). If voltage is less than 10 volts, repair open in Dark Blue wire. Perform TEST VER-2. If voltage is more than 10 volts, turn ignition off.
7. Disconnect PCM connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of high speed radiator fan relay connector, control circuit (Yellow wire). If resistance is less than 5 ohms, repair short to ground in Yellow wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of control circuit (Yellow wire) between radiator fan relay connector and PCM connector terminal No. 55. If resistance is more than 5 ohms, repair open in Yellow wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-30A - AUTO SHUTDOWN RELAY CONTROL CIRCUIT (DTC 42)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase fault messages. Using DRB-II, actuate Auto Shutdown (ASD) relay. If ASD relay is clicking, go to next step. If ASD relay is not clicking, go to step 6).
2. If vehicle will not start and run, go to «TEST FC-30B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-30b-auto-shutdown-relay) . If vehicle will start and run, condition required to set fault is not present at this time. Go to next step.
3. AUTO SHUTDOWN RELAY CONTROL CIRCUIT fault sets if Auto Shutdown (ASD) relay and fuel pump relay control circuits (Dark Blue/Yellow wire) are not in proper state when monitored by Powertrain Control Module (PCM) during cranking. Possible causes are: open or short in ASD relay and fuel pump relay control circuits (Dark Blue/Yellow wire), open or short in ASD relay ignition feed circuit (Dark Blue/White wire), or failed driver in Powertrain Control Module (PCM). Go to next step.
4. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, go to next step.
5. While still actuating ASD relay, wiggle wiring harness from ASD relay to Powertrain Control Module (PCM). Stop actuation of ASD relay. Using DRB-II, read fault messages. If AUTO SHUTDOWN RELAY CONTROL CIRCUIT fault returned, repair wiring harness as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If AUTO SHUTDOWN RELAY CONTROL CIRCUIT fault did not return, system is now functioning properly. Perform TEST VER-2.
6. Remove ASD relay. Install a known good ASD relay. If known good ASD relay is clicking, replace original ASD relay. Perform TEST VER-2. If known good ASD relay is not clicking, remove known good ASD relay. Put DRB-II in voltmeter mode.
7. DRB-II should still be actuating ASD relay. Using DRB-II, check voltage on ASD relay connector, ignition feed circuit (Dark Blue wire). If voltage is less than 10 volts, repair open in Dark Blue wire. Perform TEST VER-2. If voltage is more than 10 volts, turn ignition off.
8. Disconnect PCM connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of ASD relay connector, control circuit (Dark Blue/Yellow wire). If resistance is less than 5 ohms, repair short to ground in Dark Blue/Yellow wire. Perform TEST VER-2.
9. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of control circuit (Dark Blue/Yellow wire) between ASD relay connector and PCM connector terminal No. 51. If resistance is more than 5 ohms, repair open in Dark Blue/Yellow wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-30B - AUTO SHUTDOWN RELAY CONTROL CIRCUIT (DTC 42)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Disconnect ASD relay. Using DRB-II, check voltage on ASD relay connector, battery feed circuit (Red/White wire). If voltage is less than 12 volts, repair open in Red/White wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If voltage is more than 12 volts, turn ignition off.
2. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of ASD relay connector, output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, repair open in Dark Green/Orange wire. Perform TEST VER-2.
3. If resistance is less than 5 ohms, reconnect PCM connector. Install a known good ASD relay. If engine will start and run, replace original ASD relay. Perform TEST VER-2. If engine will not start and run, replace PCM. Perform TEST VER-2.

TEST FC-31A - NO ASD RELAY VOLT SENSE AT PCM (DTC 42)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Attempt to start engine. Crank engine for at least 5 seconds. If engine started, repair open in Dark Green/Orange wire between Auto Shutdown (ASD) relay connector and Powertrain Control Module (PCM) connector. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
2. If engine did not start, disconnect ASD relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on ASD relay connector, battery feed circuit (Red/White wire). If voltage is less than 12 volts, repair open in Red/White wire. Perform TEST VER-2.
3. If voltage is more than 12 volts, turn ignition off. Disconnect PCM connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of output circuit (Dark Green/Orange wire) between ASD relay connector and PCM connector terminal No. 57. If resistance is more than 5 ohms, repair open in Dark Green/Orange wire. Perform TEST VER-2.
4. If resistance is less than 5 ohms, reconnect PCM connector. Install a known good ASD relay. Attempt to start engine. If engine started, replace original ASD relay. Perform TEST VER-2. If engine did not start, replace PCM. Perform TEST VER-2.

TEST FC-32A - IGNITION COIL NO. 1 PRIMARY CIRCUIT (DTC 43)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase faults. Attempt to start engine. If necessary, crank engine for at least 10 seconds. Read faults. If DRB-II does not display IGNITION COIL NO. 1 PRIMARY CIRCUIT, go to next step. If DRB-II displays IGNITION COIL NO. 1 PRIMARY CIRCUIT, go to step 5).
2. At this time, condition required to set fault is not present. IGNITION COIL NO. 1 PRIMARY CIRCUIT fault sets when Powertrain Control Module (PCM) does not see peak current reached. Possible causes are: open or shorted coil, open or shorted control circuit (Gray wire), open power supply circuit (Dark Green/Orange wire), or failed driver in PCM.
3. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, go to next step.
4. Start engine. Wiggle wiring harness from Direct Ignition System (DIS) coil pack to PCM. If engine misfired or stalled, repair wiring harness as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2). If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition). Perform TEST VER-2.
5. Turn ignition off. Disconnect ignition coil connector. Turn ignition on. Using DRB-II, actuate ignition coil No. 1. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on ignition coil connector, ASD output circuit (Dark Green/Orange wire). If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
6. If voltage is more than 10 volts, use an external ohmmeter to check resistance of ignition coil No. 1 primary circuit. Put one ohmmeter lead on ignition coil connector, cylinders No. 1 and 4 pin, and other ohmmeter lead on ignition coil connector, battery positive pin. (Scheme 100) If resistance is more than 2 ohms, replace ignition coil. Perform TEST VER-2.
7. If resistance is less than 2 ohms, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 19, ignition coil No. 1 driver circuit (Gray wire). If resistance is less than 5 ohms, repair short to ground in Gray wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2).
8. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of ignition coil driver circuit (Gray wire) between ignition coil connector and PCM connector terminal No. 19. If resistance is more than 5 ohms, repair open in Gray wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

Identifying Ignition Coil Connector Terminals. Scheme 100

TEST FC-33A - IGNITION COIL NO. 2 PRIMARY CIRCUIT (DTC 43)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase faults. Attempt to start engine. If necessary, crank engine for at least 10 seconds. Read faults. If DRB-II does not display IGNITION COIL NO. 2 PRIMARY CIRCUIT, go to next step. If DRB-II displays IGNITION COIL NO. 2 PRIMARY CIRCUIT, go to step 5).
2. At this time, condition required to set fault is not present. IGNITION COIL NO. 2 PRIMARY CIRCUIT fault sets when Powertrain Control Module (PCM) does not see peak current reached. Possible causes are: open or shorted coil, open or shorted control circuit (Dark Blue/Yellow wire), open power supply circuit (Dark Green/Orange wire), or failed driver in PCM.
3. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, go to next step.
4. Start engine. Wiggle wiring harness from Direct Ignition System (DIS) coil pack to PCM. If engine misfired or stalled, repair wiring harness as necessary. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2). If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition). Perform TEST VER-2.
5. Turn ignition off. Disconnect ignition coil connector. Turn ignition on. Using DRB-II, actuate ignition coil No. 2. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on ignition coil connector, ASD output circuit (Dark Green/Orange wire). If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform TEST VER-2.
6. If voltage is more than 10 volts, use an external ohmmeter to check resistance of ignition coil No. 2 primary circuit. Put one ohmmeter lead on ignition coil connector, cylinders No. 2 and 5 pin, and other ohmmeter lead on ignition coil connector, battery positive pin. (Scheme 100) If resistance is more than 2 ohms, replace ignition coil. Perform TEST VER-2.
7. If resistance is less than 2 ohms, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 17, ignition coil No. 2 driver circuit (Dark Blue/Yellow wire). If resistance is less than 5 ohms, repair short to ground in Dark Blue/Tan wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of ignition coil driver circuit (Dark Blue/Yellow wire) between ignition coil connector and PCM connector terminal No. 17. If resistance is more than 5 ohms, repair open in Dark Blue/Yellow wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-34A - IGNITION COIL NO. 3 PRIMARY CIRCUIT (DTC 43)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, erase faults. Attempt to start engine. If necessary, crank engine for at least 10 seconds. Read faults. If DRB-II does not display IGNITION COIL NO. 3 PRIMARY CIRCUIT, go to next step. If DRB-II displays IGNITION COIL NO. 3 PRIMARY CIRCUIT, go to step 5).
2. At this time, condition required to set fault is not present. IGNITION COIL NO. 3 PRIMARY CIRCUIT fault sets when Powertrain Control Module (PCM) does not see peak current reached. Possible causes are: open or shorted coil, open or shorted control circuit (Red/Yellow wire), open power supply circuit (Dark Green/Orange wire), or failed driver in PCM.
3. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, go to next step.
4. Start engine. Wiggle wiring harness from Direct Ignition System (DIS) coil pack to PCM. If engine misfired or stalled, repair wiring harness as necessary. Perform TEST VER-2. If engine did not misfire or stall, see «INACTIVE FAULT CONDITION»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__inactive-fault-condition). Perform TEST VER-2.
5. Turn ignition off. Disconnect ignition coil connector. Turn ignition on. Using DRB-II, actuate ignition coil No. 3. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on ignition coil connector, ASD output circuit (Dark Green/Orange wire). If voltage is less than 10 volts, repair open in Dark Green/Orange wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2).
6. If voltage is more than 10 volts, use an external ohmmeter to check resistance of ignition coil No. 3 primary circuit. Put one ohmmeter lead on ignition coil connector, cylinders No. 3 and 6 pin, and other ohmmeter lead on ignition coil connector, battery positive pin. (Scheme 100) If resistance is more than 2 ohms, replace ignition coil. Perform TEST VER-2.
7. If resistance is less than 2 ohms, turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 18, ignition coil No. 3 driver circuit (Red/Yellow wire). If resistance is less than 5 ohms, repair short to ground in Red/Yellow wire. Perform TEST VER-2.
8. If resistance is more than 5 ohms, use an external ohmmeter to check resistance of ignition coil driver circuit (Red/Yellow wire) between ignition coil connector and PCM connector terminal No. 18. If resistance is more than 5 ohms, repair open in Red/Yellow wire. Perform TEST VER-2. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-2.

TEST FC-35A - PCM FAILURE SRI MILE NOT STORED OR PCM FAILURE EEPROM WRITE DENIED (DTC 62 or 63)

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition on. Using DRB-II, perform SRI memory test. If DRB-II displays WRITE FAILURE, replace Powertrain Control Module (PCM). Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If DRB-II does not display WRITE FAILURE, go to next step.
2. If DRB-II displays WRITE REFUSED, go to step 4). If DRB-II does not display WRITE REFUSED, go to next step.
3. If DRB-II displays SRI MILEAGE INVALID, update mileage and retest SRI memory. Perform TEST VER-2. If DRB-II does not display SRI MILEAGE INVALID, compare SRI mileage stored with instrument panel odometer. If mileage is same, retest SRI memory. Perform TEST VER-2. If mileage is not same, update mileage and retest SRI memory. Perform TEST VER-2.
4. When DRB-II displays WRITE REFUSED, Powertrain Control Module (PCM) was busy. Using DRB-II, perform SRI memory test. Retest SRI memory 2 more times if necessary. If DRB-II displays WRITE REFUSED, replace PCM. Perform TEST VER-2. If DRB-II does not display WRITE REFUSED, vehicle is functioning properly. Perform TEST VER-2.

No Fault Complete Test

Check TECH SERVICE BULLETINS (TSBs) for any pertinent information. If a TSB exists, perform corrective action. If TSB does not exist or if driveability problem still exists, perform tests NF-2A through NF-15A in sequence until drive-ability problem is found. See NO FAULT CODE TEST MENU table.

NO FAULT CODE TEST MENU

No Fault Quick Individual Test

If it is suspected that any item listed in NO FAULT CODE TEST MENU table is cause of a vehicle's driveability problem, perform associated test(s) individually. Return to NO FAULT CODE TEST MENU table if driveability problem still exists, or perform NO FAULT COMPLETE TEST.

No Fault Quick Symptom Test

Symptom checks cannot be used properly unless driveability problem characteristic actually happens while vehicle is being tested. To reduce diagnostic time, ensure that TEST FC-1A is reviewed before attempting to diagnose a symptom.

Select symptom that most accurately describes vehicle's driveability problem and then perform test pertaining to this symptom. Perform each test in sequence until problem is found. See NO FAULT QUICK SYMPTOM TEST MENU table.

NO FAULT QUICK SYMPTOM TEST MENU

TEST NF-2A - CHECKING SECONDARY IGNITION & TIMING

1. Turn engine off. Connect engine analyzer to engine. Start engine, and let it idle. If engine will not idle, maintain engine speed for reading scope pattern. Set scope to read display or parade pattern. Follow equipment manufacturer's procedure for pattern analysis.
2. If secondary ignition pattern is not okay, repair indicated component in secondary ignition system. Perform TEST VER-2. If secondary ignition pattern is okay, disconnect any spark plug wire. Observe secondary kilovolt line.
3. If open circuit secondary voltage is not at least 25 kilovolts, replace electronic ignition coil. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If open circuit secondary voltage is at least 25 kilovolts, reinstall spark plug wire.
4. Ensure engine temperature is more than 180°F (82°C) before proceeding. Using DRB-II, read total spark advance. Increase engine speed to 2000 RPM. If spark advance does not change with increase in RPM, replace Powertrain Control Module (PCM). Perform TEST VER-2. If spark advance changes with increase in RPM, ignition timing is functioning properly. Test is complete.

TEST NF-3A - CHECKING FUEL PRESSURE

1. Release fuel pressure. Connect fuel pressure gauge to fuel rail. Turn ignition on. Using DRB-II, actuate fuel system. If fuel pressure is 43-53 psi (3.0-3.7 kg/cm 2 ), fuel pressure is normal. Test is complete. If fuel pressure is not 43-53 psi (3.0-3.7 kg/cm 2 ), record fuel pressure reading. If pressure is more than 53 psi (3.7 kg/cm 2 ), go to «TEST NF-3B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-nf-3b-checking-fuel-pressure) .
2. If pressure is not more than 53 psi (3.7 kg/cm 2 ), stop fuel system actuation. Turn ignition off. Inspect fuel lines for kinked or restricted lines. Repair fuel lines as necessary. Perform TEST VER-2.
3. If no kinked or restricted lines exist, release fuel pressure. Remove fuel pressure gauge. Install fuel pressure gauge between fuel tank and fuel filter. Turn ignition on. Using DRB-II, actuate fuel system. If fuel pressure is at least 5 psi (.4 kg/cm 2 ) more than previously recorded pressure, replace fuel filter. Perform TEST VER-2. CAUTION: DO NOT allow fuel pressure to exceed 60 psi (4.2 kg/cm 2 ) when squeezing fuel return hose.
4. If fuel pressure is not at least 5 psi (.4 kg/cm 2 ) more than previous reading, gently squeeze fuel return hose while observing fuel pressure gauge, ensuring fuel pressure does not exceed 60 psi (4.2 kg/cm 2 ). If fuel pressure increases, replace fuel pressure regulator. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If fuel pressure does not increase, replace fuel pump and sock assembly. Perform TEST VER-2.

TEST NF-3B - CHECKING FUEL PRESSURE

1. Using DRB-II, stop fuel system actuation. Release fuel pressure. Ensure fuel tank is at least 1/4 full before performing following test. Install fuel pressure gauge and adapter between fuel tank and filter at rear of vehicle.
2. Remove fuel return line from fuel pump at fuel tank. Connect Fuel Pressure Test Adapter (6541) to fuel return line. Place other end of adapter hose into an approved 2-gallon gasoline can. Turn ignition on.
3. Using DRB-II, actuate fuel system. Observe fuel pressure gauge. If fuel pressure is 43-53 psi (3.0-3.7 kg/cm 2 ), repair fuel return line for a restriction at fuel tank. Perform TEST VER-2.
4. If fuel pressure is not 43-53 psi (3.0-3.7 kg/cm 2 ), stop fuel system actuation. Release fuel pressure. Reconnect fuel return line to fuel tank. Disconnect fuel return line from fuel rail.
5. Attach Fuel Pressure Test Adapter (6541) to fuel return line nipple at fuel rail. Place other end of adapter hose into an approved 2-gallon gasoline can. Turn ignition on. Using DRB-II, actuate fuel system. Observe fuel pressure gauge.
6. If fuel pressure is 43-53 psi (3.0-3.7 kg/cm 2 ), repair fuel return line for a restriction to fuel tank. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If fuel pressure is not 43-53 psi (3.0-3.7 kg/cm 2 ), replace fuel pressure regulator. Perform TEST VER-2.

TEST NF-4A - CHECKING COOLANT SENSOR CALIBRATION & RADIATOR

FAN OPERATION

1. Start engine. Using DRB-II, read Engine Coolant Temperature (ECT) sensor value. If ECT sensor temperature is more than 180°F (82°C), stop engine. Allow engine coolant to cool to 150°F (66°C). Start engine. Allow engine to reach normal operating temperature of 180°F (82°C). If ECT sensor value does not increase smoothly, replace ECT sensor. Perform TEST VER-2. If ECT sensor value increases smoothly, go to next step.
2. If ECT sensor value did not reach 180°F (82°C) or more, replace ECT sensor. Perform TEST VER-2. If ECT sensor value reached 180°F (82°C) or more, run engine until radiator fan operates or ECT sensor value reaches 220°F (104°C). If cooling fan does not operate, repair cooling system as necessary. Perform TEST VER-2. If cooling fan operates, system is functioning properly. Test is complete.

TEST NF-5A - CHECKING TPS CALIBRATION

1. Turn engine off. Turn ignition on. Using DRB-II, read Throttle Position Sensor (TPS) voltage. Ensure throttle is fully closed and against throttle stop.
2. If voltage is not one volt or less with throttle closed, replace TPS. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If voltage is one volt or less with throttle closed, watch voltage while slowly opening throttle wide open. If voltage change was not smooth, replace TPS. Perform TEST VER-2. If voltage change was smooth, go to next step.
3. If maximum voltage was not at least 3.6 volts at wide open throttle, replace TPS. Perform TEST VER-2. If maximum voltage was at least 3.6 volts at wide open throttle, TPS is functioning properly. Test is complete.

TEST NF-6A - CHECKING MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR

CALIBRATION

1. Turn engine off. Install vacuum "T" in MAP sensor vacuum hose. Install vacuum gauge. Start engine, and let it idle. If engine will not idle, maintain a constant RPM above idle. Using DRB-II, read MAP value. If reading is within one in. Hg of vacuum gauge reading, MAP sensor is functioning properly. Test is complete. If reading is not within one in. Hg of vacuum gauge reading, turn engine off.
2. Disconnect MAP sensor connector. Turn ignition on. Using DRB-II, check voltage on MAP sensor connector, 5-volt supply circuit (Violet/White wire). If voltage is more than 5 volts, replace MAP sensor. Perform TEST VER-2. If voltage is less than 5 volts, repair open in Violet/White wire. Perform TEST VER-2.

TEST NF-7A - CHECKING OXYGEN (O2) SENSOR SWITCHING

1. Allow engine to reach normal operating temperature. Using DRB-II, read O2 sensor state. If O2 sensor state is switching, system is functioning properly. Test is complete. If O2 sensor state is not switching, check if O2 sensor is locked on lean. If O2 sensor is locked on lean, go to «TEST NF-7B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-nf-7b-checking-oxygen-o2) . If O2 sensor is not locked on lean, turn engine off.
2. Turn engine off. Remove upper half of intake manifold. Turn ignition on. Using DRB-II, actuate fuel system. Inspect injectors for fuel leakage. If injectors are leaking, replace leaking injectors or "O" rings as necessary. Perform TEST VER-2.
3. If injectors are not leaking, stop fuel system actuation. Turn ignition off. Reinstall upper half of intake manifold. Inspect air cleaner and inlet ducts for restrictions. Repair as required. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If no restrictions are observed, go to «TEST NF-15A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-nf-15a-no-fault-code) .

TEST NF-7B - CHECKING OXYGEN (O2) SENSOR SWITCHING

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Allow engine to idle. Inspect engine for vacuum leaks. Repair vacuum leaks as necessary. Perform TEST VER-2. If no vacuum leaks exist, use DRB-II to read O2 sensor signal voltage.
2. If voltage is more than 0.1 volt, go to step 4). If voltage is less than 0.1 volt, turn ignition off. Disconnect O2 sensor connector. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of O2 sensor connector (harness side), signal circuit (Black/Dark Green wire).
3. If resistance is less than 10 ohms, repair short to ground in Black/Dark Green wire. Perform TEST VER-2. If resistance is more than 10 ohms, replace O2 sensor. Perform TEST VER-2.
4. Turn engine off. Replace O2 sensor. Turn ignition on. Using DRB-II, reset adaptive fuel memory. Start engine. Allow engine to reach normal operating temperature.
5. Using DRB-II, read O2 sensor state. If O2 sensor state is switching, repair is complete. Perform TEST VER-2. If O2 sensor state is not switching, go to «TEST NF-15A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-nf-15a-no-fault-code) .

TEST NF-8A - CHECKING IDLE AIR CONTROL MOTOR

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, set engine speed to 1100 RPM. If engine speed set at 1050-1150 RPM, idle speed motor is operating properly. Test is complete. If engine speed did not set at 1050-1150 RPM, return engine to normal idle speed. Disconnect idle air control motor connector.
2. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on idle air control motor connector, driver No. 1 circuit (Brown/White wire) while momentarily opening and closing throttle. If voltage is less than one volt, go to TEST NF-8B. If voltage is more than one volt, go to next step.
3. Using DRB-II, check voltage on idle air control motor connector, driver No. 2 circuit (Yellow/Black wire) while momentarily opening and closing throttle. If voltage is less than one volt, go to TEST NF-8B. If voltage is more than one volt, go to next step.
4. Using DRB-II, check voltage on idle air control motor connector, driver No. 3 circuit (Gray/Red wire) while momentarily opening and closing throttle. If voltage is less than one volt, go to TEST NF-8B. If voltage is more than one volt, go to next step.
5. Using DRB-II, check voltage on idle air control motor connector, driver No. 4 circuit (Violet/Black wire) while momentarily opening and closing throttle. If voltage is less than one volt, go to TEST NF-8B. If voltage is more than one volt, go to next step.
6. Check engine for vacuum leaks. Repair as required. Perform TEST VER-2. If no vacuum leaks are observed, replace idle air control motor. Perform TEST VER-2.

TEST NF-8B - CHECKING IDLE AIR CONTROL MOTOR

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

Turn engine off. Disconnect Powertrain Control Module (PCM) connector. Using an external ohmmeter, check resistance on each wire between Idle Air Control (IAC) motor connector and PCM connector. See PCM TERMINAL IDENTIFICATION table. If resistance for any wire was more than 10 ohms, repair open on necessary wire. Perform TEST VER-2 . If resistance for all wires was less than 10 ohms, replace PCM. Perform TEST VER-2.

PCM TERMINAL IDENTIFICATION

TEST NF-9A - CHECKING SOLENOID OPERATIONS

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, actuate purge solenoid. While touching top of purge solenoid, feel for operation. If purge solenoid does not operate, replace purge solenoid. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
2. If purge solenoid operates, actuate EGR solenoid. While touching top of EGR solenoid, feel for operation. If EGR solenoid does not operate, replace EGR solenoid. Perform TEST VER-2. If EGR solenoid operates, test is complete.

TEST NF-10A - CHECKING PARK/NEUTRAL SWITCH

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, read park/neutral switch input state. While watching DRB-II display, move gear selector in and out of Park and Reverse positions. If display shows P/N and D/R, system is functioning properly. Test is complete. If display does not show P/N and D/R, go to next step.
2. Turn ignition off. Place gear selector in Park position. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance on PCM connector terminal No. 30, park/neutral switch sense circuit (Brown/Yellow wire). Observe DRB-II display while moving gear selector in and out of Park and Reverse positions.
3. If display switches from less than 5 ohms to more than 5 ohms, replace PCM. Perform TEST VER-2. If display does not switch from less than 5 ohms to more than 5 ohms, check if display always stays less than 5 ohms. If display always stays less than 5 ohms, repair short to ground in Brown/Yellow wire. Perform TEST VER-2. If display does not always stay less than 5 ohms, go to next step.
4. Disconnect park/neutral switch connector. Using an external ohmmeter, check resistance of sense circuit (Brown/Yellow wire) between park/neutral switch connector and PCM connector terminal No. 30. If resistance is less than 10 ohms, replace park/neutral switch. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is more than 10 ohms, repair open in Brown/Yellow wire. Perform TEST VER-2.

TEST NF-11A - CHECKING PCM GROUNDS & POWER CIRCUITS

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 5, signal ground circuit (Black/White wire). If resistance is more than 5 ohms, repair open in Black/White wire. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) . If resistance is less than 5 ohms, go to next step.
2. Using DRB-II, check resistance of PCM connector terminal No. 11, power ground circuit (Black/Tan wire). If resistance is more than 5 ohms, repair open in Black/Tan wire. Perform TEST VER-2. If resistance is less than 5 ohms, go to next step.
3. Using DRB-II, check resistance of PCM connector terminal No. 12, power ground circuit (Black/Tan wire). If resistance is more than 5 ohms, repair open in Black/Tan wire. Perform TEST VER-2. If resistance is less than 5 ohms, go to next step.
4. Put DRB-II in voltmeter mode. Turn ignition on. Using DRB-II, check voltage on PCM connector terminal No. 9, ignition 12-volt feed circuit (Dark Blue wire). If voltage is less than 10 volts, repair open in Dark Blue wire. Perform TEST VER-2. If voltage is more than 10 volts, turn ignition off. Reconnect PCM connector. PCM grounds and power circuits are okay. Test is complete.

TEST NF-12A - CHECKING EGR SYSTEM

1. Disconnect vacuum hose from EGR solenoid. Connect vacuum gauge to disconnected vacuum hose. Start engine. If vacuum is more than 10 in. Hg at idle, go to step 3).
2. If vacuum is less than 10 in. Hg at idle, disconnect EGR vacuum signal hose at intake manifold. Connect a vacuum gauge to intake nipple. Read vacuum gauge at idle. If vacuum is more than 10 in. Hg at idle, repair restriction or leak in vacuum hose to EGR solenoid. Perform TEST VER-2. If vacuum is less than 10 in. Hg at idle, repair plugged vacuum nipple at intake manifold. Perform TEST VER-2.
3. Disconnect vacuum gauge. Reconnect vacuum hose to EGR solenoid. Disconnect vacuum hose from EGR valve. Connect vacuum gauge to disconnected hose. While observing vacuum gauge, momentarily snap throttle open. If vacuum is less than 5 in. Hg, replace EGR valve assembly. Perform TEST VER-2. If vacuum is more than 5 in. Hg, go to next step.
4. Disconnect hose to EGR valve backpressure signal tube. Adjust a shop air hose to 20 psi (1.4 kg/cm 2 ). Connect shop air to nipple on base of EGR valve. Listen for a tone change while opening and closing throttle.
5. If tone changes, replace EGR valve. Perform TEST VER-2. If tone does not change, remove vacuum gauge. Cap open nipple at EGR valve base. Connect hand vacuum pump to EGR valve.
6. Listen for engine RPM change while slowly applying vacuum to EGR valve. If engine RPM does not change, replace EGR valve. Perform TEST VER-2. If engine RPM changes, turn ignition off. Apply 10 in. Hg and hold for 30 seconds. If vacuum holds for 30 seconds, EGR system is functioning properly. Test is complete. If vacuum does not hold for 30 seconds, replace EGR valve. Perform TEST VER-2.

TEST NF-13A - CHECKING ENGINE VACUUM

Connect a vacuum gauge to engine. Start engine, and let it idle. Normal vacuum reading will vary depending on altitude. Observe vacuum gauge at idle. If vacuum gauge reading is not steady 13-22 in. Hg, perform TEST NF-15A . If vacuum gauge reading is steady 13-22 in. Hg, engine vacuum is normal. Test is complete.

TEST NF-14A - CHECKING MINIMUM IDLE AIRFLOW

1. Turn ignition off. Disconnect PCV valve hose from vacuum nipple. Install Vacuum Fitting (6457) to intake manifold PCV nipple. Disconnect 3/16" hose from throttle body. Cap 3/16" hose nipple on throttle body. Start engine. Allow engine to reach normal operating temperature.
2. If vehicle has less than 1000 miles on odometer, go to next step. If vehicle has more than 1000 miles on odometer, use DRB-II to actuate minimum airflow. Engine speed should be 700-950 RPM. If engine speed is 700-950, minimum airflow is normal. Test is complete. If engine speed is not 700-950, replace throttle body. Perform «TEST VER-2»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-2) .
3. Using DRB-II, actuate minimum airflow. If engine speed is 650-950 RPM, minimum airflow is normal. Test is complete. If engine speed is not 650-950 RPM, replace throttle body. Perform TEST VER-2.

TEST NF-15A - NO FAULT CODE MECHANICAL TEST

Note. If coming to this test from O2 sensor test and rich or lean condition is not corrected after checking items listed below, replace Powertrain Control Module (PCM).

At this point in diagnostic test procedure, all engine control systems have been determined to be operating as designed and not causing a driveability problem. Following additional items should be checked as possible causes

1. Check if any TECH SERVICE BULLETINS (TSBs) apply to vehicle.
2. Check engine compression.
3. Check for exhaust system restriction.
4. Check camshaft and crankshaft sprockets.
5. Check valve timing.
6. Check torque converter stall speed.
7. Check engine vacuum. It must be at least 13 in. Hg in Neutral.
8. Check for fuel contamination.
9. Ensure PCV system is functioning properly.
10. Ensure injector control circuit is connected to correct fuel injector and injector is not plugged or restricted.
11. Check power booster for internal vacuum leak.

TEST NS-1A - QUALIFYING NO-START CONDITION

1. Turn ignition off. Disconnect any spark plug cable at spark plug. Insert an insulated screwdriver in spark plug cable terminal. Hold screwdriver within 1/4" of ground. NOTE: When checking for spark, consider one or two sparks as a no-spark condition.
2. While cranking engine for 10 seconds, watch for spark. If a good spark occurs, go to TEST NS-2A. If a good spark does not occur, reconnect spark plug cable. Disconnect another spark plug cable at spark plug, and repeat test.
3. If a good spark occurs, replace spark plug cable that was initially used to test for spark. If a good spark does not occur, disconnect ignition coil connector. Inspect all related wiring and connectors, and repair as necessary. Perform TEST VER-2. If no problems were found with wiring and connectors, replace ignition coil. Perform TEST VER-2.

TEST NS-2A - INSPECTING FUEL SYSTEM

1. Ensure throttle cables are not holding throttle open. If throttle is held open, repair as required. Perform TEST VER-1. If throttle is not held open, use DRB-II to read Throttle Position Sensor (TPS) voltage.
2. If voltage is less than 1.5 volts, go to next step. If voltage is more than 1.5 volts, disconnect TPS connector. Inspect terminals. Repair as required. Perform TEST VER-1. If terminals are okay, replace TPS. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) .
3. If vehicle is not equipped with a factory vehicle theft alarm, go to next step. If vehicle is equipped with factory vehicle theft alarm, use DRB-II to read theft alarm status. If DRB-II displays FUEL ON, go to next step. If DRB-II does not display FUEL ON, see G - BODY TESTS W/CODES article in the ENGINE PERFORMANCE Section.
4. Using DRB-II, actuate fuel system. Listen for fuel pump operation at fuel tank. If fuel pump operation cannot be heard, go to «TEST NS-5A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-5a-inspecting-fuel-pump) . If fuel pump operation can be heard, turn ignition off.
5. Ensure fuel tank is at least 1/4 full. Release fuel pressure. Install a fuel pressure gauge in fuel supply line. Turn ignition on. Using DRB-II, actuate fuel system. Read fuel pressure gauge reading.
6. If fuel pressure is more than 53 psi (3.7 kg/cm 2 ), go to «TEST NS-4B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-4b-correcting-fuel-delivery) . If fuel pressure is not more than 53 psi (3.7 kg/cm 2 ), go to next step.
7. If pressure is less than 43 psi (3.0 kg/cm 2 ), go to «TEST NS-4A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-4a-correcting-fuel-delivery) . If pressure is more than 43 psi (3.0 kg/cm 2 ), go to next step.
8. If vehicle initially started and stalled repeatedly, go to «TEST NS-7A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-7a-inspecting-idle-air) . If vehicle did not initially start and stall repeatedly, go to TEST NS-3A.

TEST NS-3A - INSPECTING MECHANICAL SYSTEM

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Disconnect Manifold Absolute Pressure (MAP) sensor connector. Turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on MAP sensor connector, 5-volt supply circuit (Violet/White wire). If voltage is less than 4.5 volts, repair open in Violet/White wire. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) .
2. If voltage is more than 4.5 volts, reconnect MAP sensor connector. Remove all spark plugs. Inspect spark plug tips for wet fuel. If spark plug tips are wet, clean and reinstall spark plugs. If spark plug tips are not wet, reinstall spark plugs. Turn ignition on.
3. Using DRB-II, read total spark advance while cranking engine. If spark advance is not 0-25 degrees BTDC, replace Powertrain Control Module (PCM). Perform TEST VER-1.
4. If spark advance is 0-25 degrees BTDC, inspect spark plug cables for correct placement. Reposition wires as required. Perform TEST VER-1. If spark plug cables are okay, turn ignition off. Check valve timing. Correct valve timing as required. Perform TEST VER-1.
5. If valve timing is okay, check engine compression. Repair as required. Perform TEST VER-1. If engine compression is okay, replace MAP sensor. Perform TEST VER-1.

TEST NS-4A - CORRECTING FUEL DELIVERY

1. Record fuel pressure gauge reading. Turn ignition off. Release fuel pressure. Remove fuel pressure gauge. Install fuel pressure gauge between fuel tank and fuel filter. Turn ignition on.
2. Using DRB-II, actuate Auto Shutdown (ASD) fuel system. Record fuel pressure gauge reading. Compare fuel pressure gauge reading with previous reading. If fuel pressure gauge reading is not at least 10 psi more than previous reading, go to step 4). If fuel pressure gauge reading is at least 10 psi more than previous reading, turn ignition off.
3. Inspect fuel lines between fuel filter and fuel rail for restriction. Repair as required. Perform TEST VER-1. If no restrictions are observed, replace fuel filter. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) . CAUTION: DO NOT allow fuel pressure to exceed 60 psi (4.2 kg/cm 2 ) when squeezing fuel return hose.
4. Gently squeeze fuel return hose. Read fuel pressure gauge. Using DRB-II, stop fuel system actuator test. If pressure is more than 43 psi (3.0 kg/cm 2 ), replace fuel pressure regulator. Perform TEST VER-1. If it is less than 43 psi (3.0 kg/cm 2 ), replace fuel pump and sock filter. Perform TEST VER-1.

TEST NS-4B - CORRECTING FUEL DELIVERY

1. Ensure fuel tank is at least 1/4 full. Release fuel pressure. Turn ignition off. Disconnect fuel return hose from fuel rail. Connect a 6-foot fuel hose to fuel fitting. Put other end of 6-foot hose into an approved 2-gallon or more capacity gasoline container.
2. Turn ignition on. Using DRB-II, actuate fuel system. If pressure is less than 53 psi (3.7 kg/cm 2 ), go to next step. If pressure is more than 53 psi (3.7 kg/cm 2 ), replace fuel pressure regulator. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) .
3. Stop fuel system actuation. Turn ignition off. Reconnect fuel return hose. Remove fuel return hose from fuel tank. Connect Fuel Pressure Test Adapter (C-6541) to disconnected return hose.
4. Put other end of adapter hose into an approved 2-gallon or more capacity gasoline container. Turn ignition on. Using DRB-II, actuate fuel system. Read fuel pressure gauge. Using DRB-II, stop actuation test.
5. If pressure is less than 53 psi (3.7 kg/cm 2 ), repair restricted fuel pump. Perform TEST VER-1. If pressure is more than 53 psi (3.7 kg/cm 2 ), repair restricted fuel return line between fuel rail and fuel tank. Perform TEST VER-1.

TEST NS-5A - INSPECTING FUEL PUMP

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Using DRB-II, stop actuation test. Using DRB-II, actuate Auto Shutdown (ASD) relay. Touch fuel pump relay. If fuel pump relay does not pulsate when actuated, go to «TEST NS-5B»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-5b-inspecting-fuel-pump) . If fuel pump relay pulsates when actuated, turn ignition off.
2. Disconnect fuel pump relay. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on fuel pump relay connector, battery voltage circuit (Red/White wire). If voltage is less than 10 volts, repair open circuit in Red/White wire. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) . If voltage is more than 10 volts, reconnect fuel pump relay.
3. Disconnect fuel pump harness connector. Ensure fuel pump connector has clean and tight connections. Turn ignition on. Using DRB-II, actuate fuel system. While still actuating, put DRB-II in voltmeter mode. Using DRB-II, check voltage on fuel pump connector, output wire (Dark Green/Black wire). If voltage is less than 10 volts, go to step 5). If voltage is more than 10 volts, stop actuation test.
4. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of fuel pump connector, ground circuit (Black wire). If resistance is more than 5 ohms, repair open in Black wire. Perform TEST VER-1. If resistance is less than 5 ohms, replace fuel pump. Perform TEST VER-1.
5. Turn ignition off. Disconnect fuel pump relay. Connect a jumper wire between fuel pump relay connector, output circuit (Dark Green/Black wire) and ground. Put DRB-II in ohmmeter mode.
6. Using DRB-II, check resistance of fuel pump connector, output circuit (Dark Green/Black wire). If resistance is less than 5 ohms, replace fuel pump relay. Perform TEST VER-1. If resistance is less than 5 ohms, repair open in Dark Green/Black wire. Perform TEST VER-1.

TEST NS-5B - INSPECTING FUEL PUMP

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Stop actuation test. Turn ignition off. Disconnect fuel pump relay. Turn ignition on. Using DRB-II, check voltage on fuel pump relay connector terminal "A", ignition 12-volt supply circuit (Dark Blue wire).
2. If voltage is less than 10 volts, repair open in Dark Blue wire. Perform TEST VER-1. If voltage is more than 10 volts, go to next step.
3. Using an external ohmmeter, check resistance across fuel pump relay terminals. (Scheme 101) If resistance is more than 100 ohms, replace fuel pump relay. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1). If resistance is less than 100 ohms, repair open in Dark Blue/Yellow wire. Perform TEST VER-1.

Testing Fuel Pump Relay. Scheme 101

TEST NS-6A - CORRECTING NO RESPONSE CONDITION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. If vehicle starts, go to TEST NS-6B. If vehicle does not start, turn ignition off. Disconnect Throttle Position Sensor (TPS) connector. Turn ignition on. Put DRB-II in voltmeter mode.
2. Using DRB-II, check voltage on TPS connector, 5-volt supply circuit (Violet/White wire). If voltage is more than 6 volts, repair open ground circuits at Powertrain Control Module (PCM) connector terminals No. 5 (Black/White wire), No. 11 (Black/Tan wire) and No. 12 (Black/Tan wire). Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) . If voltage is less than 6 volts, go to next step.
3. If voltage is less than 4.4 volts, go to step 5). If voltage is more than 4.4 volts, reconnect TPS connector. Disconnect Manifold Absolute Pressure (MAP) sensor connector.
4. Using DRB-II, check voltage on MAP sensor connector, 5-volt supply circuit (Violet/White wire). If voltage is more than 4.4 volts, go to TEST NS-6B. If voltage is less than 4.4 volts, replace TPS. Perform TEST VER-1.
5. Disconnect MAP sensor electrical connector. Using DRB-II, check voltage on TPS connector, 5-volt supply circuit (Violet/White wire). If voltage is more than 4.4 volts, replace MAP sensor. Perform TEST VER-1.
6. If voltage is less than 4.4 volts, turn ignition off. Disconnect PCM connector. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 6, 5-volt supply circuit (Violet/White wire).
7. If resistance is less than 5 ohms, repair short to ground in Violet/White wire. Perform TEST VER-1. If resistance is more than 5 ohms, turn ignition on. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on PCM connector terminal No. 9, ignition 12-volt feed circuit (Dark Blue wire).
8. If voltage is less than 10 volts, repair open in Dark Blue wire between PCM connector and ignition switch. Perform TEST VER-1. If voltage is more than 10 volts, go to next step.
9. Using DRB-II, check voltage on PCM connector terminal No. 3, battery voltage circuit (Red/White wire). If voltage is more than 10 volts, replace PCM. Perform TEST VER-1. If voltage is less than 10 volts, go to next step.
10. On AS body vehicles, go to «TEST NS-6C»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-6c-correcting-no-response) . On AN body vehicles, remove fuse "J" from Power Distribution Center (PDC). Inspect fuse. If fuse is okay, go to next step. If fuse is blown, go to step 12).
11. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on battery voltage side of PDC fuse "J" socket. If voltage is more than 10 volts, repair open in Red/White wire between PDC fuse "J" socket and PCM connector terminal No. 3. Perform TEST VER-1. If voltage is less than 10 volts, repair open in battery voltage side of PDC fuse "J" socket. Perform TEST VER-1.
12. Turn ignition off. Disconnect Auto Shutdown (ASD) and fuel pump relays. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of PCM connector terminal No. 3, fused battery voltage circuit (Red/White wire). If resistance is less than 5 ohms, repair short to ground in Red/White wire. Perform TEST VER-1.
13. If resistance is more than 5 ohms, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is less than 5 ohms, go to step 16). If resistance is more than 5 ohms, go to next step.
14. Disconnect fuel pump connector and oxygen sensor connector. Using DRB-II, check resistance of fuel pump connector, output circuit (Dark Green/Black wire). If resistance is less than 5 ohms, repair short to ground in Dark Green/Black wire. Perform TEST VER-1.
15. If resistance is more than 5 ohms, use DRB-II to check resistance of oxygen sensor connector, relay output circuit (White wire). If resistance is more than 5 ohms, replace fuel pump. Perform TEST VER-1. If resistance is less than 5 ohms, replace oxygen sensor. Perform TEST VER-1.
16. Disconnect ignition coil connector. Using DRB-II, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, replace ignition coil. Perform TEST VER-1.
17. If resistance is less than 5 ohms, disconnect generator field connector. Using DRB-II, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, repair short to ground in generator. Perform TEST VER-1.
18. If resistance is less than 5 ohms, disconnect fuel injector harness connector. Using DRB-II, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, repair short to ground in fuel injector harness (Dark Green/Orange wire). Perform TEST VER-1. If resistance is less than 5 ohms, repair short to ground in ASD relay connector Dark Green/Orange wire. Perform TEST VER-1.

TEST NS-6B - CORRECTING NO RESPONSE CONDITION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. If ignition was not on when NO RESPONSE message was displayed, turn ignition on to get a response. If ignition was on when NO RESPONSE message was displayed, turn ignition off.
2. Disconnect DRB-II from engine diagnostic connector. Disconnect Powertrain Control Module (PCM) connector. Using an external ohmmeter, check resistance between engine diagnostic connector, SCI transmit circuit (Pink wire) and ground.
3. If resistance is less than 5 ohms, repair short to ground in Pink wire. Perform TEST VER-1. If resistance is more than 5 ohms, use an external ohmmeter to check resistance between engine diagnostic connector, SCI receive circuit (Light Green wire), and ground.
4. If resistance is less than 5 ohms, repair short to ground in Light Green wire. Perform TEST VER-1. If resistance is more than 5 ohms, go to next step.
5. Using an external ohmmeter, check resistance of SCI transmit circuit (Pink wire) between engine diagnostic connector and PCM connector terminal No. 25. If resistance is more than 5 ohms, repair open in Pink wire. Perform TEST VER-1.
6. If resistance is less than 5 ohms, use an external ohmmeter to check resistance of SCI receive circuit (Light Green wire) between engine diagnostic connector and PCM connector terminal No. 45. If resistance is more than 5 ohms, repair open in Light Green wire. Perform TEST VER-1.
7. If resistance is less than 5 ohms, connect DRB-II to a functional engine diagnostic connector on another vehicle. Turn ignition on. Using DRB-II, attempt to read fault messages. If DRB-II does not display NO RESPONSE, replace PCM on initial vehicle. Perform TEST VER-1.
8. If DRB-II displays NO RESPONSE, substitute another DRB-II cartridge. Using DRB-II, attempt to read fault messages. If DRB-II does not display NO RESPONSE, replace DRB-II cartridge. If DRB-II displays NO RESPONSE, substitute another DRB-II adapter cable. Using DRB-II, attempt to read fault messages. If DRB-II does not display NO RESPONSE, replace DRB-II adapter cable. If DRB-II displays NO RESPONSE, replace DRB-II or cartridge.

TEST NS-6C - CORRECTING NO RESPONSE CONDITION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Inspect fusible links located in engine compartment near left strut tower. If fusible link(s) is blown, go to next step. If fusible link(s) is okay, repair open in Red/White wire between PCM connector terminal No. 3 and battery positive. Perform TEST VER-1.
2. Turn ignition off. Remove Auto Shutdown (ASD) and fuel pump relays. Put DRB-II in ohmmeter mode. Using DRB-II, check resistance of Powertrain Control Module (PCM) connector terminal No. 3, fused battery voltage circuit (Red/White wire). If resistance is less than 5 ohms, repair short to ground in Red/White wire. Perform TEST VER-1.
3. If resistance is more than 5 ohms, use DRB-II to check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, go to next step. If resistance is less than 5 ohms, go to step 5).
4. Disconnect fuel pump connector. Using DRB-II, check resistance of fuel pump connector, output circuit (Dark Green/Black wire). If resistance is less than 5 ohms, repair short to ground in Dark Green/Black wire. Perform TEST VER-1. If resistance is more than 5 ohms, replace fuel pump. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) .
5. Disconnect oxygen sensor connector. Using DRB-II, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is less than 5 ohms, go to next step. If resistance is more than 5 ohms, replace oxygen sensor. Perform TEST VER-1.
6. Disconnect ignition coil connector. Using DRB-II, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, replace ignition coil. Perform TEST VER-1.
7. If resistance is less than 5 ohms, disconnect generator field connector. Using DRB-II, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, repair short to ground in generator. Perform TEST VER-1.
8. If resistance is less than 5 ohms, disconnect fuel injector harness connector. Using DRB-II, check resistance of ASD relay connector terminal "D", output circuit (Dark Green/Orange wire). If resistance is more than 5 ohms, repair short to ground in fuel injector harness. Perform TEST VER-1. If resistance is less than 5 ohms, repair short to ground in Dark Green/Orange wire. Perform TEST VER-1.

TEST NS-7A - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Disconnect Idle Air Control (IAC) motor connector. Turn ignition on. Using DRB-II, actuate IAC motor. Put DRB-II in voltmeter mode. Using DRB-II, check voltage on IAC motor connector, driver No. 3 circuit (Gray/Red wire). If voltage is less than one volt, go to TEST NS-7B.
2. If voltage is more than one volt, check voltage on IAC motor connector, driver No. 1 circuit (Brown/White wire). If voltage is less than one volt, go to «TEST NS-7C»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-7c-inspecting-idle-air) . If voltage is more than one volt, check voltage on IAC motor connector, driver No. 4 circuit (Violet/Black wire). If voltage is less than one volt, go to «TEST NS-7D»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-7d-inspecting-idle-air) .
3. If voltage is more than one volt, check voltage on IAC motor connector, driver No. 2 circuit (Yellow/Black wire). If voltage is less than one volt, go to «TEST NS-7E»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-7e-inspecting-idle-air) . If voltage is more than one volt, turn ignition off.
4. Remove IAC motor from throttle body. Reconnect IAC motor connector. Using DRB-II, actuate IAC motor. If IAC motor tip moves in and out, go to «TEST NS-8A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-ns-8a-correcting-start) . If IAC motor tip does not move in and out, replace IAC motor. Perform TEST VER-1.

TEST NS-7B - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect all terminals. Repair as required. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) . If PCM terminals are okay, go to next step.
2. Using an external ohmmeter, check resistance of driver No. 3 circuit (Gray/Red wire) between IAC motor connector and PCM connector terminal No. 39. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-1. If resistance is more than 5 ohms, repair open in Gray/Red wire. Perform TEST VER-1.

TEST NS-7C - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect all terminals. Repair as required. Perform TEST VER-1. If PCM terminals are okay, go to next step.
2. Using an external ohmmeter, check resistance of driver No. 1 circuit (Brown/White wire) between IAC motor connector and PCM connector terminal No. 40. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-1. If resistance is more than 5 ohms, repair open in Brown/White wire. Perform TEST VER-1.

TEST NS-7D - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect all terminals. Repair as required. Perform TEST VER-1. If PCM terminals are okay, go to next step.
2. Using an external ohmmeter, check resistance of driver No. 4 circuit (Violet/Black wire) between IAC motor connector and PCM connector terminal No. 59. If resistance is less than 5 ohms, replace PCM. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) . If resistance is more than 5 ohms, repair open in Violet/Black wire. Perform TEST VER-1.

TEST NS-7E - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION . For wiring diagram, see WIRING DIAGRAMS article in the ENGINE PERFORMANCE Section.

1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect all terminals. Repair as required. Perform «TEST VER-1»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__verification-procedure-ver-1) . If PCM terminals are okay, go to next step.
2. Using an external ohmmeter, check resistance of driver No. 2 circuit (Yellow/Black wire) between IAC motor connector and PCM connector terminal No. 60. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-1. If resistance is more than 5 ohms, repair open in Yellow/Black wire. Perform TEST VER-1.

TEST NS-8A - CORRECTING START & STALL CONDITION

At this point in diagnostic test procedure, all engine control systems have been determined to be operating as designed and not causing a start and stall problem. Check following items as possible causes

1. Check if any TECH SERVICE BULLETINS (TSBs) apply to vehicle.
2. Check engine compression.
3. Check for exhaust system restriction.
4. Check camshaft and crankshaft sprockets.
5. Check valve timing.
6. Check for fuel contamination.
7. Check secondary ignition system.
8. Ensure PCV system is functioning properly.

VERIFICATION PROCEDURE VER-1

1. Inspect vehicle to ensure all engine components are connected. Reassemble and reconnect components as necessary. Inspect engine oil for fuel contamination. Change oil and filter if necessary. Attempt to start engine.
2. If engine does not start, check if any TECH SERVICE BULLETINS (TSBs) apply to vehicle and return to «TEST FC-1A»(/plymouth/voyager/ii-1991-1995/remont/testing-diagnostics/#engine-controls-tests-wcodes-33l__test-fc-1a-checking-for-faults), if necessary.
3. If engine starts and Powertrain Control Module (PCM) was changed, repair is complete.
4. If engine starts and PCM was not changed, connect DRB-II to engine diagnostic connector and erase fault messages. Repair is complete.

VERIFICATION PROCEDURE VER-2

Inspect vehicle to ensure all engine components are connected. Reassemble and reconnect components as necessary. If another fault was read previously and not corrected, return to TEST FC-1A and follow path specified by other fault. If Powertrain Control Module (PCM) has not been replaced, perform following

1. Connect DRB-II to engine diagnostic connector, and erase faults. Disconnect DRB-II.
2. Using DRB-II, reset all values in adaptive memory.
3. Disconnect DRB-II.

To ensure no other fault remains, perform following

1) If vehicle is equipped with A/C, turn on A/C and blower motor. Drive vehicle for at least 5 minutes and attain a speed of at least 40 MPH. Ensure transmission shifts through all gears.

2) Upon completion of road test, turn engine off. Restart engine, and let it idle for at least 2 minutes. Turn engine off. Connect DRB-II to engine diagnostic connector.

3) Read all fault messages. If repaired fault has reset, repair is not complete. Check all pertinent TECH SERVICE BULLETINS (TSBs), and return to TEST FC-1A if necessary. If another fault exists, return to TEST FC-1A and follow path specified by other fault. If no other faults exist, repair is now complete.

See also:
• TEST NF-1A
• FUEL PRESSURE RELEASE
• VISUAL INSPECTION
• ENTERING ON-BOARD DIAGNOSTICS
• TEST NS-1A
• TEST FC-1A
• CLEARING FAULTS
• CONNECTOR IDENTIFICATION
• TEST NS-6A
• DTC 11
• DTC 54
• DTC 13
• DTC 14
• DTC 14
• DTC 15
• DTC 21
• DTC 21
• DTC 52
• DTC 51
• DTC 22
• DTC 22
• DTC 24
• DTC 24
• DTC 25
• DTC 27
• DTC 27
• DTC 27
• DTC 27
• DTC 27
• DTC 27
• DTC 31
• DTC 32
• DTC 32
• DTC 33
• DTC 35
• DTC 35
• DTC 35
• DTC 42
• DTC 42
• DTC 43
• DTC 43
• DTC 43
• DTC 62
• INACTIVE FAULT CONDITION
• TEST VER-2
• TEST FC-7B
• TEST FC-17B
• TEST FC-18B
• TEST FC-19B
• TEST FC-20B
• TEST FC-21B
• TEST FC-22B
• TEST FC-30B
• NF-2A
• NF-3A
• NF-4A
• NF-5A
• NF-6A
• NF-7A
• NF-8A
• NF-9A
• NF-10A
• NF-11A
• NF-12A
• NF-13A
• NF-14A
• NF-15A
• TEST NF-3B
• TEST NF-7B
• TEST VER-1
• TEST NS-5A
• TEST NS-4B
• TEST NS-4A
• TEST NS-7A
• TEST NS-5B
• TEST NS-6C
• TEST NS-7C
• TEST NS-7D
• TEST NS-7E
• TEST NS-8A
