How to Replace the Steering Angle Sensor Opel Vivaro A

Remove

1. 1. Position steering column in fully extended position • Release lever (1) • Fully extend steering column – Pull up • Secure lever (1)

2. 2. Disconnect battery negative lead
3. 3. Remove airbag from steering wheel • Release clip – Use small screwdriver, then slide off • Disconnect harness connector (1)

4. 4. Immobilise steering wheel in centre position
5. 5. Remove steering wheel • Remove bolt (1), then discard • Disconnect harness connector for horn switch – Release from clip • Disconnect harness connector for radio remote control (if installed) – Release from clip

6. 6. Remove 2x cowling (1) from steering column • Remove 2x screw

7. 7. Remove steering angle sensor (1) • Release 4x clip • Disconnect harness connector (2)

Install

8. 8. Install new steering angle sensor (1) • Connect harness connector (2) • Secure 4x clip

9. 9. Install 2x cowling (1) to steering column • Install 2x screw

10. 10. Install steering wheel • Position harness through steering wheel • Connect harness connector for horn switch, then secure to clip • Connect harness connector for radio remote control (if installed), then secure to clip • Install new bolt (1) 44 Nm

11. 11. Install airbag (1) to steering wheel • Connect harness connector • Secure clip – Slide on

12. 12. Position steering column to original position • Release lever (1) • Position steering column – Push down • Secure lever (1)

13. 13. Connect battery negative lead
14. 14. Program all volatile memories
15. 15. Calibrate steering angle sensor – see operation “Steering Angle Sensor, Calibrate”
