How to Replace the 12 V Socket Opel Vectra C

Electrical Socket Front/ Rear 2 illustrations ~137 words

Remove

  1. 1. Detach rear centre console cover • Unclip centre console rear cover (1) • Unclip accessories socket (2) with 12 V socket
  2. 2. Remove 12 V socket with accessories socket • Release wiring harness plug (3) • Disconnect wiring harness plug (3

Note. Accessories socket is also provided with a switch for seat heating

  1. 3. Remove 12 V socket • Release 12 V socket (1) • Lever/pull out 12 V socket (2) • Unclip support ring with cover (3)

Install

  1. 4. Install 12 V socket • Clip in socket • Insert 12 V socket
  2. 5. Install 12 V socket with accessories socket • Connect wiring harness plugs.
  3. 6. Attach rear centre console cover • Clip in centre console rear cover • Clip in accessories socket with 12 V socket
