Control Unit Terminal Assignments
Terminal assignments, occupied connections only:
| 2 | Rear fog lamp | 19 | Left signal |
|---|---|---|---|
| 3 | Rear screen wiper interval | 20 | Right signal |
| 4 | Heated rear screen switch | 21 | Rear screen washing |
| Outside mirror | 23 | Trailer signal telltale | |
| 5 | Hazard warning switch | 25 | Ignition ON (terminal 15) |
| 6 | Windscreen washing | 26 | Starter switch (W�contact) |
| 7 | Telltale signal | 27 | Dimming (Potentiometer) |
| 8 | Hazard warning telltale | 28 | Passenger compartment lamp switch |
| 9 | Low beam | 31 | Battery positive voltage supply |
| 10 | Engage central door locking system | (terminal 30) | |
| 11 | Odometer signal | 32 | Ground (terminal 31) |
| 12 | Disengage central door locking system | 33 | Passenger compartment illumination |
| 13 | Anti�theft warning system | 34 | Instrument illumination |
| 14 | Door contact switch, remaining doors | 38 | Parking lamp |
| 15 | Driver's door contact switch | ||
| 17 | Fog lamp | ||
| 18 | Windscreen wiper interval |
