Block Diargram
Voltage supply
| 15 | Ignition ON (terminal 15) | |
|---|---|---|
| 30 | Battery positive (terminal 30) | |
| 31 | Ground (terminal 31) | |
| S1/W | Ignition lock | |
| Terminal W (Japan only) | ||
| S2 | Central lamp dimming switch | |
| Passenger compartment lamp, | ||
| Fog lamp, rear fog lamp, | ||
| Parking lamp, low beam | ||
| S4 | Heated rear screen/outside mirror switch | |
| S5 | Signal switch | |
| Right and left signal | ||
| S9 | Wiper system switch assembly | |
| Windscreen wiper interval | ||
| Rear screen wiper interval | ||
| Windscreen washing/rear screen washing | ||
| S17 | Co�driver's door contact switch | |
| S41 | Release/engage central door | |
| locking switch | ||
| S47 | Driver's door contact switch | |
| S52 | Hazard warning signal switch | |
| E11 | Instrument illumination |
|---|---|
| E19 | Heated rear screen |
| E20 | Fog lamp |
| E24 | Rear fog lamp |
| E41 | Passenger compartment lamp |
| H3 | Signal telltale |
| H11 | Left signal |
| H13 | Right signal |
| H17 | Trailer signal telltale |
| M2 | Windscreen wiper interval |
| M8 | Rear screen wiper interval |
| M30 | Heated outside mirror |
| K1 | Heated rear screen |
| K5 | Fog lamp |
| K37 | Anti�theft warning system |
| K50 | ABS control unit/odometer signal |
| K89 | Rear fog lamp |
| K120 | Rear screen wiper interval |
| K121 | Heated outside mirror |
| K122 | Left signal |
| K123 | Right signal |
| K124 | Windscreen wiper interval |
