Important: On deformations in the area of the bulkhead/steering crossmember, or contact with the EPS steering column, the EPS steering column must be checked for damage.
Remove
- 1. Remove EPS steering column
- 2. Check shear plates (1) for correct seating.
Note. If the shear plate is loose or displaced, the steering column assembly or the EPS steering column must be replaced.
- 3. Measure the length of the steering column assembly or EPS steering column: Dimension I: 476.0 +3/-2 mm (Total length of steering shaft) Dimension II: 247.5 ± 1 mm (Distance from middle of fastening holes to top of EPS steering column bracket)
Note. If the specified lengths are not met, the steering column assembly or the EPS steering column is compressed and must be replaced.
Important. If damage is found on the steering column unit/EPS steering column, the steering intermediate shaft should be checked for damage. A damaged steering intermediate shaft must be replaced.
- 4. Check steering shaft for freedom of movement – press lock pin (arrow) downwards until it engages or, if the steering lock cylinder is installed, release with ignition key and turn the steering shaft.
Note. If the steering shaft does not move freely or the steering shaft bearing is felt to be damaged, the steering column assembly or the EPS steering column must be replaced.
Install
- 5. Install EPS steering column
