How to Replace the Sensor/panel Park Pilot Opel Meriva A

Remove

1. 1. Remove rear panelling
2. 2. Detach 4x wiring harness plug, sensor
3. 3. Remove sensor (3) • Release sensor (arrows) and remove
4. 4. Detach sensor panel (1) from mounting (2) • Unlock clamping ring (4) and draw out of mounting • Remove sensor panel – Release 2x lug (5)

Install

5. 5. Attach sensor panel to mounting • Install sensor panel – Lock 2x lug • Separate and lock clamping ring

Note. Clamping ring must engage audibly

6. 6. Install sensor • Install sensor and lock
7. 7. Connect 4x wiring harness plug for sensor
8. 8. Install front panelling
9. 9. Function control
