Replace Pollen Filter (Rhd) Opel Meriva A

Heating, Ventilation 3 illustrations ~180 words

Remove

  1. 1. Detach wind protection panelling (1)
  2. 2. Remove cover of pollen filter housing • Separate wiring harness plug for wiper motor (3) – Release and disconnect wiring harness plug • Release (4) cover of pollen filter housing (2) • Remove cover of the pollen filter housing from the lower mounting

Note. Illustration shows the engine compartment without the bulkhead closure panel to provide a clearer representation.

  1. 3. Remove pollen filter • Draw pollen filter (1) out of the housing (arrow) • Draw pollen filter out upwards

Note. Illustration shows the engine compartment without the bulkhead closure panel to provide a clearer representation.

Install

  1. 4. Install pollen filter • Insert pollen filter into housing
  1. 5. Install cover of pollen filter housing • Insert pollen filter housing cover in lower holder (1) and (2) • Insert pollen filter housing cover in side holder (3) and (4) • Connect wiring harness plug, wiper motor

Note. Illustration shows the housing of the pollen filter removed to provide a clearer representation.

  1. 6. Attach wind protection panelling
  2. 7. Perform function check
