Air Conditioning Compressor Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Remove the charge air cooler outlet pipe. Refer to Charge Air Cooler Outlet Pipe Replacement . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement . Remove the generator. Refer to Generator Replacement . Remove the drive belt. Refer to Drive Belt Replacement . |
| 1 | A/C Compressor and Condenser Hose Assembly Bolt Notice: Refer to Fastener Notice in the Preface section. Tighten 22 N·m (16 lb ft) |
| 2 | Sealing Washer Procedure Remove and discard the sealing washer. Refer to Sealing Washer Replacement . |
| 3 | A/C Compressor Bolt (Qty: 3) Procedure Tighten the bolts in sequence. Tighten 22 N·m (16 lb ft) |
| 4 | A/C Compressor Assembly |
