Compressor Hose Assembly Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Recover the refrigerant. Refer to Refrigerant Recovery and Recharging . Remove the charge air cooler outlet pipe. Refer to Charge Air Cooler Outlet Pipe Replacement . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement . Remove the generator. Refer to Generator Replacement . |
| 1 | A/C Compressor and Condenser Hose Assembly Nut Caution: Refer to Fastener Caution in the Preface section. Tip A/C compressor hose to A/C evaporator hose Tighten 9 N·m (80 lb in) |
| 2 | Sealing Washer Procedure Remove and discard the sealing washer. Refer to Sealing Washer Replacement . |
| 3 | A/C Compressor and Condenser Hose Assembly Nut Tip A/C compressor hose to A/C condenser Tighten 9 N·m (80 lb in) |
| 4 | Sealing Washer Procedure Remove and discard the sealing washer. Refer to Sealing Washer Replacement . |
| 5 | A/C Compressor and Condenser Hose Assembly Bolt Tighten 22 N·m (16 lb ft) |
| 6 | Sealing Washer Procedure Remove and discard the sealing washer. Refer to Sealing Washer Replacement . |
| 7 | A/C Compressor and Condenser Hose Assembly |
